ANTAIRA MSC-202A-V2 User manual

Congratulations on your purchasing this high performance PCI
Express serial and parallel I/O adapter. The adapter is high
speed PCI Express bus based and plug-and-play compliant. Its
serial ports are fully 16C950 UART compatible with most of the
RS232C devices available from the market.
The common features of the PCI Express I/O family as follows:

Full x1 PCI Express Throughput, 250Mbytes/sec

Works in 5V and 3.3V Tolerance Options

Fully Compliant with PCI Express Base
Specifications, Revision 1.0a

16C950 UARTs, Fully Compatible with 16C550, Baud Rate up
to 921.6Kbps

Low Profile PCI Express model available with different
brackets

Supports Win98/Me, NT, 2000, XP, Vista, 2003, & Windows 7
Figure 2-1. 2S Model Board Layout
MSC-202A-V2
Installation Guide
S2
S1
S1 Internal Header Connector
JP2 External Power Enabler
JP3 External Power Selector
J7 Aux. Power
Connector
1. Introduction
2. Board Layouts

PCI Express Multi Serial I/O Adapter
2
JP2- External Power Enabler: There are 4 jumpers that control
the pin-9 signal of the 4 serial ports connectors (S1~S4)
respectively. If the jumper(s) is at the “DIS” position (factory
default), the pin-9 was connected with the RI signal as standard
RS232 definition. If the jumper is at the “PWR” position, the pin-9
was connected with a power either from PCI Express slot or
from Aux Power connector (J7). The power source is controlled
by JP4 jumper (see the following section).
JP3- External Power Selector: The pin-9 of the serial port
connector will be supplied with DC5V or DC12V. There are 3
sources depends on the jumper’s position of the JP4:
AUX5V: DC5V, from J7, an optional power cable is required.
AUX15V: DC12V, from J7, an optional power cable is
required.
PCI12V (factory default): DC12V, from PCI Express golden
finger, no cable is required.
1. Turn the system power OFF before installation!
2. Use static electricity discharge precautions.
3. Remove the chassis cover from your computer
4. Locate an unused PCI Express slot (typically white and
smaller) and remove the corresponding slot cover from
computer chassis.
5. Plug the I/O card to the unused PCI Express expansion slot
and attached the I/O card bracket to the computer chassis
screw.
6. Put the chassis cover back on the computer.
7. Turn ON the power of your computer and peripherals.
8. Proceed with Software Driver Installation.
3. Jumper Settings
4. Installing the PCI Express I/O Adapter

PCI Express Multi Serial I/O Adapter
3
Note:
PLEASE DO NOT LET WINDOWS AUTO SEARCH THE DRIVERS ON THE CD, it
will cause problems because the INF files will be conflict in this case.
Instead, please browse to the correct location (folder) manually to
make sure the correct drivers are chosen and installed correctly.
Note: Windows NT driver Installations
To install the Windows NT driver, please go into WinNT4 sub-directory
and run (double click) Install_Serial.exe to install all Serial Port Drivers.
Installing Windows Drivers:
1. When the system is powered, Windows will invoke Windows’ New
Hardware Wizard. Click〝Next 〞to continue, select〝Install from
a list or specific location（Advanced）〞and click〝Next 〞.
2. Select〝Include this location in the search 〞then click〝Browse 〞
to specify the driver’s location for your Windows (for example,
XP is E:\IO\OXFORD\XP32) and click〝Next 〞to continue.
5. Software Installation
Drivers are in each
corresponding folder

PCI Express Multi Serial I/O Adapter
4
3. Click〝Next 〞to continue, and click〝Finish 〞to complete the
installation.
4. To check the Installation, right click on〝My Computer〞and
choose
〝Manage〞
. Choose
〝Device Manager 〞
and double click
〝Ports 〞.
