AOC 2230Fa User manual

2230Fa
Cabinet Color Piano Black Finish
Panel TFT Active Matrix LCD
22" Widescreen, Diagonal
558.7mm Viewable Image Size
Hard Coating (3H), Anti-glare Treatment
Pixel Pitch 0.282mm x 0.282mm
Display Area 474mm x 296mm
Brightness 300 cd/m2 (typ)
Contrast Ratio 20,000:1 (dynamic)
Response Time 2ms (typ)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Compatibility PC/Windows, Mac® Equipped With Analog VGA Dsub or DVI Port
Scanning Frequency Horizontal: 24K~80KHz
Vertical: 56~75 Hz
Pixel Frequency 165MHz
Maximum Resolution
Recommended Resolution 1680x1050x60Hz
1680x1050@60Hz
Supported Resolutions 640x480@56/60/67/72/75Hz, 720x400@70Hz, 832x624@75Hz
800x600@56/60/72/75Hz, 1024x768@60/70/75Hz
1152x864@75Hz, 1440x900@60Hz, 1280x960@60Hz
1680x1050@60Hz
Color 16.7M
Signal Input Analog: 0.7Vp-p(standard), 75 OHM, Positive
Digital Input DVI-D with HDCP*
Connectors Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power: (3-Pin Plug CEE22)
Power Source Universal 100~240VAC, 50/60Hz
Power Consumption 49Watts ( Max. )
Plug & Play DDC/2B, DDC/CI
EPA ENERGY STAR® Yes
User Control
Navigation Key (Auto, Eco/Up, Down, Menu), Power
OSD Languages
8 Languages including English, French and Spanish
Regulations
cULus, FCC, CE, Certified for Windows Vista Logo, ROHS
Built-in Speakers
2W x 2
Other Features
720p/1080i HD Compatible, Aluminum Navigation Key, User Friendly
Graphical OSD Menu, VESA 100mm Wall Mount Compliant**,
Kensington Security Slot, includes AOC proprietory
i-Menu software OSD
Dimensions (WxHxD mm) Monitor: 510x417x220, Carton: 562x454x132
Dimensions (WxHxD inches) Monitor: 20.1x16.4x8.7, Carton: 22.1x17.9x5.2
Weight 11.4 lbs (5.2 kgs) Net
14.7 lbs (6.7 kgs) Gross
Loading Qty w/pallet 20' = 800 pcs.; 40' Std = 1680 pcs.
UPC Code
685417021383
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall mount arm & bracket not
included. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
A05/08
