Gardena Easy 1887 User manual

EN Operator’s manual
Water Control
FR Mode d’emploi
Programmation d’arrosage
IT Istruzioni per l’uso
Unità di controllo per irrigazione
ES Instrucciones de empleo
Control de riego
PT Manual de instruções
Controlador de rega
EL Οδηγίες χρήσης
Σύστημα ελέγχου ποτίσματος
Easy Art. 1887
EL PT ES IT FR EN

EL PT ES IT FR EN
2
Bewässerungsart/Irrigation type/Type d'irrigation /
Tipo di irrigazione / Tipo de riego/Tipo de rega/
Τεχνητή βροχή Τύπος
Bepflanzungsart/Planting type /
Type de plantation / Tipo di piantu-
mazione/Tipo de plantación /
Tipo de plantação/Φύτευση τέχνης
1 min. 8 hrs GARDENA Micro-Drip-System
5 min. 8 hrs GARDENA Micro-Drip-System
10 min. 8 hrs GARDENA Micro-Drip-System
3 min. 12 hrs GARDENA Micro-Drip-System
5 min. 12 hrs GARDENA Micro-Drip-System
15 min. 12 hrs GARDENA Micro-Drip-System
3 min. 24 hrs GARDENA Micro-Drip-System
5 min. 24 hrs GARDENA Micro-Drip-System
10 min. 24 hrs GARDENA Micro-Drip-System, GARDENA Sprinklersystem
15 min. 24 hrs GARDENA Micro-Drip-System
30 min. 24 hrs GARDENA Micro-Drip-System
45 min. 24 hrs GARDENA Sprinklersystem
10 min. 48 hrs GARDENA Micro-Drip-System
30 min. 48 hrs GARDENA Micro-Drip-System, GARDENA Sprinklersystem
60 min. 48 hrs GARDENA Sprinklersystem
30 min. 72 hrs GARDENA Sprinklersystem
60 min. 72 hrs GARDENA Sprinklersystem
Bewässerungsempfehlungen/Irrigation recommendations /Recommandations d'irrigation /
Raccomandazioni di irrigazione/Consejos de riego/Conselhos de rega/Συστάσεις άρδευσης
2

A video of the
setting processes
is available here:
3x
Green
= OK
Ø 26,5mm G3/4"
+ Ø 33,3mm G1"
D
ABC
E
1x 9V
1x
2x
...
23x
= 1hr
= 2hrs
...
= 23hrs
Red LED
= Low
Water Now
30 min
1.
2. 3.
Run Time
Frequency
3

GARDENA Water Control Easy
Translation of the original instructions.
For safety reasons, children and young
people under 16 as well as anyone who is
not familiar with these operating instruc-
tionsshould not use the product. Persons with
reduced physical or mental abilities may use the
product only if they are supervised or instructed by
a responsible person. Children must be supervised
to ensure that they do not play with the product.
Never operate the product when you are tired, ill or
under the influence of alcohol, drugs or medicine.
Intended use:
The GARDENA Water Control is intended for private
use in domestic and hobby gardens, exclusively
for outdoor use, to control sprinklers and watering
systems. The Water Control can be used for auto-
matic watering during holidays.
DANGER! The GARDENA Water Control must
not be used for industrial purposes or in
conjunction with chemicals, foodstuffs, easily
flammable and explosive materials.
1. SAFETY
Important!
Read the operator’s manual carefully before use
and keep for future reference.
Battery:
To ensure the Water Control runs safely,
only a 9V alkaline manganese battery
(alkaline) type IEC 6LR61 must be used!
In order to prevent the Water Control from failing
because of a weak battery if you are away for
a long time, the battery must be replaced when
the LED flashes red once. When the light flashes
red 3 times the battery must be replaced imme-
diately as the valve cannot open anymore.
EN
4

Setting up:
The Water Control may only be set up vertically
with the sleeve nut to the top to prevent water
penetrating into the battery compartment.
The minimum water output to ensure that the
Water Control functions correctly is 20 – 30 l/h.
For example, at least 10 x 2-litre Drip Heads are
required to control the Micro-Drip-System.
The max. temperature for the water flow is
40 °C.
Avoid tensile strain.
vDo not pull the hose connected to the
Water Control.
CAUTION! If the control section is
removed when the valve is open, the
valve remains open until the control section
is reattached.
DANGER! Cardiac arrest!
This product makes an electromagnetic
field while it operates. This field may under some
conditions interfere with active or passive medical
implants. To decrease the risk of conditions that
can possibly injure or kill, we recommend persons
with medical implants to speak with their physician
and the medical implant manufacturer before you
operate the product.
DANGER! Risk of suffocation!
Small parts can be easily swallowed. There
is also a risk that the polybag can suffocate tod-
dlers. Keep toddlers away when you assemble the
product.
2. INITIAL OPERATION v(Fig. A–C)
A video of
the setting
processes
is available
here:
