Aqila Indoor Siren & RF Repeater User manual

PANDUAN PENGGUNA
USER GUIDE
INDOOR SIREN
& RF REPEATER
Untuk versi bahasa Indonesia
silahkan unduh pada website,
www.getaqila.com/download

PANDUAN PENGGUNA
INDOOR SIREN & RF REPEATER used to
expand the range of sensors that use RF
signals as well as amplifying alarm sounds
in the room. It has an elegant design and is
easy to install. This device is needed when
a wider RF signal coverage is required,
better stability, higher sensitivity, a wider
transmission distance, with no interference.
• Extends the signal range of the wireless
sensor.
• Receive alarms, status and information
from sensors and forward them to Aqila
Securehub™.
• LED lights in 3 dierent colors indicate
the alarm status to activate or deactivate
the alarm.
• One button to turn the LED indicator on
and o.
• Battery backup for 12 hours in the event of
a power loss.
Description
Features
Buildings that may require this device are
those with more than 1 floor or an area of
more than 200m2.
Note

PANDUAN PENGGUNA
General Display /
LED indication
Spesifikasi
1. LED indicator
Red LED blink once: Connection Process
Green LED is on: System is Disarmed
Green LED flashes once: transmits signal
Blue LED lights up: System is protected in Away
Arm mode
Blinking blue LED: System is protected in Stay Arm
mode
2. Connection / Test button
3. Electric plug release button
4. Electric plug
1
23
4
Voltage: DC100-240V 50/60 HZ
Maximum Current: 20 mA/220V
Power Rating: ≤5W (220V)
Battery Backup: 3.7V/600mA
Receiving Distance: 100M
Transmission Distance: 500M
Housing Material: Plastik ABS
Power Plug Type: EU
Operating conditions: -10oC-55oC
Size: φ80 X 41.7 mm

PANDUAN PENGGUNA
Operation Button
Turn on Device
Turn on Device
Turns On / O the LED
Indicator
Removes connection from
AQILA Securehub™ and
sensor
Turning On / O Alarm
Sounds
Press the connection
button, you will hear
a beep 1 time, and
the LED light will turn
red which means the
device has entered
“Connection Mode”
and is ready to connect
Aqila Securehub™ or
the sensor (Press the
Connection button
again within 30 seconds
to exit connection
mode).
To connect the Aqila
Securehub ™, enter
“Connection Mode”,
then press the white
tamper button on
the back of the Aqila
Securehub™.
To connect a sensor,
enter “Connection
Mode”, then connect
the sensor by triggering
the sensor, for example:
press any button on
the remote control, or
separate the transmitter
and magnet on the door
& window sensor.
Connection Mode
to connect to AQILA
Securehub™ and sensors
Press and hold the
Connection button for
3 seconds
Press the Connection
button 10 times
Press the Connection
Button 5 times
Press and hold the
Connection button for 5
seconds
Press the Connection
button 3 times
When it turned On, press
the connection button
1 time
The device beeps once,
the LED indicator turns
green
The device beeps once,
the LED indicator will
turn o
The device beeps once,
the LED indicator will turn
o / on
Sensors beeps once
Sensors beep once, the
LED indicator turns o / on
The device beeps once,
the LED indicator turns red
Function Operation Status
Connection

PANDUAN PENGGUNA
Press and hold the
Connection button for
5 seconds until a beep
is heard. All previously
made connections will be
deleted.
• To extend the sensor range, all sensors which will
be connected to Indoor Siren & RF Repeater must
first be connected to the Aqila Securehub™.
• Once the Indoor Siren & RF Repeater is connected
to Aqila Securehub™, the Indoor Siren & RF
Repeater device will not appear in Aqila Smart Apps
like other sensors. THIS IS NORMAL.
Removing
Connection to
Aqila Securehub™
or sensors.
Aqila Securehub™
beeps once and
the LED indicator
blinks once, it means
connection process has
been successful.
If Aqila Securehub™
beeps 3 times and the
LED indicator blinks
once, it means that the
connection capacity to
Aqila Securehub ™ is full
(up to 50 sensors).
If Aqila Securehub™
beeps 2 times and the
LED indicator blinks once,
it means that the sensor
has been connected
before.
Note
1
123

PANDUAN PENGGUNA
Installation
The battery back-up is
only for emergency use,
AC power should still be
the main power supply.
Install the electric plug on the device correctly by turning it. Then turn
the device on.
Do not install the device
less than 1.2 m in height.
Siren function must be
tested periodically, so that
any errors that may arise
can be identified.
Notice
