Apantac DP-1x2-II User manual

2 Port DisplayPort
SST DA/MST Hub
USER MANUAL
DP-1x2-II
USER MANUAL v.1.3
Overview
DP-1x2-II is a high-speed 2 port DisplayPort splitter/distribution amplifier targeted for
audio/video de-multiplexing and in distribution for applications such as notebook
computers, docking stations, video hub, 4K2K TV/displays, daisy chainable monitors,
digital signages and more. It consists of one DisplayPort input and two dual mode
output ports, that are configurable as either DisplayPort or HDMI.
Package Contents
1 x DP-1x2-II
1 x User manual
1 x Power adapter DC12V with lock
4 x Foot pads
Features
Support DisplayPort 1.2a
Support DisplayPort HDCP1.3
Support Link rate HBR2/HBR/RBR.
Support SST and MST mode.
Compliant with DisplayPort 1, 2, or 4 lanes.
Specifications
Function DP-1x2-II
DisplayPort Input
1
DisplayPort Output
2
Compliance
DisplayPort 1.2a / HDCP 1.3
Max. Resolution
4Kx2K@60
Max. Data Rate
21.6Gbps
Link Rate
HBR2/HBR/RBR
DIP SWITCH
2pin: SST/MST Selection
RESET Key
TACT SW x 1
POWER Display
Green LED x 1
Operating Temperature
0° to 40°C
Storage Temperature
-20° to 60°C
Humidity
0 - 80% RH, Non-Condensing
Power Supply
12V/1A DC
Weight
310g
Dimensions (LxWxH)
156x83x25mm

FRONT VIEW
1. POWER JACK 12V DC
2. DisplayPort IN
REAR VIEW
1. DisplayPort OUT
2. Reset Key
3. MODE Key
4. POWER LED
DIP Switch Setting
PIN1
MODE
OFF
MST
ON
SST
SST: All the output screen is the same single.
MST: Extend the single video source to all outputs.
※At MST mode the highest output resolution will decrease because the total bandwidth
of 21.6 Gbps is shared among all monitors.
※When the mode select is ready, please restart the power or pressing Reset Key

Installation
1. Connect the DP cable with the PC and the <IN> port
2. Connect the DP cable with the monitor and the <OUT> ports
3. Connect the power cord and turn on the DP-1x2-II
4. Turn on the PC and monitor
EDID
DisplayPort splitters do not have capability of storing the EDID, so EDID is
passed from the display to the source. When there are two displays, it
will use whichever the EDID is sent first, it will use that EDID. If you
remove the displays from the splitter, the splitter will keep the last EDID
until power cycle.
Compatibility Tests
Due to the different interpretations of DisplayPort modes by different major graphics
accelerator companies, it is important to provide detail compatibility test data as follows,
Test Equipment
Graphics Card 1
GTX 1050Ti (NVIDIA, OS: WIN 10)
Graphics Card 2
Radeon RX560 (AMD: OS: WIN 7)
Display 1
Dell P2415Q
Display 2
ASUS PB287
Display 3
AOC U2849VF
Display 4
SAMSUNG LU28D590S
DisplayPort cable
LPC-1603 2m
1. SST connection diagram
2. SST tests
DP-1x2-II (SST MODE)
Resolutions/GFX card
OUTPUT1
OUTPUT2
OUTPUT1
OUTPUT2
GTX1050Ti
P2415Q
PB287
PB287
P2415Q
4K@60Hz
Pass
Pass
Pass
Pass
4K@30Hz
Pass
Pass
Pass
Pass
1920x1080P@60Hz
Pass
Pass
Pass
Pass
Radeon RX560
LU28D590S
U2849VF
U2849VF
LU28D590S
4K@60Hz
Pass
Pass
Pass
Pass
4K@30Hz
Pass
Pass
Pass
Pass
1920x1080P@60Hz
Pass
Pass
Pass
Pass
3. MST connection diagram
4. MST testing
DP-1x2-II (MST MODE)
Resolutions/GFX card
OUTPUT1
OUTPUT2
OUTPUT1
OUTPUT2
GTX1050Ti
P2415Q
PB287
U2849VF
LU28D590S
4K@30Hz
4K@30Hz
4K@30Hz
4K@30Hz
LU28D590S
P2415Q
PB287
U2849VF
4K@30Hz
4K@30Hz
4K@30Hz
4K@30Hz
Radeon RX560
P2415Q
PB287
U2849VF
LU28D590S
No output
No output
No output
No output
Note: When Radeon RX560 in MST mode, there is no output
5. DP++ testing
INPUT
Not supported
Output
Not supported
