Anker A7912 Operating and safety instructions

Outdoor Bluetooth Speaker
Welcome Guide

1
Outdoor Bluetooth Speaker

2
Package Contents
■ Anker Outdoor Bluetooth Speaker
■ 1ft Micro USB charging cable
■ Metal hook
■ Travel pouch
■ Welcome Guide
Product Features
■ Enjoy music when hiking, rafting, at the poolside, in the shower and
more with this splashproof outdoor speaker.
■ 10 hour non-stop playtime lets you listen to your music through the
day.
■ Connects automatically to the last connected Bluetooth device
whenever powered on.
■ Bluetooth 4.0 enables high definition audio, backward compatible
with all Bluetooth versions.
■ Micro SD card reader lets you play your music without using your
phone.
■ Previous / Next Song, Volume, and Play / Pause buttons provide
device-free control.

3
Specifications
Model A7912
Bluetooth Standard 4.0
Waterproof Level IPX 4
Product Weight 263g / 9.3oz
Product Size 181.0 × 41.6 × 41.6mm / 7.1 × 1.6 × 1.6in
Play Time 10 hours
Charge Time 3 hours
Input 5V / 500mA
Operating Range 10m / 33ft
Speaker Output Power 1.5W × 2
Supported Bluetooth
Profiles HSP, HFP, A2DP, AVRCP

4
Product Overview
1. Status Indicator
2. Play / Pause
3. Volume Up / Next Song
4. Volume Down / Previous Song
5. Power / Function Button
6. Micro SD Card Slot
7. Micro USB Charging Port
8. Battery Indicator
①
②
③
④
⑥⑦⑧
⑤

5
How to Pair with Your Device
1. Press the power button for 3 seconds. The speaker will turn on and
automatically enter pairing mode indicated by the flashing blue LED.
2. Activate your device’s Bluetooth function and search for the device.
3. Once the Bluetooth speaker has been detected, select the product
name “Anker A7912” to connect. (For devices with Bluetooth versions
earlier than 3.0, press “Yes” to confirm pairing. Enter a passkey or
PIN code “0000” (4 zeros), then press the “Yes” or “OK” key to finish
pairing.)
4. When the Bluetooth speaker and your device are successfully paired,
the blue LED will go on and remain on while connected.
When turning on the speaker, it will automatically connect to the last
connected device as long as Bluetooth is still enabled. Before pairing
with another device, disable the Bluetooth function on the previous
device and the speaker will automatically return to pairing mode.
Note: To switch to SD card mode, simply insert your Micro SD card
when in standby or Bluetooth mode. The speaker enters Bluetooth mode
by default when turning on the speaker or when a Micro SD card is not
inserted.

6
Button Functions
Functions Button
Turn the Speaker On / Off Hold
Answer / End a Call Press
Reject a Call Hold Play / Pause for 2 seconds.
Turn Volume Up / Down Press or
Play Previous / Next Song Hold or
Delete Pairing Record Hold and for 2 seconds
Switch to SD Card Mode Hold for 3 seconds.

7
How to Recharge Your Speaker
When the battery is low, the speaker will beep once and the red indicator
will flash for about 10 minutes.
1. Plug the Micro USB cable into the speaker’s Micro USB charging port.
2. Insert the remaining end of the USB charging cable into (a) a USB
AC adapter (not included) connected to a wall socket, or (b) a charging
computer USB port. A steady red battery indicator will show that it is
charging.
3. When fully charged, the red battery indicator will go off.
LED Indicators
Indicator Status
Bluetooth Indicator
Flashing blue In pairing mode
Blue Connected to a device
Flashing red Low battery
Off Micro SD Card mode
Battery Indicator
Red Charging
Off Fully charged

8
Usage Tips
1. Power off the speaker when not in use and before storing.
2. The operational range of the speakers may be influenced by
obstructions such as walls and pillars. To ensure a stable connection,
we recommend avoiding such obstructions whenever possible and/or
shortening the distance during use.
3. To protect the long term performance of the battery, avoid placing the
speaker in temperatures exceeding 140°F/60°C such as in a hot vehicle
or under direct sunlight.
4. Do not submerge the speaker in water or other liquids. It can resist
splashes from all directions up to IPX level .
FAQ and Solutions
1. What should I do if the speaker doesn’t connect to my device?
■ Check to ensure your device’s Bluetooth function is enabled and is
within 3ft/1m of the speaker.
■ Delete the pairing record(s) on the speaker or your device and try
again.
2. Can I use the speaker to play music while charging?
To protect the long-term performance of the battery, it is better to charge
while the speaker is turned off, especially when the battery is low.

9
3. What should I do if the speaker disconnects from my device?
Try turning off the speaker, and pair with your device again.
FCC Statement :
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible forcompliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
