Apex Digital GD-90C User manual

IMPORTANT
Insert the battery into the quadcopter and connect the
plug. The two indicators will begin flashing. Place the
quadcopter on a flat surface.
Important: Be sure the surface is flat and level. The
quadcopter needs to calibrate it’s orientation.
PLEASE PRACTICE SIMULATEDFLIGHT BEFORE ACTUAL FLYING
Before you are familiar with the unit, please don't pilot it . Read the instruction carefully to get
familiar with the direction controls.
1. Checking that propellers are securely attached to the motors. Pull the throttle down to prevent takeoff.
2. Place quadcopter in a clear open field and point the tail towards yourself.
3. Practice operating the control sticks (as shown below), and repeat practicing “Throttle
high/low”, “ Left/right ”, “Forward/backward”, and “bank left/right”.
4.Strong impacts can jam the motors, using a long flat nose plier to unjam to rotor.
5.The simulation flight practice is very important, please keep practicing until you are comfortable with the controls.
After turn on the quadcopter
the LED indicators keep
flashing but the quadcopter
does not respond.
Transmitter and receiver
fail pairing
• Sync the remote control
and copter (refer to P.7)
• Fully charge the battery
1.The blade isn’t fully installed
2.Rotor blade deformation
3.Rotor blade not match code
• Change blade
• Correct the level refer to P6
• Replace the main wing
• Replace the main motor
The quadcopter still keeps
turning after trimming the
rudder trim, or inconsistent
speed during left/right turns.
1. This product is only suitable for users overthe age of 8. Piloting this quadcopter will be dificult at the
beginning. We recommend be occampanied by an experienced pilot at first.
2. This product is designed with high-tech electronics and mechanical parts. Do not fly near people.
Improper operation can result in injury or property damage. We will not accept any responsibility for
this.
3. We will not take any responsibilty for accidents during the operation of this device.
4. Contact cutomer service for help if you have any problems with the device.
1.Checking the surroundings before flying.
2.Do not let the plane fly out of sight when flying.
3.Do not let the child play alone, play together with adult.
4.Please make sure, there is no other player use the same frequency at the same area.
Do not fly in these areas.
Cautions: QUADCOPTER COMPONENTS
PACKAGE CONTENTS REMOTE CONTROL FUNCTIONS
The propeller system is a precision instrument that may nee d to be repaired or r eplaceedfrom
time to time f or optimal flight function. Crash landing fro m high-speed ae rial flights maycause
damage to propeller blades.
1.The aircraft has four blades, two white colors on front, and two black colors on back (see the
diagram below).
2.When replacing the propeller blades, make sure to match both the color of the blade and the
indication letter on the blade.
3.Replace broken blades with the correct blade.
Charge with our dedicated charger.
RECHARGEABLE BATTERY:
This Quadcopter uses a Li-Poly rechargeable battery.If battery no longer stays charged,dispose
of battery properly according to local disposal requirements.
CONTROLLER BATTERIES:
Remote control requires 2”AAA”batteries (not included).Please read the important battery safety
warning below.
●Do not mix alkaline,standard (carbon-zinc) and rechargeable betteries (Nickel Metal Hydride).
●Do not mix old and new batteries.
●Non-rechargeable batteries are not to be recharged.
●Rechargeble batteries are to be removed from the item before being charged (if removable).
●Rechargeble batteries are only to be charged under adult supervision.
●Exhausted batteries should be removed immediately and must be recycled or disposed of
properly according to state or local government ordinances and reulations.
●The supply terminals are not to be short-circuited.
●Only batteries of the same or equivalent type as recommended are to be used.
●Batteries are to be inserted with the correct polarity (see inside booklet for diagram).
●Do not dispose batteries in a fire-batteries may leak or explode.
BATTERY WARNINGS
The LED will be on continuously while the quadcopter is on. When it is low on
power the indicator will blink. Please land the quadcopter.
SYNCING THE REMOTE CONTROL & QUADCOPTER
STEP 1
STEP 2
FLIGHT ADJUSTMENT AND SETTING
CAUTION
CAUTION
FLIGHT ADJUSTMENT AND NOTICE FOR BEGINN E RS
Check if the screws and blades are firmly tightened
Check if t he transmitter and h elicoptera re fully charged.
Make su re that n o peopleor obstructions are in thevicinity.
You must first practice hovering to fly safely, this is a basi c
flight action(meaning keep the helicopter in mid air i n a fixed position)
Please stand approximately 6ft diagonally behind the helicopter.
1. The throttle is on the left hand, push the throttle a little up to raise the copter to
your line of sight then pull down a little to let the quadcopter slowly down to the
floor.Repeat until you can easily and quickly control the altitude.
2.Hovering flight practic: Raise the quadcopter to a certain height then hover at
that altitude.
3.Try increasing and decreasing the altitude quickly this time while still
maintaining control.
1. Use the right stick to practice moving forward and backwards.
2. Use the left and right stick to practice turns and banking.
Slowly raise the throttle stick and observe just as the helicopter lifts off the ground if it
leans in a direction. Youcan use the trim to correct this action.
1. Adjustmentof Left/Right trim
Just before the quadcopter lifts-off, the nose leans left/right.
When it leans right adjust the trim to the left side.
When it leans left adjust the trim to the right side.
2. Adjustment of Forwards/Backwards trim
Just before the quadcopter lifts-off, the nose leans forward/backwards.
When it leans forwards adjust the trim down.
When it leans backwards adjust the trim up.
3. Adjustmentof Roll trim
Just before the quadcopter lifts-off, the body rolls left/right.
When it rolls right adjust the trim to the left side.
When it rolls left adjust the trim to the right side.
If a MicroSD card is not installed the
LEDs will flash 5 times. When a
MicroSD card is intalled the leds will
stay illuminated.
Micro SD card sold seperately.
8G（FAT&FAT32format）
INSTALLA MICRO SD CARD
CAMERA / VIDEO OPERATION
The remote control can control the quadcopter’s camera.
Photo Mode: Press the camera button to take a picture. The LED
on the quadcopter will flash once to confirm it took a picture.
Video Mode: Press the video button to start recording a video.
The LED on the quadcopter will blink slowly while it is recording.
Press the video button again to stop recording.
Toaccess the photos and video you will need a MicroSD card
reader.
The maximum capacity of MicroSD card is 64G(FAT format)
TROUBLE SHOOTING DURING FLIGHT
Solution
No response after the
battery is connectedto
the quadcopter.
Main rotor continues to
spin after landing
Helicopter rotor spins but
unable to take off.
The helicopter still keeps
turning after rudder triming
or inconsistent speed during
left/right pirouette.
1. The blades haven’t been
installed in the right place.
2. Rotor blade deformation
3. Didn’t calibrate the flight.
1. Replace the main wing
Replace the main motor
2. Change blade
3. Correct the level refer to P6
Throttle stick not on the
lowest position
1.Check whether the blade
assembled correctly or not.
2.Helicopter battery depleted.
Make sure the Throttle stick is
on the lowest position
Check whether it is low power Charging the helicopter
The quadcopter shifts
forwards/ backwards.
The trim is not even. • Trim the elevator back to center.
• Restart the remote control.
1.Rotor blade turns off
2.Rotor blade deformation
1.Change replacement rotors
2.Tighten the Rotors
Can not fly the helicopter
after crashing
QUADCOPTER COMPONENTS
FLIGHT CHARGING
CONTROLLER INSTRUCTION
CAUTIONS
FLIGHT ADJUSTMENT AND SETTINGS
INSTALLINGA MICROSD CARD
CAMERA OPERATION
SYNCING THE REMOTE CONTROL
AND THE QUADCOPTER
REPLACING THE PROPELLER BLADE
GD-90C
High-voltage power lines Rainstorm and thunderstorm
Near the railway Roads and nearby places Forests and rivers High winds
The places of Crowds
Rotate
Direction
7
8
Camera
Camera board
9
10
2
2
2
2
Positive rotor blades
Reverse rotor blades
Positive rotor
Reverse rotor
Battery charge
As sh own i n the fi gur e, pus h the ro cke r of the r emot e
co ntro l to the p osi tion i n the lo wer r ight c orn er at th e
sam e tim e. At th is tim e the i ndic ator l igh t of the a ircr aft
fl ashe s and th en lo osen s the re mot e cont rol, a nd th e
ind ica tor li ght is a lway s on an d the ca libr ati on is co mpl ete.
WARNING
Whe n not i n use fo r a long t ime , plea se tak e out th e rem ote
co ntro l batt ery a nd kee p it pro per ly.
Not e: If th e rem ote co ntro l bat ter y is not r emov ed, th e lon g
sto rag e will c ause t he le akag e of the b att ery a nd dam age
the r emo te con trol d evi ce.
Throttle
1.On/off
(1)On(After put on the battery, R/C is in sleep model,indicator extinguish when off)
Short Press the ON/OFF,the remote control enters the normal mode of work, the buzzer is short
sound one beeping, and the power indicator is fading.
(2)Power off: long press the ON/OFF, the buzzer is short sound two beeping, the power indicator
is out and the remote control is off.
2.Turning
When the remote control and the aircraft are pairing the code, move the turning rocker to left and
right,the aircraft will turn left and right.
3.Forward and backward
When the remote control and the aircraft are pairing the code, move the rocker to forward and
backward, the aircraft will fly forward and backward.
4.Left and right
When the remote control and the aircraft are pairing the code, move the rocker to left and
right,the aircraft will fly left and right.
5.Fine-tuning function
The aircraft can be stabilized by adjusting the direction of the aircraft, in the opposite direction of
flight.
6.Headless mode
Short press the button to enter headless mode. The vehicle’s flying direction will be the same as
the demand of controller,no matter where the head is .
7.Speed/Stunt
Short press the button to adjust the speed. There are three speed levels.Youwill hear a beep
sound while adjusting . Beep one for level 1 ,beep two for level 2, beep three for level 3. The
higher the level ,the faster the speed.Long press the button for stunt .The beeper will keep.
ringing.
8.Take photo/video
short press the button to take photo,long press the button to take video,press again to finish
video
9.One key take off and one key landing
In the fixed high mode,after press the one key take off and one key landing buttons,
automatically aircraft up to one meter from the ground level hover, trigger buttons again, aircraft
flying will fall to the ground stops automatically
10.One key to return
Short press the button for one key to return . Press again to finish return .
11.Calibration
(1) if the aircraft is drifting to one side during takeoff, it can be calibrated to make the flight more
stable
(2)calibration method: the aircraft is placed on the horizontal surface, and the two rocker of the
remote control is pushed to the lower right corner, when observed the indicator light flashes on
the aircraft, release the remote control rocker, indicating that it has been calibrated.
(note: the aircraft should be kept at the horizontal surface. During calibration, the aircraft will not
be able to riot . After the calibration is completed, the indicator light will stop flash quickly).
12：Low Volatage Warning：
When the voltage of battery is lower than 2.5V，power light will blink ,which means you have to
change the battery. Meanwhile, a “beep beep”sound will send from the buzzer，which means
you have to stop flying the vehicle.
Caution During the flight, the indicator light of the aircraft is slow to flash while the remote control makes a
"beep beep", indicating that the battery voltage is insufficient and please land down to recharge the
battery.
Mobile phone adapter：Output: 5V
Charging current: 1-2A.
1.Takeoff the battery from the vehicle. Connect the battery with a USB cable . Plug the USB cable into
a mobile phone adapter or a computer.
2.The Charging Indicator will blink when charging. The Charging Indicator will turn OFF when fully
charged .
400
Stable, flexible, 3D to roll easily
Stable, flexible, 3D to roll easily
2M
After you skilled above basic movements, you can play some of the breathtaking tumbling action.
First, the aircraft flew more than 2 meters’ height; Press the key rollover, then push the stick of
forward/backward, or left /right to top then release the aircraft can roll over.
Speed/Stunt Takephoto/video
Headless mode
The direction rocker
The throttle rocker
Front and back fine-tuning
Left and right fine-tuning
On/off button
One key to return back
One key to take off
One key to land
3.7V 400mAh
Li-Po Battery
controller
1x USB cable
4x spare blades
1x Small screwdriver

FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is sub ect to the following two
conditions
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation. Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Note 1: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Note 2: 1.Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
2. The minimum separation generally be used is at least 20 cm.
