Apache AL13 User manual

AL13 Laminator Operation Manual

Product Overview:
Thank you for your Apache purchase. All Apache products are designed to provide excellent
function, high quality, ease of use and stylish appearance. The Apache AL13 laminator is an A3
class laminator which is capable of laminating items up to 13" wide, specifically standard 8 ½ x
11” sheet of paper sideways for quicker lamination. The AL13 is a professional grade laminator
which is designed with premium grade heating elements and motor and has 2 silicone rollers.
Additionally, the AL13 has the ability to laminate in cold mode. The AL13 is designed for long
term, heavy duty use. This laminator can help protect your documents and photos from wear,
tear, liquids, and humidity, along with preserve and enhance your presentation documents.
Key Features:
Professional Grade Motor and Heating Element
Red and Green LED Indicators
13" Laminating Width
Hot and Cold Laminating Mode
Specifications:
Model:
AL13
Power:
365W
Voltage:
110-120V AC, 60Hz
Working Temperature
Range:
Room Temperature (Cold )
212° (Hot)
Thickness Range:
Min: 150 micron
Max: 200 micron
Speed:
220mm per Minute
Pre-Heat Time:
3-5 minutes
Warranty:
1 Year Manufacturers
Dimensions:
L 17.25" x D 5.7" x H 2.5"

Operation Instructions:
1. Plug in the power cord. For cold lamination, push the switch to the cold position. For hot
lamination, push the switch to the hot position.
2. For cold laminating, the green LED light will come on, indicating the unit is ready to
begin cold laminating.
3. For hot laminating, preheat time is approximately 3-5 minutes. While the unit is
preheating, the green LED will be off. Once heated, the ready light will turn green and
you can begin hot laminating your items.
4. Place the item you wish to laminate in a laminating pouch. Insert the laminating pouch
pre-sealed end first into the laminating machine. Be sure to align your item properly and
once inserted, the rollers will start the laminating process.
5. The laminating pouch will exit from the rear. When you are finished laminating, turn the
power switch to the off position then unplug the power cord.
ATTENTION:
This laminator can reach high temperatures. Please operate in an open, dry place away from
temperature sensitive materials. Do not place anything on or near machine when in operation.
After hot laminating, please set machine to cold position and allow to run for 2 minutes to allow
the rollers to cool. Always unplug unit before servicing. To clean your rollers use laminator
roller cleaner pads available from your local office supply store. Please follow instructions
included with cleaner pads. The Limited Liability Warranty applies to laminator only. Apache
Laminators is not responsible for damage to any other personal property.
© 2009 Apache Laminators
Revision: 2.4.5 Revision Date: 2/11
