Aquavolta Hydrogen Infuser & H2 Inhalator User manual

•The Hydrogen Infuser & H2 Inhaler produces 100 ml
Hydrogen gas per minute for preparation of hydrogen-rich
beverages or for inhalation of Hydrogen with a nasal
inhaler. With the corresponding Hydrogen quirler can
fully saturated hydrogen water (1.6 mg/l) be produced
in 90 sec. For this other Hydrogen boosters need at least
600 seconds!
•Since the hydrogen drink produced does not come into
any contact with electricity and electrodes, other drinks
such as juices, milk, soups can also be enriched with
hydrogen in a few seconds.
•Inhaling 100 ml/minute (1/3 inhaling - 1/3 pause - 1/3
exhaling) creates within 10 minutes a litre of pure
hydrogen energy in your body. This is the true power
nap, whether in the office, while watching TV or while
sleeping. Hydrogen inhalation and the drinking of
hydrogen-rich water has been a megatrend in Japan
since 2016.
Drinking Hydrogen water
&
breathing Hydrogen gas
Hydrogen Infuser
&
H2Inhalator
MANUAL

Inhalt
3. Intended purpose
4. Scope of delivery
5. Overview H2-Generator
6. Generator accessories
7. Commissioning 1
8. Commissioning 2
9. Commissioning 3
10.Commissioning 4
11.Preparing to inhale
12.Inhalation operation
13.Assembly of the Infuser
14.The quirler bottle
15.Not just water!
16.Maintenance signals
17.Filter change
18.Please note
19.Safety instructions
20.Core technology: PEM electrolysis
21.The pressure sensor
22.Quirler technology
23.Transfer of hydrogen
24. Technical data
2

Intended purpose
The hydrogen generator produces 100 ml
of purest hydrogen gas per minute and
can be used for two functions
1. Production of hydrogen-rich
beverages
2. Inhalation of hydrogen
3

Scope of delivery
The larger of the two packages contains
the hydrogen generator with inhalation
accessories.
The smaller package contains the
hydrogen infuser (quirler) with the
accessories for the production of
hydrogen-rich beverages.
The infuser only works if it is connected
to the hydrogen generator.
4

Overview
H2-Generator
1. Switching sensor
2. Window for function control
3. Tank cap of refill tank for double distilled water
4. Hydrogen outlet nozzle with cap
5. Valve for O2 outlet
6. Connecting socket for H2-water quirler
7. Socket for mains plug
5

Generator accessories
1. Nose inhaler
2. Mains cable
3. Power supply unit
4. Connecting cable
5. Water collector
6. Water filter
6

Commissioning 1
Screw on the water refill tank and
fill with double distilled water up to
the line marked on the left.
Then insert the water filter and turn
the cover of the water tank back in.
7

Commissioning 2
2. Plug the adapter of the power supply
unit into the lower right socket and
connect the power plug to the power
supply unit and a 220 volt socket.
A blue flashing light on the switch
sensor indicates that a test of the
device functions is being carried out.
8

Commissioning
3
3. Open the flip-cap above the H2 outlet. Then open the
O2 valve by pulling it upwards a little.
H2outlet with flip-cap
O2outlet to be pulled
out
9

Comissioning 4"
Very important!
Do not interrupt
this process!
4. Gently shake the unit 4-5 times to remove any remaining air
bubbles from the unit. Then press the sensor switch for 5
seconds to start the activation mode.
The activation process takes 2 hours. Meanwhile the blue
sensor lamp flashes. The O2 valve must be pulled out. This
process is also necessary if the device has not been used for
a long time.
10

Preparing to inhale
1. Insert the curved short
hose of the water collector
into the open H2 outlet.
2. Firmly push the end of
the nasal inhaler onto the
second outlet of the water
collector.
3. Tighten the nasal
inhaler on the back of the
head as shown on the
right.
11

Inhalation operation
Pressing shortly on the sensor button starts the release of hydrogen into the nasal inhaler. The
sensor lights up blue. Press again to stop. After two hours the device stops automatically. So you
can work, watch TV, play cards and even sleep. If there is not enough water in the device, it beeps
and a red LED light lights up. Then it's time to refill the water tank with double-distilled water.
12

Assembly of the Infuser
Quick guide Infuser mode:
1. Fill the drink exactly up to the 400
ml mark.
2. Tighten the lid and release the H2
input socket.
3. Connect the H2 input socket to the
H2 output of the inhaler.
4. Connect the power to the inhaler.
5. Start hydrogen generator with
sensor key.
6. As soon as bubbles rise in the
quirler, start quirling with the on/off
button.
7. The vortex quirler stops after 90
seconds. Water is then fully saturated
with hydrogen.
8. Other drinks: Stop the quirler after
10 to 30 seconds with the on/off
switch. Hot drinks up to 60 degrees C
can be whirled for up to 60 seconds.
On/off switch
13
Quirler
H2
infusions tube
H2 inlet
Pouring- /
drinking
outlet
O2 – outlet must always be open when quirling!

The Hydrogen Infusor quirler bottle
The water or other desired non-carbonated drink (tea, juice, milk etc.) is filled exactly up to the 400 ml
mark (1) into the quirler bottle. The lid of the quirler is turned to the indicated position (2). The quirler is
then connected to the hydrogen generator using the short hose (3) from the quirler accessories. The
oxygen outlet must always be open!
The current for the quirler is supplied via the connecting cable from the hydrogen generator. Attention:
The plugs (4) (5) are sensitive and may only be inserted with the white arrow pointing upwards. First the
hydrogen generator is started via the sensor key (6). The oxygen outlet (7) must be open. Then secondly
the quirler with the start button (8). Production (9) stops after 90 seconds. If you have bubbled beverages
other than water with hydrogen, clean the bottle immediately after use with water at 60° and a mild
detergent. Shake well and rinse with clear water. 14
1
7
6
5
4
3
2
9
8

Not just
water!
Classic hydrogen water devices such as the popular hydrogen
boosters subject the water to electrolysis to draw hydrogen gas
from the water and enrich it with this popular gas. However,
electrolysis excludes beverages other than water because direct
contact with the electrodes can lead to undesirable chemical
reactions in juices, teas, milk, coffee or the like. Therefore in
hydrogen boosters or water ionizers only operating with water
makes sense and everything else is strictly forbidden.
The Aquavolta® Hydrogen Infuser, on the other hand, produces
hydrogen from the purest laboratory water with a purity of almost
100%. The liquid quirled with hydrogen in the Infuser has thus
no electrode contact and no unwanted chemical reactions take
place. This opens the hydrogen world for people who don't just
like to drink water. Only carbonated beverages are not
allowed.
15

1. Maintenance signals
2. Maintenance signals
•Water level warning: The LED is permanently red and
a beep sounds. Please refill the tank with double
distilled water.
•Water in the supply line to the nasal inhaler or
quirler: The LED blinks red and a beep sounds.
•Briefly press the sensor button to switch off the light and
please dry the nasal inhaler. If necessary, replace the
nasal inhaler with a new one.
•If more water than marked has accumulated in the
water container, empty it.
16
Maintenance signals

Filter change
•If the LED flashes blue, the filter must be
changed.
•First switch off the device at the switching
sensor.
•Unscrew the cover of the water tank and
replace the removable filter.
•Screw in the water tank cover again and briefly
press the sensor button. The blue light stops
flashing after a beep.
17

Please note:
01. Please use only original filters for replacement.
02. Only pour double distilled water (laboratory water) into the tank.
03. The nasal inhaler must not be used by the same person for more than 1 month
and must be replaced at the latest then.
04. During operation, steam or condensate may be released from the nasal inhaler.
Simply shake it out.
05. Never connect the nasal inhaler directly to the appliance, but always insert the
water collector between the appliance and the machine. Otherwise water could get
into your respiratory tract.
06. The correct operation of the appliance is indicated by gas bubbles rising in the
window. The maximum hydrogen production starts after approx. 5 minutes.
08. If you want to transport the device over long distances, please do not forget to
tightly close the flip-cap of the H2 outlet and the oxygen outlet so that no water can
escape.
09. We recommend to use the device at least once a day. If you do not want to use it
for more than 2 weeks, you should pour the water out of the tank. The two-hour
activation must then be carried out before restarting the system.
10. The activation process must also be carried out if you have the impression that
too few bubbles are rising in the viewing window.
11. If you fill too much water (higher than marked) when refilling it, the water may
splash out through the outlets. Then remove excess water until at the mark.
18

Safety instructions
01. Before switching on, the valve for the O2 outlet must be pulled upwards.
02. Only use the unit in a ventilated room and keep heat away from it.
03. Make sure that the power plugs are firmly plugged in.
04. The unit must be horizontal. Otherwise the tilt protection sensor could cause a
forced switch-off.
05. If the unit overheats, it switches off automatically. A red and blue LED flash
alternately in the viewing window. Then briefly press the switching sensor to switch
off the LEDs and wait until the device has cooled down before restarting.
06 If the tank is overfilled, remove the excess water. When wiping the appliance,
make sure that there are no water drops, especially on the ventilation grille on the
back.
07. The unit always switches off automatically if faults occur. Pay attention to the
displayed LEDs and the instructions in this manual. If the unit does not restart
despite correct operation, please contact your dealer's service representative. Do
not open the unit yourself under any circumstances.
08 Children and persons with impaired consciousness must operate the device with
a person who is familiar with the operating instructions.
09 If you feel unwell during or after use of the product, do not continue to use it.
10. The use of open fire in the room (fireplace) in which you use it is prohibited.
Ventilate the room before each use of the inhaler.
19

Core technology: PEM electrolysis
20
