APM ABR-2410gM User manual

Broadband Wireless Outdoor Solutions
(AP/ Wireless Client /Repeater/Wireless Bridge)
Model No: ABR-2410gM
● Wireless LAN IEEE802.11b/g compliant
● Solid housing provides protection against rigorous weather conditions IP68 compliant
● Four operating modes support: AP ,Wireless Client ,Repeater and Wireless Bridge
● Strong network security with 64/128/152-bit WEP encryption and WPA
● One detachable N-type male connectors can connect to external high gain antenna for expanding
connection distance
● Provides “RSSI” indication for AP, Repeater and Wireless Bridge
● Power over Ethernet design IEEE802.3af compliant
Spectifications
Standards Compliance IEEE802.11b/g; IEEE802.3af; IEEE802.3; IEEE802.3u
SDRAM 8 M Byte
Flash 2 M Byte
Radio Frequency Type DSSS / OFDM
Frequency Band America/FCC:2.412~2.462GHz(11 channels)
Europe CE/ETSI:2.41~2.472 GHz(13 channels)
Transmission Power IEEE802.11b/g:30dBm

Transmission Rate IEEE802.11b:1/2/5.5/11 Mbps
IEEE802.11b/g:6/9/12/18/24/36/48/54 Mbps
Super g: up to 108 Mbps
Access Point Interfaces Auto MDI/MMDI-X Ethernet 10/100Base-TX: RJ-45
Radio Wave:Antenna N-Male
Sensitivity -86dBm @ 11Mbps,PER< 8%;-64dBm @ 54Mbps,PER< 10%
Connector Type N-type male
Security Systems 64-bit/128-bit/152-bit/ WEP encryption and Wi-Fi Protected
Access(WPA)
Wireless Setting Operation Mode-AP/Wireless Client/Repeater/Bridge(WDS)PtP
and PtMP Mode
Software/Firmware Site Survey
DHCP Client
Wireless access control by MAC address(deny or accept)
WPA Support(WPA personal and enterprise)
Web-based configuration via popular browser(MS IE, Netscape…)
Windows ”Locator” program to help find IP in DHCP client mode
Firmware upgrade and configuration backup via Web
Reset to default by WebUI
Operating Environment Operating Temperature:-30~+70℃
PoE AC 100V~240V;DC 48Volt ±5%;1A(Max.)
Network Management
System OS Support
Windows 2000/XP
Warranty One year limited

Standard Accessories
