Craftsman 610.24600 User manual

User Instructions
IRA
TRACTOR LIF
Model Number 610.24600
®
Provides access to mower deck for easy
cleaning and service
Fits all 1985 through current models
of CRAFTSMAN front engine tractors
and Zero Turn Mowers
Can be fitted to most major front engine tractor brands
Adjustable arms for greater versatility
Extra heavy duty gauge steel construction
If you read and follow these instructions, this product can be
assembled in approximately 20 minutes
Assemble unit on cardboard to avoid scratches or damage to parts
Can easily be assembled by one person
All fasteners for this Tractor Lift can be purchased at Sears or any
hardware store
Patent Pending
If there are any missing
parts, or if you have any
questions on assembly,
operation, maintenance
or safety, please call
1-800-652-6231
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Visit our Craftsman website: www.sears.com/craftsman 610.24600-REV B 3/08

WARNINGS
• Always use the stabilizer bar provided when using tractor lift.
Make sure stabilizer bar is properly in place before starting any
work on tractor.
• Read and understand all safety and operating instructions
before using the tractor lift. Never allow anyone unfamiliar
with these instructions to use the tractor lift.
• Read and understand all safety and operating instructions
provided by the tractor's manufacturer before using tractor lift.
• Never lay under the tractor or mowing deck.
• When using lift, keep all bystanders, including children, away.
• This tractor lift must be only used for lifting and lowering to
and from a level and stable surface.
• Never use in wet conditions.
• Do not attempt to lift the front and back of the tractor at the same
• Do not use tractor lift as an automotive lift, or for any other use for
whist is not intended or designed.
• If tractor lift is bowing while lifting or lowering your tractor, which
indicates an overload condition, remove the tractor immediately.
• Do not attempt to lift or lower any power equipment while motor is
running.
• Never engage blades while using tractor lift.
• Always disconnect spark plug wire from tractor before beginning
any work on tractor.
• Do not exceed the rated capacity of the tractor lift - 270#.
• Failure to follow these warnings may result in property
damage and/or serious bodily injury.
SAFETY INSTRUCTIONS
• Be sure to read and follow all safety instructions and
warnings. Failure to follow these instructions may result in
damage to the product and/or serious personal injury.
• Danger of serious personal injury exists. Serious personal
injury can occur when using a lifting device.
• Never attempt to ride any vehicle up or down the tractor lift.
• Do not climb onto tractor while tractor is in the elevated position.
• When working on the front of the tractor always place wheel
chocks in back of the rear wheels/tires.
• Always raise and lower tractor lift in a controlled fashion; do not
allow the tractor to drop too quickly, damage could occur.
• Make sure lifting arms are aligned and set to the proper distance apart
so that the equipment being loaded is well balanced on the lift.
• Do not remove warning decals from product.
• Before each use, always check for any worn, loose, or
damaged parts on the tractor lift. If any damage is present,
DO NOT USE THE TRACTOR LIFT.
• Periodically check the fasteners to make sure they are still
tight and in place.
• Keep lift surface clean by occasionally cleaning with water and
any mild detergent.
• Do not add to or try to modify the tractor lift in any way.
Any modifications will void any warranties.
• Failure to abide by the warnings and read the safety instructions may
result in loss of load, damage to lift and/or property, serious personal
and/or fatal injury.
FOR MISSING PARTS, Call 1-800-652-2321, Monday - Friday, 8 a.m. - 5 p.m.E.S.T.
Page 2.

Carton Contents
;:.C_L&C:.C,:.............. _
11
6-...% 1 lO
REF NO QTY PART NUMBER DESCRIPTION REF NO QTY PART NUMBER DESCRIPTION
1 1 51001 Angle Frame Assembly 7L 1 410131 Tractor Mounting Bar - Left
2 1 51002 Handle Top 7R 1 410132 Tractor Mounting Bar- Right
3 1 51003 Handle Bottom 8 1 51006 Stabilizer Bar
4 2 41009 Lift Tube Assembly 10 1 310031 Hardware Bag
6 1 51005 Lift Cross Tube 11 1 310041 Assembly Manual
OPERATION
Tractor Lift can be used out of the box on all Craftsman tractors
with bumpers or brush guards. Tractor Lift mounting hardware is
provided if your tractor does not have a bumper or brush guard.
TOOLS REQUIRED FOR ASSEMBLY
9/16" Wrench and/or Socket
Adjustable wrench
MAINTENANCE
Store unit in a clean dry place.
Recommended tire pressure - 30 PSI.
Before each use:
• Always check tire pressure.
• Always inspect unit for damage.
• Always check fasteners for tightness.
FOR MISSING PARTS, Call 1-800-652-2321, Monday - Friday, 8 a.m. - 5 p.m.E.S.T.
Page 3.

Hardware Contents
/
26
37
m 29
m
_-I 33
23
m
m
m
m22
38
25
27
24
r-'-
-iiliiliiliiliiliiliiliiliililil
c,__
34
@
35
36
f
39
28
REF NO
22
23
24
25
26
27
28
QTY
3
6
8
6
2
4
2
PART NUMBER
310051
310072
310073
310062
300082
310061
310054
DES ORIPTI ON
3/8"-16 x 2-3/4" Hex Bolt
3/8" Split Lock Washer
3/8" USS Flat Washer
3/8"-16 Hex Nut
Hair Pin Cotter .148 Dia.
3/8"-16 l',,_ylokHex Nut
3/8"-16 x 1-1/2" Self-thread Bolt
REF NO QTY
29 6
33 1
34 4
35 4
36 4
37 2
38 4
39 1
PARTNUMBER
310055
310053
310052
310065
310075
310182
310221
31026
DESCR I PTION
3/8"-16 x 1-1/4" Hex Bolt
318"-16 x 2-1/4" Hex Bolt
1/4"-20 x 1" Hex Bolt
1/4"-20 l'¢/Iok Hex Nut
1/4" USS Flat Washer
Vinyl Handle Grip
Tube Plug RT8-1
Scuff Pad
FOR MISSING PARTS, Cattl-800-652-2321, Monday-Friday, 8 a.m.-5 p.m.E.S.T.
Page 4.

Setting up Lift Mounting Hardware -Tractor Front
Tractor Lift can be used out of the box on all Craftsman tractors with bumpers or brush guards. Tractor Lift mounting hardware is provided. If
your tractor does not have a bumper or brush guard, follow the steps below:
Note: Left and Right sides are determined by standing behind tractor looking forward.
7R
Remove,
add washer (24),
Step 1. replace.
26
Step 2.
6 %38
Step ,
Remove existing bolt "X" and set aside. If tractor does not have
this bolt use supplied 3/8" x 1-1/4" bolt with 3/8 nylok nut.
Align holes in tractor mounting bars ( 7R & 7L ) to the front
left & right side frame holes of the tractor.
Insert hex head bolt ( 29 ) through inside front hole of frame,
through tractor mounting bar and secure with nylock nut ( 27 ).
Add flat washer ( 24 ) under head of bolt removed in earlier
step and reinsert through tractor mounting bar and tighten.
For LT1000 & LT2000 series tractors, use self-thread bolts
( 28 ) in place of bolt ( 29 ) and nut ( 27 ).
Step 2.
• Push tube plugs ( 38 ) into each end of lift tube ( 6 ).
Slide lift tube through cut-out in tractor mounting bars and
center.
Pin lift tube in place with one hair pin cotter ( 26 ) on each side
of mounting bar.
Note: The mounting bars have been manufactured to attach to the
frames of most major front engine tractor brands. Additional
hardware has been included for attachment to non-Craftsman
brands.
FOR MISSING PARTS, Call 1-800-652-2321, Monday - Friday, 8 a.m. - 5 p.m.E.S.T.
Page 5.

Assemble Tractor Lift
Attach Lift Tubes to Angle Frame
• Lift tubes come pre-assembled. Attach lift tube assemblies ( 4 ) to angle frame ( 1 ) using bolts ( 22 ), flat washers ( 24 ), split lock washers ( 23 )
and hex nuts ( 25 ).
• Secure rear of lift tube assembly ( 4 ) to angle frame ( 1 ) using bolts ( 29 ), flat washers ( 24 ), split lock washers ( 23 ) and hex
nuts ( 25 ).
Note: Over-tightening receiver bolts ( 22 ) could cause damage to lift tubes ( 4 ).
29
Determining the width between lift tubes.
Front of Craftsman Tractors
Front of Craftsman Zero Turn
/25
Brush guard bumper
(can also be used for
front of Craftsman tractor)
Push mower
-4
5
Note: The higher the lift tube extensions (5)
are positioned, the harder the tractor will be to lift.
25
O
o
oo o o
DCB A A BCD
Settings:
A. Push Mower
B.
C.
D.
Brush guard /Bumper installed
Front of Craftsman Tractor
Front of Craftsman Zero Turn
FOR MISSING PARTS, Call 1-800-652-2321, Monday - Friday, 8 a.m. - 5 p.m.E.S.T.
Page 6.

Assemble Tractor Lift
Attach Handle to Angle Frame
Step 1. Attach handle bottom ( 3 ) to angle frame ( 1 ) using hex bolt ( 22 ),
flat washer ( 24 ), split lock washer ( 23 ) and hex nut (25).
Step 2.
Step 3.
Step 4.
Insert ring grip pin ( 30 ), as shown.
Insert handle top ( 2 ) into handle bottom ( 3 ). Secure with hex
bolt ( 33 ), flat washer ( 24 ), split lock washer ( 23 ) and hex nut (25).
Place handle grips ( 37 ) onto handle top tube ( 2 ). A little
soapy water will help grip slide onto tube easily.
IF HANDLE CANNOT BE
EASILY INSERTED, FLIP
HANDLE OVER AND
REINSERT,
j37 3
Handle Top Tube -j
Foot Bar Tube
FOR MISSING PARTS, Call 1-800-652-2321, Monday - Friday, 8 a.m. - 5 p.m.E.S.T.
Page 7.

Assemble Tractor Lift
Attach Stabilizer Bar
Step 1. Slide stabilizer bar ( 8 ) onto foot bar tube as shown.
Step 2. Press snap button and slide stabilizer bar against handle.
Step 3. Insert ring grip pin ( 30 ) through stabilizer bar and handle top.
Foot bar
Snap
3O
FOR MISSING PARTS, Call 1-800-652-2321, Monday - Friday, 8 a.m. - 5 p.m.E.S.T.
Page 8.

OPERATION
Using the Tractor Lift
Step 1. Engage Tractor Lift
• Center Tractor Lift in front of tractor.
, Ensure that claws at ends of lift
tubes are securely hooked under
the lift cross tube attached to tractor
(Figure 1) or to the tractor
bumper/brush guard (Figure 2.)
Figure !.
Properly engaging tractor
with mounted lift cross tube.
Figure 2.
Properly engaging tractor
with tractor bumper/brush guard.
Step 2. Lift Tractor
• Place foot onto foot bar tube and apply
continuous forward pressure with foot
while pulling down on tractor lift handle.
• Once lifted, the weight of tractor will
automatically force handle down
into correct position.
IMPORTANT: Stabilizer bar MUST be engaged
immediately after raising the tractor. See Step 3
on next page for instructions.
FOR MISSING PARTS, Call 1-800-652-2321, Monday-Friday, 8 a.m. - 5 p.m. EST.
Page 9.

OPERATION
Using the Tractor Lift
Step 3. Engaging Stabilizer Bar
Stabilizer bar MUST be engaged immediately after raising the tractor.
WARNING: Failure to engage stabilizer bar may result in serious personal
injury and or property damage.
• Remove ring grip pin ( 30 ) from tube handle. Press snap button
and slide stabilizer bar ( 8 ) from foot bar tube.
• Turn stabilizer bar 180 degrees as shown at bottom of Figure 1.
• Position stabilizer bar under base of unit between wheels.
• Slide stabilizer bar back onto foot bar tube making sure the bar is
positioned back over snap button.
--Tube Handle
Snap
Figure 1
30
Figure 2
Snap Button
FOR MISSING PARTS, Call 1-800-652-2321, Monday - Friday, 8 a.m. - 5 p.m.E.S.T.
