Animon Yard Sentinel RC User manual

Yard Sentinel RC
Yacht & RV Guard RC
STROBE
AR-132
AR-135
www.byanimon.com

This manual will provide you, the user, with directions for the safe and
efficient operation of the device. The device stands for remote control. Please
read this manual carefully before using this product, and keep it for future
reference.
IMPORTANT!
Before you plug in your unit, it is important to understand sonic and
ultrasonic signals.
The sonic signal is the alarm/ harassment sound humans can hear.
Combining this sound with ultrasonic may give you better results for startling
and repelling intruders and animals from your yard. However, if the sonic
sound bothers you neighbour, you can turn this off using the “sonic volume”
dial. Just turn the volume dial to zero.
The ultrasonic signal is the high-pitched frequency that only animals can hear.
This sound will be emitted whenever your device is on(plugged in or on battery
power).
You can adjust the frequency using the Frequency dial , but you won’t turn
it off by adjusting either the sonic volume of frequency dial.

TABLE OF CONTENTS
Introduction
Safety and maintenance
Quick Set up
Frequency dial
Modes
Sensitivity dial
Sonic volume
Placement
The science behind it
Ultrasonic
Infrared motion sensor
Strobe light with sundown sensor
Operating time
Sonic
Operating the device
Using the A/C adapter
Connecting the extension cord
Installing the battery
Available power source accessories
Turning the unit on/off
Settings
Frequency dial
Sensitivity dial
Mounting to a wall
Training a pet
Remote control
Turbo button
Standby mode
Strobe light button
Ultrasonic
Product specifications
Diagram

This pest repellent is the industry’s most advanced outdoor anti-pest product. The product
brings together peace of mind and affordability advanced outdoor anti-pest product. The
product brings together peace of mind and affordability as a result of years of research
and innovation. This device allows you to rid your yard, garden or outdoor area of pests
humanely and without the use of poisonous chemicals.
How does it work?
This pest repeller uses ultrasonic technology to repel pests from your yard as well as
sonic alarm/harassment noise and strobe lights. The device is environmentally friendly,
safe for humans and pets and won’t even harm the pests your are trying to repel.
It is equipped with an infrared motion sensor that activates when pests are in range.
The strobe light and sensor can also be activated by remote Control.
Features: Your device is equipped with several features: AC adapter 10 meter (33 feet)
extension cord.
Battery-operational: Requires four C batteries (not included) Intelligent Power System
(IPS): AC power will take priority over battery when both are installed. In the case of
power failure, device will switch to battery backup when batteries are installed.
Ultrasonic: Adjustable frequencies so high that only pests can hear the Sonic: Audible
alarm and harassment noise Strobe.
Light: Ideal for repelling nocturnal animals
Modes: Motion Sens, Constant or Continuous Sweep Infrared
Motion Sensor: Detects pest in range and activates device.
Infrared Motion Sensor: Detects pests in range and activates device.
Remote Control: Four-button remote (standby, Turbo, Ultra, strobe )
Operating Time: Select Day, Night or 24HR.

。
SAFETY
AND
MAINTENANCE
A. Please read the manual before using the product.
B. Do not restrict airflow around the unit. Do not position behind furniture or curtains. For
best effect, position in open areas.
C. Do not attempt to open the unit beyond its functional use.
D. This is not a toy. Do not hold up to your ears with either the ultrasonic or sonic sounds
activated.
E. Please consider other people and their privacy and peaceful enjoyment of property
before using the security alarm/harass- ment sound and Strobe Light.
F. This pest repellent is environmentally friendly safe and harmless to pets.
G. Keep the motion sensor lens clean by periodically wiping with a damp cloth.
H. Remove batteries when not in use to avoid leakage that could damage the unit.
I. Check all cables used to connect the device for cracks or damaged insulation. Do not
use the device in case of defects serious damage.
J. If repairs are required, original replacement pass should be used exclusively in order to
avoid serious damage. Repairs or other work may only be carried out by authorized
personnel. Please contact us for warranty information(see page 19).
K. Do not connect any power sources to 4C size battery holder except C size batteries, or
it may damage the unit. Contact us for information about our our special extension cord
with alligator clip and O/C power plug for connecting to a 12V O/C or 24V O/C Sealed
Lead-Acid (SLA) battery.

Standby mode:
To deactivate your device, press the Standby button (top right). You will hear a long
beep sound. The device’s red light will flash continuously and all the functions, except for
Turbo will be on.
Standby mode:
To activate the device, press the Standby button once. You will hear a shorter beep
sound and the device will begin working as set by the user.
The Standby mode is helpful for switch off the device when you want to use your yard
without setting off the alarm or harassment sound or let your pet into the yard without
having to unplug the device. When finished you can simply turn off the standby mode with
the remote control. You will hear a beep and the flashing LED light will turn off.
Strobe light button:
This button (bottom right) activates the Strobe Light function.
Press the button once. A light will me on to tell you that the device has been activated. It
will stay on for about 20 seconds. The Strobe Light is effective against birds and pests that
are active at night like squirrels, mice, rat, skunks, cats and dogs. The Strobe Light only
functions at night or in dark places.
Ultrasonic:
The Ultrasonic button (bottom left) turns on the high frequency sound that effectively
repels pest from your yard or other open area. Press the button once to activate. A light
will come on the sound will be activated for about 20 seconds.

。
Congratulations on your new Pest Repellent! You have option to get your device
started. Your unit came with an AC adapter. Remove the back cover from your device and
plug in the adapter. You will see an opening at the bottom of the unit that you can run the
cord through.
If you don't have an electrical outlet available in the area, you will need four C batteries
(not included).
When you install power the unit will wait a few moments at which point a red light will
turn on.The light will stay on for about 20 seconds and then switch off.Your device is now
ready to use. AII of your controls are located at the back of your device. Remove the cover
to adjust the following settings as needed.
Frequency Dial: You will see several types of pests list around the Frequency
dial(Fig. 1) and the ranges of frequencies that are ideal for repelling them. You turns
dial to the setting that best suits your needs. If you are trying to repel more than one
type of pest, set it somewhere within the ranges of each of them. Adjust the
frequency slightly every few weeks to avoid allowing the pest to adapt to the sound.

Continuous Sweep: The Continuous Sweep will activate a range of sonic and
Ultrasonic frequencies randomly at intervals. The motion detector will deactivate on
this setting. This is helpful for repelling several different types of pest.
Sensitivity Dial: The Sensitivity dial adjusts the distance at which the device’s motion
sensor will work.
Sonic Volume: The Sonic Volume adjusts the loudness of the alarm and harassment
sound. If this sound bothers you or your neighbour, turn it all the way down. The ultrasonic
signal will still be effective in repelling pests. Here are some suggested settings for
common types of pests:
Raccoon: Turn the Frequency dial all the way to left ( count-er-clockwise) of the raccoon
range, and blast the alarm/harass-ment sound.
Squirrels/ Mice: Turn the Frequency dial to the right(clock-wise). If you are not sure, start
at the top of the range(right), and adjust it downwards until you find the setting that works
best.
Rabbits: Turn the Frequency dial all the way to the left(counter-clock-wise).
Birds/Crows: Turn the Frequency dial all the way to the left(counter-clockwise), and blast
the alarm/harassment sound.
Dogs/Cats: Turn the Frequency dial all the way to the left (clockwise), and adjust
downwards until you find the setting that works best. Dogs and cats can have varying
hearing sensitivities. For large sized animals(deer, bears,etc): Turn the Frequency dial all
the way to the left, and blast the alarm.

。
The Pest Repeller remote control is simple to use with four functions offering optimal
user control over your device. It can operate up to 80 feet(25 meters) from the device. It
has four buttons that operate the Ultrasonic, Strobe, Standby, mode, or Turbo function.
Note: The volume settings for the Turbo alarm function are located at the back of your
device. After plugging in the Yard Sentinel or installing batteries, a red light will come on
for approximately 20 seconds. Once the unit is powered, the remote can be used to
activate the four functions:
Turbo Button:
The Turbo button(top left) is a safety feature to protect you and your family outdoors.
When activated, the Turbo turns on all functions for 20 seconds (Ultrasonic, Sonic and
Strobe). This can startle an intruder or large animal entering your campsite or yard, giving
you time to get help or leave the area. This function works even when the device is on
Standby mode.
It works 24 hours a day regardless of the Operating Time setting (page 10).
To adjust the volume of the alarm, remove the back cover and adjust the Sonic Volume.
This mode can also be used to repel large animals when you see hem enter your
property.

PLACEMENT
:
It’s important to place the device where it will be most effective. For ground animals, like
raccoon, coyotes, etc. Place the unit near the height of the animal you want to repel and
facing the area where they most like to frequent. Don’t place it on the ground as this will
limit the effective range of the device, Using the screws, you can hang the unit on a wall,
tree, fence, stairs, or even on top of your mail box. If your device is off the ground and
higher than the animal’s eye-lever, tilt it downward somewhat. For animals that nest in
trees- birds or squirrels-place the device on a tree or rooftop. The ultrasonic frequency
has a range of up to 70 feet(21 meters) ,but the closer it is to the animal, the more
effective it will be.
Ultrasonic signals cannot penetrate solid surfaces. Make sure there are no windows,
doors, fences or other items between the device and the area you want to cover.
The ultrasonic sound emits in a forward direction from the device with a range of about
170 degrees horizontal and 60 degrees vertical.

Mounting to a Wall
Two screws and fasteners are included with this unit for mounting on walls, drill the
screws into a suitable wall or upright surface. Align the notches on the back cover with the
screws and hang the unit.If installing the unit outdoors, place it at the height of the pests if
possible, If not,tilt the unit downwards slightly to capture the pests in the device’s effective
range(see diagram on page 7). The unit must be aimed at the direction of the pests with
no objects(e.g. Windows, walls or fences) in front of it.
Training a Pet:
Some people try the device out on their pets to see if it works or to train their pet not to
enter a particular area. It’s important to remember that your pet is used to living
comfortably in your home. He may be annoyed by the sound, but he may not be deterred
from the room, As far as he is concerned your home is his proper place.An outdoor animal
on the other hand is sensitive to noise and the alert to danger. The same way an alarm will
repel an intruder, the ultrasonic signal will repel an unwanted animal.
If you want to use the ultrasonic device to deter your cat or dog from a part of the house,
you may have to train them. When the device activates, show them what to do.
Demonstrate to them that it’s time to leave the room when they hear the noise and that
doing this will stop the noise. Dogs will, of course ,be easier to train than cat.
Note:
Just like your pet, wild animals will have certain habits and behaviour s that can
change over time. If they are accustomed to finding food in your backyard, they may
continue to come even if they are disturbed by the ultrasonic, especially if they can’t find
food elsewhere. The device is designed to to work in combination with other good pest
management practices. For tips on how to keep pests away, see page 18.

Note:
Ifyouhaveacatoradogyoumayhavetoturnthedeviceoffwhentheyareintheyard.
This depends on the frequency you are using because cats and dogs can have very
different levels of hearing depending on age or size. Other types of pets such as rodents
or insects may be more sensitive.Ultrasonic waves cannot penetrate surfaces, so put
them in a box or leave them behind and out of range of the device.
Infrared Motion Sensor:
Your device can be set to activate only when animals come into range.Set the mode
switch to “Motion Sensor” to select this feature. When an animal or human enters the
range of the device will activate both the ultrasonic and sonic.The range of the sensor may
vary due to ambient temperature.
Note:
You can test your device to see if it is working by switching the mode to “motion
Sensor” and walking or waving your hand in front. If you see the red light, you will know
the movement has been detected. If the Sonic Volume is turned up, you will also hear the
alarm/harassment noise. The ultrasonic signal may also be slightly audible to some
people.
The motion sensor is equipped with a dial that controls its sensitivity (Fig 5). Turn it all
the way up to ensure it works as well as possible(30), if you find the device activates when
there are no animals in the yard, turn it down to about 25.
Strobe Light with Sundown Sensor:
Your device is equipped with a strobe light to help drive away nocturnal creatures, like
raccoon. The strobe Light is designed to be disorienting and works along with the
ultrasonic/sonic sound.

Available Power Source Accessories:
Some of our customers choose to use their device in remote areas, or areas without
traditional power outlets.The device can be connected to a 12V D/C or 24V D/C sealed
Lead-Acid(SLA) battery.
Using our special extension cord with alligator clip and D/C power plug(Fig.8), It can
also be powered by a vehicle’s cigarette lighter’s power outlet with our special adapter
cord(Fig.9). For ordering information, see page 19.
In addition, we have 65 feet(20 meters) extension cords available (Fig 10).

Turning the device on and off:
The device does not have an on/off switch. To turn it off, unplug it, remove the batteries,
or use the standby mode on the remote control. When the unit is plugged in or batteries
are installed, it will trigger a red sensor light within 20 seconds. The light will stay on for
about 20 seconds, after which the device will be ready to operate.
To create an audio and visual assault on the animal’s senses driving them from your
property. The Strobe Light flashes repeatedly in quick succession each time it is activated.
The strobe Light will only come on at night.
Operating Time:
Some pests, like birds, are active only in the daytime. Others, like raccoon, are active at
night. You can choose whether to operate your device only in the daytime, nighttime or all
day with the power-saving operating time feature(Fig 6). The remote control’s turbo button
works 24 hours per day(see page 15).
Sonic:
In addition to the inaudible ultrasonic signal, your device is equipped with a sonic signal.
This helps to scare off any people or pests lurking around your property or large animals
such as bears, coyotes, raccoon, skunks and birds. At full volume, the sound can be
heard up to 300 feet(91 meters) away. It can also act as a security alarm for your yard.
How to use:
The sonic signal is controlled by the sonic volume dial. To turn it up, turn the dial all the
way clockwise. If you find the sonic noise bothers you or your neighbour, you can turn it off
by turning the volume dial all the way down(counter clockwise) or simply lower the volume
at your discretion. Adjusting the sonic volume will not affect the ultrasonic signal which
emits at a fixed rate.

Operating the device
Using the A/C adapter:
Remove the back cover of the unit by gently pulling off. Plug one end of the A/C adapter
into the 9 volt D/C jack located beside the frequency dial. Plug the other end into any
standard A/C outlet. Thread the A/C adapter cord through the notch at the bottom of the
unit and then replace the back cover by snapping it into place. (For diagram, see page 20).
If you do not have a weather-proof electrical outlet, the adapter should be plugged in
indoors. The device and the 9-volt port are weather resistant , but it is best to protect the
device from heavy rains or snow.
Connecting the extension cord:
To connect the extension cord, simply plug in the small side of the extension cord at the
back of the unit where it indicates D/C 9v, then attach the other larger plug to the A/C
adapter(Fig 7).
Installing the batteries:
The device can also operate on batteries. It uses four size C batteries. To install the
batteries, remove the back panel by gently pulling it off. Install the batteries as shown on
the diagram (see page 20) so the positive and negative poles match the poles printed on
the unit. With the batteries in place, replace the back cover of the unit by pressing it until it
snaps closed.
Intelligent Power System:
The device is designed to provide uninterrupted protection even during a power failure.
Install four C batteries and plug in your device. Your device will be powered through
electricity. If the power fails, the device will automatically switch to battery backup.
