AOC e1659Fwu User manual

16” class USB powered monitor, new and improved with
sleeker design and faster USB 3.0 connection
The e1659Fwu USB powered portable LED backlit monitor is a must-have laptop or desktop accessory. The widescreen
monitor receives both power and signal via a single USB cable for plug-and-play connection; it does not require a power
cord or VGA cable, and comes with a removable base for maximum flexibility.
Key Features
•15.6” viewable image and 16:9 aspect ratio
•Ultra-slim and lightweight with stylish piano-black glossy finish
•Auto-pivot feature for viewing in landscape or portrait mode according to display’s orientation
•Perfect accessory for the frequent traveler or on-the-go presentations
•USB 3.0 Technology for USB-powered for plug-and-play connection
•USB 3.0 achieves high transfer rates and delivers high-quality images
•Foldable stand for landscape and portrait mode
•Built-in DisplayLink technology for multiple USB monitors connection
AOC Monitors
USB Powered
Portable Monitor
USB Series
15.6”, 1366 x 768
E1659FWU

E1659FWU
Sleeker Design, Faster Connections
The new and improved USB monitor from AOC is sleeker in
design and faster with its USB 3.0 connection. The new
USB 3.0 achieves high transfer rates with its total of six
wires in the data cable, and delivers high quality images.
Designed with a piano-black glossy finish, this USB monitor
has a 15.6” diagonally viewable image. The e1659Fwu
offers a 500:1 contrast ratio, 5ms response time, and a
1366 x 768 resolution @60Hz.
The e1659Fwu USB Monitor has a foldable flexi-stand for
viewing in landscape or portrait mode. Landscape mode
is ideal for presentations and Excel sheets, while the
Portrait mode conveniently gives you an easy vertical
view of your instant messaging program, or sidebars such
as search results. This monitor has the unique auto-pivot
feature that automatically adjusts the image according
to the display’s orientation, so you will never have to
change settings as you switch between landscape and
portrait mode.
New Design: Thinner, Lighter, Portability at its best
It’s ultra lightweight and slim for great portability, making
it perfect for business presentations, the frequent traveler,
photo frame applications, and dual monitor setups on-
the-go. The e1659Fwu USB Monitor is the solution for the
frequent traveler who needs to pack multiple displays, as
it easily fits into a backpack or the carry case that comes
with the USB monitor.
New Design: VESA Wall Mount Compatible
You gave your feedbacks and we have heard you! The
new e1659Fwu USB Monitor now comes with VESA 75 x 75
mm Mount Compliant feature, allowing you to easily
mount the USB monitor to any wall as long as you have
the right wall mount arm and bracket.
Built-in DisplayLink Technology for multiple USB monitors connection
If necessary, multiple USB monitors can be simultaneously connected to a single laptop to function as a multi-monitor PC or
Mac, thanks to the built-in DisplayLInk USB graphics. SImply installing DisplayLInk software on the PC or Mac allows you to
easily add multiple USB monitors for external displays without unnecessary extra hardware. The e1659Fwu USB Monitor gives
you multiple external displays for your laptop without any complications
.

E1659FWU
E1659Fwu Specifications
Cabinet Color
Piano-black Glossy Finish
Panel
TFT Active Matrix LCD
16”Class, Widescreen, 16:9 Aspect Ratio
15.6”Diagonal Viewable Area
Pixel Pitch
0.252mm x 0.252mm
Display Area
344.2mm x 193.5mm
Brightness
200 cd/m2 (typ)
Contrast Ratio
500:1 (static)
Response Time
8ms (GTG)
Viewing Angle
Horizontal: 90 Degrees (CR>10)
Vertical: 50 Degrees (CR>10)
Scanning Frequency
Horizontal: 48KHz
Vertical: 60Hz
Optimal Resolution
Recommended
1366 x 768 @60Hz
1366 x 768 @60Hz
Supported Resolutions
640 x 480 @60Hz for extended mode
800 x 600 @60Hz for extended mode
1024 x 768 @60Hz for extended mode
1366 x 768 @60Hz for extended mode
Color Depth
262K
Input Signal
1x Micro USB 3.0
Input Connector
1x Micro USB 3.0
User Control
None
Adjustability
Tilt: 15° ~ 30°, Auto Pivot
OSD Languages
14 Languages including English, French and Spanish
Power Source
PC USB 5V
Power Consumption
8W (typical), Standby: 1W
Regulations
cCSAus, cTUVus, CE, FCC, RoHS, Energy Star®, Windows 8
Special Features
Ultra Slim, Foldable Stand, Low Power Consumption, Smart UI to adjust USB monitor via PC software, Better
Picture Quality via USB 3.0 technogy, VESA 75mmx75mm Wall Mount Compliant1
Dimensions (WxHxD mm)
Monitor w/ base: 375x234x23, Carton: 442×295×84
Dimensions (WxHxD inches)
Monitor: 14.8x9.21x0.9, Carton: 17.4x11.6x3.4
Weight
2.4 lbs. (1.1 kgs) Net
3.7 lbs. (1.7 kgs) Gross
Loading Qty w/pallet
20' = 2352 pcs.; 40' Std = 4704 pcs.
UPC Code
685417062485
What's in the Box
15.6” Monitor, USB 3.0 Cable, Carry case, CD (Drivers, AOC Software, User’s Manual, Warranty)
1. Wall mount arm & bracket not included.Actual product may vary from image shown on datasheet.The information contained herein is subject to
change without notice. AOC shall not be liable for technical or editorial errors or omissions contained herein. All other trade marks are property of their
respective owners.For more information, visit us.aoc.om or Call 888-838-6388
