Angstrom AVIO Series User manual

INSTALLATION GUIDE
AVIO-500 7-1/4" x 10" x 7-1/2" (mounting bracket increases depth by 3/4")
AVIO-505 7-1/4" x 10" x 7-1/2" (mounting bracket increases depth by 3/4")
AVIO-605 -3/4" x 11-3/ " x -5/ " (mounting bracket increases depth by 1")
AVIO-805 10-5/ " x 13-3/4" x 10-5/ " (mounting bracket increases depth by1-1/4")
Indoor / Outdoor Cabinet
Loudspeakers
page 1 of 2
Rev. A
Congratulations! You have purchased a high quality
stereo loudspeaker. When matched to comparable
electronic equipment, expect years o quality high
idelity sound. We are constantly striving to provide
the very best technology has to o er.
The ollowing manual is designed to give you,
the installer or owner, basic in ormation as to
the speaker’s installation and operation. It is
beyond the scope o this manual to go into all the
details that must be taken into consideration in a
sophisticated high idelity system.
I you have any questions regarding this speaker
which are not answered by this manual, contact your
local dealer or assistance. For the most current
in ormation please visit www.angstromloudspeakers.com.
REAR CONFIGURATIONS
GENERAL DESCRIPTION
These two-way speakers have specially designed
woo ers with linear long throw butyl rubber
surrounds or long li e and superior damping. Dome
tweeters are utilized or excellent high requency
dispersion throughout your entire listening
environment. The rame and grille can be custom
painted to match the room decor.
SHIPPING DAMAGE
Each speaker is thoroughly tested be ore it leaves
the actory. However, in shipment, accidents may
occur. Please inspect your speakers care ully
when you receive them to make sure there is no
damage. I there is, please noti y your dealer, or
supplier immediately or assistance. I you received
your speakers by public transportation, report the
damage at once to the shipping company.
Overall (W x H x D)
page 1 of 2
Rev. A
(2) Cabinet Speakers
(2) "U" brackets
notched &
solid end-caps
(not included w/ AVIO-500) (8) rubber eet
Elegant cover
conceals and protects
connection terminals
Rear Mounted View with
SE-DBLSVL Swivel
Bracket (not included)
Bookshel
Con iguration
Shown with
the included
U-Bracket
BOX CONTENTS
Indoor / O tdoor
5-1/4", 6-1/2", 8" Cabinet Lo dspeaker
AVIO Series Black or White
Angstrom Loudspeakers MC
391 Marwood Drive, Unit 6, Oshawa, ON L1H 7P • TEL: 416-9 - 06
www.angstromloudspeakers.com

page 2 of 2
Rev. A
USING SPEAKERS WITHOUT BRACKETS
(BOOKSHELF CONFIGURATION / not available w/AVIO-500)
This cabinet speaker may be set on a bookshel , desktop,
stand, or other lat sur ace. The speakers are shipped
with additional solid endcaps that provide a iner look
when the U-Brackets are not used.
1. Remove the endcaps by pulling the back
end o them away rom the enclosure.
2. Loosen and remove the brass thumb screws
that hold the bracket to the speaker.
3. Remove the bracket and replace the thumbscrews.
Tighten them securely with your ingers.
4. Slip the ront edge o the solid endcaps into the
available grooves and press the endcaps into place
ensuring that they engage with the thumbscrews.
5. Install the supplied vinyl eet to the bottom o
the speaker by peeling them rom the sheet
and pressing them into place. They may also be
attached to the side o the speaker i one intends to
lay the speaker on its side.
INSTALLATION
(USING OPTIONAL DOUBLE SWIVEL BRACKET)
Follow the manu acturers
instructions or the installation o
the bracket. To prepare the speaker
or this type o bracket, remove the
supplied bracket and replace the
endcaps ollowing steps 1-4 in the
previous section, “Using Speakers
without Brackets.” The bracket is
attached to the back o the speaker
using ¼-20 screws or bolts. The
length o the hardware will be
determined by the bracket thickness but it will likely
be about 1/2” to 5/8” in length. It will be necessary to
remove the terminal cover rom back o the speaker. To
do this, use your inger(s) to pull back on the bottom o
the cover at the relie in the enclosure.
INSTALLATION
1. Determine the installation location o the speaker.
Use care to ensure the structure has the ability to
carry the weight o the speaker. We recommend
that the speaker be located where there is a stud or
other support structure especially i the speaker will
be oriented horizontally. I attaching to sheetrock
(gypsum board), ensure that you use suitable
hardware such as toggle anchors (not supplied).
2. Measure the hole-spacing on the bracket and
trans er these dimensions to the mounting sur ace.
3. Install the attachment hardware, drilling holes as
necessary.
In most installations the bracket will need to
be removed rom the speaker so that it can
be tightened to the mounting sur ace without
obstruction.
4. Remove the endcaps by pulling the back end o them
away rom the enclosure.
5. Remove the bracket rom the speaker by loosening
and removing the brass thumb screws that hold the
bracket to the speaker.
6. Screw the bracket to the mounting sur ace. Either
set o holes may be used (slots or keyholes). I
the wire is coming through the wall then it can be
passed through the center-hole in the bracket i
desired or practical.
7. Prepare the wire or termination by stripping back
the insulation approximately
½” (13mm).
8. Remove the terminal cover rom back o the speaker
using your inger(s) to pull back on the bottom o the
cover at the relie in the enclosure.
9. Attach the speaker to the bracket making the thumb
screws inger tight.
10. Position the speaker so the input terminals can be
accessed.
11. Pass the wire through the cover and connect it to
the input terminals, observing polarity to ensure
consistency.
12. Snap the terminal cover into place and rotate the
speaker in the desired direction.
13. Tighten the thumb
screws. A screwdriver
may be used to ensure
they are tight.
14. Re-install the endcaps.
page 2 of 2
Rev. A
notched end cap - top
solid end cap - bottom
