AOC 177sa User manual

17” LCD Color Monitor AOC 177Sa
1
JH
Service
Service
Service
Horizontal Frequency
30-80 kHz
TABLEOFCONTENTS
Description Page Description Page
N
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
Table Of Contents.......……..............................…........1
Revision List.…........................................……......2
Important Safety Notice.…….........................……......3
1.Monitor Specification..............................………........4
2.LCD Monitor Description…………………………….......5
3.Operation Instruction……..………...............……...........6
3.1.General Instructions………..........................…...........6
3.2.Control Button…………….…..............……...............6
3.3.Adjusting the Picture...........................…............7
4.Input/Output Specification............……………............9
4.1.Input Signal Connector............………….................9
4.2 Power Supply Requirement……………………………9
4.3.Factory Preset Display Modes.................................10
4.4.Panel Specification.....……...……………..................11
5.Block Diagram………...................…………................14
5.1.Software Flow Chart………………………................14
5.2.Electrical Block Diagram…………………..…............16
6.Schematic…………………...................................…18
6.1.Main Board........................................................18
6.2. Audio Board.....………..…....................................23
6.3. Power Board....…..….….......................................24
7.PCB Layout..……………….......................................28
7.1.Main Board……..………........................................28
7.2.Audio Board…....................................................30
7.3.Power Board………...............................................31
7.4.Key Board…………...…….....................................35
8.Maintainability…………….........................................36
8.1.Equipments and Tools Requirement......................36
8.2.Trouble Shooting………….....................................37
9.White-Balance Luminance adjustment…….….....45
10.Monitor Exploded View…………………….….........47
11.BOM List….........................................................48
12.Different Parts List…….………………......…………69
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
All manuals and user guides at all-guides.com
all-guides.com

17” LCD Color Monitor AOC 177Sa
2
Revision List
Revision Date Revision History TPV Model
T76CRTDBF1A3A
A00 May.-18-07 First Version Release
T76CRTDBF1A3E
A01 Jun.-21-07 Add power board 715G2594 1
schematic and the BOM T76SRDDBF1A3AN
A02 Aug.-02-07 Add TPV Model in item 12 T77SRDDCF1A2AN
A03 Jan.-28-08 Add TPVDW Model in item 11 T77SRDDCF1ACANE
A04 Mar.-14-08 Add TPVDW Model in item 12 T77SRDDBF1ACANE
T78GRDDBF1ACANE
T78GRDDBF1AOANE
T78ARDDBF1AOANE
A05 Oct.-30-08 Add TPVDW Model in item 12
T78ARDDCF1A1ANE
T78ARDDCF1A3ANE
A06 Apr.-23-09 Add TPVDW Model in item 12
T78GRDNCF1A18NE
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
3
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service
procedures recommended by AOC and described in this service manual are effective methods of performing service
operations. Some of these service operations require the use of tools specially designed for the purpose. The
special tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in
which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, AOC Company will be referred to as AOC.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics may create shock,
fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from AOC.
AOC assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiation when open AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit.
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
4
1. Monitor Specifications
Items Descriptions
Driving system TFT Color LCD
Type CLAA 170EA
Size 43.2cm (17")
Pixel pitch 0.264mm( H )x 0.264mm( V )
Viewable angle 160˚(H) 160˚(V) (TYPE)
LCD Panel
Response time (type) 5 ms for CPT
R,G,B Analog Interface
Video
Digital Interface
Connector 15-pin D-Sub
Video Signal Analog:0.7Vp-p(standard),
75 OHM, Positive
Sync. Type H/V TTL
H-Frequency 30kHz – 80kHz
Input
V-Frequency 56-75Hz
ON Mode ≤37W
Power Consumption
OFF Mode ≤2W
Contrast Ratio 800:1
Dot Clock 135 MHz
White Luminance 300cd/m2
Max. Resolution 1280 x1024
Display Color 16.2M colors
Plug & Play VESA DDC2BTM
Power Source 100~240VAC,47~63Hz
Maximum Screen
Size
Horizontal : 337.92 mm
Vertical: 270.34 mm
Environmental
Considerations
Operating Temp: 5°C to 35°C
Storage Temp: -20°C to 60°C
Operating Humidity: 10% to 85%
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
5
2. LCD Monitor Description
The LCD MONITOR will contain a main board, an audio board, a power board and a key board which house the flat
panel control logic, brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips
each voltage.
Monitor Block Diagram
AC-IN
100V-240V
Power Board
(
Include: ada
p
ter, inverter
)
Flat Panel and
CCFL backlight
RS232 Connector
For white balance
adjustment in factory
mode
CCFL Drive.
Video signal, DDC
Key Board
HOST Computer
Audio Board
Main Board
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
6
3. Operating Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The control buttons are located at front panel of the monitor.
By changing these settings, the picture can be adjusted to your personal preferences.
-The power cord should be connected.
-Connect the video cable from the monitor to the video card.
-Press the power button to turn on the monitor, the power indicator will light up.
3.2 Control Buttons
Item Name Within OSD Without OSD
1 Power Button/Power
Indicator Power On / Off Power On / Off
2 > / Volume Control 1.Move the cursor up
2.Increase the value of the selected Activate the audio menu
3 < /Volume Control 1.Move the cursor down
2.Decrease the value of the selected Activate the audio menu
4 Menu/Enter Select Function or select Sub menu Activate OSD main menu
5 Auto/Exit Exit OSD or back to previous menu Auto configuration
All manuals and user guides at all-guides.com
all-guides.com

17” LCD Color Monitor AOC 177Sa
7
3.3 Adjusting the Picture
OSD functions
Main Menu Item
Main
Menu
Icon
Sub Menu
Item
Sub
Menu
Icon
Description
Contrast
Contrast from Digital-register.
Luminance
Brightness
Backlight Adjustment
Focus
Adjust Picture Phase to reduce Horizontal-Line noise
Image Setup
Clock
Adjust picture Clock to reduce Vertical-Line noise.
H. Position
Adjust the horizontal position of the picture.
Image Position
V. Position
Adjust the vertical position of the picture.
Warm N/A Recall warm Color Temperature from EEPROM.
Cool N/A Recall cool Color Temperature from EEPROM.
sRGB N/A Recall sRGB Color Temperature from EEPROM.
User / Red
Red Gain from Digital-register.
User / Green
Green Gain Digital-register.
Color Temp.
User / Blue
Blue Gain from Digital-register.
Input Select Yes N/A
Auto Adjust the H/V Position, Focus and Clock of
picture.
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
8
No N/A Do not execute Auto Config, return to main menu.
H. Position
Adjust the horizontal position of the OSD.
V. Position
Adjust the vertical position of the OSD.
OSD Setup
OSD Timeout
Adjust the OSD timeout.
Language
Language N/A Select the language you like.
Information
Information N/A
Show the resolution, H/V frequency and input port of
current input timing.
Yes N/A
Clear each old status of Auto-configuration and set
the color temperature to Cool.
Reset
No N/A Do not execute reset, return to main menu.
Exit
N/A N/A Exit OSD
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
9
4. Input/Output Specification
4.1 Input Signal Connector
D-SUB connector
Pin No. Description Pin No. Description
1. Red 9. + 5V
2. Green 10. Detect Cable
3. Blue 11. Ground
4. Ground 12. DDC-Serial Data
5. DDC-Return 13. H-Sync
6. R-Ground 14. V-Sync
7. G-Ground 15. DDC-Serial Clock
8. B-Ground
VGA connector layout
4.2 Power Supply Requirement
A/C Line voltage range : 100 V ~ 240 V
A/C Line frequency range : 50 ±3Hz, 60 ±3Hz
Current : TBD
Peak surge current : < 55A peak at 240 VAC and cold starting
Leakage current : < 3.5mA
Power line surge : No advance effects (no loss of information or defect) with a
maximum of 1 half-wave missing per second
DC output Voltage : 12VDC ± 5％
Current (max) : 3.5 Amp (12V)
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
10
4.3. Factory Preset Display Modes
Standard Resolution Horizontal
Frequency
Vertical
Frequency
Dos-mode 720 × 400 31.47kHz 70.0Hz
640 × 480 31.47kHz 60.0Hz
VGA 640 × 480 37.50kHz 75.0Hz
800 × 600 37.879kHz 60.0Hz
SVGA 800 × 600 46.875kHz 75.0Hz
1024 × 768 48.363kHz 60.0Hz
1024 × 768 56.476kHz 70.0Hz
1024 × 768 60.021kHz 75.0Hz
1024 × 768 48.780 60.0Hz
XGA
1024 × 768 60.241 75.0Hz
1280 × 1024 64.000kHz 60.0Hz
SXGA
1280 × 1024 80.00 75.0Hz
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
11
4.4. Panel Specification
4.4.1 Features
- Super wide viewing angle
- Super high contrast ratio
- Super fast response time
- High color saturation (EBU Like Specifications)
- SXGA (1280 x 1024 pixels) resolution
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- PSWG compatible
- RoHS compliance
- TCO’03 compliance
4.4.2 Display Characteristics
All manuals and user guides at all-guides.com
all-guides.com

17” LCD Color Monitor AOC 177Sa
12
4.4.3 Optical Characteristics
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
13
4.4.4 Electrical Characteristics
1. TFT LCD Module
2. Backlight Unit
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
14
5. Block Diagram
5.1 Software Flow Chat
1
2
N
Y
5
Y
N
1
Y
N
12
Y
N
7
Y
N
6
4
3
8
9
14
11
13
Y
N
15
Y
N
16
17
19
Y
N
18
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
15
1) MCU initialize.
2) Is the EPROM blank?
3) Program the EPROM by default values.
4) Get the PWM value of brightness from EPROM.
5) Is the power key pressed?
6) Clear all global flags.
7) Are the AUTO and SELECT keys pressed?
8) Enter factory mode.
9) Save the power key status into EPROM.
Turn on the LED and set it to green color.
Scalar initializes.
10) In standby mode?
11) Update the lifetime of back light.
12) Check the analog port, are there any signals coming?
13) Does the scalar send out an interrupt request?
14) Wake up the scalar.
15) Are there any signals coming from analog port?
16) Display "No connection Check Signal Cable" message. And go into standby mode after the message
disappear.
17) Program the scalar to be able to show the coming mode.
18) Process the OSD display.
19) Read the keyboard. Is the power key pressed?
All manuals and user guides at all-guides.com

17” LCD Color Monitor AOC 177Sa
16
5.2 Electrical Block Diagram
5.2.1 Main Board
U402
MCU
RTD2120L-LF
U401
Scalar IC RTD2025L
(
Include ADC
,
OSD
)
U302
EEPROM
A
T24C16AN
CN702
D-Sub
Connector
U702
EEPROM
M24C02
H sync
V sync
RGB
DB15_SDA,
DB15
_
SCL
EPR_SDA
EPR_SCL
LCD Interface
CN503
Key Board Control
CN502
X301
Crystal
24MHz
CLKOUT
All manuals and user guides at all-guides.com
all-guides.com

17” LCD Color Monitor AOC 177Sa
17
5.2.2 Inverter/Power Board
DIM
DIM
EMI filter
Start Circuit
PWM
Control IC
Transformer
AC input
12V
ON/OFF
Control
PWM
Control IC
Feedback
Circuit
Output
Circuit Transformer MOSFET
Over
Voltage
Lamp
ON/OFF
5V
Bridge
Rectifier
and Filter
Feedback
Circuit
Rectifier
diodes
CN902
All manuals and user guides at all-guides.com

17" LCD Color Monitor AOC 177Sa
18
6. Schematic
6.1 Main Board
CN101
CONN
2
4
6
8
10
12
1
3
5
7
9
11
Q105
PMBS3904
VIN(3)
L102
120 OHM
1 2
R102
4K7 1/10W 5%
R101
4K7 1/10W 5%
VOUT(2)
3
PANELPOWER_ON/OF F
Q101
AO3401
GND(1)
POWER
A
26Saturday , April 14, 2007
Title
Size Doc ument Number Rev
Date: Sheet of
G
L101
600 OHM
1 2
D
C109
100pF/50V
Q102
PMBS3904
3DVCC
BKLT-EN
5DVC C
R111
NC
BKLT-EN
5DVC C
VCC12V
C106
100pF/50V
C102
100pF/50V
R108
100K 1/10W 5%
1
R109
NC
R112
NC
INVON
+
C101
100uF/16V
+
C110
100uF/16V
R107
10K 1/10W 5%
VCC5V
R104
4K7 1/10W 5%
G2264-E-X-X-1-070215
BKLT-VBRI
5DVCC
R105
220R 1/10W
S
R106
10K 1/10W 5%
C103
100pF/50V
E
VBRI
VCC12V
R103
NC
2
3DVCC
5DVC C
C107
100pF/50V
+
C104
100uF/16V
BKLT-VBRI
C105
1uF/16V
U101
AIC1084-33PE
1
23
ADJ
Vo2Vin
Q104
PMBS3904
VOUT(2)
PANEL_VCC
AO3401L
VCC12V
R113
4K7 1/10W 5%
C108
100pF/50V
R110
0R05 1/10W 5%
D101
SS14
VCC5V
Q103
PMBS3904
AIC1084-33M
All manuals and user guides at all-guides.com

17" LCD Color Monitor AOC 177Sa
19
C703
NC
T0-
DSUB_5V
C706
0.047uF
NC
DSUB _ 5V
T1+
C715
150pF
R1-
GREEN+IN
T2+
TX1+
R704
360Ω1/10W
L703
30 OHM
12
ST_DET1
100
TX0-
D718 BAV99
3
1
2
ST_DET1
NC
DGND
BLUE+IN
Bus_Power
D705
TZ MC 5V 6
1 2
IN-H
100
DDC1_SCL
B1+
U701
M24C 0 2- W MN6TP
1
2
3
4 5
6
7
8
A0
A1
A2
VSS SDA
SCL
WP
VCC
DDC2_SDA
TX2+
T1-
D723
TZ MC 5V 6
1 2
GREEN+IN
100
T0+
T1+ R723
0R05 1/ 10W 5%
C705,C708,C7 12 由 10uF-->15uF; R701,R703,R7 04,R706,R7 09,R711 由 100 ohm-->360 ohm 070215
TXC-
DDC1_S CL
R720
0R05 1/ 10W 5%
GREE N+I N
TC -
C710
0.047uF
R1+
C713
0.047uF
RTD2525L
DDC1_SDA
DDC2_SCL
G2264-E-X-X-1-070215
DDC2_SDA
BLUE+IN
DGND
AVS1
T2-
R709
360Ω1/10W
RED+ IN
D717 BAV99
3
1
2
R707
L701
30 OHM
12
D714
BAV99
3
1
2
0.047u
E
3DVCC
C712
15pF
D704
BAV99
3
1
2
G1-
TXD
DGND
R705
75 OHM +-1% 1/10W
D713
TZ MC 5V 6
1 2
R706
360Ω1/10W
C710 R704
DDC1_SCL
T2+
C718
150pF
DGND
D708
TZ MC 5V 6
1 2
R710
75 OHM +-1% 1/10W
C704
0.047uF
0.047u
DGND
BLUE+IN
RED+ IN
D711
TZ MC 5V 6
1 2
3DVCC
Bus_Power
G1+
R703
360Ω1/10W
D720
TZ MC 5V 6
1 2
R702
75 OHM +-1% 1/10W
C707
D719
BAV99
3
1
2
D703 BAV99
3
1
2
DDC2_S DA
R713
2K 1/10W
D701
BAV99
3
1
2
R718 100R 1/10W 5%
0.047u
D710
TZ MC 5V 6
1 2
CN701
JACK
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
26
25
RX2-
RX2+
GND
RX4-
RX4+
SCL
SDA
VS
RX1-
RX1+
GND
RX3-
RX3+
5V
GND
HP
RX0-
RX0+
GND
RX5-
RX5+
GND
RXC+
RXC-
GND
GND
R707
100R 1/10W 5%
DDC2_SDA
DSUB_5V
SOG1
RXD
R729
2K 1/10W
C719
150pF
R714
100R 1/10W 5%
Bus_Power
C717
100pF/ 50V
C705
15pF
R701
360Ω1/10W
RTD2553V
& 2523B
TX1-
IN-H
T2-
R730
2K 1/10W
R722
0R05 1/ 10W 5%
R715
2K 1/10W
TX2-
DDC1_S DA
DDC2_SCL
R721
0R05 1/ 10W 5%
D709
TZ MC 5V 6
1 2
C708
15pF
RXD
R719 100R 1/10W 5%
R724
0R05 1/ 10W 5%
C711
0.047uF
TXD
RED+IN
U702
M24C 0 2- W MN6TP
1
2
3
4 5
6
7
8
A0
A1
A2
VSS SDA
SCL
WP
VCC
R728
4K7 1/10W 5%
D721
BAV70
3
1 2
TX0+
ST_DET2
AVS1
DGND
T1-
R711
360Ω1/10W
L704
30 OHM
12
CN702
DB15
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
1716
IN-V
TC -
R717
2K 1/10W
C707
0.047uF
D702BAV9 9
3
1
2
RXD
DDC2_S CL
D724
TZ MC 5V 6
1 2
B1-
TC +
R708
1M 1/10W 5%
L702
30 OHM
12
T0-
AHS1 AH S1
C701
100pF/ 50V
3DVCC
C716
150pF
C709
0.047uF
TXD
C714
NC
IN-V
R712
100R 1/10W 5%
DDC1_S CL
D712
TZ MC 5V 6
1 2
D707
TZ MC 5V 6
1 2
INP UT
C
36Saturday , Apr il 14, 2007
Tit l e
Size Document Number Rev
Dat e: Sheet of
DDC2_SCL
R726
0R05 1/ 10W 5%
3DVCC
IN-V
T0+
D716 BAV99
3
1
2
DDC1_SDA
R716
2K 1/10W
DDC1_S DA
TC +
IN-H
ST_DET3
D706
BAV99
3
1
2
R725
0R05 1/ 10W 5%
R727
0R05 1/ 10W 5%
ST_DET1
TXC+
D715
BAV99
3
1
2
D722
BAV70
3
1 2
All manuals and user guides at all-guides.com

17" LCD Color Monitor AOC 177Sa
20
TXD
D1
VCC
V1
STBY KEY_LEFT
DDC2_SCL
RTD_SCLK
C301
NC
SD2
MC U _V C C
SDIO2
SD1
ST_DET3
2
LED1
SDIO2
D3
MU TE
RTD_SCSB
KEY_RIGH T
PANELPOWER_ON /OFF
LED1
LED2
D301
LL4148
R342
4K7 1/10W 5%
MCU
B
46Saturday, April 14, 2007
Tit l e
Size Doc um ent Number Rev
Dat e: Sheet of
RXD
1
MCU _VC C
KEY _LEF T
R303
NC
G2264-E-X-X-1-070215
VBRI
IICSDA
KEY_AUTO
ST_DET3
RTD_SD3/SDI
R343
100R 1/10W 5%
3
SD2 DDC2_SDA KEY_POWER
E
KEY_ENTER
IICSDA
C303
10pF
CRYSTAR_OUT
LED2
R333
100R 1/10W 5% CRYSTAR_OUT
R317
4K7 1/10W 5%
5DVCC
DDC1_SDA
B1
E
DDC1_SCL
DDC2_SDA
Bus_Power
SDIO0
D3
3DVC C
SDIO0
TX
MAX810STR
RTD_SD3/SDI
KEY_POWER
D2
R316
NC
IICSCL
L301
NC
LED3
PANELPOWER_ON/OFF
LED3
ST_DET1
MUTE
U302
AT24C16N-10SU-2.7
1
2
3
4 5
6
7
8
A0
A1
A2
GND SD A
SCL
WP
VCC
07/05
D302
LL4148
DDC1_SDA
VOLUME
INV
MC U _V C C
RTD_SCLK
RX
3DVC C
DDC1_SCL
RX
MC U _V C C
STBY
WP
D2
R328
0R05 1/ 10W 5%
MC U _V C C
LED1
B1
KEY_POWER
R306
NC
R319
100R 1/10W 5%
KEY _R IGH T
WP
R329
1K 1/10W 5%
SDIO1
V1
D303
LL4148
D1
SDIO1
LED2
RP301
4.7 KOHM +-5% 1/16W
1
2
3
4
8
7
6
5
D5
SDIO1
C302
100pF/50V
RP308
100Ω1/16W
1
2
3
4
8
7
6
5
R334
100R 1/10W 5%
D4
MCU_RESET
R304
NC
RP306
4.7 KOHM +-5% 1/ 16W
1
2
3
4
8
7
6
5
SDIO0
IICSCL
KEY _AU TO
U301
NC
1
2 3
GND
RST VCC
C304
10pF
ST_DET1
PANELPOWER_ON/OFF
Q302
PMBS3906
1
2 3
POWER
SDIO2
MCU_VCC
R327
0R05 1/ 10W 5%
VBRI
R315
NC
IICSDA
C308
100pF/50V
INVON
KEY_ENTER
R331
100R 1/10W 5%
D5
RP304
4.7 KOHM +-5% 1/ 16W
1
2
3
4
8
7
6
5
SD1
TX
D2
SD1
C305
0.1uF/16V
RP305
4.7 KOHM +-5% 1/ 16W
1
2
3
4
8
7
6
5
WP
POWER
MCU_RESET
X30 1
24.000MHZ
1 2
SDI O2
RTD2120L
U402
RTD2120L-LF
1
2
3
4
5
6 7
8
17 15
41 40 39 38 37 36 35 34 33
19
28
29
20
21
22
23
24
25
26
27
16
9
10
11
12
13
14
18
30
31
32
43 42
44
45
46
47
48
P5.5/PWM5
DSCL2/P5.6
DSDA2/P5.7
RST
ASCL1/P3.0/RXD
NC NC
ASDA1/P3.1/TXD
VSS XO
VCC
P1.0/T2
P1.1 P1.2 P1.3 P1.4 P1.5 P1.6 P1.7
NC
VSYNC
NC
P6.0/ADC0
P6.1/ADC1
P6.2/ADC2
P6.3/ADC3
P6.4
P6.5
P6.6/CLKO1
P6.7
XI
P3.2/INT0
P3.3/INT1
P3.4/T0
P3.5/T1
P7.6/CLKO2
P7.7
NC
NC
NC
NC
NC NC
P5.0/PWM0
P5.1/PWM1
P5.2/PWM2
P5.3/PWM3
P5.4/PWM4
DDC2_SCL
D1
R301
4K7 1/10W 5%
RST
RTD_SCSB
KEY _EN TER
R330
2K 1/10W
RP303
4.7 KOHM +-5% 1/16W
1
2
3
4
8
7
6
5
RP307
100Ω1/16W
1
2
3
4
8
7
6
5
Q301
PMBS3906
1
2 3
R302
4K7 1/10W 5%
R336 6K8 1/10W
KEY_AUTO
MCU_VCC
MCU_RESET
DVI-DSUB SELECT
GND
D4
KEY_LEFT
INV
MCU _VC C
IICSCL
KEY_RIGHT
RP302
4.7 KOHM +-5% 1/16W
1
2
3
4
8
7
6
5
DSUB_5V
VOLUME
D3
All manuals and user guides at all-guides.com
