APW Wyott X*WAV 1422 User manual

Phone: +1
Fax: [phone]
Toll Free: [phone]
Website: www.apwwyott.com
E-mail: [email protected]
[phone]
INSTALLATION
AND
OPERATING
INSTRUCTIONS
INTENDED FOR OTHER THAN HOUSEHOLD USE
Models: XWAV-1422, -1829, -1422EZ & -1829EZ
RETAIN THIS MANUAL FOR FUTURE REFERENCE
UNIT MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES
P/N 96000079 8/07
1
PASS THROUGH OVEN
APW WYOTT
729 Third Avenue
Dallas, TX 75226
This equipment has been engineered to provide you with year-round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
Initial heating of unit may generate smoke or fumes and must be done in a well ventilated area.
Overexposure to smoke or fumes may cause nausea or dizziness.
R
ANSI/NSF4
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance. !!
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury or death. Read the Installation, Operating and
Maintenance Instructions thoroughly before installing or servicing this equipment. !!
XWAV 1829EZ
XWAV 1422

2
1. OWNER’S INFORMATION
2. SAFETY INFORMATION
General Information:
General Operation Instructions:
Warranty Information:
Reliability Backed By APW Wyott’s Warranty:
Service Information:
1. Always clean equipment thoroughly before first use. (See general cleaning instructions).
2. Check rating label for your model designation and electrical rating.
3. For best results, use stainless steel counter tops.
1. All food-service equipment should be operated by trained personnel.
2. Do not allow your customers to come in contact with any surface labeled “CAUTION HOT”.
3. Never touch ceramic or steel heaters.
All APW Wyott Pass Through Ovens are backed by a one year parts and labor warranty, including On-Site
Service calls within 50 miles of authorized service technicians.
Service Hotline [phone]
APW Wyott equipment is designed, built and sold for commercial use and should be operated by trained
personnel only. Clearly post all CAUTIONS, WARNINGS and OPERATING INSTRUCTIONS near each
unit to insure proper operation and to reduce the chance of personal injury and/or equipment damage. This
product is used for the cooking, defrosting or re-thermalization of food products only.
Always disconnect power before servicing the unit. Surfaces will remain hot after power has been turned
off. Allow unit to cool before cleaning or servicing. Never clean the unit by immersing it in water. The unit is
not protected against water jets; DO NOT CLEAN PASS THROUGH OVEN WITH A WATER JET. Always
clean equipment properly before first use.
TABLE OF CONTENTS
SECTION ITEM PAGE SECTION ITEM PAGE
1 Owner's Information 2
2 Safety Information 2
3 Specifications 3
4 Installation Instructions 4
5 Operation 6
6 Cleaning 14
7 Troubleshooting 14
8 Preventative Maintenance 15
9 Wiring Diagrams 15
10 Parts List & Exploded View 24
11 Warranty 27
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
Model Number Serial Number Date Purchased
!
!
WARNING: In Europe, appliance must be connected by an earthing cable to all other units
in the complete installation and thence to an independent earth connection in compliance
with EN 60335-1 and/or local codes
!!
WARNING: An earthing cable must connect the appliance to all other units in the complete
installation and from there to an independent earth connection.

3
3. SPECIFICATIONS
OVERALL DIMENSIONS - XWAV-1422, -1829, -1422EZ & -1829EZ
AC
D
F
GH
I
J
K
L
B
E
Electrical Rating:
XWAV1422
XWAV1829
XWAV 1422EZ
XWAV 1829EZ
5400
5400
7200
7200
5500
5500
7000
7000
208
240
208
240
208
240
208
240
26.0
22.5
34.6
30.0
26.4
22.9
33.7
29.2
6-30P
6-30P
6-50P
6-50P
6-30P
6-30P
6-50P
6-50P
MODEL WATTS VOLTS AMPS (1 Phase) NEMA PLUG
Dimensions: INCHES (mm)
DIMENSION XWAV1422 XWAV 1829 XWAV1422EZ XWAV1829EZ
24.5 (622)
21.0 (533)
15.1 (385)
18.0 (457)
14.0 (356)
16.8 (425)
10.5 (267)
22.0 (559)
43.0 (1092)
3.8 (97)
18.0 (457)
4.0 (102)
A
B
C
D
E
F
G
H
I
J
K
L
28.0 (711)
25.0 (635)
19.1 (486)
18.0 (457)
14.0 (356)
24.1 (611)
10.5 (267)
29.5 (749)
50.5 (1283)
3.8 (97)
22.0 (559)
4.0 (102)
24.5 (622)
21.0 (533)
15.1 (385)
18.0 (457)
14.0 (356)
16.8 (425)
10.5 (267)
22.0 (559)
43.0 (1092)
3.8 (97)
18.0 (457)
4.00 (102)
28.0 (711)
25.0 (635)
19.1 (486)
18.0 (457)
14.0 (356)
24.1 (611)
10.5 (267)
29.5 (749)
50.5 (1283)
3.8 (97)
22.0 (559)
4.0 (102)

4
4. INSTALLATION INSTRUCTIONS
If the carton appears damaged, or damage is discovered once the carton is opened, stop
immediately and contact the freight company to file a damage claim.
damp
1. Remove all external packaging that is protecting top portion of unit.
2. Remove unit from shipping container while in the upright position. The unit can be lifted out of the
carton by grasping under the conveyor on each side of the appliance. Please remove the plastic
bag.
3. Remove all internal packaging to the unit.
Remove tape from
conveyor trays. Remove tape from extrusion corners. Remove tape from deflecting curtains
located just above entrance and exit of conveyor.
4. Visually inspect all external and internal portions of unit for damage.
To inspect these white ceramic elements, use a small mirror held under each element to
detect cracks.
5. Wipe down the exterior of the unit using a cloth with warm water. Do not use abrasive pads or
cleaners as they will damage the stainless steel surface and high temperature plastic.
NOTE: DO NOT USE CLEANERS OFANY KIND ON THE WHITE CERAMIC HEATERS.
6.
7. Place unit in operating location.
: Make sure that the operating location is in an area where the
ambient temperature is held constant (minimum 70°F). Please avoid areas such as near
exhaust fans and air conditioning ducts.
:
Ensure that operation location is at a reasonable distance from combustible walls and materials
otherwise combustion or discoloration could occur.
Important: Remove urethane supports located
inside the tunnel oven between the top heaters and the conveyor.
Important: Inspect the
top white ceramic elements located inside the oven tunnel after removal of urethane
supports.
Important: The Ceramic elements are fragile and will break under
stress. Do not twist, pull, push, or otherwise subject the white ceramic elements to
stress.
Remove four feet from box and install into threaded nuts located at the four corners underside of the
left and right housings; Also remove conveyor extension tray(s). Conveyor extensions should be
hung off end of conveyor frame. Model XWAV 1422EZ and XWAV 1829EZ will have two conveyor
extensions for loading and exit ends.
Stand-off/Air-divider located on rear panel is
important in maintaining proper division of inlet and exhaust air flow - If removed it could result in
improper functioning of unit and cause personal injury and void your warranty.
Note
Warning
Ambient Conditions -
Operating environment
MAY WILL
CAUTION: The Pass Through Oven is shipped assembled. The unit is shipped with
urethane supports between the top heaters and the conveyor assembly. Please remove
all urethane supports and packaging materials before operating the unit. Failure to
remove all packaging materials may lead to a fire and / or damage to the appliance. !
!
Shipping Weights:
115 lbs. (52.2 kg.) 149 lbs. (67.6 kg.) 115 lbs. (52.2 kg.) 149 lbs. (67.6 kg.)
XWAV1422 XWAV 1829 XWAV1422EZ XWAV1829EZ
Power Cord:
Six (6) foot, 3 wire grounded cord. If the supply cord is damaged, the manufacturer, or an authorized
service agent, must replace it in order to avoid a hazard and warranty. Please contact the factory by
calling the 800 # located on the unit.

Caution
Warning:
Warning:
:
Place unit on a stable, level counter at a convenient height for use. Turn the adjustable feet so
that unit is level to counter top. The top of the unit is not intended for use a shelf. Materials
placed there are at risk for fire.
8. Before plugging unit into wall, make sure that the switch is in the off position.
9. Ensure no hands, tools or parts or other unintended items are located on the conveyor
as injury will result when unit is turned on.
10. Plug unit into grounded electrical outlet with correct voltage, and plug configuration.
Using any receptacle that is not designed to match the attached cord and plug cause
personal injury and void your warranty.
Operating environment
MAY
WILL Please attach the XWAV1422/Medium Size unit,
208V, 5400W only, to an individual branch circuit.
Oven Stacking
Warning:
Warning:
Warning:
The stacking kit will consist of 4 corner posts to be inserted
between stacked units.
When stacking, unit must have proper
stacking kit installed. This will prevent overheating
and damaging of electrical components.
Do not stack more than three units tall or do
not use more than two stacking kits.
Standoff on rear panel of unit is important to
allow proper inlet and exhaust fan airflow. Do not
cover inlet or exhaust fan openings as this could
damage electrical components.
1. Ensure bottom unit is mounted on secure
surface, with feet installed.
2. Remove respective corner end caps and
screws. This will allow each of the stacking
spacer retaining fingers to slide into the
extrusions.
3. Remove the feet from the top unit as shown.
4. Secure each stacking spacer to the bottom of
the unit as shown by using the bolts and
washers provided. You should have four total
of each.
5. Once the stacking kit spacers are secure, place
top unit onto bottom unit. The stacking kit
spacers each have tapered guides to allow the
unit to lock into position.
6. Refer to Figure 1. Install rear support bracket
and screws as shown. Each stacking kit
requires that two brackets be mounted on the
backside only. One bracket near the strain
relief and one at the opposite end.
7. Refer to Cleaning Instructions for cleaning of
stacking spacers and cleaning between units.
FIGURE 1
Remove End
Caps & Screws
Before Installing Kit
Stacking Kit
#94000189
5

6
5. OPERATION
1. The controls that operate the belt conveyor and the heaters are located on the front of the unit.
2. A. (NON-EZ MODELS)
1.
The direction of the belt conveyor travel is controlled by a hidden rocker switch located
beneath the left side conveyor extension, behind a removable cover attached to the base
housing panel. To change belt direction, remove this cover, flip the rocker switch to the
opposite setting, and replace the cover. This operation can be performed while the belt is
moving.
4. A. The exterior metal surfaces of the unit will get hot enough to
cause burns. Avoid touching these surfaces to prevent injury.
B. (top heaters). The white ceramic
heaters located in the top of the unit operate at very high temperatures.
5. Two adjustable deflector shields are located at the inlet/outlet of the unit, above the conveyor belt.
These shields are designed to keep maximum heat inside the unit. Position the shields as needed
for product flow.
6. This oven has 3 heating zones, 2 on top, and a bottom one. The 2 top zones share the same
parameters (set point, probe offsets, etc.) The bottom zone is completely independent of the top
one.
The On/Off switch is used to turn the unit on or off. Once the unit is turned on the
conveyor will automatically run. Warning: Ensure no hands, tools or parts are
located on the conveyor as injury will result when unit is turned on.
2. The control display (oval keypad) is used to control top and bottom heat only. The control
settings allow for separate upper and lower zone control. The settings for upper and lower
zones are 1 through 15; 1 being coolest and 15 being hottest setting. (See control operation
below)
B. (EZ MODELS)
1.
3. Note: Before moving the On / Off switch to the “On” position, please read the following statements:
CAUTION: HOT SURFACES!
WARNING: SEVERE BURN HAZARD CERAMIC HEATERS
DO NOT TOUCH
HEATERS AFTER UNIT IS TURNED ON.
CAUTION HOT SURFACE!
Control Operation (NON-EZ MODELS):

B. Preheat Mode
C. Ready Mode
There are 4 keys: Bottom Zone, Top Zone, Up, and Down. There are also 5 status LEDs: 2 that indicate the
currently selected Zone; and 2 that indicate the zone Heater output state; and 1 for theAlarm conditions.
7. Operating Modes
· Unit powers up in this state
· Unit displays Lo and the active bottom and active top LEDs are on whenever the corresponding
zone output is active.
· A normal press of Bottom Zone key selects this zone (its LED lights up) and display shows its current
set point for 5 seconds
· A normal press of Top Zone key selects this zone (its LED lights up) and display shows its current set
point for 5 seconds
· Up and Down keys are used to change set point of current zone. Set point is displayed for 5 seconds
after last Up or Down key press, then normal display resumes. Default set points are defined in Low-
level parameters.
· Preheat state ends when top and bottom zones are within the Low Temperature threshold
defined in Low-level programming.
· Unit displays rdy and the LEDs are on whenever the corresponding
zone output is active.
· All keys work in the same fashion as for the Preheat mode
· Ready state ends when one of the top bottom zones fall below the Low Temperature threshold
defined in Low-level programming (unit then goes back to Preheat mode)
A. Display
active bottom and active top
both
or
Set point temperature is displayed as a range: 1, 2, 3,..., 14, 15. 1 corresponds to the lowest sensor
temperature and 15 corresponds to the highest sensor temperature.
The factory default setting is 8.
Once the settings are changed and the unit is turned off, these new settings will remain in memory
and appear in the display once the unit is turned on.
USER INTERFACE
Bottom Zone Selected
Active Bottom Zone
Top Zone Selected Active Top Zone
Up
Alarm
Down
Bottom Zone Top Zone
7

8. Special Features/Alarms
· Heater probe is disconnected or defective
· Normal user interface operation applies, but heater output remains inoperative
· Display flashesAlarm LED as well as an Alarm ID:
o AL1 for Zone 1 (Bottom probe)
o AL2 for Zone 2 (Top, probeA)
o AL3 for Zone 3 (Top, probe B)
· Alarm shuts down all outputs
· Probe must be replaced or re-connected to allow normal use
· Heater element is too hot, most likely due to external SSR that failed short
· Display flashesAlarm LED as well as an Alarm ID:
o AL4 for Zone 1 (Bottom probe)
o AL5 for Zone 2 (Top, probeA)
o AL6 for Zone 3 (Top, probe B)
· Alarm shuts down heater regulation.
· The alarm threshold temperature is Low-level programmable
· Algorithm:
o In normal use, if temperature ever goes above (set point + threshold), High Temperature
Error is immediately triggered.
o If set point is changed (lowered) by the user, the unit will look at the current temperature for 2
minutes and display HI. The peak temperature reached during this time is recorded.
o Thereafter, unit monitors the temperature until it reaches set point. During this cooldown
time, standard HI message is still displayed. User may change set point again, but 2-minute
timer is restarted (and old Peak value still applies.)
· During the cooldown time, if ever the temperature rises the previously recorded peak
temperature, High Temperature Error is triggered.
· Once set point is reached, rdy is displayed again.
· HI is displayed only if other zone is rdy or also HI. If other zone is Lo, then LH (low-high) is displayed
instead of HI.
A. Zone Probe Error
B. High Temperature Error
not
above
8

9
STATUS LIGHTS
CONTROL BUTTONS
5 - DIGIT DISPLAY
UP (INCREASE)
DOWN (DECREASE)
HEAT
RECIPE
ON/OFF
COOK TIME
a. The 5-digit display shows both letters and numbers, and is capable of scrolling messages.
In the Recipe Programming Mode (Section 6.3), a flashing arrow appears on the left side
pointing to the value being modified.
b. The status lights indicate what is happening to various areas of the unit:
1. Three “Heat Zone” lights show when heat is being added, Zone 1 being the bottom,
Zones 2 & 3 being the top. These lights also come on when pressing the “Heat”
button to see the current temperature of the zones.
2. The “Time” status light comes on when the cook-time is being viewed or modified.
3. The “Alarm” light indicates when an alarm condition exists.
4. The “Belt” light indicates if the belt is moving or not.
c. The Control buttons are used to make changes to various settings needed for recipes. They
also are used to view present settings of the current recipe being run.
1. The “Heat” button controls the heat values for top and bottom heaters.
2. The “R” (Recipe) is used to access the Recipe Programming Mode where
individual recipe parameters are entered, including belt speed, top heat, and bottom
heat.
3. The “I/0” button turns the controller ON/OFF. In the ON mode, the unit operates
according to the current recipe desired. In the OFF mode, the “Low-Level
Programming Mode” may be accessed. This is for Advanced Users Only.
4. The “Clock” button indicates cook time, and controls the belt speed.
5. The “UPARROW” button is used to INCREASE various settings, whether recipe
selections, belt speed, or heat.
6. The “DOWNARROW” button is used to DECREASE the same settings.
I/O
R
Control Operation (EZ MODELS):
NOTE
6. The Main ON/OFF rocker switch controls electric power to the electronic controller.
: If theALARM BUZZER should sound when the switch is turned ON, PRESS the I/0 button to
MUTE theALARM. The alarm condition still exists, but the buzzer is turned OFF.
a. In the OFF position ( 0 ), the digital display is blank, all functions are OFF. The rear
exhaust/cooling fans may run because they are controlled by thermostats.
b. In the ON position ( I ), the digital display will show the current state of operation:
1. OFF belt and heaters are OFF, or
2. REC “X” unit operating according to user-defined recipe settings: belt speed (cook-
time), and heat values (top & bottom); or
3. Scrolling message of importance, stating action needed to continue proper
operation.
7. The Control Panel of the controller is shown below, and consists of a large 5-digit display, 6
rectangular status lights, and 6 control buttons with indicator lights

8. Control Operating Modes
There are 4 Modes of operation with this appliance:
1. OFF
2. HEAT (normal Mode)
3. RECIPE PROGRAMMING
4. ALARM
Because each Mode is capable of several functions, careful study should be given to their details to
maximize appliance utility. The Programming Mode should only be accessed by an
authorized, advanced user or Service Professional.
This Mode allows three (3) functions:
a. LOCKing / UNLOCKing of the control buttons (keypad). When the keypad is LOCKED, the
temperature set points, cook-time, and recipe changes are no longer accessible to the user.
All other functions operate normally, including recipe selection.
1. To change the current state to the other, PRESS the UP button for 5 seconds. The current
state will be displayed.
2. PRESS the UP button immediately a second time for 5 or more seconds. This will change the
state to the opposite value.
3. If the second PRESS is not done properly, the original state will remain.
b. LANGUAGE Selection
1. PRESS the HEAT button for 5 seconds to view the present Language setting: ENGLISH or
ESPANOL.
2. Use the UP or DOWN arrow to select the desired language.
3. DO NOT press anything for 5 seconds and the new selection is retained.
4. The following messages are available in both languages:
a. (APAGADO)
b. (BLOQUEADO)
c.
d.
(SOBRECALENTAMIENTO ZONA LLAMADADE SERVICIO)
e.
(FALLA SENSOR LLAMADA DE SERVICIO)
IF the display reads OFF, PRESS the I/0 button to Enter this Mode. PRESS the I/0 button again to Exit
this Mode.
This Mode allows seven (7) functions:
a. Recipe Selection. Use the UP/DOWN buttons to toggle to the next recipe. The display will show
the current recipe selection as “REC 1”, “REC 2”, etc. (NOTE: This is the Default display setting.)
b. Heat Regulation. As the recipe requirements dictate, the controller supplies power to the
various heat zones. When there is a Call For Heat in any Heat Zone, the status light of the
respective Zone will be illuminated. NOTE: Top heaters are regulated independently of the
Bottom heater.
c. Temperature Setting Viewing. PRESS and HOLD the HEAT button repeatedly to see the current
temperature of Zones 1,2,3 in succession. (Zone 1 = Bottom, Zone 2 = Top Left, Zone 3 = Top
Right).
LOW-LEVEL
1. Off Mode (display Reads Off)
OFF
LOCKED
UNLOCKED (DESBLOQUEADO)
ZONE OVERHEAT CALL FOR SERVICE
PROBE FAILURE CALL FOR SERVICE
2. Heat Mode (normal Mode of Operation)
10

11
d. Temperature Setting “Tweaking”. This feature allows “1-time” adjustments to temperature
settings that will be lost when a new recipe is selected.
1. and HEAT button for 10 seconds. A flashing arrow appears on the left side of
the display, pointing to the value that is now available for “tweaking”.
2. Use the UP & DOWNARROWs to adjust the values to new settings.
3. Successive PRESSes of the HEAT button jumps to the next Temperature Zone, where these
settings may now be “tweaked”.
“Tweaked” temperature settings remain good as long as the recipe is unchanged.
When a new recipe is selected, “tweaked” settings are lost.
e. Cook-time Regulation. As the recipe requirements dictate, the controller monitors and adjusts
the belt speed to achieve the desired cook-time.
f. Cook-time Viewing. PRESS and HOLD the Clock button to see the current cook-time setting
(belt speed).
0.30 = 30 seconds; 3:45 = 3 minutes, 45 seconds, etc.
Factory default minimum and maximum cook-times are set at 30 seconds (1422), 38
seconds (1829) and 10:00 minutes (both 1422 and 1829).
g. Cook-time “Tweaking”. This feature allows “1-time” adjustments to cook-time settings that will
be lost when a new recipe is selected.
1. and button for 10 seconds. A flashing arrow appears on the left side
of the display, pointing at the value that is now available for “tweaking”.
2. Use the UP & DOWNARROWs to adjust the values to a new setting.
“Tweaked” cook-time settings remain good as long as the recipe is unchanged. When a
new recipe is selected, “tweaked' settings are lost.
This Mode allows the user to set the temperature and cook-time values for every recipe that is desired.
There are a maximum of 20 recipes that can be programmed by the user. Recipe are not
programmable.
All values entered into recipes remain saved in memory and when the unit is turned
.
The controller starts at Recipe 1 every time the unit is turned . This cannot be modified.
This Mode allows three (3) functions:
a. Bottom Heat (Zone 1) temperature setting.
1. and the (Recipe) button for 5 seconds. A flashing arrow appears
on the left side of the display, pointing at the value that is now ready for programming.
2. Use the to adjust the values to the new temperature setting.
For accelerated scrolling, the button down.
3. for 5 seconds and the new value is saved in memory.
PRESS HOLD
NOTE:
NOTE: COOK-TIME is defined as: “The time required for the product Leading Edge to
Enter and Exit the Cook Zone”. COOK-TIME leading Edge IN to Trailing
Edge OUT. There is an important difference and should be understood by the operator.
NOTE:
NOTE:
PRESS HOLD CLOCK
NOTE:
3. Recipe Programming Mode
NAMES
ARE NOT LOST
OFF
ON
PRESS HOLD R
UP & DOWN ARROWs
HOLD ARROW
DO NOTHING
DOES NOT MEAN

12
b. Top Heat Zones [2 (left side, top) & 3 (right side, top)] temperature setting. Duplicate steps
for Bottom Heat setting.
Zones 2 & 3 are tied together (internal software coding) and CANNOT be set at different
values.
c. Cook-time setting.
1. Using the arrow buttons, scroll up or down to the recipe that you wish to change.
2. and the button for 5 seconds.
3. and button for 5 seconds, until a flashing arrow appears on
the left side of the display, pointing at the value that is now ready for programming.
4. Use the s to adjust the value to the new cook-time setting.
5. for 5 seconds and the new value is saved in memory.
If the s are not ed within 15 seconds of when the flashing
arrow appears, the controller jumps out of Recipe Programming Mode and retains the previous
recipe values.
: These same steps must be repeated for each recipe. After each recipe is programmed,
the display returns to display . Use the arrow to jump to the next recipe
and repeat the process as described above.
This Mode alerts the operator to situations that the controller has detected as faulty operation that
needs attention.
An starts beeping loudly when such a situation is detected. the I/0 button to
the . The alarm condition still exists, the ALARM status light continues to flash, but the
buzzer is cancelled.
Alarm conditions are in two (2) categories: (a) Temperature Probe Failure; (b) Overheat Conditions.
a. Temperature Probe Failure.
Whenever any of the three temperature probes fail (2-top, 1-bottom), the controller alerts the
operator (loud buzzer beeping). Only when the alarm condition has been fixed will the
buzzer not sound when the unit is turned ON via the I/0 button.
The controller automatically responds to such conditions, depending on which type of failure
has occurred. Responses are as follows:
1. Scrolling message on the display:
2. The affected zone status light flashes.
3. If either of the Top probes has failed, the controller continues to regulate top heat as if
nothing had happened. This is because each probe is a redundant item for the other. With
one probe input invalid, the controller reads the other input as valid.
4. If both Top probes should fail, the controller reverts to a preset “duty cycle” program that
allows a reduced amount of top heat to be generated. Since there is no reliable top probe
input, the controller controls power to the heaters on an percentage basis, such
as 66% time , 33% time . This is done to prevent a possible “Overheat” condition,
since there is now no reliable means to sense an Top overheat condition.
NOTE:
PRESS HOLD R (RECIPE)
PRESS HOLD CLOCK
UP & DOWN ARROW
DO NOTHING
NOTE: UP & DOWN ARROW PRESS
NOTE
REC “X” UP & DOWN
4. Alarm Mode
ALARM BUZZER PRESS
MUTE BUZZER
PROBE FAILURE CALL FOR SERVICE.
“ON/OFF”
ON OFF
A qualified service
professional should replace the faulty probe for proper operation to resume.

5. If the Bottom probe should fail, the controller reverts to a preset “duty cycle” program
similar to the dual-Top probe failure mentioned above.
Anormal operator response may be as such:
1. the I/0 button to the buzzer.
2. The scrolling message goes away.
3. The status light stays illuminated.
4. All other functions continue as normal:
a. Display shows current recipe selection. Recipe selection is still possible.
b. Belt moves and belt status light is illuminated.
c. Heat Zone status lights will be dark.
5. If the button is pressed to view current temperatures, the unaffected zones will
display their current temperature, but the affected zone(s) will scroll the
message, without any beeping buzzer.
b. Overheat Conditions.
Overheat conditions result from excessive power being applied to the heaters. Such situations
usually arise from a solid-state relay that has failed , of which there is one for each heat
zone (three total). However, over-voltage conditions can also cause excess heat, even though
the relays are OK. Therefore, it is necessary to properly trouble-shoot such conditions to
correctly identify the problem.
The maximum allowable temperature is programmable in the
Mode, and is factory set at 1100°F (593°C).
The controller automatically responds to such conditions as follows:
1. Scrolling message on the display:
2. Alarm status light is illuminated.
3. By shutting power to heaters until Overheat condition resolved.
Anormal operator response may be as such:
1. the I/0 button to the buzzer.
2. The scrolling message goes away.
3. The status light stays illuminated.
4. All other functions continue as normal:
a. Display shows current recipe. Recipe selection is still possible.
b. Belt moves and belt status light is illuminated.
c. Heat Zone status lights will be dark.
5. If the button is pressed to view current temperatures, the unaffected
zones will display their current temperatures, but the affected zone(s) will scroll the
message, without any beeping buzzer. (Since there is no power going
to the heaters, the temperatures should be lower than normal, a failed
relay is continuing to power the heater(s).
NOTE:
PRESS MUTE
PROBE FAILURE
ALARM
HEAT
PROBE
FAILURE
NOTE: If unexpected smoke should appear around the unit during an Overheat Alarm
condition, turn the Main Switch OFF.
CLOSED
LOW-LEVEL PROGRAMMING
TEMPERATURE ZONE OVERHEAT - CALL FOR
SERVICE.
OFF ALL ALL
NOTE:
PRESS MUTE
OVERHEAT
ALARM
HEAT
OVERHEAT
UNLESS
NOTE: In either case where the unit is in a “duty cycle” mode, the operator can still use the
unit until service is performed to correct the failure. However, the reduced heat value will
affect the output capacity of the unit.
A qualified technician should make any needed repairs.
13

7. TROUBLESHOOTING
Always ask and check the following:
Not getting power:
Conveyor not working (EZ MODELS):
YES
NO
1. Is the unit connected to a live power source of the proper voltage?
2. Check the rating label. Is the unit connected to the correct power source?
3. Check the circuit breaker.
4. Is power switch “ON” and led displaying information?
5.
1. Please refer to “Not getting power” section.
2. Check belt for obstructions. Belt may be jammed.
3. Reverse belt direction to check for belt jam - locate Reversing Switch on left side, beneath conveyor
frame, hidden by removable cover. Remove cover, flip switch, and note if belt begins to move
backwards. Does belt move backwards?
4. If , then clear belt jam and reset belt direction via Reversing Switch.
5. If , then call your local service agent.
6. Note: At slower settings the conveyor moves very slow and may appear stalled, which is not the
case.
7. If the above checks out, and you still have problems, call your local service agent.
If the above checks out, and you still have problems, call your local service agent.
1. Please refer to “Not getting power” section.
2. Is the knob turnedto correct setting per desired speed?
3. Note: At slower settings the conveyor moves very slow and may appear stalled, which is not the
case.
4. If the above checks out and you still have problems, call your local service agent.
Conveyor not working (NON-EZ MODELS):
14
6. CLEANING
Insure the appliance has been turned off and has had sufficient time for all surfaces to cool down before
cleaning. Use only mild soap and water to clean this appliance. Appliance cleaning should be performed
daily.
DO NOT USEABRASIVE PADS OR CLEANING SOLUTIONS ON THISAPPLIANCE.
Remove the crumb pans and wipe out debris with a damp rag and mild soap solution.
Remove the deflector panels located at the entrance and exit of the oven tunnel. Wipe down the
area under the deflector panels, and the deflector panels, with a damp rag and mild soap. Reinstall
the deflector panels by reversing the procedure used to remove them.
Using a damp rag with mild soap and water, wipe down the exterior surfaces of the appliance.
Using a damp rag with mild soap solution, wipe down all areas of the conveyor. DO NOT ATTEMPT
TO CLEAN THE UPPER WHITE CERAMIC, OR LOWER METAL HEATERS.
When units are in the stacked configuration, it is still necessary to clean between the units. Using a
damp rag with mild soap and water, wipe down the tops and undersides of all units. Ensure there
are no foreign objects between the units that could catch fire.
Using a damp rag with mild soap and water, wipe the surfaces of the stacking spacers on all four
corners.
NOTE:
Daily Cleaning
!
!
!
!
!
!

!
!
!
!
!
!
!
Please follow the cleaning section for the daily preventative maintenance schedule.
DO NOT USE ABRASIVES OR CLEANING SOLUTIONS ON THIS APPLIANCE.
Routinely check before every operation that adequate distance is allowed between fans and
anything that would possibly allow foreign debris or substances to be taken in by inlet fan.
Clean fan guards on a daily basis to ensure proper inlet cooling to electrical components and
efficient hot air exhaust.
On a daily basis make sure side walls of tunnel oven remain clean to assist in maintaining even
cooking around product. Be careful not to bump or hit the upper ceramic heaters when wiping
down.
Ensure belt is properly tensioned as to prevent slippage or binding, which causes strain on
motor.
DO NOT ATTEMPT TO MAINTENANCE, SERVICE OR CLEAN THE UPPER CERAMIC AND
LOWER METAL HEATERS.
8. PREVENTATIVE MAINTENANCE SCHEDULE
15
Food not cooking properly:
1. Please refer to “Not getting power” section.
2. Are the controller and speed control adjusted to the desired setting?
3. Are the deflector curtains in the proper position?
4. If the above checks out, and you still have problems, call your local service agent.
9. WIRING DIAGRAMS/SCHEMATICS
OVERHEAD XWAV1422
(NON-EZ MODELS)
OVERHEAD XWAV1829
(NON-EZ MODELS)
RTD 2
RTD 3
9
10
11
12
11
12
13
14 14
13 15
16
16
REAR HEATERS ZONE 3
FRONT HEATERS ZONE 2
10
9
RTD 2
15
16
RTD 3 To: Controller AN3
RTD 2 To: Controller AN2
To: Terminal Block
To: Terminal Block
To: Relay
To: Relay
10
RTD 2
RTD 3
REAR HEATERS ZONE 3
FRONT HEATERS ZONE 2
16
RTD 2
15
13 13
14 14
11 11
12 12
15
16
10
9
9
RTD 3 To: Controller AN3
RTD 2 To: Controller AN2
To: Terminal Block
To: Terminal Block
To: Relay
To: Relay

BL GROR
MOTOR SPEED POT. POWER SWITCH
ESCUTCHEON
29 30
TO CONTACTOR "A1 " TO POWER SUPPLY
6PIN-RED
TO SPEED MOTOR-BLUE
TO SPEED MOTOR-GREEN
TO SPEED MOTOR-ORANGE
16
UNDER CARRIAGE (NON-EZ MODELS)
L2
L1
L2
L1
L1
L2
T.STAT
1
1
2
5
5
GR
2
26
26
T.STAT
POWER CORD L1= BLACK L2= WHITE
2
TO: POWER SWITCH
LEFT SIDE HOUSING
(NON-EZ MODELS)
RIGHT SIDE HOUSING
(NON-EZ MODELS)
TO 3 POLE TERMINAL BLOCK TO 2 POLE TERMINAL BLOCK
TO 2 POLE TERMINAL BLOCK
24
7
5
2
RED
7
24
28
28
29
CONTACTOR
A2 A1
T1/2 T2/4
T3/6
14
22 21/NC
13/NO
5/L3
3/L2
1/L1
22
GR
OR
RED
BLACK
BLACK (-)
ORANGE(+)
GREEN (-)
5/24V DC
OUTPUT
208 V
MOTOR
BL
1. ORANGE
2. WHITE
3. BLUE
4. RED 5. GREEN 6. BLACK
RED (+)
6. BLACK 5. OPEN
4. RED
3. BLUE
2. WHITE
1. OPEN
FEMALE TERMINAL
MALE TERMINAL
94100134
94200093
94000172
TO: POW ER SWITCH
TO 3 POLE TERMINAL BLOCK
29
TO: POWER SWITCH
MOTOR SPEED
POT
BLUE
GR
OR
Motor wiring for left to right configuration of
conveyor belt non-reversable switch

+-
---
+++
SSR1
SSR2
SSR3
(1) BOTTOM ELEMENT
TOP ELEMENTS
Note: 1417 = (5) Top Elements
1422 = (6) Top Elements
1829 = (8) Top Elements
SOLID-
STATE
RELAYS
R1
R2
R3
OUTPUTS
ECM-3 DIGITAL
TEMP CONTROL
INPUTS
ZONE 1
RTD BTM
ZONE 2
RTD TOP
ZONE 3
RTD TOP
C1 C1
CONVEYOR
SPEED POT
MAIN SWITCH
M1
C1
POWER SUPPLY
85 - 265 VAC INPUT, 1~
24 VDC / 5 VDC OUTPUT
TO REVERSE DIRECTION
OF CONVEYOR BELT,
CONNECT / DISCONNECT
WHITE WIRE TO TERMINAL
“A2” ON CONTACTOR.
TEMPERATURE SWITCHES
L1 L2
A2A1
C1 BRUSHLESS
MOTOR
WHITE
CONTACTOR COIL
BLUE
GREEN
ORANGE
TOP FAN
EXHAUST
BOTTOM FAN
COOLING
XWAV LADDER SCHEMATIC (NON-EZ MODELS)
17

XWAV 1422EZ POWER SUPPLY WIRING DIAGRAM 208 or 240VAC, 1 PH, 50/60 HZ
NOTE: Top & Bottom Heaters are either 208V or 240V, and must match power supply voltage.
208 or 240VAC, 1 PH, 50/60 Hz
Power Supply, 5500 Watts
18
13 N.O . 5L3 3 L2 1 L1
14 6T3 4T2 2T1 N.O .
ZONE1 ZONE 2 ZONE 3
ALAR M
TIME
BELT
HEAT ON / OF F
RECIPE COOKTIME
ZONE 1 SSR ZONE 2 SSR ZONE 3 SSR
-DC+ -DC+ -DC+
1
2 3
24 VDC OUT
208- 240 VAC IN
TOP TOP HEAT HEAT ZONE 2 ZONE 3
PRODUCT FLOW
RED
BLK
BLU
WH
L2/N
L1
G
L1-BLACK
L2-WHITE
L1 L2
ECM-3 CONTROLLER
CONTACTOR 24VDC COIL
MOTOR SIGNAL
PROCESSOR
CONTACTOR
CONVEYOR MOTOR
24VBLDC
REAR FANS
FAN THERMOSTAT FAN THERMOSTAT
MOTOR POWER SUPPLY
RTD PROBE
RTDPROBE
BELT
REVERSE
SWITCH
MAIN
ON / OFF
SWITCH
ZONE 1 - BOTTOM HEAT USER INTERFACE
KEYPAD
CABLE
RTD PROBE
YEL
WH
BLK
A2- COIL A1+
YEL
YEL RED RED
BLK
19 20 21 22
326816899
23
30
-24VDC BLK -24VDC WHITE
+24VDC RED
WH
25
6
25
6
24
7
7
24 6
25
WH
2
27
1
55
55
2
22
5
7
24
7
24
RED
RED
18
17
18
17
17
YEL
YEL
P16 -
P16 -
P20 +
P20 +
23
23
RED +
BLK -
--- +++
15
16
16
15
10
10 10
14 13 12 11
99
3
26
3
26
3
26
15
20 +
19 - 21 _ 22 + -
+
AN3
AN1
AN2
120
208
240
SELECT VOLTAGE JUMPER
28
44
30
29
4
28
28
COM
N.O.
AC
RELAY
23
29
29 29
6-30P
BLACK
RED
BLACK RED

19
XWAV 1422EZ LADDER WIRING SCHEMATIC
L1 L2
TOP FAN
EXHAUST
BOTTOM FA N
COOLING
THERMOSTATS
POWER SUPPLY
85 - 265 VAC, 1~ INPUT
24 VDC OUTPUT
MAIN SWITCH
CONTACTOR COIL
BRUSHLESS
MOTOR
C1
M1
C1
+-
A1 + A2 -
ECM-3
ELECTRONIC
CONTROLLER
---
+++
ZONE 1
RTD BTM
ZONE 2
RTD TOP
ZONE 3
RTD TOP
SOLID-
STATE
RELAYS
R3
R2
R1
C1 C1
SSR 3
SSR 2
SSR 1 (1)BOTTOMELEMENT
( 6 ) TOP ELEMENTS
ANALOG INPUTS
HI-VOLT AC IN
LOW-VOLTAGE DC I/O
HI-VOLT AC OUT
R
MSP
+-
+5VDC
MOTOR SIGNAL
23
18
5
24
6
P20 + RED
P16 - YEL
YEL BLU
R
BLK
25
4
20 19
21
22
2
7
329
26 16
8911
9
11
13
16
13
30
14
15
14
12
10
12
WH
BELT
REVERSING
SWITCH
17
BLK
28

20
XWAV 1829EZ POWER SUPPLY WIRING DIAGRAM 208 or 240VAC, 1 PH, 50/60 HZ
13 N.O. 5L3 3L2 1L1
14 6T3 4T2 2T1 N.O .
ZO NE 1 ZON E 2 ZONE 3
ALARM
TIME
BELT
HEAT ON / OFF
RECIPE COOKTIME
ZONE 1 SSR ZONE 2 SSR ZONE 3 SSR
-DC+ -DC+ -DC+
1
2
3
24 VDC OUT
208- 240 VAC IN
TOP TOP HEAT HEAT ZONE 2 ZONE 3
PRODUCT FLOW
RED
BLK
BLU
WH
L2/N
L1
G
L1
L2
L1 L2
ECM-3 CONTROLLER
CONTACTOR 24VDC COIL
MOTOR SIGNAL
PROCESSOR
CONTACTOR
CONVEYOR MOTOR
24VBLDC
REAR FANS
FAN THERMOSTAT FAN THERMOSTAT
MOTOR POWER SUPPLY
RTD PROBE
BELT
REVERSE
SWITCH
MAIN
ON / OFF
SWITCH
USE INTERFACE
KEYPAD
CABLE
RTD PROBE
YEL
WH
BLK
A2-
COIL
A1+
YEL
YEL RED
RED
BLK
19 20 21 22
326816899
29
29
-24VDC BLK -24VDC WHITE
+24VDC RED
WH
25
6
25
6
24
7
7
24 6
25
WH
2
27
1
55
55
2
22
5
7
24
7
24
RED
RED
17
18
17
18
17
YEL
YEL
P16 -
P16 -
P20 +
P20 +
29
29
RED +
BLK -
--- +++
15 16
16
15
10
10 10
14 13 12 11
99
3
26
3
26
3
26
15
SPLICES
20 +
19 - 21 _ 22 + -
+
AN3
AN1
AN2
120
208
240
SELECT VOLTAGE JUMPER
30 30
28
4
28
30
23
23
30
4
28
2 8
RTD PROBE
COM
N.O.
AC
RELAY
6-50P
23
31
32
ZONE 1 - BOTTOM HEAT
NOTE: Top & Bottom Heaters are either 208V or 240V, and must match power supply voltage.
208 or 240VAC, 1 PH, 50/60 Hz
Power Supply, 7000 Watts
