MB-1 MOBILE FOG MACHINE
User Manual
- ENGLISH
© 2020 Antari Lighting and Effects Ltd.

2
© 2020 Antari Lighting and Effects Ltd. www.antari.com
- ENGLISH-
Safety Information
Please read the following safety information carefully before operating the
machine. This information includes important safeguards about installation,
usage, and maintenance. Pay attention to all warning labels and instructions in
this manual and printed on the machine.
If you have questions about how to operate the machine safely, please contact your local
Antari dealer for help.
․ Keep this device dry.
․ Always connect to a grounded circuit to avoid risk of electrocution.
․ Do not operate if power cord is damaged. If power cord is damaged, replace it
immediately with a new one of same power rating.
․ Remove the machine from battery or power adaptor before servicing and when not in
use.
․ This product is for indoor use only! Do not expose to rain or moisture. If fluid is spilled,
remove machine from battery or power adaptor and clean with a damp cloth. If fluid is
spilled onto electronic parts, immediately unplug the machine and contact your local
Antari dealer for advice.
․ No user serviceable and modifiable parts inside. Never try to repair this product, an
unauthorized technician may cause damage or malfunction to the machine.
․ For adult use only. Never leave the machine running unattended.
․ For persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge, supervision or instruction must be given concerning use of appliance
in a safe way and understand the hazards involved.
․ Install the machine in a well-ventilated area. Provide at least 50 cm space around the
machine.

3
© 2020 Antari Lighting and Effects Ltd. www.antari.com
․ Never add flammable liquid of any kind to the machine.
․ Make sure there are no flammable materials close to the machine while operating.
․ Only use Antari fluid. Other fluid may lead to heater clog and malfunction.
․ If the machine fails to work, unplug the machine and stop operation immediately.
Contact your local Antari dealer for advise.
․ Before transporting the machine, make sure the fluid tank is completely drained.
․ Fog fluid may present health risks if swallowed. Do not drink fog fluid. Store it securely.
In case of eye contact or if fluid is swallowed, immediately look for medical advice.
Unpacking and Inspection
Immediately upon receiving the machine, carefully unpack the carton, check the content to
ensure that all parts are present and have been received in good condition. If any parts
appear damaged or mishandled from shipping, notify the shipper immediately and retain the
packing material for inspection.
What is included: 1 x MB-1 Fog Machine
1 x Battery
1 x Battery charger
1 x FLM-05S water-based liquid
1 x User Manual
1 x Flightcase
Product Dimensions
228 mm
112 mm
66 mm

4
© 2020 Antari Lighting and Effects Ltd. www.antari.com
Product Overview
Setting Up
Step 1: Place the machine on a flat surface and in a suitably large area with at least 50 cm
of open space around the machine.
Step 2: Fill the fluid tank with Antari FLM-05S fluid.
Step 3: Charge the battery by plugging the charger adaptor into a grounded electrical
outlet. Yellow light on the adaptor indicates charging, when it turns green then the charge
complete. Please note the battery requires 3 hours charge time.
Mode Switch
ON / OFF Switch Control
Fog Output Nozzle
S-Terminal Connector
Volume Switch

5
© 2020 Antari Lighting and Effects Ltd. www.antari.com
Plug in the charger
Yellow indicates charging
Green indicates charging
complete
Always connect the machine to a protected circuit and ensure it is properly
grounded to avoid risk of electrocution.
Step 4: Slide in the battery into bottom of MB-1 with label face up. Turn on the machine to
start operation.
Pull to release locking lever
Step 5: To start making fog, press the button to start making fog, release to stop.
Step 6: To turn off the machine, remove battery from machine.

6
© 2020 Antari Lighting and Effects Ltd. www.antari.com
Operation
Control Panel Operation
The machine can be operated with the On/Off button and output level can be adjusted from
the switch located on the side. When using MOMENTARY Mode press and hold the button
to make fog, release to stop. In LATCHING Mode, press button once to produce fog, press
again to stop.
MCT-2 Cable Timer Remote Operation (Optional)
To operate the machine by remote control, connect the remote to the S-terminal connector
located on the side of machine. Use the switch to turn fog on/off, and use the rotary knob to
adjust the interval and duration time.

7
© 2020 Antari Lighting and Effects Ltd. www.antari.com
MCR-1F Wireless Operation (Optional)
W-1 Wireless Transmitter
Wireless remote control system MCR-1F consists of a transmitter equipped with two buttons to
activate and deactivate fog output with an external receiver connect to the side of MB-20 fog
machine.
Press [A] button to emit fog.
Press [B] button to stop.
In a an unobstructed open space the effective distance is 50 meters, usage depending on
obstacle level has an effective distance is 10-25 meters.
Registering a transmitter
Transmitters can be paired from the receiver. Each receiver can pair up to 5 transmitters.

8
© 2020 Antari Lighting and Effects Ltd. www.antari.com
Follow the steps below to pair or delete a transmitter from a receiver.
To Pair
Step 1: Connect receiver to S-terminal connector located on the side of machine
Step 2: Press and hold [A] to pair
Transmitter battery replacement
If the effective distance seems to decrease, it is possible the battery level is low and
requires replacement. In order to replace the battery, undo the three screws on the back of
transmitter to release the cover. Replace with the same type and specification of battery
which is 27A 12V
DCP-12 Power Adaptor and Dummy Battery (Optional)
Use dummy battery for continuous operation. Slide in dummy battery into bottom of MB-1
machine. Connect the battery with power adaptor. Follow operation instruction above to
operate.
Fluid
Only use Antari FLM-5S water-based liquid for the MB-1 Fog Machine.
The machine is tested and calibrated with this liquid to get the best output
performance. Warranty will be voided if any other type of liquid is used.
Improper use of liquid may lead to machine failure or malfunction.

9
© 2020 Antari Lighting and Effects Ltd. www.antari.com
Service and Maintenance
․ Do not allow the machine to become contaminated.
․ Remove dust from air vents with air compressor, vacuum or a soft brush.
․ Only use a damp cloth to clean the casing.
․ Before storing run distilled water through the system to help avoid condensing the
pump or heater.
․ It is recommended to run the machine on a monthly basis in order to achieve best
performance and output condition.
․ Excessive dust, liquid and dirt built up will degrade performance and cause
overheating.
․
Maintenance of Rechargeable lead-acid Battery
․
To give the rechargeable battery long lifespan and best performance, please follow below
instructions:
! Please fully charge the battery upon receipt of the machine.
! Every 2-4 weeks, check and ensure the battery has sufficient power to work. At least
charge the battery to full every 4-6 months.
! Before storage, please have the battery fully charged.
! Please store the fully charged battery and the machine in cool and dry area, avoid
directly sunlight.
! Please charge the battery within 24 hours if the battery is going to run out of power.
! If you have any question on maintenance and usage, please contact your local dealer
for advice.

10
© 2020 Antari Lighting and Effects Ltd. www.antari.com
Technical Specifications
- Input voltage
- Rated power
- Warm-up time
- Fluid consumption
- Fluid tank capacity
- Compatible fluid
- Ambient temp. range
- Control
- Optional accessories
- Dimension
- Weight
DC 12V (Battery)
AC 100-240V, 50-60Hz (Battery charger)
75W
1 second (approx.)
1.1 ml/min
110 ml (0.03 gal)
Antari FLM-5S Fog Fluid
0 °C - 40 °C (32 °F-104 °F)
Manual
Wireless (Optional)
Timer (Optional)
MCR-1F Wireless Remote
MCT-2 Cable Timer Remote
DCP-12 Power Adaptor and Dummy Battery
L 228 W 66 H 112 mm
(L8.98 W2.60 H4.41 inch)
1.8 kg (3.97 lbs)
1 kg (2.2 lbs) without battery
