Applied Research and Technology ISO-8U User manual

ISO - 8U
Eight Output Isolated Power Supply With USB
User's Manual

IMPORTANT SAFETY INSTRUCTION – READ FIRST
This symbol, whenever it appears alerts you to the
presence of uninsulated dangerous voltage inside the
enclosure-voltage that may be sufficient to constitute a risk
of shock.
This symbol, whenever it appears, alerts you to important
operating and maintenance instructions in the
accompanying literature. Please read the manual.
Read Instructions: Retain safety and operating instructions for
future reference. Heed all warnings printed here and on the
equipment. Follow the operating instructions printed in this user
manual.
Do not open: There are no user serviceable parts inside. Refer
any service work to qualified technical personnel only.
Environment: Protect from excessive dirt, dust, heat, and
vibration when operating and storing. Avoid tobacco ash, drink
spillage and smoke, especially that associated with smoke
machines.
Handling: Protect the controls from damage during transit. Use
adequate padding if you need to ship the unit. To avoid injury to
yourself or damage to the equipment, take care when lifting,
moving or carrying the unit.
Servicing: Refer servicing to qualified technical personnel.
Installation: Install the unit in accordance with the instructions
printed in the user manual.

1
INTRODUCTION
Thank you for purchasing Applied Research and Technology’s
ISO-8U.Two high power outputs can provide 250mA. All other
outputs are capable of providing up to 100mA. There is one
variable voltage output to simulate worn batteries.
Each output is individually current limited and short circuit
protected. An Output status indicator goes out when there is a
fault (i.e. short, current protection or temp overload).
A USB type A jack can provide high power charging up to
10Watts.
The unit comes with a wide variety of cables to connect your
pedals including battery clip adapters, large and small diameter
power plugs, and “Y” for expanding the number of devices you
can connect and even a polarity reversing cable.
FEATURES
• Eight Isolated DC Outputs
• One Adjustable Output
• Each Output Has a switchable voltage
• USB Power jack for high speed charging
• Comes with multiple adaptor cords
• Runs off a Universal power supply
• Tie wrap slots for clean wire routing
• Perfect for powering guitar pedals, and pedal boards
• Designed and developed in the USA

2
INSTALLATION and OPERATION

3
Status LED’s
These LED's remain lit as long as there are no electrical faults
with the cabling or the pedal you are supplying power too. If a
particular fault seen at one of the outputs, the LED dim or turn
off and the voltage at that output will diminish. The cable
connection on the output with the fault will have to be removed
and reconnected for the output to be reset.
SAG Voltage
To enable this function on voltage output1 the dip switch will
need to be set to 4-9v. Then the user can vary the voltage from
the pot on the unit face.
APPLICATIONS
The ART ISO-8U is designed so that it can be mounted on a
pedal base using Velcro. The front and sides are recessed to
protect the cables and controls.
The bottom edge of the ISO-8U has slots that allow you to use
cable ties to control the routing of the power cables. Once you
loosely insert the wire ties through the slots you can run the
power cables through the remaining loops. Once all of the
cables are in place, you can tighten down the wire ties.

4
Cable Choices
Qty Cable Description
6 - 24-inch straight barrel 5.1mm to 5.1mm barrel
2 - 24-inch Rt. Angle 5.1mm to 5.1mm barrel
1 - Battery clip to 5.1mm barrel
1 - Polarity reversal 5.1mm to 5.1mm barrel
1 - “Y” cable (5.1mm) barrel
1 - 3.5mm barrel to 5.1mm barrel

5
Powering your Pedals
The first step in using the ART ISO-8U to power your device,
would be to make sure that pedal device you want to use can
be powered by a dc supply. The range on the ART ISO-8U is 9
or 12vdc or combining to outputs to achieve 18 or 24vdc,
remember that there is a max current draw on each output.
Then verifying the polarity of the pedal device you are wanting
to power. Generally, 9V battery powered devices will draw less
that 100mA.
The ART ISO-8U uses the negative center pin configuration.
This will determine if you need to use the polarity
reversal cable or one of the standard cables. This
will allow you to use a pedal that has a positive
center pin. Before you connect the cable from the
unit, make sure you set the dipswitch to the appropriate voltage
(9v or 12v).
If you have a pedal device that does not have a power jack
and is powered by a 9V battery, then you can use the cable
that has the battery tab connector.
There is a limitation on current loading, as this unit is not
meant to run all of the outputs at their maximum current draw.

6
WARRANTY INFORMATION
Limited Warranty
Applied Research and Technology will provide warranty and
service for this unit in accordance with the following warrants:
Applied Research and Technology, (A R T) warrants to the
original purchaser that this product and the components thereof
will be free from defects in workmanship and materials for a
period of three years from the date of purchase. Applied
Research and Technology will, without charge, repair or
replace, at its option, defective product or component parts
upon prepaid delivery to the factory service department or
authorized service center, accompanied by proof of purchase
date in the form of a valid sales receipt.
Online Registration
We recommend that you register your product online to insure
prompt warranty repair servicing on any repair issues. Please
go to www.artproaudio.com. Select “Support”, then "Product
Registration". Then input your information here.

7
Exclusions
This warranty does not apply in the event of misuse or abuse
of the product or as a result of unauthorized alterations or
repairs. This warranty is void if the serial number is altered,
defaced, or removed.
A R T reserves the right to make changes in design or make
additions to or improvements upon this product without any
obligation to install the same on products previously
manufactured.
A R T shall not be liable for any consequential damages,
including without limitation damages resulting from loss of use.
Some states do not allow limitations of incidental or
consequential damages, so the above limitation or exclusion
may not apply to you. This warranty gives you specific rights
and you may have other rights, which vary from state to state.
For units purchased outside the United States, an authorized
distributor of Applied Research and Technology will provide
service
Fill in the following information for your reference:
Date of purchase ___________________
Purchased from ___________________

8
SERVICE
The following information is provided in the unlikely event that
your unit requires service.
Be sure that the unit is the cause of the problem. Check to
make sure the unit has power, all cables are connected
correctly, and the cables themselves are in working condition.
You may want to consult with your dealer for assistance in
troubleshooting or testing your particular configuration.
If you believe that the ART unit is at fault, go to
www.artproaudio.com.
Select “Support”, then “Return Authorization Request” to
request a return authorization number.
If you are returning the unit for service, pack the unit in its
original carton or a reasonable substitute. The original
packaging may not be suitable as a shipping carton, so
consider putting the packaged unit in another box for shipping.
Print the RA number clearly on the outside of the shipping box.
Print your return shipping address on the outside of the box.
Include, with your unit, a note with the RA number and your
contact information, including a return shipping address (we
cannot ship to a P.O. box) and a daytime phone number, and a
description of the problem, preferably attached to the top of the
unit. Also include a copy of your purchase receipt.

9
SPECIFICATIONS
Input Connections 12v/2.5A Universal
Output Connections 2.1mm x 5.1mm barrel
connection, negative tip
Max output current Out1-6: 100mA
Out 7, 8: 250mA
Cables provided 6-24-inch 5.1mm to 5.1mm
2-24-inch Rt. Angle 5.1mm to
5.1mm
1-Battery clip to 5.1mm
1-Polarity reverse 5.1mm to
5.1mm
1-“Y" cable (5.1mm)
1-3.5mm to 5.1mm
USB Output 10 Watts Max
External Power required 100-240VAC 50/60hz 30W
universal power supply
configured for country of
destination
Dimensions (HxWxD) 1.33-inch x 6.95-inch x 3.3-inch
(34 x 177 x 84 mm)
Weight 1.3lbs / .59kg

www.artproaudio.com
E-mail: [e-mail]
© 2020 Applied Research & Technology / Yorkville Sound
ISO-8U ISO-5004-102
