AOM BRP User manual

USE AND MAINTENANCE MANUAL
WRITTENBYREDIMECSnc
SETTIMOMILANESE(MI)
SPRAYGUN MOD. BRP
®
A.O.M.- AMERICA LLC
54 S. Commerce Way, Suite 180
Bethlehem, PA 18017 USA
AOM
BRP
Cert. -04985-99-AQ-MIL-SINCERT
(Rev. 1 - 14/03/01)
USA - BRP - 1.0

DECLARATION OF CONFORMITY
SIGNATURE:...........................................
ASTURO ORIGINALI MAVES Spa
Via Cascina Venina, 20
20090ASSAGO(MI)-ITALY
++39 02-8905416 - FAX ++39 02-89305497
P.IVA/ VAT (registrationnumber) 11164500156
MODEL BRP
SERIAL NUMBER
YEAR OF MANUFACTURE 200
ACCESSORIES SUPPLIED
A.O.M. spa DECLARES on its own responsibility that the machine to which this declaration refers,
conforms with the prescriptions in the following directives:
DIRETTIVA 89/392/CEE MODIFICATADALLA DIRETTIVA 91/368/CEE
DALLADIRETTIVA 93/44/CEE E DALLA DIRETTIVA 93/68/CEE (DIRETTIVAMACCHINE)
DIRECTIVE 89/392/EECAMENDED BY DIRECTIVE91/368/EEC
BY DIRECTIVE 93/44/EECAND BY DIRECTIVE 93/68/EEC(MACHINE DIRECTIVE)
The machine also conforms with following standards:
UNI EN 292/1 (november 1992) Sicurezza del macchinario, Concetti fondamentali, principi gene-
rali di progettazione.- Terminologia, metodologia di base
Machinesafety, Fundamental concepts. General designprinciples -Terminology, basicmethodology.
UNI EN 292/2 (november 1992) Sicurezza del macchinario - Concetti fondamentali, principi gene-
rali di progettazione - Specifiche e principi tecnici
Machine safety - Fundamental conceps. General design principles - Techinical specification and
principals.
PLACE:
ASSAGOS/N
SURNAME - NAME:
BRANCHINIRIZIERI
POSITION:
SOLE DIRECTOR
DATE:
/ / /
®

Dear Customer,
Thank you for choosing one of A.O.M.- AMERICA products.
A.O.M.- AMERICA is a division of a leading manufacturer in the field of
painting systems and machinery.
The name ASTURO ORIGINALI MAVES Spa has always meant reliability
and safety, a fact which has been supported by over 80 years of experience
and by our Customer satisfaction.
All our components have been designed and manufactured to guarantee
the best performance ever.
To maintain the high quality level and lengthy reliability of our products
throughout the years, always use original spare parts.
All ASTURO ORIGINALI MAVES Spa units are equipped with the
CERTIFICATION in accordance with EUROPEAN DIRECTIVE 89/392
(Machine Directive.)
We are certain we have met all safety requirements and we feel confident
we have further improved working standards.
Our units, in fact, have the identification in accordance with rulings.
Furthermore, they are delivered with the instruction manual and the certifica-
te with the Declaration of Conformity to European Directive 89/392 and to
its various amendments.
The Management

USE AND MAINTENANCE MANUAL
Page 4 of 13
®
HOWTOUSE THEMANUAL..................................................................................................................1
SYMBOLS USED....................................................................................................................................1
INFORMATION LETTER.........................................................................................................................2
1.1 PACKAGING...........................................................................................................................3
2.1 IDENTIFICATION DATA.................................................................................................................3
2.2 MACHINEDESCRIPTION............................................................................................................4
2.3 TECHNICAL FEATURES..............................................................................................................5
2.4 STANDARDAND OPTIONALCOMPONENTS...........................................................................5
2.5 PAINTS, FLUIDSAND OTHER PRODUCTS...............................................................................6
2.6 DIMENSIONS.........................................................................................................................6
3.1 INSPECTION OF PURCHASED PRODUCT...............................................................................7
3.2 INSTALLATION CONDITIONS......................................................................................................7
3.3 HOW TO USE THE GUN...............................................................................................................7
3.4 EQUIPMENT AND CONDITIONS NECESSARYFOR OPERATION .........................................8
3.5 SAFETY PROCEDURES DURING USE..............................................................................8
4.1 PRESSURE DISCHARGE OPERATIONS...................................................................................9
4.2 ROUTINE MAINTENANCE...........................................................................................................9
4.3 TROUBLESHOOTING.......................................................................................................10
WARRANTY
GUN ASSEMBLING DRAWING
GENERAL CONTENTS
HOW TO USE THE MANUAL
The following manual is a document that accompanies the machine thouroughout its lifetime.
It is, therefore, an integral part of the machine. Carefully read the following warnings and
proceduresbeforeengagingin any activity withthismachine,including handling and unloading
it from its transportation mean.
SYMBOLS USED
All operations which might be dangerous if not performed correctly are indicated with the
following symbol:
All operations which, in order to avoid risks, must be performed by trained and authorized
personnel are indicated by the following symbol:
All personnel in charge of using the machine must be thoroughly trained; all the above
information must be thouroughly understood and applied.

USE AND MAINTENANCE MANUAL
Page 5 of 13
®
INFORMATION LETTER
The following maintenance and instruction manual is an integral part of the machine and
must always be available to the personnel in charge of using and maintaining it. The operator
and the personnel in charge of handling the machine must have knowledge of the contents of
the manual. The descriptions and illustrations in the manual are not to be considered as
binding. Although the main features of the machine described in this manual are not subject
to change, ASTURO ORIGINALI MAVES Spa reserves the right to change those
components, details and accessories it deems necessary to improve the machine or to
meet manufacturing or commercial requirements, at any time and without updating this manual
immediately.
WARNING
ALL RIGHTS ARE RESERVED. The reproduction of any part of this manual, in any given
form, without prior written authorization from ASTURO ORIGINALI MAVES Spa, is strictly
forbidden. The content of this manual can be modified without prior notice. Great care has
been taken in collecting and checking the documentation contained in this manual in order to
make it as complete and comprehensible as possible. ASTURO ORIGINALI MAVES Spa
machinesarenot designedtofunction in areasatrisk of firesand/orexplosions. Forproblems
or information call A.O.M.- AMERICA customer care technical service or your local dealer.
WARNING
The machine original configuration must not be modified in any way.
On receiving the machine make sure that:
+ The packaging is intact and undamaged.
+ The supply corresponds to what has been ordered.
+ In case of damage please call A.O.M.- AMERICA
CUSTOMER CARE TECHNICAL SERVICE
A.O.M.- AMERICA LLC
54 S. Commerce Way, Suite 180
Bethlehem, PA 18017 USA
TEL. [phone] or 610-954-5530
FAX. [phone]
INTERNET SITE: www.aomspray.com
E-MAIL: [email protected]

USE AND MAINTENANCE MANUAL
Page 6 of 13
®
AOM
BRP
1.1 PACKAGING
To transport the BRP gun, the unit is packaged in a cardboard box. All optional components
are placed with the gun inside the same box. When transporting and storing the machine
make sure the surrounding temperature remains between -15 and 40 °C (5°Fand 104°F). If
transportation or storage operations last 24 hours or less do not exceed 50°C (122°F)
otherwise the unit could be damaged.
If the need arises to store the machine, make sure the humidity values in the storage area
remain between 30 and 80%.
2.1 IDENTIFICATION DATA
The manufacturer identification and CE RULING n° 89/392 conformity is placed on a side of
thegun(as shownbelow).
The plate must not be removed at any time even if the machine should be sold again.
CE-MARK
MODEL
BRP
l
ASTURO ORIGINALI
l
MANUFACTURER

USE AND MAINTENANCE MANUAL
Page 7 of 13
®
AOM
BRP
2.2 MACHINE DESCRIPTION
The low pressure BRP gun is used to spray paints. It is possible to obtain smooth and even
large-size surfaces with this gun thanks to its micro-spraying system. The spray gun has a
threaded connection which is to be connected to the paint inlet hose. It is also possible to
adjust the inlet air flow and the paint output.
The spray gun used with a paint hose allows a long painting autonomy; it is also possible to
connect the spray gun to a common compressor with reduced working pressure. BRP
ASTURO spray guns are available both in standard and HVLP versions and with stainless
steel paint hose to be used with corrosive products (Code 183XXI). It is possible to adjust the
painting fan to obtain high quality finishing. The drawing below indicates the most important
features of the gun.
l
l
l
l
Spraying cap with fan
direction adjustment
l
l
Gun body made of aluminum
alloy (heavy anodizing).
Fan regulator
Fluid regulation
Stainless steel nozzle
Connection for paint
hose
llNickled brass air inlet
(thread1/4gas)
Air flow inlet regulator

USE AND MAINTENANCE MANUAL
Page 8 of 13
®
2.3 TECHNICAL FEATURES
The painting spray gun must be used with a compressor of 5 bar (71 psi) at least. Its design
improves the distribution of the air supplied from the internal holes also at very low working
pressures.
ASTURO ORIGINALI MAVES Spa carries out all the necessary tests on the painting spray
gun before delivering it to its customers.
NOZZLE TECHNICAL FEATURE TABLE
The above technical features are only exemplifying and can vary without prior notice.
2.4 STANDARD AND OPTIONAL COMPONENTS
The spray gun is delivered with the following standard components:
+1 - Dismantling wrench.
+1 - Cleaning brush.
+1 - Use and maintenance manual.
+1 - Declaration of conformity to CE RULINGS.
+1 - Warranty certificate.
Onrequest:
+Nozzles with different measures.
+Connection hoses.
+Stainless steel filter holder with FM 1/4” (or 3/8”) filter.
+M3/8” fluid in let fiting.
Nitre
Surface
primer Basecoat Clearcoat Matallic/water base Nitre Enamel Wood filler Lacquer Oil-based paint Rust proof coat Primer Sealer Enamel Hammered- effect paint Orange-peel effect paint
Ø1.0 - 1.2 ü ü ü ü
Ø1.4 - 1.5 ü ü ü ü
Ø1.7 - 1.9 ü ü ü ü
Ø2.2 - 2.5 ü ü ü ü ü
NOZZLE
PRODUCT
BODY SHOP WOODWORKING METAL PAINTING
FEATURE VALUE
Air consumption 200Lt/min (70 c.f.m.)
Nozzle size 0,8-1,0-1,2-1,4-1,5-1,7-1,9-2,2-2,5
Fan width 320mm (12.5 in.)
Max. pressure 5 Bar (71 PSI)
Working pressure 4 Bar (57 PSI)
Weight 375 gr (13.2 oz.)
Air inlet M 1/4"
Paint inlet M 1/4" (or M3/8")

USE AND MAINTENANCE MANUAL
Page 9 of 13
®
2.5 PAINTS, FLUIDS AND OTHER PRODUCTS
TheBRPsprayguns are designed for paintingoniron,woodand plastic material. The materials
which can be used in this spray gun are: monocomponent varnishes and enamels, liquid
inks, double coated metal stains, pastel colors, heavy lacquers and monocomponents, bi-
component inks and water-based paints in general. The manufacturer must authorize the use
ofthespray gun with otherproductsand the unit technical featuresmightbe changed in order
to function properly with the new materials.
ASTURO ORIGINALI MAVES Spa is relieved of all responsibility in case of accidents
resulting from the use of the spray gun by unauthorized and unqualified personnel or by
personnel using the equipment differently than intended.
2.6 DIMENSIONS
The spray gun has the following dimensions:
DO NOT USE THE PAINTING SYSTEM WITH
FLAMMABLE OR HIGHLYTOXIC PRODUCTS
SUCH AS GASOLINE, HERBICIDE AND PESTICIDE
AOM
BRP

USE AND MAINTENANCE MANUAL
Page 10 of 13
®
(1)
(2)
(B)
(A)
(4)
3.1 INSPECTION OF PURCHASED PRODUCT
Inspect the spray gun before its use to check for damages caused by transportation or
improper storage. Make sure that all standard and optional components have been delivered.
3.2 INSTALLATION CONDITIONS
It is advisable to use dry compressed air to obtain the
best painting results.
Tomountthe hoses proceedasfollows (use the drawing
below):
+Connect the air inlet hose (RED hose) to the spray
gun 1/4” nipple (A). The compressed air must come
froma normalcompressorwith anoperatingpressure
of 4 bar (60 psi).
+Connect the paint inlet hose to the spray gun
connection (3).
+Select the most appropriate nozzle.
WARNING
Before you start using the equipment, make sure the
connectionsandhosesarein perfect working conditions,
that is without holes, bends or splits .
3.3 HOW TO USE THE SPRAYGUN
+Adjust the fan with the regulator knob (1) (if the knob
is opened the fan becomes wider, if the knob is
closedthefangetsnarrower).
+Adjust the fan position by rotating the air cap (B).
+Gradually open the fluid passage by turning the fluid
regulator knob (2) until the desired quantity is
obtained. Check the regulation on a smooth trial
surface until the desired fan width is obtained. FAN POSITION
CAP
(3)
AOM
BRP

USE AND MAINTENANCE MANUAL
Page 11 of 13
®
3.4 EQUIPMENT AND CONDITIONS NEEDED TO WORK
Painting operations MUST be carried out in an appropriate spray booth equipped with a
filtering system. Do not use the spray gun if the filtering system is not activated. Always wear
protection gloves, goggles, breathing filters with active carbon and adequate clothing for the
protection of the entire body.
3.5 SAFETY PROCEDURES DURING USE
TO USE the painting unit STRICTLYOBSERVEthe following precautions and safety criteria.
ASTURO ORIGINALI MAVES Spa declines every responsibility whatsoever in case the
user does not observe said precautions and safety criteria; furthermore, it is not responsible
for any kind of negligence when using the equipment.
WARNING
IAlways wear protective gloves, masks, breathing filters with activated carbon and
adequate clothing for the protection of the entire body when using the spray gun.
IThe spray gun is employed with paints and thinners which are highly inflammable,
therefore, use the spray gun in well ventilated areas and avoid any action which might
startafire (eg. smoking,hightemperatureslags or shavings,sparksorelectric elements).
ICHECKthechemical compatibility oftheproductson their technical safetycharts.Further
information on the materials which make up the spray gun are available, on request, at
ASTURO ORIGINALI MAVES Spa.
ITheuseofproducts which contain organicsolventsmightcause intoxication because of
the created toxic vapours.
IDO NOT USE the unit with food or medicines.
IDO NOT EXCEED the indicated maximum working pressure (see section 2.3).
IBEFORE starting on any dismantling, cleaning, maintenance or assembly operation
DISCHARGE the pressure in the hoses (see section 4.1).
INever aim the spray gun at anything other than the surface you intend to spray.
IMPORTANT
DO NOT USE the unit with HALOGENATED HYDROCARBON thinners (eg.
Ethylchloride, Trichloride, etc.) which might explode when in contact with
aluminum or galvanized parts.

USE AND MAINTENANCE MANUAL
Page 12 of 13
®
4.1 PRESSURE DISCHARGE PROCEDURES
When the spray gun is stopped to carry out maintenance operations or at the end of the work
session the operator must discharge the remaining pressure.
WARNING
THE PRODUCT IN THE FLEXIBLE HOSE IS STILL UNDER PRESSURE.
PROCEED AS FOLLOWS:
1) Shut off the spray gun air supply.
2) Take a metal bucket and by pressing the spray gun against its side discharge the residue
product by pressing the trigger.
3) Clean as described in the following paragraph.
4.2 ROUTINE MAINTENANCE
The routine maintenance of the BRP spray gun is simple and does not require special
operations because its components do not need to be lubricated. Clean the spray gun daily
oratthe endofeachworking sessionsothat product residue willnotdry out onitswalls, thus
guaranteeing long term efficiency.
CLEANING OPERATIONS:
Should the spray gun be connected to ASTURO K24 pumps, see par. 5.4 in the K24 use and
maintenance manual. Should the spray gun be connected to a different equipment, see the
relevant manual. Unscrew the cap ring and with the given wrench disassemble the nozzle.
Place everything in the thinner. Clean the head of the spray gun, the needle and the nozzle
withthegivenbrush. Assemble the spraygun,lubricatethe threaded parts withathinlayer of
oil and screw it tightly.
DO NOT USE POINTED METAL OBJECTS TO CLEAN CLOGGED PASSAGE HOLES.
THESE OPERATIONS WOULD DAMAGE THEM, REDUCING THEIR SPRAYING
QUALITY.
Wash the paint cup with thinner. In case industrial washers are used to clean the spray gun,
close the flow regulator knob and the needle adjustment knob tightly by turning them clockwise
in order to avoid thinner infiltrations which might, in time, damage the packings. Once in a while,
lubricate the threaded parts such as the aircap and the needle stroke adjustmentknob with a
thin layer of synthetic oil, in order to avoid seizing up caused by the effect of thinners on the
spray gun components.
THE LUBRICANTS USED MUST NOT CONTAIN SILICONE.
WARNING
IF THE NEED ARISES CALL THE A.O.M.- AMERICA CUSTOMER CARE TECHNICAL
SERVICE

USE AND MAINTENANCE MANUAL
Page 13 of 13
®
4.3 TROUBLESHOOTING
This chapter describes how to solve the most common problems which could affect the unit.
The problem is indicated by the following symbol: (6)
The possible cause is indicated by the following symbol: (ß)
The possible solution is indicated by the following symbol: (l)
6 THE SPRAY GUN SPRAYS INTERMITTENTLY ?
ß Spray nozzle is loose.
ß Worn needle packing.
ß Worn nozzle cone.
lTightenthenozzle.
lReplace the packing.
lReplace the nozzle.
6 UNEVEN JET ?
ß Worn or dirty cap air holes.
ß Worn or dirty nozzle.
lClean the spray gun components carefully.
lReplace damaged parts.
6 PAINT LEAKS OUT OF THE PACKING?
ß Worn packing.
lReplace the packing.
6 NOZZLE LEAKS WITHOUT PRESSING THE TRIGGER?
ß Needle and nozzle are dirty with dry paint
ß Worn needle and nozzle.
lCleanthe spray gunpartsvery carefully.
lReplace the needle and the nozzle.
6 AIR COMES OUT WHEN THE TRIGGER IS RELEASED?
ß The air valve rod does not slide.
ß The air valve body is dirty.
ß Air valve packing nut too tight
lLightly lubricate the components of the spray gun.
lClean with care.
lLoosen packing nut.
WARNING
If using a pump see pump use and maintenance manual.

WARRANTY
All ASTURO ORIGINALI MAVES Spa appliances are guaranteed for a period of 12 months
from the date written on the invoice, unless otherwise stated in writing. The warranty covers
all manufacturing faults and material defect. Replacements and repair operations are covered
only if carried out by our company and at our servicing shops.
The faulty parts must be sent FREIGHT FREE.
Once the components have been repaired they will be sent FREIGHT PAID to the customer.
The warranty does not cover our company personnel aid during installation or dismantling
operations.If for practical purposes one of our employee is sent to the premises, a charge
will be made for the time plus extra for travelling and expenses.
Our warranty does not cover direct or indirect damage, to people or property, caused by our
appliances and it does not cover repair operations carried out by the owner or by a third
party.
Thefollowingarenotcovered by our warranty:
+failure caused by incorrect use or assembly.
+failure caused by external agents.
+failure caused by lack of maintenance or negligence.
WARRANTY FORFEITURE:
If the form attached below is not completed and returned.
In case of delayed payment or other contract defaults.
All repair operations carried out under warranty do not interrupt its duration.
Whenever changes or repairs are carried out on our machinery without prior authorization
Whenever the unit seems tampered with, dismantled or previously repaired in unauthorized
workshops.
Whenever the serial number is damaged or removed.
When the damage is caused by improper use or functioning, or if the machine falls, is bumped
or by other causes of malfunctioning not due to normal working conditions
Alldisputes will besettledin thecourtof justiceofMilan (Italy).
NAME:
COMPANY:
ADDRESS:
V.A.T.NUMBER
UNITMODEL:
SERIALNUMBER:
DATE:
STAMPAND SIGNATURE:
Send this form fully completed (capital letters) to:
A.O.M.- AMERICA
54 S. Commerce Way, Suite 180
Bethlehem, PA 18017 USA

USE AND MAINTENANCE MANUAL
BRP Rev. 1
SPRAY GUN ASSEMBLY DRAWING
®
18
11
1210
13
15
17
16
23
12
10
11
13 14
1
3
2
4
AOM
19
BRP
567
89

BRP Rev. 1
USE AND MAINTENANCE MANUAL
SPRAY GUN COMPONENTS
Pos. CODE Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
23
24
25
...........
..........
16515A
19612A
16519A
...........
24087R
24039R
24034R
24058R
24060R
24056R
24062R
24535R
16570A
24055R
24052R
16530A
16591A
16582A
16592A
24092R
24097R
KIT
202XX Needle-nozzle-cap kit (replace xx with ∅) (Pos. 1-2-6)
18345A BRP packing and spring kit (Pos. 7-8-10x2-11x2-12x2-15-16-17)
302034 Stainless steel filter holder with filter C.P.paint 100 M FG 1/4 - M1/4
302090 Mini filter holder for laminar filter
16228A AIR CAP Ø0.8
16230A AIR CAP Ø1.0
16232A AIR CAP Ø1.2
16234A AIR CAP Ø1.4
16235A AIR CAP Ø1.5
16237A AIR CAP Ø1.7
16239A AIR CAP Ø1.9
16242A AIR CAP Ø2.2
16245A AIR CAP Ø2.5
16408A NOZZLE Ø0.8
16410A NOZZLE Ø1.0
16412A NOZZLE Ø1.2
16414A NOZZLE Ø1.4
16415A NOZZLE Ø1.5
16417A NOZZLE Ø1.7
16419A NOZZLE Ø1.9
16422A NOZZLE Ø2.2
16425A NOZZLE Ø2.5
16248A FLUIDADJUSTING Ø0.8
16250A FLUIDADJUSTING Ø1.0
16252A FLUIDADJUSTING Ø1.2
16254A FLUIDADJUSTING Ø1.4
16255A FLUIDADJUSTING Ø1.5
16257A FLUIDADJUSTING Ø1.7
16259A FLUIDADJUSTING Ø1.9
16262A FLUIDADJUSTING Ø2.2
16265A FLUIDADJUSTING Ø2.5
1
2
6
®
Air cap ring
BRP nozzle
BRP complete body
Trigger pin
New complete BRP fluid regulator
Fluid adjusting needle
Spring-pushing needle for pressure supply
Spring/knob plate
Needle adjusting stroke knob
3x7x0,5 (0.11x0.27x0.02) zinc washer
Air/needle valve packing
Air/needle valve packing spring
Nickeled air packing nut
3/8” fluid inlet nipples
Air valve spring
LEG/BRIair valverod
3030 viton O ring
Airvalvebody
Trigger pin screw
BRI/BBS complete pressure regulator
BRI nickeled trigger
Legend BRI/Legend wrench
mm 12x40x125 (0.46x1.55x4.86in.)
nylon cleaning brush
