Safety
National Conventions
The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These
blocks are notes, cautions, and warnings, and they are used as follows:
NOTE: A NOTE indicates important information that helps you make better use of your computer system.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates the potential for bodily harm and tells you how to avoid the problem.Some warnings
may appear in alternate formats and may be unaccompanied by an icon. In such cases, the specic presentation of the
warning is mandated by regulatory authority.

2
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the
type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will t
only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an
electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of
the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the
monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in re or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate congured
receptacles marked between 100-240V AC, Min. 5A.
The wall socket shall be installed near the equipment and shall be easily accessible.

3
Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and use
mounting accessories recommended by the manufacturer. A product and cart combination should be moved with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a re or electric
shock. Never spill liquids on the monitor.
Do not place the front of the product on the oor.
If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit
instructions.
To avoid potential damage, for example the panel peeling from the bezel, ensure that the monitor does not tilt
downward by more than -5 degrees. If the -5 degree downward tilt angle maximum is exceeded, the monitor damage will
not be covered under warranty.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a re or damage to the monitor.
See below the recommended ventilation areas around the monitor when the monitor is installed on the stand:
Installed with stand
Installed with stand
12 inches
30cm
4 inches
10cm
4 inches
10cm
4 inches
10cm
Leave at lease this
space around the set

4
Cleaning
Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent
which will cauterize the product cabinet.
When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it
will scratch the screen surface.
Please disconnect the power cord before cleaning the product.

5
Other
If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a
Service Center.
Make sure that the ventilating openings are not blocked by a table or curtain.
Do not engage the LCD monitor in severe vibration or high impact conditions during operation.
Do not knock or drop the monitor during operation or transportation.
The USB Type-C port could only be connected to specify equipment with re enclosure in compliance with IEC
62368-1 or IEC 60950-1.

6
Setup
Contents in Box
****
*
*
CD Manual Warranty card Stand / Base Stand Screws Remote control Batteries Clip
Power Cable DP Cable HDMI Cable USB Cable USB C-C
Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch
o󰀩ce for conrmation.

7
Setup Stand & Base
Please setup or remove the base following the steps as below.
Setup:
Remove:

8
Adjusting the monitor
For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own
preference.
Hold the stand so you will not topple the monitor when you change the monitor’s angle.
You are able to adjust the monitor as below:
-5° ~ 15°
100mm
15.5°15.5°
NOTE:
Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD screen.
-5°
0° 90°
* Display design may di󰀨er from those illustrated.
WARNING:
• To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more
than -5 degrees.
• Do not press the screen while adjusting the angle of the monitor. Grasp only the bezel.

9
Connecting the Monitor
Cable Connections In Back of Monitor and Computer:
32
41
5
6
7
8
911
10
1. Power Switch
2. Power
3. DP
4. HDMI-1
5. HDMI-2
6. HDMI-3
7. USB C
8. USB upstream
9. USB3.2 Gen1 x2
10. USB3.2 Gen1 + fast charging x1
11. Earphone
Connect to PC
1. Connect the power cord to the back of the display rmly.
2. Turn o󰀨 your computer and unplug its power cable.
3. Connect the display signal cable to the video connector on the back of your computer.
4. Plug the power cord of your computer and your display into a nearby outlet.
5. Turn on your computer and display.
If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.
To protect equipment, always turn o󰀨 the PC and LCD monitor before connecting.

10
Adaptive-Sync function
1. Adaptive-Sync function is working with DP/HDMI
2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www.AMD.com
Graphics Cards
• RadeonTM RX Vega series
• RadeonTM RX 500 series
• RadeonTM RX 400 series
• RadeonTM R9/R7 300 series (excluding R9 370/X)
• RadeonTM Pro Duo (2016 edition)
• RadeonTM R9 Nano
• RadeonTM R9 Fury series
• RadeonTM R9/R7 200 series (excluding R9 270/X, R9 280/X)
Processors
• AMD RyzenTM 7 2700U
• AMD RyzenTM 5 2500U
• AMD RyzenTM 5 2400G
• AMD RyzenTM 3 2300U
• AMD RyzenTM 3 2200G
• AMD PRO A12-9800
• AMD PRO A12-9800E
• AMD PRO A10-9700
• AMD PRO A10-9700E
• AMD PRO A8-9600
• AMD PRO A6-9500
• AMD PRO A6-9500E
• AMD PRO A12-8870
• AMD PRO A12-8870E
• AMD PRO A10-8770
• AMD PRO A10-8770E
• AMD PRO A10-8750B
• AMD PRO A8-8650B
• AMD PRO A6-8570
• AMD PRO A6-8570E
• AMD PRO A4-8350B
• AMD A10-7890K
• AMD A10-7870K
• AMD A10-7850K
• AMD A10-7800
• AMD A10-7700K
• AMD A8-7670K
• AMD A8-7650K
• AMD A8-7600
• AMD A6-7400K

11
HDR
It is compatible with input signals in HDR10 format.
The display may automatically activate the HDR function if the player and content are compatible. Please contact the
device manufacturer and the content provider for information on the compatibility of your device and content. Please
select “OFF” for the HDR function when you have no need for automatical activation function.
Note:
1. Only the HDMI interface is available and the DisplayPort interface cannot function in WIN10 version V1703.
2. The USB C (DP Alt) interface does not support HDR.
3. The display resolution is set to 5120x1440@60Hz, and HDR is preset to ON. Under these conditions, the screen may
slightly dim, indicating HDR has been activated.
5120 x 1440

12
Adjusting
Hotkeys
1 2 3 4 5
1 Source/Up
2 Dial Point/Down
3 Game Mode/Left
4 Shadow Control /Right
5 Power/ Menu/Enter
Power/Menu/Enter
Press the Power button to turn on the monitor.
When there is no OSD, Press to display the OSD or conrm the selection. Press about 2 seconds to turn o󰀨 the monitor.
Dial Point/Down
When there is no OSD, press Dial Point button to show / hide Dial Point.
Game Mode/Left
When there is no OSD, press ” Left” key to open game mode function, then press ” Left” or “ Right” key to select
game mode (FPS, RTS, Racing, Gamer 1, Gamer 2 or Gamer 3) basing on the di󰀨erent game types.
Shadow Control/Right
When there is no OSD, Press Shadow Control button to active Shadow Control adjustment bar, Press “ Right” to
adjust contrast for clear picture.
Source/Up
When the OSD is closed, press Source/Up button will be Source hot key function.

13
1Press to switch power on and
o󰀨.
2Change the signal input source.
3Access the OSD menu.
4Adjust the OSD options upwards.
5Return to previous OSD level.
6Conrm the OSD adjustment/
Access the OSD menu. .
7Access the OSD menu.
Conrm the OSD adjustment.
8Adjust the OSD options down.
9Open gaming mode.
10 Exit OSD menu.
11 Turn down the brightness
12 Turn up the brightness
13 Turn down the volume
14 Turn up the volume
15 Mute
Description of the remote
control buttons
1
3
6
7
10
12
14
2
5
4
8
9
11
13
15

14
OSD Key Guide (Menu)
Enter Move Exit
Enter : Use Enter key to enter the next OSD level
Move : Use Left / Up / Down key to move OSD selection
Exit : Use Right key to exit OSD
Enter Move Exit
Enter : Use Enter key to enter the next OSD level
Move : Use Right / Up / Down key to move OSD selection
Exit : Use Left key to exit OSD
Enter Move Exit
Enter : Use Enter key to enter the next OSD level
Move : Use Up / Down key to move OSD selection
Exit : Use Left key to exit OSD
Enter Move
Move : Use Left / Right / Up / Down Key to move OSD selection
Exit Enter Select
Exit : Use Left key to exit OSD to previous OSD level
Enter : Use Right key to enter next OSD level
Select : Use Up / Down key to move OSD selection
Enter Select
Enter : Use Enter key to apply the OSD setting and back to previous OSD level
Select : Use Down key to adjust OSD setting

15
Enter Select
Select : Use Up / Down key to adjust OSD setting
Enter Select
Enter : Use Enter key to exit OSD to previous OSD level
Select : Use Left / Right key to adjust OSD setting

16
OSD Setting
Basic and simple instruction on the control keys.
Enter Move Exit
Light FXAudio
OSD SetupExtras
1). Press the MENU-button to activate the OSD window.
2). Follow Key Guide to move or select (adjust) OSD settings
3). OSD Lock/Unlock Function: To lock or unlock the OSD, press and hold the Down–button for 10s while OSD function
is not active.
Notes:
1). If the product has only one signal input, the item of “Input Select” is disable to adjust.
2). ECO modes (except Standard mode), DCR and DCB mode , for these three states that only one state can exist.

17
Game Setting
Game Setting
OffGame Mode
Low Input Lag On
Overdrive Off
Shadow Control 50
Frame Counter Off
Game Color 10
MBR 0
Volume 50
Adaptive-Sync On
Exit Enter Select
Game Mode
O󰀨 Turn o󰀨 game mode.
FPS For playing FPS (rst Person Shooters) games. Improves
dark theme black level details.
RTS For playing RTS (Real Time Strategy). Improves the image
quality.
Racing For playing Racing games, Provides fastest response time
and high color saturation.
Gamer 1 User’s preference settings saved as Gamer 1.
Gamer 2 User’s preference settings saved as Gamer 2.
Gamer 3 User’s preference settings saved as Gamer 3.
Shadow Control 0-100
Shadow Control Default is 50, then end-user can adjust
from 50 to 100 or 0 to increase contrast for clear picture.
1. If picture is too dark to be saw the detail clearly,
adjusting from 50 to 100 for clear picture.
2. If picture is too white to be saw the detail clearly,
adjusting from 50 to 0 for clear picture
Game Color 0-20 Game Color will provide 0-20 level for adjusting saturation
to get better picture.
MBR 0-20
MBR (Motion Blur Reduction) Provides 0-20 levels of
adjustments to reduce motion blur.
Note: 1. The MBR function can be adjusted when Adaptive-
Sync is turned o󰀨, the low input delay is turned on and the
refresh rate is ≥75Hz .
2. The brightness of the screen will decrease as the
adjustment value increases.
Adaptive-Sync On / O󰀨
Disable or Enable Adaptive-Sync.
Adaptive-Sync Run Reminder: When the Adaptive-Sync
feature is enabled, there may be ashing in some game
environments.

18
Overdrive
O󰀨 Adjust the response time.
Note: 1. If the user adjusts OverDrive to “Strong” the
displayed image may be blurred. Users can adjust the
OverDrive level or turn it o󰀨 according to their preferences.
2. The “Boost” function is optional when Adaptive-Sync
is turned o󰀨, the low input delay is turned on, and the
refresh rate is 1. The MBR function can be adjusted when
Adaptive-Sync is turned o󰀨, the low input delay is turned on
and the refresh rate is ≥75Hz ..
3. The screen brightness will decrease when the “Boost”
function is turned on.
Weak
Medium
Strong
Boost
Low Input lag On / O󰀨 Turn o󰀨 frame bu󰀨er to decrease input lag
Frame Counter
O󰀨 / Right-Up /
Right-Down / Left-
Down / Left-Up
Instantly display the vertical frequency of the current signal.
(Frame counter feature only works with AMD graphic card.)
Volume 0-100 Adjust volume setting
Notes:
When “HDR Mode” under “Image Setup” is set to “non-o󰀨”, the items “Game Mode”, “Shadow Control”, “Game Color”
cannot be adjusted.
When “HDR” under “Image Setup” is set to “non-o󰀨”, the items “Game Mode”, “Shadow Control”, “Game Color”, “MBR”
cannot be adjusted. “Boost” under “Overdrive” is not available.
