AQUA FILTER RX-AFRO3-AQ User manual
www.aquafilter.com
RX-AFRO3-AQ
3 Stage Reverse Osmosis System
for Aquarium
- High quality
- Competitive Pricing
- Three Stages of Filtration
- Hand Built & Factory Tested
- Easy Maintenance
- Easy to install with System Specifications
- Made in EU
- Ideal for aquariums
- High efficiency
- Provides excellent water quality
Features:
AQUAFILTER RX-AFR3-AQ is a new type of aquarium
filters. Water after RO system has decreased pH. It is an
excellent source to prepare appropriate conditions for
aquatic organisms.
System is equipped with two pre-filtration stages. The first is
an in-line cartridge containing activated carbon. It effectively
removes chlorine and organic substances. The second is
sediment cartridge which removes sediments such as sand,
silt, rust, etc.
The main filtration takes place on RO membrane, which
removes 96-99% of all impurities from water. Wastewater is
being poured to drain.
The aquarium filter is offered in set with filter cartridges, RO
membrane, additional accessories and valves preventing
the membrane from being dried.
*pH of water after RO system depends on source water
General Description:
www.aquafilter.com
AIPRO
AICRO
TFC-75F
Reverse Osmosis Membrane
(75 GPD), 0.0001 micron
Thin Film Composite
Semi-permeable membrane will remove salts, minerals, metals,
bacteria, viruses, cysts, TDS, Hardness, Fluorides, Pesticides,
Lead, Mercury, Cadmium & Arsenic and more. Due to the time needed
to remove all these ingredients your RO system includes a storage tank.
In-Line Sediment Cartridge (Pre-Filter)
Spun-bounded polypropylene
10 micron sediment filter traps dirt, sediment, rust and other
particulate matter.
In-line Coconunt
Shell Carbon Cartridge ( )
Pre-Filter
Activated carbon
In-line Coconut Carbon filter is used to reduce chlorine, color, and other organic
impurities
NOTE
- Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system.
- Water filtration systems can help reduce the presence of contaminants. In addition, some water filtration systems can help reduce the presence of microorganisms or other contaminants with potential health effects.
- We strongly recommend regularly scheduled maintenance and replacement of the filter cartridge in order for the product to perform properly.
- Replace the filter cartridge at least every 3 or 6 months (depending on water quality)
- RO membrane recommended to change every 2.5 -3 years (depending on water quality)
LIMITED WARRANTY: Manufacturer warrants that this product is free from defects in materials and workmanship. This warranty, together with any and all warranties implied by law, shall be limited to a period of two (2) years from the date
of original purchase.
This limited warranty does not apply to failures that result from abuse, misuse, alteration or failure to properly comply with installation, or cartridge change instructions.
We strongly recommend adding to all point of use filtration systems a Pressure Limiting Valve (PLV-0104 series) to guard against unwanted extreme water pressure events pressure increases, surges, and water hammer which could occur
in the water pipes. Not having one installed could mean that if you ever did have to claim damage caused by a burst water filter system, the claim will be denied.
CATALOG# STAGE COMPONENT FUNCTION
Specifications:
Connection adapter: 1/2”
Working Temp.: 2°C - 45°C (35º F - 113º F)
Operating Pressure: Max. 6.0 bar (90 psi) Min. 2.8 bar (40 psi)
Typical Rejection Rate: 98% TDS (Total Dissolved Solids)
pH Parameters: Maximum 11 Minimum 2
Iron: Maximum 0.2 ppm
TDS (Total Dissolved Solids) < 1800 ppm
Turbidity < 5 NTU
The package contains:
- The RX-AFRO3-AQ comes complete with the following
cartridges:
AICRO, AIPRO
- RO membrane element type: TFC-75F Manufactured by
Filmtec™ for Aquafilter
- Automatic Shut-off Valve, Mini Flow Restrictor,
- Feed water connector: 1/2”
- Drain Saddle Valve, Filter housing wrench
- 1/4 inch Tubing for System Connection
- System built with quick type fittings
- Completely Assembled
- 100% Factory Tested and Sterilized Ready for Installation
- Manual instructions
- Color box
Additional accessories
RX-AFRO3-AQ-CRT
Cartridge sets for
RX-AFRO3-AQ
AIMIAO2_K
Leak detection sensor
PLV-0104-80
Pressure limiting valve c
w
AQCWW-W
Quick onnectors
rench
Reverse Osmosis
Membrane
TFC-75F
Top and bottom
O-ring for the
membrane housing
OR-N-630X40
1
2
3
