APW Wyott EGD48GB Series User manual

APW WYOTT Foodservice Equipment Company
P.O. Box 1829
Cheyenne, WY 82003
[phone] Phone [phone] Toll Free
[phone] Fax
INSTALLATION AND OPERATING INSTRUCTIONS
Electric Drop-In Griddles
With Griddle Box
8/03 Form #8815200 REV-B
1
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
Model Number Serial Number Date Purchased
WARNING: Improper installation, operation, service or maintenance can cause
property damage, injury or death. Read and understand these instructions thoroughly
before positioning, installing, maintaining or servicing this equipment.
!!
PRODUCT MANUAL
Safety Instructions
Installation Instructions
Operation Instructions
Maintenance Instructions
Replacement Parts List
Warranty/Service Information
ANSI/NSF4
Models: EGD48GB & EGD72GB

2

Installation and start-up should be performed by a qualified installer who thoroughly read, understands and
follows these instructions.
If you have questions concerning the installation, operation, maintenance or service of this product, write
Technical Service Department APW/Wyott Foodservice Equipment Company, P.O. Box 1829, Cheyenne,
WY 82003.
SAFETY PRECAUTIONS
Before installing and operating this equipment be sure everyone involved in its operation is fully trained and
is aware of all precautions. Accidents and problems can result by a failure to follow fundamental rules and
precautions.
The following words and symbols, found in this manual, alert you to hazards to the operator, service
personnel or the equipment. The words are defined as follows.
!
!WARNING: This symbol refers to a potential hazard or unsafe practice, which could result
in serious injury or death.
!
!DANGER: This symbol warns of imminent hazard which will result in serious injury or
death.
!
!CAUTION: This symbol refers to a potential hazard or unsafe practice, which may result in
minor or moderate injury or product or property damage.
!
!NOTICE: This symbol refers to information that needs special attention or must be fully
understood even though not dangerous.
GENERAL INFORMATION
THIS MANUAL SHOULD BE RETAINED FOR FUTURE REFERENCE
CAUTION: These models are designed, built, and sold for commercial use. If these
models are positioned so the general public can use the equipment, make sure that
cautions, warnings, and operating instructions are clearly posted near each unit so that
anyone using the equipment will use it correctly and not injure themselves or harm the
equipment.
!
!
!
!
WARNING: Check the data plate on this unit before installation. Connect the unit only to
the voltage and frequency listed on the data plate. Connect only to 1 or 3 phase as listed on
the data plate.
WARNING: Improper installation, operation, service or maintenance can cause property
damage, injury or death. Read and understand these instructions thoroughly before
positioning, installing, maintaining or servicing this equipment.
!!
!
!WARNING: Electrical and grounding connections must comply with the applicable
portions of the national electrical code and/or other local electrical codes.
!
!WARNING: Disconnect device from electrical power supply and place a Tag Out-Lockout
on the power plug indicating that you are working on the circuit.
3

Congratulations on your purchase of APW/Wyott commercial cooking or refrigeration equipment.
APW/Wyott takes pride in the design and quality of our products. When used as intended and with proper
care and maintenance, you will experience years of reliable operation from this equipment. To ensure best
results, it is important that you read and follow the instructions in this manual carefully.
TABLE OF CONTENTS:
!
!WARNING: An earthing cable must connect the appliance to all other units in the
complete installation and from there to an independent earth connection.
!
!NOTICE: This product is intended for commercial use only. Not for household use.
!
!WARNING: SHOCK HAZARD:Do not open any panels that require the use of tools.
!
!
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury or death. Read installation, operating and maintenance
instructions thoroughly before installing or servicing this equipment.
!
!
NOTICE: The unit, when installed, must be electrically grounded and comply with local
codes, or, in the absence of local codes, with the national electrical code ANSI/NFPA70-
latest edition. Canadian installation must comply with CSA-STANDARD C.22.2 Number 0
M1982 General Requirements-Canadian Electrical Code Part II, 109-M1981-
Commercial Cooking Appliances.
!
!
NOTICE: Local codes regarding installation vary greatly from one area to another. The
National Fire Protection Association, Inc., states in its NFPA96 latest edition that local
codes are “Authority Having Jurisdiction” when it comes to requirement for installation of
equipment. Therefore, installation should comply with all local codes.
WARNING: Install per the spacing requirements listed in the installation section of this
manual. We strongly recommend having a competent professional install the equipment.
A licensed electrician should make the electrical connections and connect power to the
unit. Local codes should always be used when connecting these units to electrical power.
In the absence of local codes, use the latest version of the National Electrical Code.
!
!
!
!WARNING: Afactory authorized agent should handle all maintenance and repair. Before
doing any maintenance or repair, contact APW Wyott.
Safety Precautions..................................3
Specifications..........................................5
Installation...............................................5
Equipment Preparation...........................6
Seasoning...............................................6
Operation................................................7
Cleaning .................................................8
Cooking Chart.........................................9
Trouble Shooting ....................................9
Calibration Procedure...........................10
Wiring Diagram 48” ...............................11
Wiring Diagram 72”...............................12
Parts Breakdown & List ..................13, 14
Overview...............................................15
Preparation/Setup.................................16
Grill Position Responsibilities ...............19
Grill Operation-Loading Meat ...............20
Close/Clean-up.....................................21
Warranty ...............................................24
4

LOCATION OF DATAPLATE
The data plate for the electric drop-in griddles with grill box is located on the bottom panel near the knock
out for bringing in the power cord.
IMMEDIATELY INSPECT FOR SHIPPING DAMAGE
All containers should be examined for damage before and during unloading. The freight carrier has
assumed responsibility for its safe transit and delivery. If equipment is received damaged, either apparent
or concealed, a claim must be made with the delivering carrier.
A) Apparent damage or loss must be noted on the freight bill at the time of delivery. It must then be
signed by the carrier representative (Driver). If this is not done, the carrier may refuse the claim.
The carrier can supply the necessary forms.
B) For concealed damage or loss, if not apparent until after equipment is uncrated, a request for
inspection must be made to the carrier within 15 days. The carrier should arrange an
inspection. Be certain to hold all contents and packaging material.
SPECIFICATIONS
Electrical
EGD48GB, 208 Volt, 50/60 Hz, 3 Ph, 21,600 Watts, 3 Ph Amps L1-69.0, L2-69.0, L3-45.0
EGD48GB, 240 Volt, 50/60 Hz, 3 Ph, 21,600 Watts, 3 Ph Amps L1-60.0, L2-60.0, L3-39.0
EGD48GB, 480 Volt, 50/60 Hz, 3 Ph, 21,600 Watts, 3 Ph Amps L1-30.0, L2-30.0, L3-20.0
EGD72GB, 208 Volt, 50/60 Hz, 3 Ph, 32,400 Watts, 3 Ph Amps L1-90.0, L2-90.0, L3-90.0
EGD72GB, 240 Volt, 50/60 Hz, 3 Ph, 32,400 Watts, 3 Ph Amps L1-78.0, L2-78.0, L3-78.0
EGD72GB, 480 Volt, 50/60 Hz, 3 Ph, 32,400 Watts, 3 Ph Amps L1-39.0, L2-39.0, L3-39.0
Dimensions Body With Work Shelf Ship weight
Height Depth Width Height Depth Width
EGD72GB 14” 35-5/8” 75-3/4” 14” 51” 75-3/4” 556 lbs.
356mm 905mm 1924mm 356mm 1295mm 1924mm
EGD48GB 14” 35-5/8” 51-3/4” 14” 51” 51-3/4” 377 lbs.
356mm 905mm 1314mm 356mm 1295mm 1314mm
Griddle Surface Dimensions
Width Depth Width Depth
EGD72GB 69.5” 23.94” 1181mm 608mm
EGD48GB 46.5” 23.94” 1765mm 608mm
INSTALLATION
A qualified installer who thoroughly reads, understands and follows these instructions should perform
installation and start up. If you have questions concerning the installation, operation, maintenance or
service of this product. Call:
APW Wyott Technical Services Department
1-800-752-0863 Ask for Jerry Knowlton or Rod Commander
Monday through Friday 9AM 6:30PM Eastern Time
Uncrate the griddle, make sure no parts are discarded with crating material. Place the griddle in it’s
mounting position.
5

This griddle is wired for 208 volt or 240 volt service. Proper installation should comply with the attached
rating plate containing model number, serial number, voltage and amperage. The unit has been pre wired
at the factory. Connect the leads supplied to branch circuit protecting device of adequate rating for the
griddle. Consult local and/or national electrical code for proper protection device.
WARNING: This unit is supplied with connection wires for the length provided. If the wires
are connected to a longer run, the size of the wires must be confirmed. Consult your local
electrical code or the national electrical code if the wiring is longer than those supplied. !
!
WARNING: This device should be safely and adequately grounded in accordance with
local codes, or, in the absence of local codes, with the National Electrical code,
ANSI/NFPA 70, Latest Edition to protect the user from electrical shock. It requires a
grounded system and a dedicated circuit protected by a fuse or circuit breaker of proper
size and rating. Canadian installation must comply with the Canadian Electrical Code,
CSA C22.2, as applicable
!
!
EQUIPMENT PREPARATION
The griddle is shipped with protective coatings of oil and/or grease. Remove the griddle plate coating just
prior to its first cooking use. If the griddle is to be shut down for an extended period, put a heavy coat of clean
grease back over the griddle plate.
Wipe the remaining cabinet parts down with a hot, wet cloth to remove any shipping dust and protective oil.
!
!
CAUTION: Care must be exercised not to overheat the griddle plate on initial start up by
setting the controls above normal operating temperature. Overheating may cause the
plate to warp and will carbonize the grease (this will cause sticking).
!
!
CAUTION: This griddle plate is steel, but the surface is relatively soft and can be scored or
dented by carelessly using a spatula. Be careful not to dent, scratch, or gouge the plate
surface. Do not try to knock off loose food that may be on the spatula by tapping the corner
or the edge of the spatula on the griddle surface.
SEASONING
1. Wipe any remaining water off grill with paper towels.
2. Use a 1/9-sized pan to pour a small amount of liquid corn shortening (from bag-in-box) onto grill
surface.
3. Use a dry paper towel to cover entire grill surface with a VERY LIGHT coat of shortening.
4. Caution: Do not use hot shortening from fryers.
5. Coating grill with shortening is called “seasoning” and prevents rusting of grill surface.
6. Pour remaining corn shortening into a fry kettle.
7. Take sandwich board to back room to be washed, rinsed and sanitized.
8. Wipe clean area between board and grill with a sanitized towel. Check entire grill area again.
Also, wipe ledge below grill, surrounding walls and bottom of bun warmer (or MPHC).
9. Take condiment pan and grill cleaning tools to back room to be cleaned and properly stored. C l ea n
grill cleaning tools with hot, soapy water.
10. Return sandwich board and grill guards to grill.
11. Empty grease buckets following “Grease Bucket” procedures, as necessary.
6

OPERATION
Turning the dial knob (recessed in the front panel) controls the heat of the griddle surface. When a control is
turned on, a signal light directly above the dial will glow. This indicates the griddle is heating in that zone.
The individual controls operate each 12” wide cooking zone. Make sure power is supplied to the unit then
turn the control knob to the desired temperature. When the light is out, with the dial set on a temperature
setting, the griddle plate has reached the desired temperature. The lights will intermittently come on during
cooking cycles to indicate temperature is being maintained. For best results, allow the griddle to heat 20-30
minutes before beginning to cook product.
When setting zones to different temperatures, do not set zones beside each other more than 50ºF apart.
Because of the mass of the griddle plate and conduction of the heat they will tend to reach the same
temperature. When you want zones at greater temperature variation, leave a zone or more between the
cooking zones. Turn off the zone or zones between the two cooking areas. Note: this will effect the
efficiency of the griddle. The heat being supplied will heat the areas between the cooking zones. You can
run the zones not being used at a temperature between the two set points, this will improve the recovery of
the hotter zone.
During idle times during the day, turn the griddle to a lower temperature setting. If you need to prepare
product, the griddle will heat up rapidly; and, holding the griddle at a lower temperature will save energy
costs.
When finished, turn all temperature controls to “OFF.”
TEMPERATURE CONTROL KNOB: SET
TO DESIRED TEMPERATURE
PILOT LIGHT: WILL BE LIT
WHEN UNIT IS HEATING
Pilot Light: Will be lit
when unit is heating
Temperature Control Knob:
Set to desired temperature
7

CLEANING
IMPORTANT: At the end of each day’s operation, turn all temperature controls to “OFF.”
NEVER clean any electrical unit by immersing it in water.
After each cooking load, scrape the griddle surface with a scraper or rigid spatula to remove excess fat and
food particles.
Once a day, or whenever necessary, thoroughly clean and wipe out grease trough. As necessary during
use, wipe out accumulated material to provide good drainage. Remove the grease receptacle, empty and
wash.
CAUTION: Turn off the griddle and allow it to cool before cleaning. Hot surfaces can burn.
Avoid contacting hot surfaces. !
!
Clean all stainless surfaces with warm soapy water. Use a sponge or soft cloth, wipe clean and dry. Do not
use abrasive cleaners since this might damage the stainless finish. If the stainless steel surfaces become
discolored, scrub by rubbing only in the direction of the finish grain. Never use vinegar or corrosive
cleaner. Do not use steel wool, steel wool may leave particles that can rust and cause pitting. To remove
the control knobs for cleaning, pull straight out. Wash in soapy water. Rinse, dry and replace on the shaft.
KEEP GRIDDLE PLATE SURFACE CLEAN. To produce evenly cooked, perfectly browned griddle
products, keep the griddle free of carbonized grease.
Carbonized grease on the surface hinders the transfer of heat from the griddle surface to food. This results
in spotty browning and loss of cooking efficiency; and, worst of all, carbonized grease tends to cling to the
griddled foods, giving them a highly unsatisfactory and unappetizing appearance. To keep the griddle clean
and operating at peak efficiency, follow these simple instructions.
After each use, clean the griddle with a wire brush or flexible spatula.
Each week, or whenever necessary, clean the griddle surface thoroughly. If desired, use a pumice or
griddle stone over the surface. Rub with the grain of the metal while still warm. A detergent may be used on
the plate surface to help clean it, but care must be taken to be sure the detergent is thoroughly removed.
After removal of the detergent, the surface of the plate should then be covered with a thin film of oil to
prevent rusting. Avoid steel wool. After each thorough cleaning, the cooking surface must be reseasoned.
8

CAPACITIES MODEL EGD48GB MODEL EGD72GB BOTH MODELS
CAPACITIES QTY/ APPROX QTY/ APPROX COOKING TIME &
LOAD PROD/HR LOAD PROD/HR TEMPERATURE
MEATS
Hamburgers 2.5oz 3.5”dia 65 945+ 86 1300+ 3 min. @ 350ºF
Minute steak 4 oz 1/2”th 24 360+ 32 400+ 4 min. @ 350ºF
Beef Tenderloin 5 oz 1”th 48 280+ 64 370+ 8 min. @ 360ºF
Liver 3 oz. 3/8” th. 36 450+ 48 600+ 3-4 min. @ 350ºF
Bacon 22 to 32 slices/lb 3.5lbs 30lbs 4.67lbs 40lbs 5-6 min. @ 350ºF
Pork Link Sausages
fresh 1.25 oz 3.5” long 12lbs 70lbs 16lbs 93lbs 10 min. @ 325ºF
Hot Dogs split 64 900+ 86 1200+ 3 min. @ 350ºF
Ham Steak 1lb 1/2” th 24 325+ 32 433+ 4 min. @ 350ºF
OTHER FOODS
Eggs, Fried 64 900+ 86 1200+ 3 min. @ 300ºF
Pancakes 4” diameter 40 450+ 53 600+ 3-4 min. @ 375ºF
Fried Potatoes blanched
Servings 51 750+ 68 1000+ 3 min. @ 375ºF
Fried Onions blanched
Servings 76 1100+ 103 1470+ 3 min. @ 340ºF
Hamburger Buns 3.5” dia. 32 600+ 43 852+ 2 min. @ 350ºF
TROUBLE SHOOTING GUIDE
PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
Unit Fails to
Operate
Temperature
Too Low
Temperature
Too High
No Power
Loose Connection
Open Circuit Breaker
or Fuse
Faulty Thermostat
Draft on Product
Set Point too Low
Thermostat Calibration
Incorrect
Heating Element
not Working
Faulty Thermostat
Set Point too High
Thermostat Calibration
Incorrect
Faulty Thermostat
Make sure the thermostat is set to a temperature and not turned
off.
Make sure the unit is connected to a live power source.
Place all of the thermostats in the “OFF” position and disconnect
power from the unit. WARNING: Failure to do so may result in
electrical shock. Check and tighten all connections.
Reset breaker or replace fuse.
Place all of the thermostats in the “OFF” position and disconnect
power from the unit. WARNING: Failure to do so may result in
electrical shock.
Replace thermostat.
Remove draft
Adjust the thermostat to the temperature desired.
Calibrate the thermostat using the procedure in this manual.
Place all of the thermostats in the “OFF” position and disconnect
power from the unit. WARNING: Failure to do so may result in
electrical shock. Replace heating element.
Place all of the thermostats in the “OFF” position and disconnect
power from the unit. WARNING: Failure to do so may result in
electrical shock. Replace thermostat.
Adjust the thermostat to the temperature desired.
Calibrate the thermostat using the procedure in this manual.
Place all of the thermostats in the “OFF” position and disconnect
power from the unit. WARNING: Failure to do so may result in
electrical shock. Replace thermostat.
COOKING CHART
9

If all of the above are correct and the unit still does not work, call an APW WyottAuthorized Service Agency.
NOTICE: Only a qualified technician who is experienced in and knowledgeable with the operation of this
electrical equipment should perform Service work. Contact the Authorized Service Agency for reliable
service, dependable advice or other assistance and for genuine factory parts.
A current listing of all authorizedAPW Wyott Authorized Parts and Service Distributors is included with this
unit. In the absence of this list, call the APW Wyott 24-Hour Service Hot Line at 1-800-733-2203. This will
give access to the nearest AuthorizedAPW Wyott Parts & Service Distributor.
WARRANTY WILL BE VOID AND THE MANUFACTURER IS RELIEVED OFALL LIABILITY IF:
1. Service work is performed by other than an APW Wyott Authorized Service Agency.
2. Other than Genuine APW Wyott replacement parts are installed.
CALIBRATION
Checking the Grill Thermometer:
1. Fill a meat pan with two inches of water and place it on the chili stove.
2. Place a half-size pan into the meat pan to float in the water.CAUTION HOT
3. Allow the water to come to a boil.
4. Place the thermometer in the half-size pan for five minutes.
5. The thermometer should read 212°F. at sea level. Subtract 1.8°F. for every 1000 feet above sea
level.
6. Adjust the thermometer according to the manufacturer’s instructions.
Calibrating the Grill:
1. Set the grill at the proper setting and allow to heat for at least one hour.
2. Place the grill thermometer directly over the sensing bulbs. (See “Sensing Locations”diagram on
following page). Measure off the grill according to the diagram. Use only these locations for
calibration points.
3. Make a note of the high temperature (when element light turns off) and the low temperature (when
the element light turns on). You can use the work sheet to write down the readings. Get a high and a
low reading for each of the sensing locations.
4. Add the high and low temperatures together for each sensing location and divide by two to get an
average.
5. If the difference between the high and low reading for any of the sensing locations exceeds 30°F.,
call a technician.
6. If the average temperature of a sensing location is within 10°F. of the proper temperature, no
adjustment is needed for that thermostat.
To Adjust a Thermostat:
1. Pull off the knob.
2. Use a small screwdriver to turn the set screw clockwise to decrease temperature, counterclockwise
to increase temperature. A quarter turn is equal to about 18°F. You may have to hold the shaft to
prevent it from turning while adjusting the set screw.
3. Check the high and low temperatures again. Adjust the set screw again if necessary.
4. When finished adjusting the set screw, put a drop of nail polish or appliance paint on the screw head
to keep it from turning.
5. Replace the knob.
6. For grills installed after 1979, there are calibration plates between the control panel and the
adjustment knobs. To adjust these thermostats:
A. Loosen the three screws that hold the calibration plate.
B. Hold the temperature adjustment knob and turn the calibration plate so the indicator arrow
lines up with the average temperature for that section of the grill.
C. Tighten the screws.
10
