Anova D226 User manual

D226
Owner’s Manual (4 in 1): Petrol Brush cutter / Petrol grass trimmer / Petrol Pole Pruner
Long-reach petrol combustion engine hedge trimmer

English –1
INFORMATIONTO SYMBOLS
Symbols WARNING! A brush cutter or trimmer can be dangerous if used incorrectly or
carelessly,andcancauseseriousor fatal injury to the operator or others. It is
extremely important that you readandunderstand thecontents of this owner’s
manual.
Please read the operator’s manual carefully and make sure you understand the
instructions before using the machine.
Always wear:
• A protective helmet where there is a risk of falling objects
• Approved hearing protection
• Approved eye protection
Max. speed of output shaft (if applicable), rpm
Watch out for thrown objects and ricochets.
Wear sturdy, non-slip boots.
Always wear approved protective gloves.
Do not use saw blades
The operator of the machine must ensure, while working, that no persons or
animals come closer than 15 metres.
Machines fitted with saw blades or grass blades can be thrown violently to
the side when the blade comes into contactwith afixedobject.Thisis called
blade thrust.The blade is capable of amputating an arm or leg. Always keep
people and animals at least 15 metres from the machine.
Keep the machine a sufficient distance away from electrical power lines.
Noise emission to the environment according to the European Community’s
Directive.The machine’s emission is specified in chapter Technical data and
on label.

English –2
INFORMATIONTO SYMBOLS
Close the choke.
Open the choke.
Thescrewbesidethe"T"stampisTheIdle-speedadjustmentscrew.
Thescrewbesidethe"H"stampisTheHigh-speedadjustmentscrew.
Thescrewbesidethe"L"stampisTheLow-speedadjustmentscrew.
This machine shall always use a mixture of petrol and two-stroke oil.
The chain oil tank
Adjust the oil pump
If you turn the rod by screwdriver follow the arrow to the "MAX" position, the
chain oil flow increase, and if you turn to the "MIN" position, decrease.
Shows the direction of the saw chain installation.
Machine can equip a typical metal blade –three teeth blade.
Machine can equip a typical metal blade –four teeth blade.
Do not use saw blades.
An arrow indicating rotation direction of cutting attachment.

English –3
CONTENTS
Contents
INFORMATION TO SYMBOLS
Symbols .........................................................................................................................................................................1
CONTENTS
Contents ........................................................................................................................................................................3
Note the following before starting: ................................................................................................................................ 4
IDENTIFICATION
What is what on the machine? .......................................................................................................................................5
GENERAL SAFETY PRECAUTIONS
Preparation ....................................................................................................................................................................6
Personal protective equipment ......................................................................................................................................6
Machine ′ s safety equipment ..........................................................................................................................................7
Cutting equipment .........................................................................................................................................................11
ASSEMBLY
Fitting the main body ....................................................................................................................................................16
Assembling the handlebar (or front handle)...................................................................................................................16
Connecting the tube (for TBC226MJ/ TBC233MJ)..........................................................................................................17
Fitting blades and trimmer heads .................................................................................................................................17
Fitting guide bar and saw chain......................................................................................................................................19
Fitting the cutting device for hedge trimmer...................................................................................................................20
Adjusting the harness and brush cutter ........................................................................................................................21
FUEL HANDLING
Fuel safety ....................................................................................................................................................................22
Fuel ...............................................................................................................................................................................22
Fuelling .........................................................................................................................................................................23
STARTING AND STOPPING
Check before starting ....................................................................................................................................................24
Starting and stopping ....................................................................................................................................................25
WORKINGTECHNIQUES
General working instructions ........................................................................................................................................26
MAINTENANCE
Carburettor ....................................................................................................................................................................31
Air filter ..........................................................................................................................................................................31
Fuel filter .......................................................................................................................................................................32
Bevel gear .....................................................................................................................................................................32
Spark plug .....................................................................................................................................................................32
Maintenance schedule ..................................................................................................................................................33
TRANSPORTING AND STORAGE...............................................................................................................................34
TECHNICAL DATA
Technical data ...............................................................................................................................................................35

English –4
CONTENTS
Note the following before starting:
Please read the operator’s manual carefully. Become familiar with the owner’s manual before attempting to operate the
equipment.
- Long-term exposure to noise can result in permanent hearing impairment. So always use approved hearing protection.
- Under no circumstances may the design of the machine be modified without the permission of the manufacturer.
Always use genuine accessories. Non-authorized modifications and/or accessories can result in serious personal injury
or the death of the operator or others.
- This machine can cause serious injuries if used incorrectly or carelessly, and can cause serious or fatal injury to the
operator or others. It is extremely important that you read and understand the contents of this operator’s manual.
Become familiar with all controls and proper use of the machine, including the correct handling, preparation,
maintenance, starting and stopping of the machine.
- It is believed that a condition called Raynaud’ s phenomenon loss of color and numbness in the fingers, which affects
the fingers of certain individuals may be brought about by exposure to vibration and cold. Maintain good blood circulation
by performing vigorous arm exercises during frequent work breaks and also by not smoking. Continual and regular users
should monitor closely the condition of their hands fingers. If any of the above symptoms appear, seek medical advice
immediately.
- Never allow children to use this machine.
- Warning! Do not use the machine when the operator is tired, ill or under the influence of alcohol or other drugs;
- Alert! National regulation can restrict the use of the machine;
- Daily inspect the machine before use and after dropping or other impacts to identify any significant defects;
- Beware of overhead power lines.
- Avoid operating while people, animals, especially children, are nearby. The machine operator must ensure that no
people or animals come closer than 15 metres while working.
- Beware of the risk of being struck by falling branches or branches that, having hit the ground, rebound.
- Keep firm footing and balance during operation, use the harness provided.
- Do not operate the brush cutter or hedge trimmer or pole pruner with a damaged or excessively worn cutting device.
- Always ensure that all handles and guards are fitted when using the machine. Never attempt to use an incomplete
machine or one fitted with an unauthorized modification.
- Always use two hands to operate this machine.
- While operating this machine, always ensure that the operating position is safe and secure, especially when using
steps or a ladder.
- Always be aware of your surroundings and stay alert for possible hazards of which you may not be aware due to the
noise of the machine.
- Stop the engine before
- cleaning or when clearing a blockage;
- checking, carrying out maintenance or working on the machine;
- adjusting the working position of the cutting device;
- leaving the machine unattended.
- Always ensure a correct working posture, operator need for sufficient rest periods and changing working positions.
- Never use a machine with faulty safety equipment. The machine’s safety equipment must be checked and maintained
as described in this section. If your machine fails any of these checks contact your service agent to get it repaired.

English –5
IDENTIFICATION
What is what on this machine?
For brush cutter or grass trimmer:
1 Trimmer head
2 Top protecting cap
3 Gear box
4 Locking screw
5 Cutting attachment guard
6 Front drive shaft tube
7 Lock pin
8 Lock knob
9 Connector
10 Barrier
11 Front handle
12 Rear drive shaft tube
13 Suspension ring
14 Engine switch
15 Throttle trigger lockout
16 Rear handle
17 Output flange
18 Engine unit
19 Spark plug cover
20 Starter handle
21 Fuel tank
22 Primer bulb
23 Choke knob
24 Air filter cover
25 Handle screw
26 Throttle trigger
27 Locking nut
28 Bottom Protecting cap
29 Bottom clamping plate
30 Metal blade
31 Top clamping plate
32 Harness
For Long-reach petrol combustion engine hedge trimmer:
33 Blade transportion guard
34 Cutting blade
35 Grease nozzle
36 Transmission
37 Locking lever
38 Grip
39 Safety lever
40 Gear box
For Pole pruner:
41 Saw chain
42 Guide bar
43 Chain cover
44 Chain oil tank cap
45 Grease nozzle
46 Transmission
47 Chain tension adjuster
48 Chain oil flow adjuster
49 Guide bar cover

English –6
PREPARATION
The machine is only designed for trimming grass, cutting bushes, trimming branch or leaves, delimbing (removal of
branches from trees or parts of trees), pruning (removal of live or dead branches, or of multiple leaders of shoots, from
standing trees).
The only accessories you can operate with this engine unit are the cutting attachments we recommend in the chapter on
Technical data.
Never use the machine if you are tired, if you are ill, if you have drunk alcohol, or if you are taking medication that could
affect your vision, your judgement or your co-ordination.
Wear personal protective equipment. See instructions under the heading “Personal protective equipment”.
Never use a machine that has been modified inany way from its original specification.
Never use a machine that is faulty.Carry out the checks, maintenance and service instructions described in this manual.
Some maintenance and service measures must be carried out by trained and qualified specialists. See instructions
under the heading “Maintenance”.
If the cutting attachment strikes any foreign object or the machine starts making any unusual noise or vibration, shut off
the power source and allow the machine to stop. Disconnect the spark plug wire from the spark plug and take the
following steps:
- Inspect for damage;
- Check for, and tighten, any loose parts;
- Have any damaged parts replaced or repaired with parts.
All covers, guards and handles must be fitted before starting. Ensure that the spark plug cap and ignition lead are
undamaged to avoid the risk of electric shock.
This machine produces an electromagnetic field during operation. This field may under some circumstances interfere
with active or passive medical implants. To reduce the risk of serious or fatal injury, we recommend persons with
medical implants to consult their physician and the medical implant manufacturer before operating this machine.
The exhaust gases emitted from engine contain dangerous carbon monoxide.
Running an engine in a confined or badly ventilated area can result in death due to asphyxiation or carbon monoxide
poisoning.
Personal protective equipment
IMPORTANT!
You must use approved personal protective equipment whenever you use the machine. Personal protective equipment
cannot eliminate the risk of injury but it will reduce the degree ofinjury if an accident does happen. Ask your dealer forhelp
inchoosing the right equipment.
WARNING! Listen out for warning signals or shouts when you are wearing hearing protection. Always remove
your hearing protection as soon as the engine stops.
HELMET
A protective helmet where there is a risk of falling objects
HEARING PROTECTION
Wear hearing protection that provides adequate noise reduction.
EYE PROTECTION
Always wear approved eye protection. If you use a visor then you must also wear
approved protective goggles. Approved protective goggles must comply with
standard ANSI Z87.1 in the USA or EN 166 in EU countries.

English –7
GLOVES
Wear sturdy anti-vibration gloves. Glovesshould be worn when necessary, e.g., when
fitting cutting attachments.
BOOTS
Wear boots with steel toe-caps and non-slip sole.
CLOTHING
Wear close-fitting clothes made of a strong fabric and avoid loose clothing that can
catch on twigs and branches. Always wear heavy, long pants.Do not wear jewellery,
shorts sandals orgobarefoot.Securehairso itis aboveshoulder level.
FIRST AID KIT
Always have a first aid kit nearby.
Machine ′ s safety equipment
This section describes the machine ′ s safety equipment, its purpose, and how checks and maintenance should be
carried out to ensure that it operates correctly. See the ”What is what?” section to locate where this equipment is
positioned on your machine.
The life span of the machine can be reduced and the risk of accidents can increase if machine maintenance is not
carried out correctly and if service and/or repairs are not carried out professionally. If you need further information
please contact your nearest service workshop.
IMPORTANT! All servicing and repair work on the machine requires special training.This is especiallytrue of the
machine ′ s safety equipment. If your machine fails any of the checks described below you must contact your service
agent.When you buy any of our products we guarantee the availability of professional repairs and service. If the retailer
who sells your machine is not a servicing dealer, ask him forthe address of yournearest service agent.
WARNING! Never use a machine with faulty safety equipment.The machine’s safety equipment must be
checked and maintained as described in this section. If your machine fails any of these checks contact your
service agent to get it repaired.

English –8
Throttle lockout
The throttle lockout is designed to prevent accidental operation of the throttle control.
When you press the lock (A) (i.e.when yougrasp the handle) itreleases the throttle control
(B).When you release the handle the throttle control and the throttle lockout both move
back to their original positions.This movement is controlled by two independentreturn
springs.This arrangementmeansthat the throttle control is automatically locked at the idle
setting.
Make sure the throttle control is locked at the idle setting when the throttle lockout is
released.
Press the throttle lockout and make sure it returns to its original position when you release
it.
Check that the throttle control and throttle lockout move freely and that the return springs
work properly.
Daily check that the cutting attachment stops turning when the engine idles. See
instructions under the heading Start. Start the machine and apply full throttle. Release the
throttle and check that the cutting attachment stops and remains at a standstill.If the
cutting attachmentrotates withthethrottle in the idle position then the carburettor idle
setting must be checked. See instructions under the heading Maintenance.

English –9
Engine switch
Press down the “O”side of the engine switch to stop the engine.
Start the engine and make sure the engine stops when you move the engine switch to the
stop setting.
Cutting attachment guard
Thisguardisintended toprevent loose objects from being thrown towards the
operator.The guard also protects the operator from accidental contact with the
cutting attachment.
Check that the guard is undamaged and not cracked. Replace the guard if it has
been exposed to impact or is cracked.
Always use the recommended guard for the cutting attachment you are using. See
chapter onTechnical data.
WARNING! Never use a cutting attachment without an approved guard. See the chapter onTechnical data. If an
incorrect or faulty guard is fitted this can cause serious personal injury.
Vibration damping system
Your machine is equipped with a vibration damping system that
is designed to minimize vibration and make operation easier.
Using incorrectly wound cord or a blunt or incorrect cutting
attachment (wrong type or incorrectly filed, see instructions
under the heading Filing the blade) increases the level of
vibration.
The machine ′ s vibration damping system reduces the transfer of
vibration between the engine unit/cutting equipment and the
machine ′ s handle unit.
Regularly check the vibration damping units for cracks or
deformation.
Check that the vibration damping element is undamaged and
securely attached.
WARNING! Overexposure to vibration can lead to circulatory damage or nerve damage in people who have
impaired circulation. Contact your doctor if you experience symptoms of overexposure to vibration. Such
symptoms include numbness, loss of feeling, tingling, pricking, pain, loss of strength, changes in skin colour or
condition.These symptoms normally appear in the fingers, hands or wrists.The risk increases at low temperatures.
Quick release (if equipped)
There is an easily accessible, quick release fitted at the front as a safety precaution in case the engine catches fire, or in
any other emergency that requires you to free yourself from the machine and harness.See instructions under the
heading adjusting the harness and brush cutter.
Check that the harness straps are correctly positioned. Once the harness and machine have been adjusted, check that the
harness quick release works correctly.

English –10
Muffler
Themufflerisdesigned tokeep noise levelstoa minimum and to direct exhaust fumes away from the user.
To reduce fire hazards, keep the engine and silencer free of debris, leaves and excessive lubricant.
Never use a machine that has a faulty muffler.
Regularly check that the muffler is securely attached to the machine.
WARNING! The inside of the muffler contain chemicals that may be carcinogenic. Avoid contact with these
elements in the event of a damaged muffler.
WARNING! Bear in mind that:The exhaust fumes from the engine are hot and may contain sparks which can start
a fire. Never start the machine indoors or near combustible material!
Locking nut
A locking nut is used to secure some types of cutting attachment.
Whenfitting,tightenthenutin theoppositedirectionto the direction of rotation of the cutting attachment.To remove it, undo
the nut in the same direction as the cutting attachment rotates. (CAUTION! The nut has a left-hand thread.) Tighten the
nut using the socket spanner.
Thenylonlininginside thelocking nutmustnot beso worn that you can turn it by hand.The lining should offer a resistance
of at least 1.5 Nm.The nut should be replaced after it has been put on approx. 10 times.

English –11
Cutting equipment (Brush cutter & Grass trimmer)
This section describes how to choose and maintain your cutting equipment in order to:
• Reduce the risk of blade thrust.
• Obtain maximum cutting performance.
• Extend the life of cutting equipment.
IMPORTANT!
Only use cutting attachments with the guards we recommend! See the chapter on Technical data.
Refer to the instructions for the cutting attachment to check the correct way to load the cord and the correct cord
diameter.
Keep the teeth of the blade correctly sharpened! Follow our recommendations. Also refer to the instructions on the blade
packaging.
WARNING!Alwaysstoptheenginebeforedoinganyworkonthecuttingattachment.Thiscontinuestorotateevenafterthe
throttlehasbeenreleased.EnsurethatthecuttingattachmenthasstoppedcompletelyanddisconnecttheHTleadfromthe
sparkplugbeforeyoustarttoworkonit.
WARNING! Using an incorrect cutting attachment or an incorrectly sharpened blade increases the risk of blade
thrust.
Cutting equipment
Grass blades and grass cutters are intended for cutting coarse grass.
A trimmer head is intended for trimming grass.
General rules
Only use cutting attachments with the guards we recommend! See the chapter on Technical data.

English –12
Keep the teeth of the blade correctly sharpened! Follow our instructions anduse the recommended file gauge.An
incorrectly sharpened or damaged blade increases the risk of accidents.
Check the cutting attachment for damage or cracks. A damaged cutting attachment should always be replaced.
Sharpening grass cutters and grass blades
• See the cutting attachment packaging for correct sharpening instructions. Sharpen blades and cutters using a
single-cut flat file.
• Sharpen all edges equally to maintain the balance of the blade.
WARNING! Always discard a blade that is bent, twisted, cracked, broken or damaged in any other way. Never
attempt to straighten a twisted blade so that it can be reused. Only use original blades of the specified type.
Trimmer head
IMPORTANT!
Always ensure the trimmer cord is wound tightly and evenly around the drum, otherwise the machine will generate
harmful vibration.
Only use the recommended trimmer heads and trimmer cords.These have been tested by the manufacturer to suit a
particular engine size.This is especially important when a fully automatic trimmer head is used. Only use the
recommended cutting attachment. See the chapter on Technical data.
Smaller machines generally require small trimmer heads and vice versa.This is because when clearing using a cord
the engine must throw out the cord radially from the trimmer head and overcome the resistance of the grass being
cleared.
The length of the cord is also important.A longer cord requires greater engine power than a shorter cord of the same
diameter.
Make sure that the cutter on the trimmer guard is intact.This is used to cut the cord to the correct length.
To increase the life of the cord it can be soaked in water for a couple of days.This will make the line tougher so that it
lasts longer.

English –13
Cutting equipment (Pole pruner - D226ML-1)
This section describes how you can achieve maximum clearing capacity and extend the life of the cutting attachment
through correct maintenance and using the right type of cutting attachment.
Only use recommended cutting attachments, using non-approved cutting attachments
can cause serious or fatal injury to the operator and damage to the machine.
Maintain the correct raker clearance! Follow our instructions and use the recommended
raker gauge. Too large a clearance increases the risk of kickback.
Keep the chain properly tensioned! If the chain is slack it is more likely to jump off and
lead to increased wear on the bar, chain and drive sprocket.
Keep cutting equipment well lubricated and properly maintained! A poorly lubricated chain
is more likely to break and lead to increased wear on the bar, chain and drive sprocket.
Specification of bar and sw chain
Bar length (inches/cm)
Number of teeth on bar tip sprocket (T). Small number = small tip radius = low risk of
kickback.
GUAGE: Bar groove width or Drive link width (inches/mm). The groove in the bar must
match the width of the chain drive links.
Chain pitch (inches). The spacing between the drive links of the chain must match the
spacing of the teeth on the bar tip sprocket and drive sprocket.
Pitch= D/2
Number of drive links. The number of drive links is determined by the length of the bar, the
chain pitch and the number of teeth on the bar tip sprocket.
The table contains a list of all possible combinations between bar and chain, indicating those which may be used on
each machine, marked with the symbol “*”.
Pitch
Guide bar
Chain
Pole pruner model
Zoll
Length
Inches/cm
Groove width
Inches/mm
Number
of teeth
Code
Code
Number of
drive links
D226
3/8”
10”/25cm
0.050”/1.3mm
7
D226ML-1-02
Oregon
91P040X
40
*
*
For replacement use only above bars and chains. If you use non-approved combinations it may cause serious
personal injury and damage to the machine.
General information on sharpening cutting teeth
WARNING! Always stop the engine before doing any work on the cutting attachment. This continues to rotate even
after the throttle has been released. Ensure that the cutting attachment has stopped completely and disconnect the
HT lead from the spark plug before you start to work on it.

English –14
Never use a blunt chain. When the chain is blunt you have to exert more pressure to force the bar through the wood
and the cuttings will be very small. If the chain is very blunt it will not produce any cuttings at all. Wood powder would
be the only result. The cutting part of the chain is called the cutting link and this consists of a cutting tooth (A)
and the raker lip (B). The cutting depth is determined by the difference in height between
the two.
Maintenance the saw chain as below sheet:
Make sure every cutter has the same length and edge angles as illustrated.
File all the teeth to the same length. When the length of the cutting teeth is reduced to 4
mm (0.16") the chain is worn out and should be replaced.
Maintenance guide bar • Reverse the bar occasionally to prevent partial wear.
• The bar rail should always be a square. Check for wear of the bar rail. Apply a ruler to
the bar and the outside of a cutter. If a gap is observed between them, the rail is normal.
Otherwise, the bar rail is worn. Such a bar needs to be corrected or replaced.
Whether there are burrs on the edges of the bar. Remove these with a file if necessary.
Whether the tip of the bar is uneven or badly worn. If a hollow forms on the underside of
the bar tip this is due to running with a slack chain.
To prolong the life of the bar you should turn it over daily.
(1) Ruler (2) Gap (3) No gap
Type
of
chain
File diameter
Top plate angle
Down angle
Head tilt angle
(55°)
Depth
gauge
standard
Vise rotate angle
Vise tilt angle
Side angle
91P
5/32”
30°
0°
80°
0.025”
Depth gauge
File

English –15
Cutting equipment (Long reach hedge trimmer - D226ML-2)
To ensure good cutting results it is important that the contact pressure between the blades is correct. The contact
pressure is adjusted by turning the screws on the underside of the bar clockwise as far as they will go. Then turn the
screws anticlockwise a 1/4 turn. Lock the screws using the locking nut on the top of the bar. Check that the screws are
loose enough to allow the washers under the screw heads to slide sideways.
When the blades are correctly adjusted the play between the blades should be 0,2–0,4 mm, measured at the screws.
The edges of the blades are too hard to be filed. Dull blades should be sharpened using a grinder.
Replace the blades if they are bent or damaged.

English –16
ASSEMBLY
Original instructions
Fitting the main body
Insert the output shaft tube (C) into the clamp collar (B) of engine (A), align the hole on tube and the hole on clamp collar,
and then connect them use a screw (D). Use a screw (E) tension the clamp collar.
Assembling the front handle
• Align the position hole (B1) on the clamp ring (B) with one position hole (A1) of three on the tube (A), and then fit the
barrier (C) on the clamp ring, and while aligning hole on clamp ring and the groove on spacer block. (Fig. 1)
• Align the position pin (D1) on the front handle (D) with the position hole (B1) on the clamp ring (B). (Fig. 2)
•Push down the front handle (D) until the hole on the front handle aligned to the groove on the spacer block. (Fig. 3)
•Insert the locking screw into the front handle, and then turn it clockwise to tighten the front handle. (Fig. 4)

English –17
ASSEMBLY
Original instructions
Connecting the tube
• Align the hole (A1) on the front tube (A) and the lock pin (B). Then, Pull out the Lock pin, and while inserting the front
tube in the connector (D) to the end. After loosened the lock pin, it will return to its original position automatically, and
insert into the hole on the front tube. Make sure the front tube can’t be rotated after the lock pin came back to its original
position. Turn the lock knob (C) counter-clockwise to tighten the front tube securely.
Fitting blades and trimmer heads
When fitting the cutting attachment it is extremely important that the raised section on the top clamping plate/support
flange engages correctly in the centre hole of the cutting attachment. If the cutting attachment is fitted incorrectly it can
result in serious and/or fatal personal injury.
Never use a cutting attachment without an approved guard. See the chapter on Technical data. If an incorrect or faulty
guard is fitted this can cause serious personal injury.
If a saw blade or grass blade are to be used the machine must be equipped with the correct handlebar, blade guard and
harness.
Fitting the guard extension
CAUTION! The guard extension shall always be fitted when using the trimmer head and combination guard.The guard
extension shall always be removed when using the grass blade and combination guard.
Use a screw (E) fix the fitting (C) on the gear box (B). Hook the guard (A) onto the fitting, and then secure with a bolt (D).
Enter the guard extension guide in the slot of the combination guard.Then click the guard extension into position on the
guard with some claws.
The guard extension is removed easily using a
screwdriver, see illustration.

English –18
ASSEMBLY
Original instructions
Fitting a blade guard, grass blade and grass cutter
• Use a screw (E) fix the fitting (C) on the gear box (B). Hook the guard (A) onto the fitting, and then secure with a bolt
(D).Usethe recommended blade guard. See the Technical data section. CAUTION! Ensure that the guard extension is
removed.
• Fit the top clamping plate (B) on the output shaft.
• Turn the blade shaft until one of the holes in the top clamping plate aligns with the
corresponding hole in the top protecting cap.
• Insert the locking pin (A) in the hole to lock the shaft.
• Place the blade (C), bottom clamping plate (D) and bottom protecting cap (E) on the
output shaft.
• Fit the nut (F).The nut must be tightened to a torque of 35-50 Nm (3.5-5 kpm). Use the
socket spanner in the tool kit. Hold the shaft of the spanner as close to the blade guard as
possible.To tighten the nut, turn the spanner in the opposite direction to the direction of
rotation (Caution! left-hand thread).
•Pull out the locking pin after all installation process has been finished.
Fitting the trimmer guard and trimmer head
• Fit the correct trimmer guard for use with the trimmer head. CAUTION! Ensure that the
guard extension is fitted.
• Hook the trimmer guard/combination guard onto the fitting on the shaft and secure with
three bolts.
• Fit the top clamping plate (B) on the output shaft.
• Turn the blade shaft until one of the holes in the top clamping plate aligns with the
corresponding hole in the top protecting cap (C).
• Insert the locking pin (A) in the hole to lock the shaft.
•Screw on the trimmer head (D) in the opposite direction to the
direction of rotation.
To dismantle, follow the instructions in the reverse order.

English –19
ASSEMBLY
Original instructions
Fitting guide bar and saw chain (for Pole Pruner - D226ML-2)
1、Fit the cutting head (B) on the shaft tube (A) so that the screw hole on the
cutting head is aligned with the position hole (A1) on the shaft tube as shown.
Then, tighten the lock screw (D) and the position screw (C) securely.
Make sure that the drive shaft inside the shaft engages with the cut-out in
the cutting head.
2、Unscrew the nut (G) and remove the chain cover (H).
Fit the saw chain around the guide bar. Fit the guide bar (E) over the bar bolt.
Place the guide bar in its rearmost position. Place the saw chain over the
drive sprocket (K) and in the groove on the guide bar. Begin on the top side
of the guide bar.
Make sure that the edges of the cutting links are facing forward on the top
edge of the guide bar.
Locate the chain adjuster pin (J) in the hole (E1) in the guide bar. Check that
the drive links of the saw chain fit correctly on the drive sprocket and that the
saw chain is in the groove in the guide bar. Fit the chain cover and tighten
the nut finger-tight.
3、Tension the saw chain by turning the Chain tension adjuster (L) clockwise
using the combination spanner (M). The saw chain should be tensioned until
it does not sag from the underside of the bar.
①Chain tension ②Chain loosen
4、The saw chain is correctly tensioned when it does not sag from the underside of the guide bar, but can still be turned
easily by hand. Hold up the guide bar tip and tighten the nut (G) with the combination spanner (M).
①Tighten ②Loosen
If necessary, readjust with the nut loose.
When fitting a new chain, the chain tension has to be checked frequently until the chain is run-in. Check the chain
tension regularly. A correctly tensioned chain ensures good cutting performance and long life.
Chain oil
WARNING! Poor lubrication of cutting equipment may cause the chain to snap, which could lead to serious, even fatal
injuries. The special oil for lubricating the chain is biodegradable. Use of a mineral oil
or engine oil causes serious damage to the environment. So only use
special oil for this machine.
Never use waste oil! This is dangerous for yourself, the machine and the
environment.
Chain oil must demonstrate good adhesion to the chain and also maintain its
flow characteristics regardless of whether it is warm summer or cold winter
weather.
The oil pump is preset at the factory to meet most lubrication requirements.
A full oil tank will run out as long as exhaust of a full tank of fuel, so fill oil
tank completely every time you refuel fuel tank.
Tighten the oil tank cap (P) securely after every filling.
