PAGING MICROPHONE
Introduction
Please read this manual before using the product in order to give
you the necessary product and installation instructions to assure a
seamless installation and non-compromised overall sound quality
and functionality.
Thanks for purchasing our DIMIC1/12(S) Digital paging station
(Digital paging station slave unit).
DIMIC1/12(S) is a versatile tabletop microphone (or slave unit), easy
to configure via the host’s graphical user interface. You can even
incorporate the unit(s) in your work surface, or mount the unit(s) on
the wall.
Affordable, versatile, but by no means a compromise on sound
quality or on functionality – Typically Apart!

Instruction manualDIMIC1/12(S)
5
Safety precautions
• Keep this manual for future reference.
• Take care of your connection wires: they should be free of
damage. Damaged wires may result in poor sound quality or
malfunctions and can cause damage to the installation.
• Only use accessories specified by the manufacturer.
• Make sure the wall construction can support the units’ weight.
• No mains power shall be connected to the device, doing so will
damage the unit.
• This device should only be serviced by qualified personnel. If not
serviced by qualified personnel, warranty may be void.
• Use cables with clear color indication and maintain polarity
throughout the whole system.
• Please check the packing for any kind of damage upon
reception of the goods. If the packing is damaged, please
contact your dealer before opening it.
• Please note that this unit must be protected from moisture and
is meant for indoor use only.

6
PAGING MICROPHONE
Features and benefits
• Inconspicuous and elegant design
• Remarkable sound quality
• Flexible microphone stem (DIMIC1/12)
• Exchangeable paper inserts (labels next to knobs)
• Unidirectional condenser microphone (DIMIC1/12)
• Speech-optimized sound processing (DIMIC1/12) with speech
optimized EQ, filter and limiter
• 12 selection buttons and status LEDs (DIMIC12/12S)
• Push-to-talk button and multicolor paging status LED
• All zone selection knob (DIMIC1)
• Expandable up to 64 zones, 64 presets and up to 120 mics!
• Universal configuration of push buttons, making it easy to
select zones, zone groups or to perform additional tasks
such as entrance control, lighting control, home or office
automation…depending on the master unit’s capabilities
• Virtually endless applications
• Wall mounting possible
• Flush mounting possible
• Output volume control
• Automatic addressing

Instruction manualDIMIC1/12(S)
7
• Balanced line-out allows long cables (DIMIC1/12)
• Easy connection using standardized CAT5 cables
• External power supply possible
• Indoor use only
Connecting the unit
Consult the manual of your master unit before connecting the
microphone. Use a standard CAT5 cable to connect the microphone
to the main unit. Normally, the main unit will also provide the
necessary power to the microphone. Consult the manual of your
main unit for more details.
DIMIC12S, the slave unit, cannot be used without the DIMIC12
digital paging station. The purpose of the slave unit is to expand the
number of zones and/or programmable function keys on the paging
station. The slave unit is connected to the paging station using the
flat cable supplied with the slave unit. It is possible to daisy chain up
to 7 slave units.
The opening for the flat cable is at the right side of the DIMIC12
unit. Just pop off the small lid and connect the flat cable. Connect
the other end to the left side of the slave unit and so on…

8
PAGING MICROPHONE
Front layout DIMIC12
Knobs 1 - 12 are for zone selection or programmable functions.
The amber LEDs next to the knobs will light up when the knobs are
pushed. The behavior of the LEDs and knobs depend on what has
been programmed in the master unit. The knobs can be configured
as latching or non-latching knobs, zone selection knobs, function
knobs or preset recall knobs.

Instruction manualDIMIC1/12(S)
9
Knobs 13 and 14 are the actual paging buttons: when pushing
knob 13, all pageable zones will be paged. When pushing knob 14,
all selected and pageable zones will be paged. The corresponding
selection LEDs will light up to confirm the selection.
The ready-busy LED is green when the unit is ready and when
paging is allowed. It turns orange when a paging request is sent
to the master unit and turns red when paging is forbidden due
to priority restrictions. During the time the chime is sounding, the
ready-busy LED will stay orange. When the chime has finished
playing, the LED will turn green to indicate that paging is possible.
The amber selection LEDs of the selected zones will flash during
paging.
Multifunction status LED (DIMIC12 only):
GREEN ORANGE RED
Unit is ready Paging requested Paging forbidden
Paging in progress
(zone LEDs will flash)
Chime is sounding

10
PAGING MICROPHONE
Knobs 1 – 12 are for zone selection or programmable functions.
The amber LEDs next to the knobs will light up when the knobs are
pushed. The behavior of the LEDs and knobs depend on what has
been programmed in the master unit. The knobs can be configured
as latching or non-latching knobs, zone selection knobs, function
knobs or preset recall knobs.
Front layout DIMIC12S

Instruction manualDIMIC1/12(S)
11
“Slave to paging station” interconnection flatcable,
supplied with the DIMIC12S.
The holes for wall mounting are spaced 54 mm apart
horizontally, and 82 mm vertically, heart to heart.
Rear panel
Holes for wall mounting the unit(s)
Bottom view
The slave units are supplied with metal brackets, which allow you to
mechanically attach the units to each other
Combining / expanding the unit

12
PAGING MICROPHONE
1. Output level adjustment: turn the potmeter to adjust the
output level
2. Output link: RJ45 connector. Connect multiple DIMIC1/12(S)
units in a daisy chain. The maximum number of units depends
on the capabilities of the master unit. Output (link) and input
are internally hardwired to each other.
3. Input: RJ45 connector: connect the DIMIC12 to the master
unit using a standard CAT5 cable.
4. 24 VDC jack: connect an additional DC adapter here if the
master unit is unable to supply the power for the required
number of microphones. Consult the manual of your master
unit for more details.
Please note that the combination of multiple mics and excessive
CAT5 cable length will cause a substantial voltage drop on the
CAT5 cable. In case of doubt, use a DC adapter as power source for
the microphone/slave.

Instruction manualDIMIC1/12(S)
13
DIMIC1 has no zone selection knobs. Only the push-to-talk button
is present. Configuration and default functionality depends on the
master unit’s possibilities. Ready-busy has the same functions as
DIMIC12.

14
PAGING MICROPHONE
Using the DIMIC1/12(S) for the first time
Default settings: out of the box, the DIMIC12 is set up as a 4-zone
paging mic. Knobs 1 to 4 are configured as zone 1 to 4 selection
knobs. Knobs 5 – 12 have no function (yet) and must be configured
via the user interface of the master unit. The slave unit has no
default settings and must be configured before use. Knob 13,
marked “all zones”, functions as an all zone paging knob. Knob 14,
marked “selective” functions as a push-to-talk button.
LED messages: during power on, the DIMIC12(S) LEDs light up 5
times from bottom to top, left and right rows simultaneously, to
indicate that the unit is performing a diagnostic self-check.
When the LEDs light up going up and down, left and right rows in
opposite directions, the microphone is requesting an address from
the master unit.
Confirm the request by pressing the “all zones” or “selective”
button. The LEDs will stop blinking to indicate that the unit has
been accepted by the master unit. The address is permanently
stored in memory and can only be erased via the user interface of
the master unit.
The behavior of the 12 knobs can be configured in the user
interface of the master unit. It is possible to make the knobs work
as latching or non-latching knobs, or to assign a special function, a
preset containing preselected zones…
By default, the zone selection knobs work like this: when a zone is
selected, the corresponding LED will light up. When the selected
zone is being paged, the LED will blink. When paging is finished,
the LED will go out and the unit is ready for a new selection. You

Instruction manualDIMIC1/12(S)
15
Attention!
can also program the unit, so that the selected zone LEDs stay
lit after paging. Consult the manual of the master unit for more
details.
By using automated addressing, the master unit will recognize
the microphone/slave, and will automatically recall the settings
and functions of the push buttons after power up. When a new
microphone is added to the system, you must configure the newly
added microphone via the user interface of the main unit.
Do not connect a slave unit to the microphone unit when powered
on. The slave unit will not be recognized and will not function when
hot plugged!!!
When a communication error occurs between microphone and
master unit, or between microphone and slave unit, the LEDs of the
microphone/slave will start to scroll continuously from bottom to
top, left and right simultaneously, to indicate that communication
has failed. Check all connections as well as the cycle power of the
main unit and microphone/slave to restore normal functionality.
DIMIC1/12(S) cannot function unless properly connected to a
compatible master unit!
Do not connect the microphone to a computer or other network.
This will cause malfunctions and may cause damage to your
network and/or microphone. You must connect the microphone to
the master unit via the CAT5 cable.

16
PAGING MICROPHONE
RJ45 cable connections:
Pin 1: Audio + (balanced)
Pin 2: Audio – (balanced)
Pin 3: GROUND
Pin 4: not used
Pin 5: not used
Pin 6: 24 VDC power supply (max. 75 mA per mic or slave)
Pin 7: RS485
Pin 8: RS485

Instruction manualDIMIC1/12(S)
17
RJ45 standard wiring:

18
PAGING MICROPHONE
Specifications
Dimensions base (w x d x h) 110 x 240 x 58 mm
Cut-out dimensions 85 x 230 mm
Mic stem length including mic
and windscreen (DIMIC1/12)
395 mm
Weight DIMIC1 600 g
Weight DIMIC12 650 g
Weight DIMIC12S 350 g
Power supply 12 – 24 VDC/75 mA max
Nominal sensitivity (DIMIC1/12) 85 dB SPL
Maximum sound pressure level
(DIMIC1/12)
>110 dB SPL
Nominal output level
(DIMIC1/12)
775 mV
THD (DIMIC1/12) typical <0.5%
Frequency response -3 dB
(DIMIC1/12)
220 – 20000 Hz (speech filter)
Lo-cut (DIMIC1/12) 220 Hz, 6 dB/oct
Accessories Mounting brackets (Slave units
only), link cable (Slave units
only), manual, CAT5 cable
5m, microphone (DIMIC1/12),
windscreen (DIMIC1/12)

developed
by
Audioprof nv
Industriepark Brechtsebaan 8 bus 1
2900 Schoten - Belgium
Company names, product names and trademarks are property of their
respective owners.
