AOX COMPAC Series User manual

USER’S MANUAL COMPAC SERIES
Our Showroom at
Blk 28, Sin Ming Lane #03-143
Midview City, S573972
Our Warehouse at
No 1, Sunview Road #07-17
Eco-Tech@Sunview, S627615
Call us at
[phone]
Our Service Centre at
Blk 26, Sin Ming Lane #03-122
Midview City, S573971
Follow us at
facebook.com/aoxwater
Visit us at
www.aox.com.sg
Voted No. 1 Brand
Multi-Award Winning Brand
Stay Healthy Choose AOX

THANK YOU FOR CHOOSING AOX
We are condent that the AOX-Compac HS will provide you with the highest quality of antioxidant alkaline water. This
unit is equipped with 4 stage lters for removing impurities, bacteria and viruses from your water. In addition, the
AOX-COMPAC HS can be paired with accessories for different functionality and usage. It is geared towards a
minimalistic concept, freeing up precious space in your kitchen.
Replacement of Filters
1. Please note that incoming water quality and usage may affect the lifespan of the AOX lters
2. Optimal Lifespan:
To ensure optimal antioxidant properties and alkalinity of the drinking water, it is recommended that you
change your lters on every 6 to 9 months or so. If the incoming water has more suspended particles, it may
‘choke” the lter(s) before the recommended date.
3. CAUTION:
DO NOT USE where the water is microbiologically unsafe or of unknown quality without adequate
disinfection.
How to Change Filters?
1. Close the inlet valve
2. Gently pull open the top cover and detach the inlet tube from the lters. (Photo A & B)
3. Remove the lters and t in a new set following the same sequence.
4. Close the cover
5.Turn on the inlet water valve
6.Turn on the water on the tap and ush out 10 litres of water
7.The dispenser is now ready
Photo A
Turn anti-clockwise
to remove the cover.
Tighten back the cover by
turning clockwise after
draining of water.
Photo F
Cover. Pull it off gently
from its magnetic housing
Filtration System
(Please use only microbiologically safe water or of known quality with adequate disinfection)
Diagram 1
Notes:
It is normal to experience a “popping” sound or to have lots of air bubbles (that may cause the water to look cloudy) when the lters are
new. This is due to the air trapped in the new lters.
If you nd some particles in the water, please do not be alarmed.The particles are tested by independent labs to be activated carbon or
alkaline minerals which is safe for consumption.The quality and taste of the water is dependent on the incoming water source and the
lter’s usage.
To ensure that you get optimal antioxidants and alkalinity, please follow the recommended lter change schedule.You may refer to the
date written on the sticker (pasted on the side of the dispenser) or when you hear the FCT (Filter Change Timer) beeping.
1 Micron Carbon
Block Filter
TAP
WATER
F12-U
AOX Antioxidant
Alkaline Minerals
Filter
F3-U
Post Activated
Carbon Filter
with KDF-55
F4-U
ALKALINE
WATER

Non-electrical Models
AOX-COMPAC is tted with a Variable Pressure Regulator (VPR). (Photo C)
To increase the pressure, use an item with a at surface, insert it into the VPR and turn it counter clockwise.To
reduce the pressure, turn it clockwise.
Note: During installation, our technician would have adjusted the water pressure to the optimal level. Refrain
from adjusting the pressure unnecessarily.
Adjusting the Water Pressure
Photo C
1
2
3
4
1.Water Outlet
2. Variable Pressure Regulator
3.Water Inlet
4. Filter Change Timer
COMPAC - TT Tap 1
COMPAC - TT Tap 2
AOX-Compac HS
AOX-Compac HS
AOX-Compac HS
TT Tap 1
TT Tap 2
COMPAC - SSF TAP
SSF

Hot or Cold Models
COMPAC - HRV
COMPAC - HRT
How to Use the 3-in-1 Tap?
AOX-Compac HS
AOX-Compac HS
Boiler UTS HRV Tap
Boiler UTS HRT Tap
1.Open valve in water line
2.Turn left faucet on (hold if necessary) to ll tank (about 1 minute).When tank is full, water will ow from faucet. (refer to
g 2). Once water start owing from the faucet, turn it off.
3. Plug the electrical cord of the boiler into a grounded 3-prong outlet
4.Turn on the button on the right (refer to g.3),then set the temperature to 98°/90°C.The temperature should be reached
in about 10 minutes.The green light indicates that the water is boiling, the red light indicates that it is heating.
5.As the water temperature can reach as high as 98°C, care must be taken to avoid scalding.
6.The tap is tted with a child-proof control knob which requires a pull and turn action to operate it (refer to g. 4).
Fig. 2
PULL
TURN
Fig. 3 Fig. 4
Notes:
It is normal to experience “popping” sound or to have lots of air bubble (that may cause the water to look cloudy) when
the lters are new. This is due to the air trapped in the new lters.
If you nd some particles in the water, please do not be alarmed. The particles are tested by independent labs to be
activated carbon or alkaline minerals which is safe for consumption.The quality and taste of the water is dependent on the
incoming water source and the lter’s usage.
To ensure that you get optimal antioxidants and alkalinity, please follow the recommended lter change schedule. You
may refer to the date written on the sticker (pasted on the side of the dispenser) or when you hear the FCT (Filter Change
Timer) beeping.
