APEC ULTRA REVERSE OSMOSIS SYSTEM Quick start guide

ULTRA REVERSE OSMOSIS SYSTEM
INSTALLATION INSTRUCTION
AND OWNER’S MANUAL
Free Drinking Water .Com

1
Thank you for choosing APEC Reverse Osmosis systems. You now own the finest
reverse osmosis system in America!
Please read and become familiar with the instructions before
proceeding with the installation.
Before Installation:
Inspect the system:
Please take the system and all the components out of box. Inspect the system and
all the connection fittings carefully, making sure nothing was damaged during
shipping. If any part is cracked or broken, please do not proceed with the
installation and contact APEC or your distributor for an exchange or diagnosis.
Operating Parameter
Operating pressure: 100 psi maximum
Feed water temperature: 40-100 degree F (4-37 degree C)
Do not connect or run HOT water through this system.
Basic Terms
GPD = Gallons Per Day (flow rate)
PSI = Pounds Per Square Inch (pressure)
TDS = Total Dissolved Solids (contaminants)
PPM = Parts Per Million (unit used to measure TDS level)
TDS Meter = A digital meter for measuring the TDS level in the water
Copyright:
This manual is copyrighted by APEC Inc. Under the copyright laws, this manual may not
be reproduced in any form, in whole or part, without the prior written consent of APEC Inc.

2
Part I. HOOK UP THE RO SYSTEM TO YOUR HOME FAUCET
RO hook up: Remove your faucet’s aerator (if there is one). Hook up the
RO system’s faucet Adapter to your faucet (see Figure A). If the connection
does not match, try using the other Valve Adapters provided.
Figure A
A. This is the Pure Water Outlet Line. B. Please hook up faucet adapter
Please remove the Red Cap from to your kitchen faucet aerator.
The end of the tubing.
Figure B
1. Feed water: Turn the faucet on to FULL to supply maximum water pressure
to the RO system. Simply pull out the knob on the diverter head to direct the
water into the RO System(see Figure B). If input water is very cold, you can
adjust the faucet to supply luke warm water (NO hot water please!). Strong
input water pressure and warm water temperature will help increase output
flow rate.
2. Output water: Remove the red cap from end of the pure water output
tubing, place the tubing in your water container to catch the pure water.
3. Brine water: Brine (waste) water will drain through the brine outlet on the
faucet adapter (all reverse osmosis systems must generate brine water to make
pure water).

3
4. Flushing system: Let the RO run for 10-15 minutes to flush out the new
Membrane – discard the output water during the flush. When done flushing,
the fresh pure water is now ready for your enjoyment!
Part II. MAINTENANCE – FILTER CHANGE
* Quick Connect Guide:
Connect Tubing
Press Down on collet To Pull Out Tubing
Figure C
Filter Ports: All filters have Quick-Connect ports. Remove and connect
tubing to filter ports as shown in the above “Quick-Connect
Guide” diagram.
Remove Filter: Please change one filter at a time to avoid mixing up the filters.
New filters come with 2” protective plugs on each end. You can
take them out by pressing on the collet ring with one finger and
use a pair of pliers to pull out the protective tubing (see
Figure.C).

4
Stage-1: Sediment Filter (Manufacturer Part# K2505 filter)
Change every 6 months or 600-800 gal pure water used:
Figure D
(Back View Of System)
The Stage-1 Sediment filter is tucked behind the membrane housing. For
ease of access, pull and lift the 2nd stage filter to the top position. Then, do
the following:
Step 1. Disconnect tubing from Point D & Point E(see “Quick-Connect”
diagram). Discard used filter.
Step 2. Snap on the new filter onto the 2 holding clips. Make sure the Flow
direction “arrow ” on the filter is pointing toward the right direction
(see Figure D). Re-connect tubing to both ends of the new filter.

5
Stage-2 Pre-Carbon Filter (Manufacturer Part# K2533 filter)
Change every 6 months or 600-800 gal pure water used:
Figure E
(Back View Of System)
The Stage-2 Pre-Carbon filter is located between Stage-1 and Stage-4 filters (see
Figure E). Locate it, and follow these steps:
Step 1. Disconnect tubing from Point F& Point G (see “Quick-Connect”
diagram). Discard used Filter.
Step 2. Snap on the new filter onto the 2 holding clips. Make sure the Flow
Direction “Arrow ” on the filter is pointing towards the left direction.
(see Figure E). Reconnect tubing to both end of the new filter.

6
Stage-3 Membrane (Manufacturer Part# Filmtec TW30-1812-
75) Change every 2-5 years:
If Stage 1 & 2 pre-filters are changed regularly, the Stage-3 Membrane can last 2-
5 years depending on your input water’s quality. The Membrane needs replacing
when: The TDS (total dissolved solids) level in the pure water starts to increase
(detected by a TDS meter from APEC), or when the water taste quality starts to
decline. Replace the Membrane as follows:
1. Locate the Membrane-Housing (with “Filmtec Membrane” label on it.)
2. Disconnect tubing from the Membrane-Housing Cap. Remove membrane-
housing cap by turning it counter-clockwise. Pull out the old membrane using a
plier. Then insert the new membrane into the housing. Make sure the end with
“2 small black rings” goes in first as shown below. (see Figure F).
3. Close the cap on membrane-housing. Reconnect tubing to the cap. Let RO
run for 10-15 minutes to flush out the new membrane – discard the
output water. When done flushing, the pure water is ready for use.
Figure F
(Front View Of System)

7
Stage-4 Post-Carbon Filter (Manufacturer Part# K2533 filter) Change
every 2-5 years:
Figure G
Figure H
Front View Of System
Follow the same procedures as for changing the Stage-2 carbon filter. They are
identical 10” carbon filters.
To remove the Pure water output line, first use a pair of pliers and remove the
tubing lock (red clip) from Point K. See Figure G.
Use a flat head screwdriver to push and hold the collet ring into the stage 4 filter.
Then pull out the pure water line. Discard the old filter and reconnect pure water
line to new filter. Make sure the Flow direction “arrow” on the filter is pointing
towards the right direction. See Figure H.

8
RO-Ctop Pure Water Production Rate
Input Water Pressure Time to fill 8 oz cup Time to fill 1 gallon jug Gallons Per Day
60 psi
60 seconds 16 minutes 90 gpd
50 psi 72 seconds 19.2 minutes 75 gpd
40 psi 90 seconds 24 minutes 60 gpd
30 psi 120 seconds 32 minutes 45 gpd
20 psi 180 seconds 48 minutes 30 gpd
* Production rate is based on input water temperature of 25 C (77 F).
The RO-Ctop runs solely on the input water pressure from your water pipe line.
The speed in which the system generates pure water will depend on the water
pressure that is flowing into the system. The RO-Ctop operates more efficiently at
higher input water pressures, and the increased pressure helps the system to
produce more pure water with correspondingly less brine water. Lower input
water pressure has the opposite effect and will reduce water production while
increasing brine water discharge.
The chart above shows the strong effect water pressure has on the pure water
production rate of the system. A water pressure gauge (sold separately) will give
you an accurate measure of your incoming water pressure. You can also use the
pure water production rate of the RO-Ctop as a simple guide. For example, it
should take approximately 60 seconds to fill an 8 oz cup at 60 psi, which is a
good pressure and flow rate for the system. For very low water pressure, an
optional booster pump (sold separately) can be added to the RO-Ctop to
increase the output rate of the system.
* * * End of Owner’s Manual * * *

9
WARRANTY POLICY
For a period of one year from the date of original purchase, APEC will replace any
part of the reverse osmosis system which APEC finds to be defective in operation
due to faulty materials or workmanship with the exception of the replaceable filters
and membrane which shall be prorated. The customer pays only for freight and
any local labor charges. Replaceable filters and membrane shall be changed and
maintained on a regular basis for this warranty to be valid. Service schedule
depends on local input water quality.
GENERAL CONDITIONS
Damage to any part of this reverse osmosis system because of misuse,
misapplication, negligence, alteration, accident, installation or operation contrary
to our instructions, incompatibility with accessories not installed by APEC, or
damage caused by freezing, flood, fire, or Act of God, is not covered by this
warranty. In all such cases, regular charges will apply. This limited warranty does
not include service to diagnose a claimed malfunction in this unit. This warranty is
void if unit is not operated under normal municipal water conditions which the
particular model is intended to be used on.
We assume no warranty liability in connection with this reverse osmosis system
other than specified herein. This warranty is in lieu of all other warranties,
expressed or implied, including warranties of fitness for a particular purpose. We
do not authorize any person or representative to assume for us any other
obligations on the sale of this reverse osmosis system. This warranty becomes
effective when the system is installed correctly and successfully. Behind this product
are years of research, design, and production skills. This reverse osmosis unit has
been carefully tested and approved at our factory. Through this warranty we are
demonstrating our confidence in APEC equipments.
Even though the Ultra Reverse Osmosis systems have extremely high endurance for
operating conditions such as pH, maximum TDS, temperature, and optimum water
pressure, we can only offer full warranty based on the criteria of Standard
Operating Conditions as follows. These conditions must be met for warranty to be
valid.
Water Pressure pH Range Max. TDS Water Temperature
Standard System 40-95 psi 2-11 2000 ppm 40-120 F
Permeate Low Pressure System 30-95 psi 2-11 2000 ppm 40-120 F
Booster Pumped System 0 -30 psi 2-11 2000 ppm 40-120 F
