APM CO., LTD
APE-502401a-1
AP Specification
Standards Compliance IEEE 802.11a
IEEE 802.3
IEEE 802.3u
IEEE 802.3af
SDRAM 32 M Byte
Flash 8 M Byte
Radio Frequency Type DSSS/ OFDM
Modulation IEEE 802.11a : OFDM with BPSK, QPSK, 16QAM, 64QAM
Frequency Band IEEE 802.11a:
5.15 ~ 5.25 GHz (lower band)
5.25 ~ 5.35 GHz (middle band)
5.725 ~ 5.825 GHz (hi-band)
Frequency can be adjusted from software
Transmission Power IEEE 802.11a: 20 dBm
Transmission Rate IEEE 802.11a: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54 and 108Mbps
Access Point Interfaces Auto sensing MDI/MDI-X Ethernet 10/100Base-TX: RJ-45
Sensitivity IEEE 802.11a: -70dBm @ 54Mbps, PER<10%
Antenna Type Integrated 15dBi 5.0GHz flat panel antenna
Security Systems 64-bit/ 128-bit/ 152-bit WEP encryption; Wi-Fi Protected Access
(WPA) and WPA2
22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
www.apm.com.tw [email protected] Tel: [phone] Fax: [phone]

2 of 2
APM CO., LTD
Wireless Setting Operation Mode – AP / Wireless Client / Repeater / Wireless
Bridge (WDS) PtP and PtMP
Wireless Mode – 11a/ Super A
Software/Firmware Site Survey
DHCP Client
Suppressed SSID
Support DFS and TPC
Support VLAN
Support Multiple SSID
Wireless access control by MAC address (deny or accept)
WPA Support (WPA personal and enterprise)
Web-based configuration via popular browser (MS IE, Netscape…)
Windows “Locator” program to help find IP in DHCP client mode
Firmware upgrade and configuration backup via Web
Rouge AP Detection
Reset to default by WebUI
SNMP V2.0
Operating Environment Operating Temperature: -30 ~ +70°C
PoE DC 48 Volt ± 5%; 0.4A (Max.); AC adapter AC 110V ~ 240V
Regulatory Approval
Network Management Windows 2000/XP
System OS Support
Warranty One year limited
Standard Accessories
Bracket Kit
25M Cable 2M Cable
Bracket Kit (U Bolt) Power over Ethernet
