Aqara Hub M2 User manual

Aqara Hub M2 Quick Start Guide · 01
Hub M2使用說明書 · 11
Bedienungsanleitung des Hub M2 · 17
Manuale di istruzione del Hub M2 · 25
Manual de usuario de Hub M2
Mode d’emploi pour Hub M2
· 33
· 41
Руководство пользователя Hub М2 · 50
Hub M�取扱説明書 · 59
허브 M2사용설명서 · 67

* This product is for indoor use only.
Product Introduction
The Aqara Hub M2 is a smart home control center. It can be connected with a WiFi or Ethernet
network, and supports interaction and connection with Aqara Zigbee accessories. It also has an
IR remote control function, which can add and manage the control of different IR devices. The
Aqara Hub M2 allows you to control your Aqara accessories more conveniently.
Indicator light
Button
LAN Port Micro-B
Power Port
USB Type A Port
(Reserved)
Infrared emission area Infrared receiving area
01

02
Search for "Aqara Home" on the app store (Apple Store , Google Play ,Huawei App Gallery etc) or
scan the QR code. Download and install the Aqara Home app.
Quick Setup
1. Download the app
Choose the installation location of the hub: the hub should be 2-6 meters away from the
router in the house, and avoid metal obstacles between the hub and the router or around the
hub.
2. Set up the hub
2m~6m
1

03
* If you need to use wired network communication between the hub and the router, please use a network cable
with RJ45 network port to connect the LAN ports of the hub and your router, and wait for the orange and green
lights on the side of the network port to light up.
Power the hub on: please use the 5V-1A or 5V-2A adapter (purchase it separately) and the USB
power cable to power the hub on.
2

04
Wait for the yellow/red hub indicator light to change from always on to flashing.
Make sure that the mobile phone is connected with the 2.4GHz Wi-Fi network.
3
4
*
*
If you use a dual-band router, please make sure your phone is connected with 2.4GHz Wi-Fi or disable 5GHz Wi-Fi.
Keep your phone close to the hub and make sure both of them are connected with the same Wi-Fi network.
* For iOS users, if you want to realize Apple HomeKit control, please scan or manually enter the HomeKit Setup
Code (keep the code in a safe place in case you need to add it again) on the bottom of the hub or on the manual
according to the app instructions during the hub adding process, and bind the hub to HomeKit. Aer it is bound
successfully, you can view the added hub in Apple Home app.
Please open the Aqara Home app, click “+” in the upper right corner, select “Hub M2” and
follow the instructions to complete adding the hub.
If you fail to add the hub, please press the button on the hub for more than 10 seconds until
the yellow/red light flashes quickly, and then add it again. If you need any help, please
contact www.aqara.com/en/support.html.
5
6
*
*
*
*
*
*
Please make sure the device is connected with the 2.4GHz Wi-Fi network.
Wi-Fi name or password may contain special characters. Please replace them with ordinary characters and try
again.
The device does not support the WAP/WAP2 Wi-Fi network.
Please check whether the router turns on the Wi-Fi connection watcher function, which causes network
connection failures.
Please check whether the router turns on the AP isolation function, which causes the phone to not be able to
search for the hub within the LAN.
It is recommended not to connect it to a bridge network.
If the device could not be added, please follow these steps:

05
*
*
*
”Failed to add accessory”. Due to multiple adding failures, the error information of iOS cache cannot be removed.
Please restart the iOS device and reset the hub.
”Accessory already added”. Aer restarting the iOS device and reset the hub, you can manually enter the HomeKit
setup code and add it again.
”Accessory not found”. Please wait for 3 minutes aer resetting the hub. You can manually enter the HomeKit setup
code and add it again.
Trouble adding to HomeKit :
3. Device Operations
Add an accessory: aer the hub is successfully added, please refer to the accessory
installation guide to add an accessory.
Control IR home appliances: please configure the brands and models of the IR home
appliances you need to control in the app according to the app guidelines, and then perform
the corresponding app control and automation control.
1
2
4. Restore to Factory Settings
Quick press the button on the hub ten times.

06
Indicator Light Description
Light Color Description
Yellow/Red
Aer the hub powers on, the system is starting up.
The hub enters the initialization status, waiting for
network connection; Flashing appears aer the first
use or within fieen minutes aer the reset
Light Status
Steady on
Flashing
Blue
Wi-Fi is connecting; the hub is connecting to the
network.
Working normally
White The hub enters the network connection failure
status; only aer you power the hub on/off or reset
the hub, it can enter the status to wait for the
network connection
Purple The hub is allowed to add accessoriesFlashing
Steady on
Flashing
Steady on
Flashing
Wi-Fi is connecting; app is connecting to the hub;
the network is down; the hub is reconnecting to the
network aer it is powered off and on
*Due to updates to the device firmware, the actual operation may be slightly different from the above description.
Please follow the instructions in the current version of the Aqara Home app or operate the device according the
actual device status.

Specifications
Model: HM2-G01
Dimensions:φ100.5×30.75mm(φ3.95×1.21 in.)
Input Power: 5V 1A or 5V 2A
Wireless Protocol: Wi-Fi IEEE 802.11 b/g/n 2.4GHz, Zigbee3.0 IEEE 802.15.4, BLE 5.0
Operating Temperature: -5°C~+50°C(23°F~122°F)
Operating Humidity: 0%-95%RH, no condensation
Support System: Android 6.0 or iOS 12.0 and above
Wi-Fi Operation Frequency: 2412-2472 MHz
Wi-Fi Maximum Output Power< 20 dBm
Bluetooth Operation Frequency: 2402-2480 MHz
Bluetooth Maximum Output Power< 13 dBm
Zigbee Operation Frequency: 2405-2480 MHz
Zigbee Maximum Output Power < 13 dBm
Notice
CommunicationbetweeniPhone,iPad,AppleWatch,HomePod,orMacandtheHomeKit-
enabled Aqara Hub M2 issecuredbyHomeKittechnology.
AcustomerwhoownsanAppleTV(4thgenerationorlater)withtvOS10orlater,aniPadwithiOS
10orlater,oraHomePodcancontrolHomeKit-enabledaccessoriesawayfromhomeand
automaticallythroughtriggerssuchastimeofday,location,sensordetection,ortheactionofan
accessory.
UseoftheWorkswithApplebadgemeansthatanaccessoryhasbeendesignedtowork
specificallywiththetechnologyidentified inthebadgeandhasbeencertifiedbythedeveloper
tomeetAppleperformancestandards.Appleisnotresponsiblefortheoperationofthisdevice
oritscompliancewithsafetyandregulatorystandards.
07

FCC ID: 2AKIT-HM2-G01
Federal Communications Commission (FCC) compliance statement:
1. This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
RF Exposure statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of 20
cm between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
08

IC: 22635-HM2G01
IC NOTICE TO CANADIAN USERS
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to
the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
This device complies with RSS-247 of Industry Canada. Operation is subject to the condition that
this device does not cause harmful interference.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of 20
cm between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1)L'appareil ne doit pas produire de brouillage;
(2)L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Cet appareil numérique de la Classe B conforme à la norme NMB-003 du Canada.
Cet appareil est conforme à la norme RSS-247 d'Industrie Canada. Le fonctionnement est
soumis à la condition que cet appareil ne provoque pas d'interférences nuisibles.
Cet équipement est conforme aux limites d’exposition aux rayonnements de la IC établies pour
unenvironnement non contrôé. Cet équipement doit être installé et fonctionner à au moins
20cm de distance d’un radiateur ou de votre corps.Cet émetteur ne doit pas être co-localisé ou
fonctionner en conjonction avec une autre antenne ou un autre émetteur.
09

10
Hereby, [Lumi United Technology Co., Ltd.] declares that the radio equipment type
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by [Lumi United Technology Co., Ltd.] is under license. Other
trademarks and trade names are those of their respective owners.
Under normal use of condition, this equipment should be kept a separation distance of at least
20cm between the antenna and the body of the user.
EU Declaration of Conformity
All products bearing this symbol are waste electrical and electronic equipment (WEEE
as in directive 2012/19/EU) which should not be mixed with unsorted household
waste. Instead, you should protect human health and the environment by handing
over your waste equipment to a designated collection point for the recycling of waste electrical
and electronic equipment, appointed by the government or local authorities. Correct disposal
and recycling will help prevent potential negative consequences to the environment and human
health. Please contact the installer or local authorities for more information about the location
as well as terms and conditions of such collection points.
WEEE Disposal and Recycling Information
[Hub M2, HM2-G01] is in compliance with Directive2014/53/EU. The full text of the EU declaration
of conformity is available at the following internet address: https://www.aqara.com/DoC/

產品介紹
Aqara Hub M2是智能家庭控制中心，支持WiFi或者以太網網絡接入；支持和Zigbee子設備
進行互聯互通；具備紅外外能遙控器功能，可以添加和管理不同的紅外設備的控制。讓你更
加便捷的控制插座，燈泡，窗簾，空調，風扇等。
*本產品僅限室內使用。
指示燈
按鍵
LAN接口
紅外發
射區域
紅外接
收區域
Micro-B
電源接口
USB Type A
接口（預留）
11

快速設定
在應用商店中搜索“Aqara Home”或者掃描以下二維碼下載“Aqara Home”app。
1、下載客戶端
選擇Hub安裝位置：Hub最好離家中路由器2-6米左右，Hub和路由器之間以及Hub周圍
避免出現金屬遮擋物。
2、設定Hub
2m~6m
12
1

給Hub接通電源：請使用5V-1A或5V-2A轉接器（需要您單獨準備）和USB電源線給Hub接
通電源。
等Hub指示燈從黃燈/紅燈常亮變為黃燈/紅燈閃爍。
*如果需要Hub和路由器之間使用有線網路通訊，請使用帶RJ45網口的網線將HubLAN口和你的路由器LAN
口連接起來，並且等待網口側的柳丁綠兩顆燈亮起。
13
2
3

確保手機已經連接2.4GHz頻段段Wi-Fi網絡。
如果設備添加失敗，請確認以下幾點:
打開Aqara Home app，點擊首頁右上角“+”，選擇“Hub M2”，並且依照app訓示進行操
作。
如添加失敗，請將按Hub重置按鍵10S以上，待黃燈/紅燈閃爍後，在app上重試添加。如
需幫助請査詢：www.aqara.com/en/support.html。
*
*
若使用雙頻路由器，請先確保手機連接的是2.4GHz WiFi或者關閉5GHz Wi-Fi網絡；
請將手機儘量靠近Hub進行連接，同時請確保手機與Hub處於同一Wi-Fi網絡。
*針對iOS用戶，若要實現Apple HomeKit控制，請在Hub添加過程中根據app提示，掃描或手動輸入Hub底部
或說明書上的HomeKit設定程式碼（請妥善保存），將Hub綁定至HomeKit，綁定成功後，即可在Apple“家庭”
app中查看到已添加的Hub。
*
*
*
*
*
*
請確保設備連接2.4GHz的Wi-Fi網絡;
Wi-Fi名稱或密碼包含不支持的特殊字符，導致無法連接路由器，請修改成常用的字符後再試；
設備暫時不支持WAP/WAP2企業級的Wi-Fi網絡;
檢查路由器是否開啟Wi-Fi防蹭設置，導致設備無法正常聯網;
檢查路由器是否開啟AP隔離，導致手機在局域網內無法搜索到設備;
建議不要連接橋接網絡。
如果HomeKit綁定失敗，請確認以下幾點:
*
*
*
提示“無法添加配件”。由於反復多次添加失敗，導致iOS系統緩存的錯誤信息無法釋放，請重啟iOS設備並重
置設備後再試。若仍失敗，請檢查路由器兼容性，並嘗試更換其他路由器再試。
提示“配件已添加”。請重啟iOS設備並重置設備後，採用手動輸入HomeKit設置代碼方式重新添加。
提示“未找到配件”。請重置設備後，等待3分鐘後，採用手動輸入HomeKit設置代碼方式重新添加。
14
4
5
6
添加子設備：Hub添加成功後，請參攷子設備快速安裝指南進行添加子設備的操作。
控制紅外類家電：請根據app指引，在app上配寘您需要控制的紅外家電的品牌和型號後
進行對應的app控制和自動化控制。
3、使用
1
2

15
指示燈說明
指示燈顏色 含義
黃色/紅色
通電後，系統啟動中
Hub進入初始化狀態，等待入網；首次使用或重置
後十五分鐘內出現
藍色
正在連接網絡中；設備連接網絡的過程中出現
正常運作中
白色 Hub進入不可入網狀態；需重新拔插電源或重置
Hub後，才能進入等待入網狀態
紫色 允許添加子設備
指示燈狀態
常亮
閃爍
閃爍
常亮
閃爍
常亮
閃爍 Wi-Fi正在連接，app連接Hub、網絡中斷或拔插電
源後Hub重新連接網絡時出現
*由於设备固件的陞級與更新，實際操作可能與以上描述略有差异，請按照當前app內指引或者實際設備狀態
提示進行操作。
快速按擊閘道按鍵十次。
4、恢復出廠設定

16
用戶須知
1、
2、
3、
本產品為支持HomeKit的配件，推薦使用最新版本iOS或iPadOS。要遠程控制支持HomeKit
的配件或設置自動化，需要安裝一台HomePod或Apple TV或一台已設為家居中樞的iPad，
建議將軟件和操作系統更新到最新版本。
Hub與iPhone、iPad、Apple Watch、HomePod或Mac之間的通訊受HomeKit技術保護。
使用帶有Works with Apple的徽章，意味著該配件經過專門設計，可與徽章中所標識的技術
配合使用，並且已通過開發者認證，符合Apple性能標準，Apple不對此產品的操作或其符合
的安規標準負責。
Bluetooth®文字商標及標誌為 Bluetooth SIG, Inc. 之註冊商標，任何按[Lumi United
Technology Co., Ltd.]使用商標的情況均已獲授權。其他商標和商標名稱分別為相關擁有者
所有。
基本參數
產品型號：HM2-G01
產品尺寸：φ100.5×30.75mm(φ3.95×1.21 in.)
輸入電壓：5V 1A 或 5V 2A
無線連接：Wi-Fi IEEE 802.11 b/g/n 2.4GHz，Zigbee3.0 IEEE 802.15.4，BLE 5.0
工作溫度：-5℃~+50℃(23℉~122℉)
工作濕度：0~95% RH，無冷凝
支持系統：Android 6.0或iOS 12.0及以上版本

* Dieses Produkt ist nur für die Verwendung in Innenräumen geeignet.
Einführung des Produkts
Der Aqara Hub M2 ist eine intelligente Haussteuerungszentrale. Er kann mit einem WiFi- oder
Ethernet-Netzwerk verbunden werden und unterstützt die Interaktion und Verbindung mit
Zigbee-Untergeräten. Außerdem verfügt er über eine IR-Fernbedienungsfunktion, mit der die
Steuerung verschiedener IR-Geräte hinzugefügt und verwaltet werden kann. Mit Aqara Hub M2
können Sie Stecker, Glühbirne, Vorhang, Klimaanlage, Ventilator usw. bequemer steuern.
Kontrollleuchte
Schaltfläche
LAN-Anschluss
Mikro-B-Stromanschluss
USB-Anschluss Typ A (Reserviert)
Bereich der
Infrarot Emission
Bereich des
Infrarot-Empfangs
17
