AquaTru LLC AquaTru User manual

AP200-011714
owner's
manual
© 2016 AquaTru
™
, LLC. All Rights Reserved. 10.16/R3

SAFETY INSTRUCTIONS 2
FEATURES 3
MAIN PARTS 5
WATER FILTRATION PROCESS 6
INSTALLATION 7
HOW TO USE 9
CLEANING 10
MAINTENANCE/FILTER REPLACEMENT 11
TROUBLESHOOTING 12
ONE-YEAR LIMITED WARRANTY 14
ARBITRATION AGREEMENT 15
TABLE OF CONTENTS
Thank you for purchasing the AquaTru™
reverse osmosis home water purifier!
This state of the art water purification
system will greatly improve the quality
and taste of your water. AquaTru™ is a
healthy choice and a great way to save
money while being environmentally
friendly. We want you to be fully satisfied
with your AquaTru™ water purifier.
That’s why the AquaTru™ comes with
a one-year limited warranty.
Once you’ve experienced the purity of
AquaTru™ water, visit us at our website
to find out more ways to improve the
quality of your water and your life with
our premium products and upgrades.
Please be sure to read the following
instructions carefully before use to
ensure optimal performance and safety.
www.aquatruwater.com
AquaTru™, LLC
1392 Sarah Place, Ste. B
Ontario, CA 91761
800.220.6570

Beyond Filtration Aq uaTr u™
SAFETY INSTRUCTIONS FEATURES
READ AND SAVE THESE INSTRUCTIONS
WARNING: IF NOT OBSERVED, SERIOUS PHYSICAL INJURY OR PROPERTY DAMAGE
MAY OCCUR AS A RESULT.
WARNING: Use only on municipally treated water or other supply known to be
microbiologically safe.
• Connect only to a circuit that is protected by a ground-fault circuit-interrupter (GFCI).
• Do not repair, disassemble, or modify.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
READ ALL INSTRUCTIONS BEFORE OPERATING THE AquaTru™.
• Use or place the unit on a level area and do not apply force to the unit.
• Periodical filter replacement is a prerequisite for obtaining clean water.
• Do not use filtered water for the water exchange of an aquarium or a fishbowl.
• Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection before or after the system.
• Hand wash only. Not dishwasher safe!
• Household use only.
• Do not operate below 40° F.
• When placing AquaTru™ on a kitchen countertop, always avoid
placing near hot surfaces like stoves and ovens.
NOTICE: TO REDUCE THE RISK ASSOCIATED WITH PROPERTY DAMAGE DUE TO WATER LEAKAGE:
• Read and follow these instructions before installation and use of the AquaTru™.
• To protect from freezing, remove filter cartridges when temperatures are expected to
drop below 40°F.
• Do not use in areas when temperatures may exceed 110°F.
• Do not place the AquaTru™ in direct sunlight.
Advanced 4-Stage Purification System
The AquaTru™ water purification system provides powerful quadruple
purification performance utilizing reverse osmosis technology.
Cost Savings Efficiency
Avoiding bottled water cost by creating your own clean water, and long lasting filters
all add up to significant savings over the life of the product.
One-Touch Water Dispensing
Simple intuitive one-touch controls for dispensing water.
Space Saving and Compact Design
Efficient and elegant countertop design takes up minimal space in the kitchen.
Quick Filter Replacement
Easy access to the filter bay to replace filters. No tools required!
Easy DIY Installation
Ready to use in less than 10 minutes.
32

Beyond Filtration Aq uaTr u™
MAIN PARTS
1. Side Panel
2. Pre/Carbon Filter (Part# AT3001)
3. Reverse Osmosis Filter (Part# AT3002)
4. VOC Carbon Filter (Part# AT3003)
5. Filtered Water Tank (Part# AT3004)
6. Unfiltered Tap Water Tank (Part# AT3005)
7. Dispensing Button
8. Display
9. Power Adapter (universal voltage)
1. Side
Panel
4. VOC Carbon Filter
3. Reverse Osmosis Filter
2. Pre/Carbon Filter
5. Filtered Water
6. Unfiltered Water
7. Dispensing
Button
8. Display
9. Power
Adapter
54

Beyond Filtration Aq uaTr u™
WATE R FILTR ATION PRO CESS
Quadruple Action Purification:
1 Dual Stage Pre Filter
The pre filter reduces sand, silt, sediment, rust and particles from water. Activated carbon
eliminates chlorine taste, removes odors and conditions the water before it is treated by the
reverse osmosis membrane.
2 Reverse Osmosis Filter
The RO membrane reduces impurities from the water down to 1/10000 of a micron.
3 VOC Carbon Filter
This carbon filter is made of high quality activated carbon. It is designed to remove volatile organic
compounds, enhance the taste and prepare the water for consumption.
INSTALL AT IO N
CAUTION: Before installing the filters and cleaning the water tank make sure that you
have thoroughly cleaned your hands and you're working surfaces are sanitized.
1 Remove all parts from the box.
2 Wash with soap and rinse both water tanks before using unit.
3 Open side panel by lifting up from bottom.
4 Remove filters from vacuum sealed bag.
5 Insert filters into each filter bases by turning the filter in a clockwise direction.
6 When installing filters be sure to insert them into the correct base by matching
the label numbers and colors. Please note: the filter base pivots outward to make
removing and reinstalling filters more accessible.
7 Pivot the filter back to its vertical upright position.
8 Close the side panel.
Unfiltered Water Tank Filtered Water Tank
VOC Carbon Filter
Reverse Osmosis Filter
Pre Filter/Carbon Filter
FILTER 4 FILTER 3 FILTER 1-2
76

Beyond Filtration Aq uaTr u™
HOW TO USE
9 Plug in unit. Connect only to a circuit that is protected by a ground-fault circuit-interrupter (GFCI).
10 Power on the AquaTru™ using the switch located on the back.
11 Fill tap water tank with cold tap water and then reinstall. Be sure that both tanks are properly
seated. This can be done by pressing down on the tanks once in place.
WARNING: Use only on municipally treated water or other supply known to be
microbiologically safe.
First Time Start Up Procedure
Run 4 full unfiltered water tanks through the AquaTru™ before drinking.
9 Once the tanks have been installed on the unit, it will begin to filter water automatically.
Note: It will take longer than normal for the first tank to go through a cycle. On the first cycle a
white cloud will be visible in the tap water tank. This is perfectly normal, the white cloud is tiny air
bubbles released by the RO membrane.
NOTICE: Keep a close eye for any water leaks. In case of a leak, check the "Troubleshooting"
guide on pages 12-13.
10 AquaTru™ will stop filtering water when the cycle is complete or when it is time
to refill the tap water tank.
Note: When it is time to refill the unfiltered water tank it will be quarter full.
All RO water filtrations systems will waste water when “back washing” the RO membrane.
Most traditional RO systems have this dirty little secret. They waste up to 5 gallons of water
to make 1 gallon of pure water. With our new patent pending AquaTru™ recirculation RO
system, it only takes 1 gallon of tap water to make 3/4 gallon of pure water. The water left in
the tap tank contains all the impurities from the tap water.
The water in the tap water tank must be discarded every time you
refill the tap water tank. Failure to do so will damage the unit &
void the warranty.
11 Empty and rinse both water tanks.
12 Repeat steps 8-12, 3 more times.
13 When 4 cycles have been completed, your new water purifier is ready to be used.
CAUTION: ONLY USE COLD TAP WATER
CAUTION: Before installing the filters and cleaning the water tank make sure that you have
thoroughly cleaned your hand and you're working surfaces are sanitized.
WARNING: Use only on municipally treated water or other supply known to be
microbiologically safe.
1 Fill the unfiltered water tank with cold tap water and install on the AquaTru™ base.
2 Let AquaTru™ cycle until the front display turns off and your front filtered water tank is full.
3 When it is time to refill the unfiltered water tank, the display will illuminate the top circle.
(Figure 1) Remove tank and discard the remaining water. Refill the unfiltered tank with
cold tap water until it reaches just below the tank handle. Reinstall tank.
4 When clean water tank is full, press blue button to dispense water.
5 You can also remove water tank and place it in the refrigerator to make cold water.
Visit our website to order extra water tanks to continually purify and refrigerate water.
INSTALL AT IO N
12
3
4
Figure 1
98

Beyond Filtration Aq uaTr u™
CLEANING & MAINTENANCE CLEANING & MAINTENANCE
Cleaning
Tanks – Clean both water tanks every week with soap and water. When cleaning, be sure to release
soapy water from spout and tank valves on the bottom of each tank. This can be done by pressing the
dispense button and spring loaded white pin at bottom of tank.
Unit/Base – Clean the outside of the unit using a non-abrasive sponge or towel with soap and water.
To avoid water spots use clean drying towel to thoroughly dry all surfaces of the AquaTru™.
Filters – For optimal results, we suggest that you clean filters by running one tank of purified water
through the unit each week. This will flush out any remaining contaminants that have been collected
by the filters. First, use AquaTru™ to create one full tank of clean water. Next, empty and rinse rear tap
water tank. Lastly, pour clean water into tap water tank and reinstall both tanks.
Please note: During normal use small amounts of water can occasionally leak from valves.
Use a dry towel to soak up any spillage before reinstalling tanks.
Filter Replacement
AquaTru™ will track the usage of your filters and let you know when it’s time for them to be changed.
When the time comes, the front display will notify you by illuminating the filter that needs changing.
During normal use, the lights will move from filter to filter to indicate that the water is cycling through
the purifying process.
When the filter needs to be changed, the filter light will remain lit on the filter that needs to be
changed. Upon replacement, press the filter reset button located on the back of the unit and the lights
will resume cycling through the filter numbers.
Please visit our website to purchase replacement filters / www.aquatruwater.com.
Filter Replacement
Depressurize the filters.
WARNING:
After removing the cover wait for 60 seconds before proceeding to remove the filters.
After replacing a filter discard the first 2 full water tanks that AquaTru™ produces.
4: VOC Carbon Filter3: RO Filter1-2: Pre Filter/Carbon
Filter
IMPORTANT: Once you have installed
the new clean filters you must press
the filter reset button located on the
back of the unit. If you do not do this
step the filter light indicator will stay
lit and the AquaTru™ will not track the
life of the new filter.
For best results cycle 1 gallon of clean
purified water through the machine
once a week.
Long Term Storage / Vacation
If leaving on vacation start by switching the unit off. Next, wash both tanks with soap and water. Allow the
tanks to dry thoroughly before reinstalling them. When you have returned from vacation purge the system of
stagnant water by running four full tap water tanks through the system. Once the fourth tank has been filtered
the unit is ready to use. This process can be avoided by having a house sitter run one tank of tap water through
the AquaTru™ at least once a week.
Filter 1-2 | Pre/Carbon Filter (Part# AT3001)
Filter 3 | Reverse Osmosis Filter (Part# AT3002)
Filter 4 | VOC Carbon Filter (Part# AT3003)
Figure 1
Figure 2
1 Pivot the filter outward to make it
easier to remove and reinstall the
filters (Figure 1).
2 Remove old filter by turning it
counter clockwise (Figure 1).
3 Install new filter by turning it
clockwise. Be sure to tighten securely.
4 Pivot the filter back to its
vertical upright position.
5 Close side panel.
6 Press Filter Reset Button located
on the back of the AquaTru™ unit
(Figure 2). Press and hold
for at least 3 seconds.
7 After installing a new filter always
discard the first two full water tanks
the AquaTru™ produces.
1110

Beyond Filtration Aq uaTr u™
TROUBLESHOOTING TROUBLESHOOTING
REASON
Unit is not plugged in.
Power switch is not on.
Tap water tank is empty.
Tanks are not properly seated.
You did not remove tap water tank
when you refilled it.
The tap water tank is empty.
The water tank is dirty.
Tanks are not properly seated.
The valve may not be closing properly.
The filter might have come to
the end of its life. As the RO filter gets
older the filtering times may increase.
RO filter may have become
completely clogged.
New VOC carbon filter has been
installed.
May need to be changed.
Normal pump operation.
New filter installation.
PROBLEM
Unit will not
power on
Clean water tank is
empty but AquaTru
will not start
The top circle
is illuminated
Water tanks smell
Water tank is
leaking
AquaTru is
filtering slower than
usual
My clean water
has higher TDS
than before
AquaTru makes a
strange noise
SOLUTION
Plug power adapter into unit. Then plug
power cord into CFI equiped outlet.
Turn power switch on, located
on back of the unit.
Refill tap water tank.
Reinstall both tanks.
The tap water tank always has to be removed
from the base & remaining water has to be
discarded. Failure to do so will void warranty
& the unit will stop filtering water.
Refill tap water tank.
Wash water tank with soap
and water once a week.
Reinstall tanks.
To test valve, press the small white pin
with spring located at the bottom of
either tank. Do this above a sink as water
will release from the tank.
Run a tank of clean purified water to flush
filters.
Replace RO filter. Part# AT3002. The RO
filter life is 1400 gallons. Very hard water
can slow down the filtering time. Note
that longer filtering times do not impact
the efficiency of the filters.
Run four tap water tanks to
rinse out particles from new
carbon filter.
Generally, RO system lower TDS
readings by 90% as compared
to tap water readings.
The water pump will make noise during
water filtration.
Some filters make extra noise as they
become saturated. This is normal and
should reduce in time.
REASON
New filters have not been flushed
completely.
Filter may need to be replaced.
The water tanks are dirty.
Small residual water may leak from the
front spout.
Filters installed incorrectly.
Defective filter.
Filter needs to be replaced.
Micro air bubbles from RO filter.
The tanks has accumulated minerals
from tap water.
When filters are changed it is normal
for some water to escape the filter base
and leak into the bottom of the unit.
There are holes located on the bottom
of the unit to allow the water to drain.
The clean water tank may have become
full or the tap water tank needs to be
refilled.
Air bubbles have gotten trapped in the
system.
PROBLEM
Bad tasting water
Water dispenser
is leaking
Leaking water
from unit
Filter light is on
and won't turn off
White cloud in
tap water tank
My tap water tank has
white scaling
When I installed new
filters water started
leaking from the
bottom of the AquaTru
My unit turns off
randomly in the
middle of filtering
water
SOLUTION
Run four tap water tanks to rinse out
particles from new filter.
Order new filters at AquaTru.com.
Wash water tanks with soap and water
once a week.
Avoid by holding water receptacle for a
an extra moment when
dispensing water. This will allow
you to catch the remaining water.
Reinstall each filter. Remove the filter
o-ring & reinstall the o-ring ensuring
that each has been properly seated.
Wet the o-ring with clean water before
installing filter.
Compare each filter to make sure that
all outside O-rings are identical in size.
Filters should fit tightly when installed.
If loose, the filter is defective.
Replace the filter that is illuminated
then press the filter reset button on the
back of the unit.
This is normal and may be
experienced during every use.
The scaling can be removed by using
a solution of 1 part vinegar to 1 part
water. Fill the dirty tank with the solu-
tion and let it soak overnight or for a
minimum of 3 hours. Alternatively you
may use descaling solutions sold at your
local shopping store. Thoroughly rinse
tanks before reinstalling.
Wait 60 seconds after removing cover,
before removing the filter. This will
minimize the spillage.
Begin by turning the unit off and on
again. Second, dispose remaining tap
water, refill tap water tank and reinstall.
Third, remove clean water tank from
base then reinstall. If none of these
steps resolve the issue remove side
panel of filter bay and let unit sit for one
minute. After the unit has decom-
pressed remove and reinstall each filter
one at a time then reinstall side panel.
CAUTION: Before doing any maintenance or troubleshooting, make sure that you have
thoroughly cleaned your hands and you're working surfaces are sanitized.
WARNING: To refill the tap water tank, ALWAYS remove the tank and discard the remaining
water BEFORE refilling.
1312

Beyond Filtration Aq uaTr u™
ARBITRATION AGREEMENT
PLEASE READ THIS AGREEMENT CAREFULLY. YOU ACCEPT THE TERMS OF THIS AGREEMENT BY RETAINING THE
PRODUCT(S) SHIPPED IN CONNECTION WITH THIS AGREEMENT (THE “PRODUCTS”) FOR MORE THAN THIRTY (30)
DAYS AFTER RECEIPT. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT, YOU MAY RETURN THE PRODUCT TO
COMPANY WITHIN THIRTY (30) DAYS OF RECEIPT FOR A FULL REFUND.
THIS ARBITRATION AGREEMENT (“AGREEMENT”) AFFECTS YOUR LEGAL RIGHTS AND REMEDIES BY PROVIDING THAT
DISPUTES BETWEEN YOU AND THE MANUFACTURER, DISTRIBUTOR AND/OR SELLER OF THIS PRODUCT (COLLECTIVELY,
“COMPANY”), MUST BE RESOLVED THROUGH BINDING ARBITRATION AND NOT IN COURT. IT ALSO PROVIDES THAT
ANY DISPUTE CANNOT BE RESOLVED IN A CLASS ACTION OR OTHER PROCEEDING WHERE YOU REPRESENT OTHER
PERSONS OR OTHER PERSONS REPRESENT YOU, AND THAT NO CLASS OR REPRESENTATIVE ARBITRATIONS ARE
PERMITTED. PLEASE CAREFULLY READ ALL TERMS IN THIS AGREEMENT.
1. RESOLUTION OF CLAIMS OR DISPUTES.
Any claim or dispute between you and Company (or any of Company’s subsidiaries or affiliates) arising out of
or relating in any way to the Product or this Agreement shall be resolved through final, binding arbitration. This
arbitration obligation is reciprocally binding on both you and the Company and applies regardless of whether the
claim or dispute involves a tort, fraud, misrepresentation, product liability, negligence, violation of a statute, or any
other legal theory. Both you and Company specifically acknowledge and agree that you waive your right to bring a
lawsuit based on such claims or disputes and to have such lawsuit resolved by a judge or jury.
2. LIMITATION OF LEGAL REMEDIES.
All arbitrations under this Agreement shall be conducted on an individual (and not a class-wide) basis, and an
arbitrator shall have no authority to award class-wide relief. You acknowledge and agree that this Agreement
specifically prohibits you and the Company from commencing arbitration proceedings as a representative of
others or joining in any arbitration proceedings brought by any other person. The parties agree that no class or
representative actions of any type are permitted.
3. ARBITRATION PROCEDURES.
a. Before instituting an arbitration, if you have any dispute, we strongly encourage you to contact the Company to
try to resolve the matter by calling 800.218.3560, although you are not required to do so.
b. The arbitration of any claim or dispute under this Agreement shall be conducted in accordance with the expedited
procedures set forth in the JAMS Comprehensive Arbitration Rules and Procedures as those Rules exist on the date
you receive the Product, including Rules 16.1 and 16.2 of those Rules. These rules and procedures are available
by calling JAMS or by visiting its web site at www.jamsadr.com. The arbitration of any claim or dispute under this
Agreement shall be conducted by an arbitrator who has at least five years of experience conducting arbitrations.
c. The arbitration of any claim or dispute under this Agreement shall be conducted in the State of California or
the location in which you received this Agreement. For claims of $10,000 or less, you may choose whether the
arbitration proceeds in person, by telephone, or based only on submissions.
d. The Company shall pay costs for the arbitration of claims, including any JAMS Case Management Fee and all
professional fees for the arbitrator’s services. The Company shall pay the fees and costs of its own counsel, experts
and witnesses and shall not be able to recoup them from you even if you do not prevail in the arbitration. Unless
otherwise provided by law, you acknowledge and agree that you shall pay the fees and costs of your own counsel,
experts and witnesses.
4. CHOICE OF LAW.
The arbitration provisions of this Agreement and any arbitration conducted pursuant to the terms of this Agreement
shall be governed by the Federal Arbitration Act (9 U.S.C. Secs. 1-16). In this respect, the parties acknowledge that
this Agreement involves a transaction conducted in interstate commerce. Otherwise, this Agreement and the rights
of the parties hereunder shall be governed by and construed in accordance with the laws of the State of California,
exclusive of conflict or choice of law rules.
5. SEVERABILITY.
If any provision of this Agreement is declared or found to be unlawful, unenforceable or void, such provision will be
ineffective only to the extent that it is found unlawful, unenforceable or void, and the remainder of the provision
and all other provisions shall remain fully enforceable.
ONE-YEAR LIMITED WARRANTY
ONE YEAR LIMITED WARRANTY
Your AquaTru™ water purifier is warranted to be free from defects in materials and workmanship
for one year from the original purchase date. Should the product have a defect in materials or
workmanship, we will repair or replace it without charge to you (a shipping and processing fee
will apply). Warranty does not include filters. To obtain service under warranty, simply call our
customer service center toll-free at 800.220.6570.
This warranty does not cover filters, damage caused by accident, misuse or any use other than as
intended and described in this product manual, or damage resulting from failure to maintain and
clean this product as specified in this product manual. This warranty applies only to the original
purchaser of the AquaTru™ water purifier.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT, INCLUDING IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION
TO THE WARRANTY PERIOD, AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY
AFTER THIS PERIOD.
Some states do not allow limitations on the duration of implied warranties, so the above limitation
may not apply to you. While this warranty gives you specific legal rights, you may also have other
rights which may vary from state to state.
Contact Info for Warranty Service:
A q u a T r u ™, L L C
1392 Sarah Place, Ste. B | Ontario, CA | 91761
1.800.220.6570 | www.aquatruwater.com
© 2016 AquaTru™, LLC. All Rights Reserved.
1514

Beyond Filtration Aq uaTr u™
1716
