Anova CG2360 User manual

HEDGE TRIMMER
CG2360
OWNER'S MANUAL

GREETINGS
Thank you for purchasing an ANOVA machine.
You will enjoy and discover a great performance in a great machine.
SAFETY FIRST
Instructions contained in warnings within this manual marked with a symbol
concern critical points which must be taken into consideration to prevent
possible serious bodily injury, and for this reason you are requested to read
all such instructions carefully and follow them without fail.
■WARNINGS IN THE MANUAL
This mark indicates instructions which must be followed in order to prevent
accidents which could lead to serious bodily injury or death.
This mark indicates instructions which must be followed, or it leads to
mechanical failure, breakdown, or damage.
This mark indicates hints or directions useful in the use of the product.
INDEX
1. Identification …………………………………………………………………………2
2. Warning labels on the machine ……………………………………………………3
3. Symbols on the machine ………………………………………………………… 4
4. For safe operation …………………………………………………………………5
5. Fuel …………………………………………………………………………………11
6. Operation …………………………………………………………………………14
7. Maintenance ………………………………………………………………………19
8. Storage ……………………………………………………………………………25
9. Troubleshooting guide ……………………………………………………………26
10. Waste disposal and environmental protection …………………………………26
11. Specifications ……………………………………………………………………27

1. Identification
1. Rear handle
2. Throttle trigger lockout
3. Engine switch
4. Starter handle
5. Engine
6. Front handle
7. Blade cover
8. Throttle trigger
9. Rotation control lever
10. Fuel tank cap
11. Primer blub
12. Air filter cover
13. Handle screw
14. Choke
15. Blade guard
16. Blade
17. Unsharpened plate

2. Warning labels on the machine
(1) Read operator's instruction book before operating this machine.
(2) Appropriate ear, eye, and head protection must be worn.
(3) Handling this machine improperly could result in accidents causing
serious injury or death. Read this manual carefully and practice using the
hedge-trimmer until you are fully acquainted with all operations and have
learned to use it correctly.
(4) This is extremely sharp and can easily cause cuts.
(5) Guaranteed sound power level for this equipment.
(6) Always wear safety and anti-vib ration(AV) gloves when operating the
device
(7) Always wea r safety and slip -resistant boots when operating the device.
3. Symbols on the machine
For safe operation and maintenance, symbols are carved in relief on the machine. According to
these indications, please be careful not to make any mistake.
(a) The port to refuel the "MIX GASOLINE"
Position: fuel tank cap
(b) The direction to close the choke
Position: air filter cover
(c) The direction to open the choke
Position: air filter cover
(d) Engine switch on
Position: engine switch
(e) Engine switch off
Position: engine switch

If warning label peels off or becomes soiled and impossible to read, you should
contact the dealer from which you purchased the product to order new labels and
affix them in the required location(s).
Never modify your machine.
We won’t warrant the machine, if you use the remodeled hedge trimmer or if you
don’t observe the proper usage written in the manual.
4. For safe operation
■Before operate the product
Become familiar with the owner’s manual before attempting to operate the
equipment.
1. THIS MACHINE CAN CAUSE SERIOUS INJURIES. Read the instructions carefully for the
correct handling, preparation, maintenance, starting and stopping of the machine. Be familiar
with all controls and the proper use of the machine. Also, know how to stop the machine quickly
in an emergency.
2. Keep this manual handy so that you may refer to it later whenever any questions arise.
Also note, if you have any questions which cannot be answered herein, contact the dealer from
whom you purchased the product.
3. Always be sure to include this manual when selling, lending, or otherwise transferring the
ownership of this product.
4. Never allow children or anyone unable to fully understand the directions given in the manual
to use the machine.
WORKING CONDITION
1. When using the product, you should wear proper clothing and protective equipment.
(1) Helmet
(2) Ear protectors
(3) Protection goggles or face protector
(4) Thick work gloves
(5) Non-slip-sole work boots
2. And you should carry with you.
(1) Attached tools
(2) Properly reserved fuel
(3) Spare blade
(4) Things to notify your working area (rope, warning signs)
(5) Whistle (for collaboration or emergency)
(6) Hatchet or saw (for removal of obstacles)
3. Do not wear loose clothing, jewelry, short trousers, sandals, or go barefoot. Do not wear
anything which might be caught by a moving part of the unit. Secure hair so it is above shoulder
length.
WORKING CIRCUMSTANCE
1. Never start the engine inside a closed room or building. Exhaust gases contain dangerous
carbon monoxide.
2. Never use the product,

a. when the ground is slippery or when you can’t maintain a steady posture.
b. At night, at times of heavy fog, or at any other times when your field of vision might be
limited and it would be difficult to gain a clear view of the working area.
c. During rain, during storms at times of strong or gale-force winds, or at any other times
when weather conditions might make it unsafe to use the product.
WORKING PLAN
1. You should never use the product when under the influence of alcohol, when suffering from
exhaustion or lack of sleep, when suffering from drowsiness as a result of having taken cold
medicine or at any other time when a possibility exists that your judgment might be impaired or
that you might not be able to operate the product properly and in a safe manner.
2. When planning your work schedule, allow plenty of time to rest. Limit the amount of time over
which the product is to be used continuously to somewhere around 30 ~ 40 minutes per
session, and take 10 ~ 20 minutes of rest between work sessions. Also try to keep the total
amount of work performed in a single day under 2 hours or less.
1. If you don’t observe the working time, or working manner (See
OPERATION”), Repetitive Stress Injury (RSI) could occur. If you feel
discomfort, redness and swelling of your fingers or any other part of your body, see a doctor
before getting worse.
2. To avoid noise complaints, in general, operate product between 8 a.m. and 5 p.m. on
weekdays and 9 a.m. to 5 p.m. on weekends.
Check and follow the local regulations as to sound level and hours of
perations for the product.
BEFORE STARTING THE ENGINE
Beware of overhead power lines.
1. The area within a perimeter of 15 m of the person using the product should be considered a
hazardous area into which no one should enter. If necessary, yellow warning rope, warning
signs should be placed around the perimeter of the area. When work is to be performed
simultaneously by two or more persons, care should also be taken to constantly look around or
otherwise check for the presence and locations of other people working so as to maintain a
distance between each person sufficient to ensure safety.
2. Check the condition of working area to avoid any accident by hitting hidden obstacles such as
stumps, stones, cans, or broken glass.
3. Always ensure all handles and guards are fitted when using the machine. Never attempt to
use an incomplete machine or one fitted with an unauthorized modification.
4. Do not operate the machine with a damaged or excessively worn cutting device.
Remove any obstacle before beginning work.
5. Inspect the entire unit for loose fasteners and fuel leakage. Make sure that the cutting
attachment is properly installed and securely fastened.
STARTING THE ENGINE
1. Keep bystanders, especially children, and animals at least 15 m away from the operating
point. If you are approached, immediately stop the engine.

2. The product is equipped with a centrifugal clutch mechanism, so the cutting attachment
begins to move as soon as the engine is started by putting the throttle into the start position.
When starting the engine, place the product onto the ground in a flat clear area and hold it firmly
in place so as to ensure that neither the cutting part nor the throttle come into contact with any
obstacle when the engine starts.
• Never place the throttle into the high-speed position when starting the
engine.
• Never start the engine at the cutting attachment side.
3. After starting the engine, check to make sure that the cutting attachment stops moving when
the throttle is moved fully back to its original position. If it continues to move even after the
throttle has been moved fully back, turn off the engine and take the unit to your authorized
servicing dealer for repair.
USING THE PRODUCT
Cut only materials recommended by the manufacturer. And use only for tasks
explained in the manual.
1. Grip the handles firmly with both hands using your whole hand. Place your feet slightly apart
(slightly further apart than the width of your shoulders) so that your weight is distributed evenly
across both legs, and always be sure to maintain a steady, even posture while working.
2. Maintain the speed of the engine at the level required to perform cutting work, and never
raise the speed of the engine above the level necessary.
3. If the unit starts to shake or vibrate, turn off the engine and check the whole unit. Do not use
it until the trouble has been properly corrected.
4. Keep all parts of your body away from moving cutting attachment and hot surfaces.
5. Never touch the muffler, spark plug, or other metallic parts of the engine while the engine is in
operation or immediately after shutting down the engine. Doing so could result in serious burns
or electrical shock.
6. While operating the machine be always sure of a safe and secure operating position
especially when using steps or a ladder.
7. Always be aware of you surroundings and stay alert for possible hazards that you may not
hear due to the noise of the machine.
8. To reduce fire hazard keep engine and silencer tree of debris, leaves, or excessive lubricant.
9. Stop the engine before:
-- cleaning or when clearing a blockage;
-- checking, maintenance or working on the machine.
• IF SOMEONE COMES
1. Guard against hazardous situations at all times. Warn adults to keep pets and children away
from the area. Be careful if you are approached. Injury may result from flying debris.
2. If someone calls out or otherwise interrupts you while working, always be sure to turn off the
engine before turning around. Avoid operating while people, especially children are nearby.
MAINTENANCE
1. Do not attempt to repair the machine unless you are qualified to do so.
2. In order to maintain your product in proper working order, perform the maintenance and
checking operations described in the manual at regular intervals.
3. Always be sure to turn off the engine before performing any maintenance, checking

procedures or working on the machine.
The metallic parts reach high temperatures immediately after stopping
the engine.
4. When replacing the cutting attachment or any other part, or when replacing the oil or any
lubricant, always be sure to use only High Quality products.
5. In the event that any part must be replaced or any maintenance or repair work not described
in this manual must be performed, please contact a representative from the store nearest
authorized servicing dealer for assistance.
6. Do not use any accessory or attachment other than those were recommend for the unit.
7. Under no circumstances should you ever take apart the product or alter it in any way.
Doing so might result in the product becoming damaged during operation or the product
becoming unable to operate properly.
HANDLING FUEL
1. The engine is designed to run on a mixed fuel, which contains highly flammable gasoline.
Never store cans of fuel or refill the tank of the unit in any place where there is a boiler, stove,
wood fire, electrical sparks, welding sparks, or any other source of heat or fire which might ignite
the fuel.
2. Handle fuel with care, it is highly flammable. Never smoke while operating the unit or refilling
its fuel tank.
3. When refilling the tank, always turn off the engine and allow it to cool down. Take a careful
look around to make sure that there are no sparks or open flames anywhere nearby before
refueling.
4. Wipe spilled fuel completely using a dry rag if any fuel spillage occurs during refueling. If fuel
is spilled, do not attempt to start the power source, but move the hedge trimmer away from the
spillage before starting.
5. After refueling, screw the fuel cap back tightly onto the fuel tank and then carry the unit to a
spot 3 m or more away from where it was refueled before turning on the engine.
6. Do not inhale fuel fumes as they are toxic.
Never refuel indoors.
If the fuel tank is drained, this should be done outdoors.
TRANSPORTATION
1. When transporting or storing the hedge trimmer, always fit the cutting device transport guard.
Lift up the product and carry it paying attention to the blade.
2. Never transport the product over rough roads over long distances by vehicle without
removing all fuel from the fuel tank. If doing so, fuel might leak from the tank during transport.
3. When transporting or storing the machine always fit the cutting device guard.
5. Fuel
■FUEL
• Gasoline is very flammable. Use only an approved container for
store the petrol. Avoid smoking or bringing any flame or sparks near
fuel. Make sure to stop the engine and allow it cool before refueling
the unit. Select outdoor bare ground for fueling and move at least 3 m
(10 ft) away from the fueling point before starting the engine.

• The engines are lubricated by oil specially formulated for air-cooled 2-
cycle gasoline engine use. Please use an anti-oxidant added quality oil
expressly labeled for air-cooled 2-cycle engine use (JASO FC GRADE OIL
or ISO EGC GRADE).
• Do not use BIA or TCW (2-stroke water-cooling type) mixed oil.
■RECOMMENDED MIXING RATIO GASOLINE 40 : OIL 1
• Exhaust emission are controlled by the fundamental engine parameters and
components (eq., carburation, ignition timing and port timing) without addition of any
major hardware or the introduction of an inert material during combustion.
• These engines are certified to operate on unleaded gasoline.
• Make sure to use gasoline with a minimum octane number of 89RON (USA/Canada:87AL).
• If you use a gasoline of a lower octane value than prescribed, there is a danger that the engine
temperature may rise and an engine problem such as piston seizing may consequently occur.
• Unleaded gasoline is recommended to reduce the contamination of the air for the sake of your
health and the environment.
• Poor quality gasolines or oils may damage sealing rings, fuel lines or fuel tank of the engine.
■HOW TO MIX FUEL
• Pay attention to agitation.
1. Measure out the quantities of gasoline and oil to be mixed.
2. Put some of the gasoline into a clean, approved fuel container.
3. Pour in all of the oil and agitate well.
4. Pour in the rest of gasoline and agitate again for at least one minute. As some oils may
be difficult to agitate depending on oil ingredients, sufficient agitation is necessary for the
engine to last long. Be careful that, if the agitation is insufficient, there is an increased
danger of early piston seizing due to abnormally lean mixture.
5. Put a clear indication on the outside of the container to avoid mixing up with gasoline or
other containers.
6. Indicate the contents on outside of container for easy identification.
■FUELING THE UNIT
1. Untwist and remove the fuel cap. Rest the cap on a dustless place.
2. Put fuel into the fuel tank to 80% of the full capacity.
3. Fasten the fuel cap securely and wipe up any fuel spillage around the unit.
1. Select bare ground for fueling.
2. Move at least 10 feet (3 meters) away from the fueling point before starting
the engine.
3. Stop the engine before refueling the unit. At that time, be sure to sufficiently agitate the mixed
gasoline in the container.
■FOR YOUR ENGINE LIFE, AVOID:
1. FUEL WITH NO OIL (RAW GASOLINE) –It will cause severe damage to the internal engine
parts very quickly.
2. GASOHOL –It can cause deterioration of rubber and/ or plastic parts and disruption of
engine lubrication.
3. OIL FOR 4-CYCLE ENGINE USE –It can cause spark plug fouling, exhaust port blocking, or
piston ring sticking.
4. Mixed fuels which have been left unused for a period of one month or more may clog
the carburetor and result in the engine failing to operate properly.

5. In the case of storing the product for a long period of time, clean the fuel tank after rendering
it empty. Next, activate the engine and empty the carburetor of the composite fuel.
6. In the case of scrapping the used mixed oil container, scrap it only at an authorized repository
site.
6. Operation
■STARTING ENGINE
If the cutting mechanism strikes any foreign object or the hedge trimmer starts making
any unusual noise or vibration, shut off the power source and allow the hedge trimmer to
stop. Disconnect the spark plug wire from the spark plug and take the following steps:
 inspect for damage;
 check for, and tighten, any loose parts;
 have any damaged parts replaced or repaired with parts having equivalent
specifications.
The cutting head will start moving upon the engine starts.
1. Feed fuel into the fuel tank and tighten the cap securely.
2. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of
surrounding objects as it will start moving upon starting of the engine.
3. Push the primer bulb several times until fuel comes in the bulb.
4. When the engine is cool, move the choke lever downward to the closed position.
(a) primer bulb
(b) choke lever
(c) open
(d) close
Walbro caruburettor
Other carburetors
5. Set the engine switch to the “I” position.
(e) engine switch

6. While holding the unit firmly, pull out the starter rope quickly until engine fires occur.
• Avoid pulling the rope to its end or returning it by releasing the knob. Such actions can cause
starter failures.
7. For Walbro carburetor: briefly operate throttle trigger to allow the choke return to the open
position automatically and restart engine.
For other carburetors: turn the choke knob to the open position and restart engine.
8. Allow the engine to warm up for a several minutes before starting operation.
1. When restarting the engine immediately after stopping it, leave the choke
open.
2. Over choking can make the engine hard to start due to excess fuel. If you
have fooded the engine, remove the spark plug and gently pull the grip of the starter cord to
eliminate any excess fuel; then dry the spark plug electrodes and replace it on the engine.
■STOPPING ENGINE
1. Release the throttle lever and run the engine for half a minute.
2. Shift the engine switch to the “O” position.
(e) engine switch
• Except for an emergency, avoid stopping the engine while pulling the throttle trigger.
If the engine won't stop when setting the engine switch to the stop position,
lose the choke lever and stop the engine.
In this case, please repair the machine at your nearest servicing dealer.

CUTTING WORK
• Weather conditions and altitude may effect carburation.
• Do not allow anyone to stay close to the hedge trimmer while working
or while adjusting the carburetor.
HOW TO USE : REAR HANDLE
• To reduce fatigue when trimming hedges, the handle can be swiveled through 90° to the left or
right.
• Do not press the throttle trigger during this operation!
Proceed as follows:
1. Free the handle by pressing the pull up the rotation control lever.
2. Turn the handle until the rotation control lever clicks into place.
3. When the handle is locked in its new designated operating position, you can apply the throttle
trigger again.
(f) throttle trigger (g) rotation control lever
• You can swivel the handle even with the engine idling because the hedge-trimmer is equipped
with a blade brake that maintains the blades at a standstill.
■HEDGE TRIMMING TECHNIQUES
Trim sides of a hedge first, and then the top.
Vertical cut:
• Use an arcing cut from the bottom upwards, then downwards to use both sides of the blades.
Horizontal cut:
• In order to get the best cutting results, slightly tilt the blade (5÷10°) towards the cutting
direction.

Cut slowly, especially with thick hedges.
Always follow the safety precautions.
The hedge-trimmer must only be used to trim hedges or small bushes. It is forbidden to
cut other types of material. Do not use the hedge-trimmer as a lever to lift, move or break
objects, nor lock it on fixed supports. It is forbidden to apply tools or applications that
are not the ones indicated by the manufacturer onto the hedge-trimmer’s power take-off.
Do not use it for pruning trees or cutting grass.
• Use only as much throttle as is needed to do the job. Excessive engine speed is unnecessary.
• Avoid cutting thick branches, for which will damage the blades and shorten the life of drive
systems.
• Tilting the trimmer 5 to 10° to the cutting object will make the job easy and bring a good result.
• When a new machine is first operated, in the first few minutes grease may come out of the
gear case. But, since this is excess grease, there is no cause for alarm. Just wipe it off with the
engine stopped for next use.
• Always remember that the TIP of the line does cutting. You will achieve better results by not
crowding the line into the cutting area. Allow the unit to trim at its own pace.
7. Maintenance
• When the hedge trimmer is stopped for servicing, inspection or torage,
shut off the power source, disconnect the spark plug wire from the spark
plug and make sure all moving parts have come to a stop. Allow the hedge trimmer to
cool before making any inspections, adjustments, etc. Contact with moving cutting head
or hot muffler may result in a personal injury.
BLADE
• Check the blade and the fasteners for looseness, cracking, or bending.
• Check the cutting edges and reform with a flat file. Point:
1. Keep the end corner sharp.
2. Round the root of the edge.
3. Do not use water when using a grinder.
• You need not to adjust the gap between upper blade and lower
blade as this
product is designed to have optimal gap when it is properly set up.
When mounting the blade, make sure to fasten the
spacer, washer and bolt, then fasten the nut.

■SHARPENING
Always keep the file or sharpener at an angle of 45° to the
blade, and:
• Always grind in the direction of the cutting edge;
• Note: files cut only in one direction; lift the file from the blade
when returning to start a new pass;
• Remove all burr from the edge of the blade with a slip stone;
• Remove as little material as possible;
• Before refitting the sharpened blades, remove filings and then apply grease.
Do not try to sharpen a damaged blade: change it or take it to a Service dealer.
THROTTLE TRIGGER LOCKOUT
• Stop operation when the throttle trigger
lockout is defective.
• Throttle trigger lockout is the device not to
accelerate the throttle trigger without intention.
While pushing the throttle trigger lockout, you can accelerate the
throttle trigger.
(1) throttle trigger lockout

1. Check if the throttle trigger does not move when you do not press the throttle trigger lockout.
2. Check if the throttle trigger moves when you grasp or release it while pushing the throttle
trigger lockout.
3. Check if the throttle trigger lockout returns to its original position when you release your hand
from throttle trigger lockout.
• If you find any defects at the checks above, contact your nearest servicing dealer for repair.
ANTI-VIBRATION SYSTEM
The deformed or damaged anti-vibration system may cause of the
breakages like getting rickety or falling off of engine and/or blade.
• Check periodically if the springs are not deformed or damaged.
AIR FILTER
• The air filter, if clogged, will reduce the engine performance and increase the fuel
consumption. Check and clean the filter element in warm, soapy water as required. Dry
completely before installing. If the element is broken or shrunk, replace with a new one.
FUEL FILTER
• When the engine runs short of fuel supply, check the fuel cap and
the fuel filter for blockage.

WAY OF THE COOLING AIR
• This engine is air-cooled. Dust clogging between the inlet port of the cooling air and cylinder
fins will cause overheating of the engine. Periodically check and clean the cylinder fins after
removing the air cleaner and the cylinder cover.
SPARK PLUG
• Starting failure and misfiring are often caused by a fouled spark plug. Clean the spark plug
and check that the plug gap is in the correct range. For a replacement plug, use the correct
type.
• REPLACEMENT PLUG IS: NGK CMR6A
• Note that using any spark plug other than those designated may result in
the engine failing
to operate properly or in the engine becoming overheated and damaged.
• To install the spark plug, first turn the plug until it is finger tight, then tighten it a quarter turn
more with a socket wrench.
TIGHTENING TORQUE: 10–15 N·m
GEAR CASE
• Supply multi-purpose grease at every 25 hours of use.
1. Use a grease pump.
2. Feed grease until it comes out of the base of blades.
(1) Grease nipple: A type
ADJUSTING CARBURETOR
The carburetor has been adjusted at the factory. Should your unit
need readjustment due to the changes in altitude or operating
conditions, please let your skillful dealer make the adjustment. A
wrong adjustment may cause damage to your unit.
(1) Idle adjusting screw
Turn the idle adjusting screw clockwise, the idle speed increase. Turn
it counter-clockwise, the idle speed decrease.
The movement is transmitted from the engine to the blade by a centrifugal mass clutch that
prevents the blade from moving when the engine is running at idle speed. Before each use, you

shall confirm that there is no blade movement when the chain saw running at idle speed. If the
blade moves at idle speed, you should turn the idle adjusting screw counter-clockwise until the
blade stop.
(1) High speed adjusting screw (Opening 1 ± 1/4), (2) Speed decrease (3) Speed increase
PROCEDURES TO BE PERFORMED AFTER EVERY 100 HOURS OF USE
1. Remove the muffler, insert a screwdriver into the vent,
and wipe away any carbon buildup. Wipe away any carbon
buildup on the muffler exhaust vent and cylinder exhaust
port at the same time.
2. Tighten all screws, bolts, and fittings.
3. Check to see if any oil or grease has worked its way in
between the clutch lining and drum, and if it has, wipe it
away using oil-free, lead-free gasoline.
8. Storage
When the hedge trimmer is stopped for servicing, inspection or storage, shut off the power
source, disconnect the spark plug wire from the spark plug and make sure all moving parts have
come to a stop. Store the hedge trimmer where the fuel vapour will not reach an open flame or
spark. Always allow the hedge trimmer to cool down before storing.
1. Oil the blade to prevent rust.
2. Empty the fuel tank and put the cap back on.
3. Remove the spark plug, pour a small amount of oil into the cylinder. Rotate the crankshaft
several times using the starting rope in order to distribute the oil. Put the spark plug back in.
5. Wrap the engine with a plastic sheet. When transporting or storing the hedge trimmer, always
fit the cutting device transport guard.
6. Store the trimmer indoors in a dry place, dust free place, out of the reach of children.
9. Troubleshooting guide
Case 1. Starting failure
CHECK PROBABLE CAUSES ACTION
fuel tank  incorrect fuel  drain it and use correct fuel
fuel filter fuel filter is clogged clean
carburetor adjustment screw  out of normal range  adjust to normal range
sparking (no spark) spark plug is fouled/wet  clean/dry
sparking (no spark) plug gap is incorrect  correct (GAP: 0.6 ~ 0.7 mm)
spark plug disconnected retighten

Case 2. Engine starts but does not keep running/hard re-starting
CHECK PROBABLE CAUSES ACTION
fuel tank  incorrect fuel or staled fuel  drain it and use correct fuel
carburetor adjustment screw  out of normal range  adjust to normal range
muffler, cylinder (exhaust port)  carbon is built-up  wipe away
air cleaner  clogged with dust  wash
cylinder fin, fan cover  clogged with dust  clean
10. Waste disposal and environmental protection
Never pour remainders of chain lubricant or 2-stroke fuel mixture in the drain or sewerage
system or soil, but dispose of it in a proper, environmentally friendly way, e.g., at a special
collecting point or dump.
If your device should become useless somewhere in the future or you do not need it a ny
longer, do not dispose of the device together with your domestic refuse, but dispose of it in an
environmentally friendly manner. Thoroughly empty the oil/lubricant and fuel tanks and dispose
of the remainders at a special collecting point or dump. Please also dispose of the device itself
at an according collecting/recycling point. By doing so, plastic and metal parts can be sep
arated and recycled. Information concerning the disposa l of materials and devices are available
from your local administration.

11. Specifications
