Aosom B71-046 Installation guide

ASSEMBLY & INSTRUCTION MANUAL
READ AND SAVE THIS INSTRUCTIONS FOR FUTURE USE
INcef004V01_US
B71-046 B71-046V01

A1
C1
D1
B1 B1
A3
A2
E1
Warning: The manual contains very important safety information, please read it
carefully before assembling and keep it safe for future reference.
1) Carefully check the box for any damages. If damaged, please take a photo
for your record and contact our service team for help.
2) The workbench can be dangerous if it is not installed correctly. Fasten all
bolts, nuts, screws before using it.
3) Don’t overload product on the workbench, it is restricted to 2200
LBS(1000KG).
4)Use safety goggles to install the workbench.
5) When using the workbench, ensure all casters are locked to avoid any
mishaps. Unlocked casters can be very dangerous.
6) Keep away from children. This is not a toy and Children should not be
allowed to play on it.
7) Keep workbench away from water and moisture.
8) Please do not discard the box until after you have finished assembling the
workbench.

02
01
Tips:
1) Do not fasten all bolts and nuts ghtly, you may need to rework if you make a mistake.
2) We recommend 2 adults are required to complete the installaon
1. Fasten legs to the bamboo board.
A) Place the bamboo board on a clean surface
(floor). To protect the bamboo board, we
recommend you to use a soft cloth or box
on the floor.
B) Make sure the holes on legs and board are
aligned and on the same side. Refer to
below picture.
C) Use M8x16 hex bolt to fasten 2 legs to
bamboo board.

05
03
04
3. Fasten leg extensions to legs and adjust to required
height .
Use M10x60 hex bolt and M10 Big plas�c
nuts to fasten them.
5. Tighten all bolts and nuts, reverse the workbench, then Finish.

06

08
07
For workbench with drawer, the side board and rail is pre-installed at the produc�on factory.
For workbench with drawer, pls make sure the drawer is correctly installed,
do not place heavy tools or items inside, it may destroy the drawer.
Warning:
