Anetsberger Brothers GoldenFRY FFM-150 Installation guide

1
Anetsberger Brothers, Inc.
180 North Anets Drive • Northbrook, Illinois 60062 • 847-272-0770 • Fax [phone]
For ANETS Factory Warranty Service • 800-837-2638
Installation,
User Operation,
&
Maintenance
Manual
Keep this Manual in a Convenient Location for Reference
The Anets GoldenLine
Quality Equipment For The Restaurant, Supermarket, and Bakery Industries
WARNING
After installation of this equipment, immediately contact your local gas
supplier to obtain information about what action to take whenever any
person smells gas. Post this information in a prominent location.
!
DANGER
Improperinstallation,adjustment,alteration,service,ormaintenancecan
cause property damage, injury or death. Read the installation, operating
andmaintenanceinstructionsthoroughlybeforeinstallingorservicing this
equipment.
!
Form I-230
Rev. 6/03
Price $20.00 US
FOR YOUR SAFETY
DONOTstoreorusegasoline or other flammable vapors
or liquids inthe vicinity of this or any other appliance.
!
GoldenFRGoldenFR
GoldenFRGoldenFR
GoldenFRYY
YY
Y
Model FFM80 shown
Portable Filter Systems
Models
FFM-80
FFM-150

2
TABLE OF CONTENTS
ShippingContainerInspection ....................................................... 2
CodeRequirements ...................................................................... 2
FilterUnitPreparationInstructions ................................................ 3
FilterDiagrams .............................................................................. 4
FilteringInstructions ...................................................................... 5
OilDisposalInstructions ............................................................... 6
ReplacingTheFilterPaper ............................................................ 7
FilterTroubleshootingGuide .......................................................... 8
FilterWarranty .............................................................................. 9
1. Carefullyexaminetheshippingcontainerforexternaldamage. When damage isnoted,notifythe
deliverycarrier immediately. Saveallpackingmaterialsfor damageclaim examination.
2. Ifnoexternaldamageisnoted,remove theshippingcontainerfromthefilterand examinetheunit
carefullyfordamage. Place thefilterin asafelocation,if damageisnoted,sothat thefreightdamage
claimsadjustercanexamineit.
SHIPPING CONTSHIPPING CONT
SHIPPING CONTSHIPPING CONT
SHIPPING CONTAINER INSPECTIONAINER INSPECTION
AINER INSPECTIONAINER INSPECTION
AINER INSPECTION
NOTE: A Parts List for each Anets Filter System is among the items shipped with each unit. If an
additional copy of this list is needed, please contact the factory as directed on the back cover.
Models CoModels Co
Models CoModels Co
Models Covv
vv
verer
erer
ered Byed By
ed Byed By
ed By TT
TT
This Manhis Man
his Manhis Man
his Manualual
ualual
ual
FFM-80 Portable Filter System - 80 lb. capacity
FFM-150 Portable Filter System - 150 lb. capacity
StandardAccessories furnishedinthe shippingcarton withthis filterinclude:
(1) FilterScreenAssembly
Boxof Filter Paper (100 pcs.)
ReturnHoseAssembly
DD
DD
DANGERANGER
ANGERANGER
ANGER
Read these specifications, Code Requirements, Installation Requirements, Installa-
tion Instructions, and Operating Instructions very carefully. Failure to follow the Instruc-
tions could cause the filter system to malfunction. A filter system malfunction can result
in property damage, serious bodily injury, or death.
!

3
INSTINST
INSTINST
INSTALLAALLA
ALLAALLA
ALLATION INSTRTION INSTR
TION INSTRTION INSTR
TION INSTRUCTIONSUCTIONS
UCTIONSUCTIONS
UCTIONS
Pleasemakesure thatyourdesired filter locationhas electrical supplyfactorsthat aresuitablefor this
product. Requirements are 120Volts,60 Hz, 8Amps,1-phase,three-wire connection,includingan
electricalground.Thisunit isnot fused. Protectcircuit withproper sizedfuses orcircuit breaker. Line
disconnectswitch, circuit breaker, orplug and receptacleof powercord connectionshould bereadily
accessibleto the operator.
FILFIL
FILFIL
FILTER ELECTRICAL SPECIFICATER ELECTRICAL SPECIFICA
TER ELECTRICAL SPECIFICATER ELECTRICAL SPECIFICA
TER ELECTRICAL SPECIFICATIONSTIONS
TIONSTIONS
TIONS
1. Assemble filter envelopetofilterscreenbysliding theenvelopeoverthefilterscreen, folding
backthe openend overthe filterscreen. Make surethe hole inthe filterenvelope fitsover
thefittingonthefilterscreen.
FILFIL
FILFIL
FILTER UNIT PREPTER UNIT PREP
TER UNIT PREPTER UNIT PREP
TER UNIT PREPARAARA
ARAARA
ARATIONTION
TIONTION
TION (Refer to Photos On Page 4)
2. Assemble filterenvelopeclipover foldedbackendof envelope andoverfittingon filter
screen.
3. Attachknurledretainingnutontofittingonscreen,securingtheassembly.
4. Attach quick-connectcouplinglocatedon draintubetoknurled retaining nut.
5. Placefilterunitintothefiltertank.
6. Connect thefilterassemblyto thepumpusingthe quick-connect assembly.
7. Putthe filter tank cover onthe tank.
8. Connect thehoseassembly tothefilter pump.
WARNING
ElectricalGroundingInstructions
This appliance is equipped with a three-prong (grounding) plug for
your protection against shock hazard, and should be plugged
directly into a properly grounded, three-prong receptacle. DO NOT
cut or remove the grounding prong from this plug.
!
!
WARNING
Only use filter paper envelopes from Anetsberger Brothers that have been specifi-
cally designed for this filter system. Using the wrong type of filter paper can cause
damage to the pump system, and will void the Warranty

4
FFM PORFFM POR
FFM PORFFM POR
FFM PORTT
TT
TABLE FILABLE FIL
ABLE FILABLE FIL
ABLE FILTERTER
TERTER
TER
Filter envelope
Knurledretainingnut
FFM PORFFM POR
FFM PORFFM POR
FFM PORTT
TT
TABLE FILABLE FIL
ABLE FILABLE FIL
ABLE FILTERTER
TERTER
TER
Quickconnectcoupling
Filter envelope
Pumpquick-connectcoupling
Knurledretainingnut
Completely Disassembled
Filterenvelopeclip
Filterenvelopeclip
Cover
Filtertank
Foldablehandle
Pumpquick-connectcoupling
Hoseassembly
Filter screenassembly
Quickconnectcoupling
forfilterscreenassembly

5
FILFIL
FILFIL
FILTERINGTERING
TERINGTERING
TERING
FILFIL
FILFIL
FILTERING INSTRTERING INSTR
TERING INSTRTERING INSTR
TERING INSTRUCTIONSUCTIONS
UCTIONSUCTIONS
UCTIONS
CAUTION
Never operate the filter unit unless the cooking oil or shortening in the
fryers has been brought up to cooking temperature.
WARNING
Alwayswear protective heat-resistant gloves when performing thefiltering operation.
1. Before filteringthe shortening ina fryer,turnthe thermostatknob to “OFF”or theGas Valve to
“PILOT”topreventthefryerfromre-lightingduringfiltering. Onsomemodels the system
automaticallypreventstheburnersfromlightingwhen thedoorofthefryeris open.
2. Rollfilterunderdrainpipeextensiononthe fryerandslowlyopendrainvalve(blackhandle), lettingall
theshorteningdraininto the filtertank. Leavethisvalve open.
3. Hold hoseassemblynozzle overthefryer kettle,turnonthe pumpswitchand flushsedimentout ofthe
fryer. Whilethesystemiscycling,use along-handledcleaningbrush towipethe bottom ofthefryer
andpushexcesscrumbs throughthedrain andintothefilter.
4.Allowthepumpto run untiltheshorteningreturninginto thefryerisclear. Thenclosedrainvalve
(blackhandle),andallowthe fryertorefill.
DANGER
Never drain more than one fryer at a time – the filter pan may overflow.
!
!
Note On Using Filter Powder
If filter powder is being used, add 1 cup of powder (for 14” fryers) or 2 cups (for 18” fryers) to
eitherthe fry tank orthefiltertank. If added to frytank,makesure powder is completelyflushed
during fry tank cleaning (Step 3) before closing drain valve (Step 4). If added to filter tank, the
powder will be removed when the filter envelope is changed and the filter tank is cleaned.
WARNING
When cleaning the inside of the frypot, do not damage the temperature and
hi-limit probes that protrude into the frypot.
If solid shortening is being used it is very important that all oil is allowed to flow back into
the vat and none is left in the hoses. Failure to do so could cause the pump to fail if the
oil solidifies in the line.
WARNING

6
OIL DISPOSALOIL DISPOSAL
OIL DISPOSALOIL DISPOSAL
OIL DISPOSAL
Ifthecooking oilor shorteningfrom afryer is tobe disposed,follow steps1 and2from FilteringInstruc-
tionsinprevious section. Turnon thepumpusing theswitchon thefilter and directthe oilintoan appro-
priatedevice suchas anoil shuttleto movethe usedoil toits disposal tank.
IMPORTANT NOTE:
Thepumponthis filter unitisequipped with asafetythatwill turnoffthemotor ifitoverheatsor an
electricalfaultoccurs. If thisoccurs,let thepump motorcoolfor 15minutes, then pressthe manual
resetbutton on thebottom of themotor and restartthe motor.
DANGER
Never run water through the filter system. This will cause rust and corrosion in the
motor and pump and will void the Warrranty.
WARNING
Always wear protective heat-resistant gloves when performing the oil disposal operation.
6.On gas-operated thermostat models(such as Anets 14G, 14GS, MXEG, 18EG, 20EG) the thermostat
knobcan now be turnedback to the desired temperature. CAUTION: Onthese models the thermostat
mustbe set to “OFF” orthe Gas Valveto “PILOT”before filtering or the burnersMAY comeback on if
thedoorsareclosedduringfiltering.
7.On electric-operated thermostat models (suchas Anets MX-14E, MX-14EX, MX-14AA,18E, 18AA,
20E,14EL-14 and 14EL-17) thepower switch on thecontrol panel must bereset for the fryerto
operateagain.

7
1. Unplugthe cordfrom the receptacle.
2. Disconnecttheline fromthepump tothe filterscreen.
3. Removethe filter cover.
4. Removethefilter screenassembly fromthefilter panand place ona cleansurface for disassembly.
5. Detachquick-connectcouplingon drain tubefromknurledretaining nut.
6. Detachknurledretainingnutfromfittinginscreen.
7. Removefilterenvelope clipfrom endof filterscreen andfolded back endof envelope.
8. Removefilterenvelopefromfilterscreen.
9.Cleanthefilter pan,filterscreenand allcomponentsthoroughlyusing asolutionofhot waterand
detergent. Make surethat allfood andbreading particlesare removedfrom thepan and from the filter
screen.
10. Drythe pan,the screenand allcomponents completelybefore startingto reassemble.
11. FollowinstructionsunderFILTER UNITPREPARATIONtoinstallnewfilterenvelope.
REPLAREPLA
REPLAREPLA
REPLACINGCING
CINGCING
CING THE FILTHE FIL
THE FILTHE FIL
THE FILTER PTER P
TER PTER P
TER PAPERAPER
APERAPER
APER
Ifthefilter paperbecomestorn, orif thetimeto filtertheoil fromone unit becomesexcessive, itistime to
replacetheFilterEnvelope.
Theoilsoaked filterenvelopemay stillbe very hotand couldcauseburns.
WARNING
DANGER
Make sure the filter pan has cooled completely to room temperature before
attempting to change the paper.
! !
WARNING
Only use filter paper envelopes from Anetsberger Brothers that have been specifically
designed for this filter system. Using the wrong type of filter paper can cause damage
to the pump system, and will void the Warranty

8
FILFIL
FILFIL
FILTER SYTER SY
TER SYTER SY
TER SYSTEMSTEM
STEMSTEM
STEM TRTR
TRTR
TROUBLESHOOOUBLESHOO
OUBLESHOOOUBLESHOO
OUBLESHOOTING GUIDETING GUIDE
TING GUIDETING GUIDE
TING GUIDE
PROBLEM
Pump does not
start when the
switch is activated.
1. Make sure the power cord is plugged into the proper 120 Volt receptacle. i
2. Turn the switch on the front of the filter to “ON”.
3. If the pump still hasn’t started, depress the thermal overload button on the
bottom of the motor. If the motor is hot to the touch, wait at least 15 minutes
before trying this.
4. If the pump starts and stops again in a short time, or if it hums but does not
pump, there is a restriction somewhere in the filter screen or in the pump itself. Go
to Step 5. If there is no reaction from the pump, go to step 6.
5. Allow the oil/shortening in the filter pan to cool, then empty the pan and verify
that the filter paper and screen assembly is assembled correctly. Disassemble the
filter screen and look for blockages of sediment or solid shortening within.
6. Problem is with the motor/pump or the wiring. Remove the motor from the
filter and bench test by connecting a 120V line to the motor leads. If it runs, the
problem is with the wiring between the motor and the power supply. If it does not
run, the motor needs to be replaced.
Filteringprocedureis
veryslow. Shorten-
ing/oilreturningtothe
fryerveryslow.
1. Ifsolidshorteningis being usedallowHOToil torecirculatethroughthe lines
longenoughtoensurethatallsolidifiedshorteninghasmelted.
2. Afterallthe shortening/oilhas been pumpedback intothefryer,inspectthe
filterpaper envelope. Make surethat anyexcess sedimentis removedfrom the
topof the filterpaper envelope.
3. Ifthefilter paperenvelope isdirty ortorn, disassemblethe filter screen
assembly. Inspect forblockages inthe lines. Replacewitha cleanfilter paper
envelope.
SOLSOL
SOLSOL
SOLUTIONUTION
UTIONUTION
UTION
3. Iftheoil stillreturnsto thefryer slowly,theproblemmaybe ablockage within
thepumpitself. The pumpsection ofthe motorcanbe easilydisassembled to
lookforblockagesofsedimentorsolid shorteningwithin.
WARNING
Onlyusefilter paperenvelopesfrom AnetsbergerBrothersthat havebeen
specificallydesignedforthisfiltersystem. Usingthewrongtypeof filterpaper
cancausedamage tothe pumpsystem, and willvoid thewarranty.

9
LIMITEDWARRANTY
ANETSBERGERBROTHERS, INC., Northbrook,Illinois, USA,certifies
thatallequipmentofitsmanufactureis,tothebestofitsknowledge,freefrom
defectivematerialandworkmanship.
ANETSBERGERBROTHERS,INC., agreestoreplace anyintegralpart of
itsequipmentthatprovesdefectivewithin15 monthsofdateoforiginalship-
mentfromthefactory,or12monthsfromthedateofinstallation,whicheveris
sooner. Buyer must return thedefective part tothe factory,freightprepaid,
for inspection. AnetsbergerBrothers,Inc.,further agreestoassume thecost
ofinstallingsaidreplacementpartwithinthesameperiod.
Overtimecharges,calibration,adjustmentsandabnormalinstallationcharges
shallnot beat the expense ofAnetsbergerBrothers, Inc.
Theconditionsandwarrantyexpressedabovearevalidonlyifequipmenthas
beenproperly installed and operated. No other warranty,expressed orim-
plied,shall govern equipmentmanufactured by AnetsbergerBrothers, Inc.
UndernocircumstancesshallAnetsbergerBrothers,Inc., beliableforlossof
profitsorany direct orindirect cost, expenses,lossor damagesarisingout of
defectsinor failureofthe equipmentorany partthereof.
Keep this Manual in a Convenient Location for Reference
Anetsberger Brothers, Inc.
180 North Anets Drive • Northbrook, Illinois 60062 • 847-272-0770 • Fax [phone]
Toll-free Customer & Warranty Service: 800/837-2638
WebSite: www.anetsberger.com
email: [e-mail]
