Item Number:AP9575S/AP9578S
INSTALLATION INSTRUCTIONS www.aprilproducts.co.uk
Single Over Bath Screen/Sail Over Bath Screen
Tools Required
Lifetime Product Guarantee
To activate your Product Guarantee please
visit www.aprilproducts.co.uk and complete
the online form.
6
PH2 TYPE
2.75
This product should be installed by a suitably qualified and proficient person. The fitting instructions should be
followed carefully to ensure a proper and safe installation. Failure to follow these instructions could result in future
injury.
These instructions and list of parts assume that installation is done against solid/tiled walls.
Please check this product for damage prior to starting the installation. No claims can be made after the product has
been fitted.
PLEASE NOTE :The minimum and maximum adjustment sizes noted on the product brochures are based on
perfectly plumb walls and trays.

Box Contents
COMPONENTS AND BOX CONTENTS
1
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
2
2
1
1
1
3
3
Wall profile
Upright profile
Frame profile
Vertical seal
Profile Top cap
Screw cover cap
Cap
Bottom seal
Pivot part 1
Pivot part 2
Pivot part 3
Wall plug
SN
Screw ST3.5 X 10
Screw ST4 X 30
Moving panel
SN Description Qty
Description Qty
3
3
3

A
B
C
D
Ф 6 drill bit
12-15mm
form bath
edge
4X45
Step 1: Position the wall profile (1) onto the bath , approximately 12-15mm from the outside bath edge to ensure that
the screen runs along the inside edge of the bath rim. (A).
Step 2: Level the profile with a spirit level , then mark the position using a pencil. Mark through the 3 pre-drilled screw
holes in the wall profile then drill the marked points using a 6mm masonry drill bit ,once this is done insert 3 wall plugs
(11) into the wall holes (B).
NOTE :You may find it easier to mark and drill the wall if you apply masking tape to it first.
Step 3: Secure the wall profile using 3 x ST4X45 screws (12). (C)
Step 5 : Carefully position the screen into the wall profile. (D)
Step 6 : Secure to the wall profile using 3 x ST3.5X10 screws (13) and cover caps (14,15) (E,F)
E
Ф2.75 drill bit

G
Allow 24 hours before use
for silicone to set .
For cleaning instructions
see guarantee .
Bottom seal
NOTE : To ensure a watertight seal ensure the bottom seal (10) is fully
inserted into the base of the hinge as per the above diagram.
I
H

This product has been treated with Clean & Clear™ easy clean glass treatment, a protective barrier which creates
a ‘non-stick’ surface on your glass, helping to resist lime scale build up and water spots. For further information on
Clean & Clear™ please visit www.aprilproducts.co.uk
Clean & Clean™ glass can be cleaned with any suitable nonabrasive glass cleaner - with PH value of between 3-
11; the coating will not be damaged. Avoid surfactants and heavily perfumed products. Vinegar and water based
products are very effective. Do not use abrasive scrubbing cleaners or equipment for cleaning.
Limited 5 year Warranty for Clean & Clear™ treatment: To guarantee treated surfaces will remain more repellent
than untreated glass for 5 years from start of use, as long as basic manufacturer maintenance recommendations
are followed and no harsh or abrasive cleaners are used.
It is important to clean your April shower enclosure after every use. Please wipe down all glass and metal parts
with a clean soft cloth. Ensure that all residual water on the glass is removed after every use.
For reliable, watertight performance from your April enclosure your shower head should not be positioned so that
the shower sprays directly onto the enclosure door. Failure to comply with this may cause the shower to leak.
Outward opening doors may cause water to drip onto the floor, please ensure that the floor covering immediately
outside the enclosure will not be affected by water.
