Applied Wireless KTXW24SSA1 User manual

1
User’s Guide
Instructions for Installation and Operation
2.4 GHZ SPREAD SPECTRUM REMOTE CONTROLS
Handheld Transmitte
r
Model KTXW24SSA1
KTXW24SSA2
KTXW24SSA4
KTXW24SSA6
KTX24SSA12
Remote Control Receiver w/Relays
Model RCR24SSA-6R
Long Range Wireless Applications 2
This page intentionally left blank.

3
Applied Wireless Inc.
Remote Control Transmitters
Models KTXW24SSA1,-2,-4,-6, KTX24SSA-12
Remote Control Receiver
Models RCR24SSA-6R
Product Descriptions
These remote control receivers and transmitters are designed to provide
a quick and cost effective solution for a variety of wireless remote control
applications. The receiver utilizes Spread Spectrum technology and
offers excellent electromagnetic interference (EMI) tolerance - often
found in AC and DC motor applications. The receiver includes three low
voltage, internal, 10-Amp, SPDT relays and an external whip antenna.
Expected range with these products is 350 to 500 feet*. The range may
be increased through the use of a higher gain antenna (800253-5-RC) at
the receiver. These products will not interfere with or be affected by Wi-Fi
systems.
The receiver runs on 12 to 24 Volts AC or DC (supply not included).
Through the use of jumper settings on the receiver board, the receiver
can be operated in momentary, latched (one button on, another button
off), or toggle modes. It can be configured to operate as channels 1
through 6 (default) or channels 7 to 12.
The receiver can quickly “learn” up to 60 Applied Wireless transmitters
with different address codes. All keyfob transmitters come from the
factory with a unique ID code. A receiver will only respond to the
transmitter whose ID code has been “learned”. All other transmissions
from transmitters with different ID codes will be ignored. Multiple
transmitters and receivers may be used in the same area without
interfering with each other.
Power for the 6-button handheld is supplied by a 3V CR123 battery
(included).
Power for the 12-button handheld transmitter is supplied by two AA
batteries. An indicator LED indicates the transmitter is transmitting.
* Unobstructed, straight line-of-sight range, when used with the standard
antennas included with the receiver.
4
Installation Instructions
Before Beginning the Installation
Plan your installation carefully. The physical location and orientation of
the receiver will have a significant influence on reception, particularly at
longest ranges. For best results, the receiver antenna, should be
positioned vertically (pointing either up or down). If the receiver is
mounted in a metal enclosure, a 600279-8 bulkhead extension cable will
enable the antenna to be mounted externally. Also, keep in mind that
the RF signal from the transmitter will travel through most non-metallic
building materials (wood, stucco, brick, etc.), however maximum stated
reception range is based on unobstructed line of sight conditions.
Keyfob Button / Relay Assignment
Relays in the receivers respond to the buttons on the transmitters as follows:
Transmitte
r
Type
Transmitte
r
Button Number
Corresponding Rela
y
in
RCR24SSA-6R
Six-Button
KTX
1 Bank A, Relay #1
2 Bank A, Relay #2
3 Bank A, Relay #3
4 Bank A, Relay #4
5 Bank A, Relay #5
6 Bank A, Relay #6
Twelve-Button
KTX
1 Bank A, Relay #1
2 Bank A, Relay #2
3 Bank A, Relay #3
4 Bank A, Relay #4
5 Bank A, Relay #5
6 Bank A, Relay #6
7 Bank B, Relay
#
1
8 Bank B, Relay
#
2
9 Bank B, Relay
#
3
10 Bank B, Relay
#
4
11 Bank B, Relay
#
5
12 Bank B, Relay
#
6
See Page 9 for Bank A/B Jumper Setting. Bank A is default
setting.

5
RCR24SSA-6R Programming and Configuration
Transmitter Learn Mode
The receiver will learn up to 60 transmitter IDs.
To learn a transmitter:
1. Power up the receiver.
2. Momentarily press the learn button; the light LEARN light
will go on.
3. Press any button on the transmitter until the LEARN light
goes out.
4. To learn another transmitter, repeat the process.
Codes cannot be deleted individually. The entire list of learned
codes can be cleared by pressing and holding the LEARN switch for
at least 10 seconds and then releasing it. The LEARN light will flash
on and off for a few seconds to indicate the entire list of learned
transmitters is empty.
Relay Response Mode Configuration (DIP Switch S1)
Each of the six relays of the 6-channel remote control receiver may be
configured for one of three possible “Response Modes.” A Response
Mode defines how a relay functions when that relay’s associated button
is pressed on the handheld transmitter (part number KTXWSSA6). The
individual Response Modes for Relay 1 through Relay 6 are determined
by the settings of DIP Switches S1-1 through S1-6 respectively, as
shown in Fig. 1. The three available Response Modes are Momentary
(factory default), Toggle, and Latched. The following sections describe in
detail the characteristics of, and configuration settings for, the various
Relay Response Modes.
S3-1 ,S3-2 S3-3
S3
S3-1
S3-2
S3-3
S3-4
NOTE: For S3-1, S3-2 and S3-3, only he highest number
switch is recognized if more than one is turned ON.
This does not apply to Master Reset (S3-4).
S3
6
Momentary Mode (factory-default)
A relay energizes when its associated button on the transmitter is
pressed. The relay deactivates when the transmitter’s button is released
(or reception of the transmitter’s signal ceases). A relay is configured for
Momentary Mode when that relay’s associated section of DIP Switch S1
is set to the center (MOM) position.
Toggle Mode
A relay energizes when its associated button on the transmitter is
pressed, and remains energized after the button is released. A
subsequent press of the same button on the transmitter will deactivate
the relay. In this mode, each of the relays is completely independent of
the others, thus any number of relays configured for Toggle Mode may
be energized at any given time. A relay is configured for Toggle Mode
when that relay’s associated section of DIP Switch S1 is switched down
to the TOG position.
Latched Mode
The following applies to only those buttons where S1 setting is set to
LATCHED mode. Otherwise they will be TOGGLE or MOMENTARY as
set by S1.
(DIP Switch S3)
A relay energizes when its associated button on the transmitter is
pressed, and remains energized after the button is released. That relay
is turned off when another Latched Mode relay is activated. A relay is
configured for Latched Mode when that relay’s associated section of DIP
Switch S1 is switched up to the LATCH position. If any relays are
configured for Latched Mode, a “Latch Group” must also be selected via
DIP Switch S3 (refer to Fig. 1). A Latch Group consists of two or more
relays. Only one relay within a Latch Group can be energized at any
given time. The receiver offers four different Latch Groups: Horizontal,
Vertical, Corner, and Global. Each Latch Group is organized by the
physical orientation of the buttons on the handheld transmitter, as shown
in the following four illustrations. The desired Latch Group may be
selected via DIP Switch S3 (refer to Fig. 1).

7
LATCH GROUPING OPTIONS
NOTE: When a KTX24SSA-12 transmitter controls two RCR24SSA-6R
receivers, all relay response modes are available for all 12 channels.
However, Latched Groups are limited to two 6 channel groups as shown.
S3-1
S3-2
S3-3
S3-1
8
Master Reset Function (optional)
In addition to the Latch Groups described above, the 6-channel receiver
provides an optional Master Reset function. If the Master Reset function
is enabled, pressing Button 6 on the transmitter will turn off any relay(s)
that is(are) energized (either latched or toggled) at that time. When the
Master Reset function is enabled, Relay 6 is nonfunctional (does not
respond to Button 6 on the transmitter), regardless of the Response
Mode to which it is configured (via DIP Switch S1-6). The Master Reset
function is enabled by setting DIP Switch S3-4 to its ON position.
Miscellaneous Considerations for Configuration
• When changing any DIP Switch settings, the receiver MUST be
disconnected from power. Configuration changes do not take effect
until the receiver is powered up (i.e. the DIP Switches are only
interrogated by the receiver’s microprocessor at power-up initialization).
• DIP Switch S1-7 and S1-8 are not used. They are reserved for future
product enhancements.
• For DIP Switches S3-1, S3-2, and S3-3 only the highest-numbered
switch is recognized if more than one is turned on. This does not apply to
S3-4 (Master Reset).
LED Indicators (Receiver)
Power LED: Indicates that voltage is applied to the receiver.
Relay LED’s (6): They indicate for each relay whether the relay is
activated.
Learn LED: Indicates when “Learn” mode is activated.
Controlling 120V Circuits and High Amperage Loads
The RCR receiver is not UL listed, and 110 or higher voltage circuits
should not be directly connected to the receiver relays. These circuits
can be controlled however by using a contactor with a 24-VAC coil (AW
PN 269006, 25A contactor).
For low voltage loads over 10 Amps, Applied Wireless offers internal 16A
relay option or high current relays (AWPN 269007, 30A 12VDC Relay)
that can be controlled by the RCR receiver.

9
RCR24SSA-6R Programming and Configuration
Frequency Setting (DIP Switch S2)
It is recommended that you do not change this setting unless needed.
In order for more than one system to operate in the same area, up to 16
different frequency settings are available. Remove the lid from the case
of the RCR24SS-6R receiver. S2 is a 4 position dip switch which is near
the edge of the board and can be set to up to 16 unique patterns that
correspond to 16 different frequency settings. The pattern set in the
receiver frequency switch has to match the pattern set in the transmitter
frequency switch, which is also a 4 position dip switch exposed when the
case is taken apart.
Bank Switch Setting
To allow 2ea RCR24SS-6R receivers to be used with 12 channel
transmitters an internal jumper setting is available. When the lid is
removed from the case of the RCR24SS-6R receiver, a jumper setting
near relay K5 in the 6 channel receiver is a 3 position header with a
jumper installed. If the jumper is installed between the center pin and the
pin marked “A” then the 6 relays will respond to Buttons 1 thru 6. If the
jumper is moved to between the center pin and the pin marked “B” then
the relays will respond to Buttons 7 thru 12.
10
Board Switch & Jumper Locations

11
RCR24SSA-6R Receiver Block Diagram
+12 V
-
+
MOME N T A RY T OGGLE
AND
L AT CHI NG L OGI C
RX2 4 SSA
SU PERHET
RECEIVER/
DECODER
REG
LEARN
+12 V
+12 V
+12 V
+12 V
+12 V
+12 V
ANTENNA
+12 TO 24 V
AC/ DC
NC1
C1
NO1
NC2
C2
NO2
NC3
C3
NO3
NC4
C4
NO4
NC5
C5
NO5
NC6
C6
NO6
12
RCR24SSA-6R Receiver Package Information
6.50 6.00
3.85
O .190
4.35
1.3 6
1.4 2
4.00
ANTENNA
POWER
DATA
LEARN L ED
RELAY 6
RELAY 5
RELAY 4
RELAY 3
RELAY 2
RELAY 1
LE ARN S WITCH
12 - 2 4 V AC/ DC
RELAY 1
RELAY 2
RELAY 3
RELAY 4
RELAY 5
RELAY 6
NC6
C6
NO6
NC5
C5
N0 5
NC4
C4
N0 4
NC3
C3
N0 3
NC2
C2
N0 2
NC1
C1
N0 1
1.239
1.239
NC-Normally Closed Contact
Cx- Common Contact
NO- Normally Open Contact-
Terminal Strips may be “unplugged” for ease of installation.

13
RCR24SSA-12R Receiver Block Diagram
+12 V
-
+
MOMENTARY TOGGL E
AND
L ATCHI NG LOGIC
RX24SSA
SUPERHET
RECEIVER/
DECODER
REG
L EARN
+12 V
+12 V
+12 V
+12 V
+12 V
+12 V
ANTENNA
+12 T O 24 V
AC/D C
NC1
C1
NO1
NC2
C2
NO2
NC3
C3
NO3
NC4
C4
NO4
NC5
C5
NO5
NC6
C6
NO6
+12 V
-
+
MOMEN T A RY T OGGLE
AND
L AT CHI NG L OGI C
REG
+12 V
+12 V
+12 V
+12 V
+12 V
+12 V
+12 T O 24 V
AC/D C
NC1
C1
NO1
NC2
C2
NO2
NC3
C3
NO3
NC4
C4
NO4
NC5
C5
NO5
NC6
C6
NO6
14
Ordering Information
Frequency
(MHz)
Model
Number
6-Button Watertight
Transmitter 12-Button Transmitter
2400-
2483
RCR24SSA-6R KTXW24SSA2, -4, -6
RCR24SSA-6R
1
KTX24SSA-12
Receiver Electrical Characteristics
Paramete
r
Min Typ Max Uni
t
Operating Voltage Range (AC or DC) 10 12 26 Volts
Operating Current, Un-Activated 30 mA
Operating Current, All Relays Activated 220 270 mA
Relay Contact Ratings @ 28VDC 10 A
Center Frequency 2400-2483 MHz
Antenna Input Impedance Ω 50 Ohms
Operating Temperature -20 +60 C
Number of Address Codes Possible 4.2 Billion
KTXW24SSA6-1, -2, -4, -6 Transmitter
Battery: one CR123A coin cell
Size: 3.40 x 2.56 x 1.10 inches (86 x 65 x 28 mm)
KTX24SSA-12 Transmitter
Battery: two 1.5 VDC, type AA
Size: 5.74 x 1.82 x 1.31 inches 146 x 46 x 33 mm)
FCC ID: UYI24
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference and (2) This device
must accept any interference received, including interference that may
cause undesired operation.
Related Products
AW Part
Number
Description
800253A-3-RC Antenna, Rubber Duck, 3dBi, 110mm, Swivel, RPSMA
(included)
800253A-5-RC Antenna, Rubber Duck, 5dBi, 190mm, Swivel, RPSMA
610307 AC Power Adapter, 120VAC -12VDC, 200mA
610300 AC Power Transformer, 120VAC-24VAC, 20VA
800216 AC Power Adapter, 120VAC-12VDC, 500mA
269006 AC Power Line Contactor, SPST, 25A, 24VAC coil
610347 AC Power Adapter, 120VAC-24VDC, 0.8A
600279-8 Coaxial Bulkhead Extension Cable, 8 Inch
1 Requires two receivers, one set to Bank A, the other to Bank B. Set Channel
group jumper to 7-12.

15
Application Circuit – DC Motor Forward/Reverse Circuit
This is an example of using the RCR24SSA-6R Receiver for wireless
forward and reverse remote control of a DC motor. The wiring diagram
shows the motor connected to Relays 1 and 2. Thus it follows that
Buttons 1 and 2 on the handheld transmitter would control the motor
(e.g. Button 1 for forward, Button 2 for reverse). With Relays 1 and 2
configured for Momentary Mode (factory
default), the motor runs in the desired direction only when the
appropriate button on the transmitter is pressed. When the button is
released, the motor stops.
If the motor is equipped with limit switches, Relays 1, 2, and 3 could be
configured for Latched Mode. In this configuration, a momentary press of
Button 1 or 2 would cause the motor to run continuously in the
appropriate direction, until it reaches the limit switch. Button 3 can be
used to stop the motor at any time (Relay 3 would not be connected to
anything).
RECEIVER
16
ONE YEAR LIMITED WARRANTY (USA)
Products manufactured by APPLIED W IRELESS, INC. (AW) and sold to purchasers in the USA are
warranted by AW according to the following terms and conditions. You should read this Warranty
thoroughly.
 WHAT IS COVERED, AND DURATION OF COVERAGE:
AW warrants the product to be free from defects in materials and workmanship for one (1) year from the
date of purchase by the original end user purchaser.
 WHAT IS NOT COVERED:
This warranty does not apply to the following:
1. Damage caused by accident, physical or electrical misuse or abuse, improper installation, failure to
follow instructions contained in the User’s Guide, any use contrary to the product’s intended
function, unauthorized service or alteration (i.e. service or alteration by anyone other than AW).
2. Damage occurring during shipment.
3. Damage caused by acts of God, including without limitation: earthquake, fire, flood, storms, or
other acts of nature.
4. Damage or malfunction caused by the intrusion of moisture or other contamination within the
product.
5. Batteries supplied by AW in or for the product.
6. Cosmetic deterioration of chassis, cases, or pushbuttons resulting from wear and tear typical of
normal use.
7. Any cost or expense related to trouble-shooting to determine whether a malfunction is due to a
defect in the product itself, in the installation, or any combination thereof.
8. Any cost or expense related to repairing or correcting the installation of an AW product.
9. Any cost or expense related to the removal or reinstallation of the product.
10. Any product whose serial number or date code is altered, defaced, obliterated, destroyed, or
removed.
This warranty is extended to the original purchaser of the product(s) only, and is not transferable to any
subsequent owner or owners of the product(s). AW reserves the right to make changes or improvements
in its products without incurring any obligation to similarly alter products previously purchased.
 EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES:
AW expressly disclaims liability for incidental and consequential damages caused (or allegedly caused)
by the product. The term “incidental or consequential damages” refers (but is not limited) to:
1. Expenses of transporting the product to AW to obtain service.
2. Loss of use of the product.
3. Loss of the original purchaser’s time.
 LIMITATION OF IMPLIED WARRANTIES:
This warranty limits AW’s liability to the repair or replacement of the product. AW makes no express
warranty of merchantability or fitness for use. Any implied warranties, including fitness for use and
merchantability, are limited in duration to the period of the one (1) year express limited warranty set forth
herein. The remedies provided under this warranty are exclusive and in lieu of all others. AW neither
assumes nor authorizes any person or organization to make any warranties or assume any liability in
connection with the sale, installation, or use of this product.
Some states do not allow limitations on how long an implied warranty lasts, and some states do not
allow the exclusion or limitation of liability for incidental or consequential damages so the limitations or
exclusions stated herein may not apply to you. This warranty gives you specific legal rights and you may
have other rights which vary from state to state.
(continued on next page)

17
ONE YEAR LIMITED WARRANTY (USA), cont.
 HOW TO OBTAIN WARRANTY SERVICE:
If a product covered by this warranty and sold in the USA by AW proves to be defective
during the warranty period AW will, at its s ole option, repair it or replace it with a
comparable new or reconditioned product without charge for parts and labor, when said
product is returned in compliance with the following requirements:
1. You must first contact AW at the following address/phone for assistance:
APPLIED WIRELESS, INC.
1250 Avenida Acaso, Suite F
Camarillo, CA 93012
Phone: [phone]
If you are instructed to return your product directly to the factory, a Return
Merchandise Authorization number (RMA) will be issued to you.
2. You must package the product carefully and ship it insured and prepaid. The RMA
number must be clearly indicated on the outside of the shipping container. Any
product returned without an RMA number will be refused delivery.
3. In order for AW to perform s ervice under warranty, you must include the following:
(a) Your name, return shipping address (not a PO Box), and daytime telephone number.
(b) Proof of purchase showing the date of purchase.
(c) A detailed description of the defect or problem.
Upon completion of service, AW will ship the product to the specified return shipping
address. The method of shipping shall be at AW’s sole discretion. The cost of return
shipping (within USA) shall be borne by AW.
18
Troubleshooting Guide
Symptom Possible Problem Notes
Poor Range Antenna Receiver Antenna
connected, vertically
oriented and placed
preferably at least 7' high
and away from metal
surfaces.
Antenna will not work inside
a metal box
RF Interference Check equipment operation
at a different location.
Battery If the remote transmitter has
an indicator LED, does it
light brightly when button is
pressed? If not, replace
battery.
Doesn't Work Power Check power to receiver
(power LED lit?)
Relay Connection Verify connected to the
correct Relay.
ID Code Match Re-"Learn" remote to
receiver. MUST BE DONE
WITH ANTENNA
REMOVED.
Re-Boot Needed Remove power from
receiver for at least 5
seconds.

19
Applied Wireless products are designed and
manufactured with pride in the United States of
America
 Copyright 2014 by Applied Wireless, Inc. All rights reserved.
Specifications subject to change without notice.
APPLIED WIRELESS, INC.
1250 Avenida Acaso, Unit F, Camarillo, CA 93012
Phone: [phone] Fax: [phone]
Email: [e-mail]
www.appliedwireless.com
Pub. # UG-RCR24SSA, Rev. Date 3/25/15
