Aqua-Scope FLOLWE01 Operating manual

LoRaWAN Flood Sensor
SKU: FLOLWE01
Version: 1.0.0
Product Description
The Flood Sensor detects the presence of water on its sensor pins and sends an alarm message to a
LoRa network when triggered. In addition, the device will regularly report the ambient temperature and
humidity and send an alarm when the readings exceed thresholds that can be set for both humidity and
temperature.
The device itself is designed to sit on the floor, where 3 brass telescopic pins can detect water on both
hard floors (tiles) and soft carpets. The unit comes with a mounting bracket. It can be screwed or taped
to the wall or floor. When the main sensor is in the bracket, a super-flat sensor pad connected by wire to
the bracket is used to detect water.
When an alarm is active, the unit emits a sound and a red LED flash. The unit is powered by an internal
CR123 battery that lasts approximately 10 years in normal operation.
Pairing with the LoRaWAN Network
Please register the device with its three keys at your LoRaWAN server before you start using it. The
Device EUI is printed on the device. Enter this key and your registered email address at https://aqua-
scope.com/lora to obtain the missing keys. The email address is the account email from Aqua-Scope
Shop purchases or the data is provided by your point of sale.
Connecting to Aqua-Scope Monitor
The sensor can be connected directly to an Aqua-Scope monitor using the LoraP2P protocol. To switch
the sensor to LoraP2P, press and hold the button when the battery is inserted. When you see three red
flashes, release the button. The device is now in LoraP2P mode. If you do this again, you will see 3 *
green blinking and the device is back in LoRaWAN mode. Once in LoraP2P mode, please scan the QR
code with your Aqua-Scope app to connect the device to your Aqua-Scope monitor.
Users and Installation Manual: LoRaWAN Flood Sensor (FLOLWE01)
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua-scope.com

Installation and Functions
The first step is to insert the CR123 battery. Turn the top of the sensor housing counterclockwise to open
the housing. Inside you will see the functional components of the unit:
1. CR123 battery holder. Be sure to insert the battery with the correct polarity. Inserting the battery
the wrong way will not damage the electronics, but will drain the battery without any function.
2. Button
3. Dual Color LED
4. Buzzer Sound
5. Computing/Communication Module
6. Temperature/Humidity Sensor
After inserting the battery, the LEDs will blink red/green. This indicates an attempt to JOIN the LoRaWAN
network. Success is indicated by 3 * green blinks, failure is indicated by 3 * red blinks. Pressing the
button will always force a rejoin if the device is not (anymore) joined. Pressing the button will also send a
heartbeat for testing purposes. The unit constantly checks for flooding and measures temperature and
humidity every 15 minutes. This interval is set in configuration parameter #2 and can be changed. If
either temperature or humidity changes more than 0.5°C or 5%, a sensor report is sent. The thresholds
for sending can be changed in configuration parameter #6 or #7. Regardless of any value changes, the
unit will send a status report every hour. This value can be changed in configuration command #4. The
food alarm is indicated wirelessly plus red LED plus buzzer on the unit.
The status report includes
Battery status or alarm status (5 byte)
Temperature (4 bytes)
Humidity (4 bytes)
Close the housing by turning the top of the housing 1/8 turn clockwise. There are two installation
options:
Place the Sole unit directly on the floor without any other accessories.
Mount the bracket to the wall by peeling off the 3M decal or screwing it in place with the supplied
Users and Installation Manual: LoRaWAN Flood Sensor (FLOLWE01)
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua-scope.com

screw. Insert the sensor device into the bracket and plug the sensor pad into the bracket
receptacle.
LoRaWAN Payload Commands (Payload Format)
LoRaWAN commands can be daisy chained into the payload up to the defined maximum payload size of
51 bytes. This mean that for all commands sent to defined number of bytes in the payload is required to
avoid misinterpretation of command and/or command values in the receiver side. All uplink and
downlink commands use FPort=10.
Uplink Command Configuration Report: 0x04 - IDX - VAL_MSB - VAL_LSB (4 Byte): This
command reports a configuration parameter of the device: IDX is the number of the configuration
parameter. The 16 Bit VAL is the parameter itself. Configuration parameters are always 16 Bit
values. The table below describes the configuration parameters and their values.
Uplink Command Sensor Report: 0x06 - ID - VAL_MSB - VAL_LSB (4 Byte): This command
reports sensor values. The ID indicates the sensor type and defines the format of the 16-Bit VAL.
The sensor types of this devices are listed below.
Uplink Command Firmware Version Report: 0x0a - VER_MSB VER_2 VER_3 VER LSB (5
Byte): This command reports the 32-bit value of the current firmware. It is sent unsolicited as the
first command during boot-up and as replying command to downlink command 'Hardware Version
Get'.
Uplink Command Alarm Report: 0x0b - STATE - TYPE - VAL_MSB - VAL_LSB (5 Byte): This
command reports start and end of alarms. The STATE-Byte indicates the status of the alarm (0x01
= active, 0x00 = inactive). The TYPE Byte indicates the type of alarm and defines the content of
the 16 Bit VAL. Possible alarm IDs and the values reported are listed below.
Uplink Command Battery Report: 0x12 - VOLT - BAT_MSB - BAT_LSB (4 Byte): This
command reports the status of the battery. VOLT is the measured voltage of the battery in 100 mV
steps, the BAT value is the consumption of the current battery - as counted inside the system - in
mAh.
Downlink Command Configuration Set: 0x04 - IDX - VAL_MSB - VAL_LSB (4 Byte): This
command allows setting configuration parameters of the device: IDX is the number of the
configuration parameter. The 16 Bit VAL is the parameter itself. Configuration parameters are
always 16 Bit Values. The table below describes the configuration parameters and its values.
Downlink Command Sensor Get: 0x06 - ID (2 Byte): This command requests the report of
sensor values. The ID indicates the sensor type. The sensor types of the devices are listed below.
Downlink Command Alarm Clear: 0x0b - TYPE (2 Byte): This command clears an alarm. TYPE
is the type of alarm to be cleared. Type = 0 clears all active alarms. For other types of alarms to
be cleared please refer to the uplink command 0x0b.
Downlink Command Configuration Get: 0x14 - IDX (2 Byte): This command allows reading
the configuration value IDX. The device will respond with an upstream command Configuration
Report
LoRaWAN Sensor Types
The following sensor types are supported by the Aqua-Scope Monitor.
Users and Installation Manual: LoRaWAN Flood Sensor (FLOLWE01)
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua-scope.com

0x01: Temperature: VAL is temperature in 1/10 Degree Celsius, (2-complement). Example: 0x06
0x01 0x00 0xCD => Temperature 0x00CD = 205 = 20.5 C., 0x06 0x01 0xFF 0xEA =>
Temperature 0xFFEA = -20 = -2 C
0x02: Humidity: VAL is relative humidity in percent. Example: 0x06 0x02 0x00 0x3C => Humidity
0x003C = 60 = 60 % RH.
0x03: Uptime: VAL is the number of hours after last boot (battery change)
LoRaWAN Alarm Types
The following alarmtypes are supported by the Aqua-Scope Monitor.
0x0001 (Bit 00) : All Alarms
0x0002 (Bit 01) : Flood Sensor Tripped, VAL is 0x01 or 0x00.
0x0004 (Bit 02) : Temperature out of limits, VAL is actual temperature. For encoding of
temperature please refer to section 'LoRaWAN Sensor Types'.
0x0010 (Bit 04) : Humidity out of limits, VAL is actual humidity. For encoding of humidity please
refer to section 'LoRaWAN Sensor Types'.
0x1000 (Bit 12) : Battery Low.
LoRaWAN Configuration Parameters
All Configuration Parameters are 2 Byte values that can be set and read out using LoRaWAN
'Configuration Get' and 'Configuration Set' commands.
#2: Heartbeat Interval: This parameter defines after how many measurement intervals the
sensor will send a report regardless of changes temperature or humidity. The factory default is 24
which translates together with the default value of parameter #4 (900 seconds = 15 minutes) into
24 * 15 minutes = 6 hours.
#3: Temperature Unit: Fahrenheit (0x01) versus Celsius (0x00 = default)
#4: Measurement Interval in Seconds: Temperature and Humidity are measured regularly.
This parameter defines the time interval for these measurements in sec. The default is 900 = 15
minutes. The value range is 10 – 60000. Please note that measuring a value does not
automatically cause a LoRaWAN packet sent out but only if one of the sensor values deviates more
then defined in parameter #6 or #7
#6: Temperature Change Threshold: A change by this value (in 1/10 °C) will cause a LoRaWAN
report. Default = 0x05 = 0.5 °C
#7: Humidity Change Threshold: A change by this value (in %) will cause a LoRaWAN report.
Default = 0x05 = 5 %
#8: Temperature Upper Watermark: An alarm is sent out when the temperature raises over
this value. The value is defined in 1/10 °C, default is 300 = 30.0 °C.
#9: Humidity Upper Watermark: An alarm is sent out when the humidity raises over this value.
The value is defined in %, default is 90 = 90 %
#10: Temperature Lower Watermark: An alarm is sent out when the temperature drops below
this value. The value is defined in 1/10 °C, default is 0xFF38 = -200 = -20.0 °C.
#11: Humidity Lower Watermark: An alarm is sent out when the humidity drops below this
Users and Installation Manual: LoRaWAN Flood Sensor (FLOLWE01)
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua-scope.com

value. The value is defined in %, default is 10 = 10 %
Scope of Delivery
Water Sensor
Bracket
1 x CR123 battery
One external flood sensor with cable
1 x screw and dowels
Manual
Technical Data
Platform: STM32WLE5CCU6
Wireless Connection:
Spec:LoRaWAN 1.0.3
Join: OTAA
Class: A
Frequency: EU868
Range: > 2km (TX 22 dB)
Battery: CR123
Protection: IP 54
Sensor-Pad
Height: 7 mm
Connection: Audio Coaxial
Kabel-Length: 110 mm
Protection: IP 67
Environmental Conditions
Shipping and Storage: -65 °C … 125 °C
Operation: - 40 °C … 85 °C
Humidity: 0...90 %
Dimensions: 65 x 65 x 32 mm
Weight (without Battery): 90 gr.
Support and Contact
Should you encounter any problem, please give us the opportunity to address it before returning this
product. Please check our website www.aqua-scope.com and particularly the support section for answers
and help. You can also send a message to [email protected].
While the information in this manual has been compiled with great care, it may not be deemed an
assurance of product characteristics. Aqua-Scope shall be liable only to the degree specified in the terms
of sale and delivery. The reproduction and distribution of the documentation and software supplied with
this product and the use of its contents is subject to written authorization from Aqua-Scope. We reserve
the right to make any alterations that arise as the result of technical development.
Users and Installation Manual: LoRaWAN Flood Sensor (FLOLWE01)
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua-scope.com

Phone: [phone]
eMail: [email protected]
Web: www.aqua-scope.com
Declaration of Conformity
Aqua-Scope Technology OÜ, Sakala 7-2, 10141 Tallinn, Republic of Estonia, declares that
this radio emitting device works on the following frequences:
Български С настоящото Aqua-Scope Technology OÜ декларира, че този тип
радиосъоръжение FLOLWE01 е в съответств ие с Директива 2014/53/ЕС. Цялостният текст на ЕС
декларацията за съответствие може да се намери н а следния интернет адрес: www.aqua-scope.com/ce.
Čeština Tímto Aqua-Scope Technology OÜ prohlašuje, že typ rádiového zařízení FLOLWE01 je v souladu se
směrnicí 2014/53/EU. Úplné znění EU prohlášení o shodě je k dispozici na této internetové adrese: www.aqua-
scope.com/ce.
Dansk Hermed erklærer Aqua-Scope Technology OÜ, at radioudstyrstypen FLOLWE01 er i overensstemmelse
med direktiv 2014/53/EU. EUoverensstemmelseserklæringens fulde tekst kan findes p følgende internetadresse:
www.aqua-scope.com/ce.
Deutsch Hiermit erklärt Aqua-Scope Technology OÜ, dass der Funkanlagentyp FLOLWE01 der Richtlinie
2014/53/EU entspricht. Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden
Internetadresse verfügbar: www.aqua-scope.com/ce.
Eesti Käesolevaga deklareerib Aqua-Scope Technology OÜ, et kesolev raadioseadme tp FLOLWE01 vastab
direktiivi 2014/53/EL nuetele. ELi vastavusdeklaratsiooni tielik tekst on kttesaadav jrgmisel internetiaadressil:
www.aqua-scope.com/ce
English Hereby, Aqua-Scope Technology OÜ declares that the radio equipment type FLOLWE01 is in compliance
with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet
address: www.aqua-scope.com/ce
Español Por la presente, Aqua-Scope Technology OÜ declara que el tipo de equipo radioeléctrico FLOLWE01 es
conforme con la Directiva 2014/53/UE. El texto completo de la declaracin UE de conformidad está disponible en la
direccin Internet siguiente: www.aqua-scope.com/ce
Ελληνικά Με την παρούσα ο/η Aqua-Scope Technology OÜ, δηλώνει ότι ο ραδιοεξοπλισμός FLOLWE01 πληροί
την οδηγία 2014/53/ΕΕ. Το πλήρες κείμενο της δήλωσης συμμόρ φωσης ΕΕ διατίθεται στην ακόλουθη ιστοσελίδα
στο διαδίκτυο: www.aqua-scope.com/ce
Français Le soussigné, Aqua-Scope Technology OÜ, déclare que l'équipement radioélectrique du type FLOLWE01
est conforme la directive 2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible
l'adresse internet suivante: www.aqua-scope.com/ce
Hrvatski Aqua-Scope Technology OÜ ovime izjavljuje da je radijska oprema tipa FLOLWE01 u skladu s Direktivom
2014/53/EU. Cjeloviti tekst EU izjave o sukladnosti dostupan je na sljedećoj internetskoj adresi: www.aqua-
scope.com/ce
Italiano Il fabbricante, Aqua-Scope Technology OÜ, dichiara che il tipo di apparecchiatura radio FLOLWE01
Users and Installation Manual: LoRaWAN Flood Sensor (FLOLWE01)
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua-scope.com

conforme alla direttiva 2014/53/UE. Il testo completo della dichiarazione di conformit UE disponibile al seguente
indirizzo Internet: www.aqua-scope.com/ce
Latviešu Ar šo Aqua-Scope Technology OÜ deklarē, ka radioiekārta FLOLWE01 atbilst Direktīvai 2014/53/ES. Pilns
ES atbilstības deklarācijas teksts ir pieejams šādā interneta v ietnē: www.aqua-scope.com/ce Lietuvių Aš, Aqua-
Scope Technology OÜ, patvirtinu, kad radijo įrenginių tipas FLOLWE01 atitinka Direktyvą 2014/53/ES. Visas ES
atitikties deklaracijos tekstas prieinamas šiuo internet adresu: www.aqua-scope.com/ce
Magyar Aqua-Scope Technology OÜ igazolja, hogy a FLOLWE01 típus rádiberendezés megfelel a 2014/53/EU
irányelvnek. Az EUmegfelelőségi nyilatkozat teljes szövege elérhető a következő internetes címen: www.aqua-
scope.com/ce
Malti B'dan, Aqua-Scope Technology OÜ, niddikjara li dan it-tip ta' tagħmir tar-radju FLOLWE01 huwa konformi
madDirettiva 2014/53/UE. It-test kollu tad-dikjarazzjoni ta' konformit tal-UE huwa disponibbli f'dan l-indirizz
talInternet li ġej: www.aqua-scope.com/ce
Nederlands Hierbij verklaar ik, Aqua-Scope Technology OÜ, dat het type radioapparatuur FLOLWE01 conform is
met Richtlijn 2014/53/EU. De volledige tekst van de EUconformiteitsverklaring kan worden geraadpleegd op het
volgende internetadres: www.aqua-scope.com/ce
Polski Aqua-Scope Technology OÜ niniejszym oświadcza, że typ urządzenia radiowego FLOLWE01 jest zgodny z
dyrektywą 2014/53/UE. Pełny tekst deklaracji zgodnośc I UE jest dostępny pod następującym adre sem
internetowym: www.aqua-scope.com/ce
Português O(a) abaixo assinado(a) Aqua-Scope Technology OÜ declara que o presente tipo de equipamento de
rádio FLOLWE01 está em conformidade com a Diretiva 2014/53/UE. O texto integral da declarao de conformidade
está disponível no seguinte endereo de Internet: www.aqua-scope.com/ce
Română Prin prezenta Aqua-Scope Technology OÜ declară că tipul de echipamente FLOLWE01 este în
conformitate cu Directiva 2014/53/UE. Textul integral al declarației UE de conformitate este disponibil la
următoarea adresă internet: www.aqua-scope.com/ce
Slovensko Aqua-Scope Technology OÜ potrjuje, da je tip radijske opreme FLOLWE01 skladen z irektivo
2014/53/EU. Celotno besedilo izjave EU o skladnosti je na voljo na naslednjem spletnem naslovu: www.aqua-
scope.com/ce
Slovensky Aqua-Scope Technology OÜ týmto vyhlasuje, že rádiové zariadenie typu FLOLWE01 je v slade so
smernicou 2014/53/EÚ. Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: www.aqua-
scope.com/ce
Soumi Aqua-Scope Technology OÜ vakuuttaa, että radiolaitetyyppi FLOLWE01 on direktiivin 2014/53/EU
mukainen. EUvaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa
internetosoitteessa: www.aqua-scope.com/ce
Svenska Härmed försäkrar Aqua-Scope Technology OÜ att denna typ av radioutrustning FLOLWE01
verensstmmer med direktiv 2014/53/EU. Den fullständiga texten till EUförsäkran om verensstämmelse finns på
följande webbadress: www.aqua-scope.com/ce
Disposal Guidelines
Users and Installation Manual: LoRaWAN Flood Sensor (FLOLWE01)
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua-scope.com

Do not dispose of electrical appliances as unsorted municipal waste, use separate collection
facilities. Contact your local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into
the groundwater and get into the food chain, damaging health and well-being.
Users and Installation Manual: LoRaWAN Flood Sensor (FLOLWE01)
Copyright © 2023 Aqua-Scope Technologies, Sakala tn 7-2, 10141 Tallinn, Estonia, www.aqua-scope.com
