araknis AN-620-SW User manual

AN-620-SW
Araknis 620 Switch Quick Start Guide
Welcome to Araknis Networks™
Thank you for choosing an Araknis 620 series managed switch. With multi-gigabit
connectivity on all ports, updated modern aesthetics, and a managed interface, the
Araknis 620 series switch is a sleek and highly capable addition to any network.
Series overview
Model Ethernet
Ports SFP+Ports
PoE
Budget
(Watts)
AN-620-SW-R-8-POE 8 2 240
AN-620-SW-R-24-POE 24 2 720
1

Unboxing
The package contains:
Switch Rubber feet for flat
surfaces (4)
Rack-mount kit:
ears (2), screws
(8)
Quick Start Guide
QRcard
AC power cord
2

Installing the switch
Rack mount Shelf mount
Caution: -.To avoid possible interference or damage, do not stack equipment on top
of the switch.
Rack mounting guidelines
lThe maximum ambient temperature of the space the switch is installed in should
not exceed 122 °F/50 °C.
lAllow to air flow through the rack.
lVerify all the leveling feet or casters are adjusted correctly and they come in
contact with the supporting surface. Always load heavier equipment at the
bottom of the rack.
lMake sure the rack is grounded and the equipment is surge protected.
3

lDo not overload the power equipment, or the switch. Check out our WattBox Best
Practices for more information.
4

Step 3: Connections
SFP+ ports
The SFP+ (Small Form Factor Pluggable plus) ports support up to 10 Gbps connection
and are typically used to connect switches together. Use SFP+ adapters for RJ45 or
multi-mode fiber cables (sold separately).
5

PoE budgeting
The PoE budget (Power over Ethernet) limits the amount of power available to all ports,
with a maximum of 60W on an individual port. Add the total number of possible watts
that the connected devices can consume to make sure everything can receive power
reliably. See the example below.

Model PoE budget
(Watts)
AN-620-SW-R-8-
POE 240
AN-620-SW-R-
24-POE 720
Total PoE budget available = 240
Total PoE device consumption = 47
Remaining PoE budget available = 193
6

LED states &reset procedures
Front
LED LED state Description
Power

On The switch is powered on.
Off The switch is powered off.
Speed/PoE


On The port is passing 2.5Gbps and/or PoE.*
Off The port is not passing 2.5Gbps and/or PoE.*
Link/Act


On The port detects a connection.
Blinking Packets are flowing through the port.
Off The port does not detect a connection or the
port is disabled.
*Configurable in the web interface.
7

Rear
LED LED state Description
RJ45 2.5G

On The RJ45 port is negotiating packets at 2.5Gbps.
Off
The RJ45 port is not negotiating 2.5Gbps but may be
passing traffic. Check the Link/Act LED to verify if packets
are flowing through the port.
SFP 10G


On The SFP port is negotiating packets at 10Gbps.
Off
The SFP port is not negotiating 10Gbps but may be
passing traffic. Check the Link/Act LED to verify if packets
are flowing through the port.
Link/Act

Blinking Packets are flowing through the port.
Off The port does not detect a connection.
8


Reset procedures
The reset button is on the back of the
switch.
Note: -__.The front and back power LEDs have the same behavior.
Reset button action LEDstate Description
Hold the reset button for 1-9
seconds Blinking slowly Restarts the switch
Hold the reset button for 10-
19 seconds
Blinking
moderately
Resets the username and
password to araknis.
Hold the reset button for
more than 20 seconds Blinking rapidly Resets the switch to factory defaults.
9

Step 5: Configuration
Araknis switches can be configured through OvrC or the local interface. The local
interface is accessible using OvrC’s webconnect feature, typing the switch’s DHCP
address into your browser’s address bar, or using the switch’s default IP address.
Configuring the switch in OvrC
OvrC provides remote device management, real-time notifications, and intuitive
customer management, using your computer or mobile device. Setup is plug-and-play,
with no port forwarding or DDNS address required.
To add this device to your OvrC account:
1. Connect the switch to the internet.
2. Log into OvrC (www.ovrc.com).
3. Scan the site using an OvrC Pro
device, or add the switch manually
by entering the MAC address and
Service Tag.
Logging into the web interface
1. Log into the switch using the default
credentials:
Username araknis
Password araknis
2. You must update the password after
initial login.
10

Pro Tip: -_Strong passwords are long and unrelated to the client’s public details. For
example, thepepperonipizzas is stronger and easier to remember than
P@ssword or thesmiths.
Other access methods: DHCP IPaddress
The switch is configured to DHCP by default so that the DHCP
server can assign an IP address when the switch is connected to
the network (the DHCP server is usually the router). This address
can be used for accessing the web interface.
Use one of these methods to find the IP address of the switch:
lCheck the device list in OvrC.
lCheck the client table on your router.
lUse a network scanner (e.g. Fing) to scan the network. The
Araknis switch manufacturer field displays SnapAV.
lSee the highlighted field in the Fing screenshot to the right
for an example of an Araknis device being identified.
Accessing the switch using the default
IPaddress
If the switch is not given a DHCP address, or needs to be accessed while not connected
to a network, you can configure your computer’s network connection to access the
switch using the default IP address, 192.168.20.254.
1. Connect your PC to the switch using an Ethernet cable.
2. Open the Control Panel and click Network and Internet.
11

3. Click Network and Sharing Center.
4. Click Change adapter settings.
12

5. Right-click the icon for the wired network connection, then left-click Properties.
6. Select Internet Protocol Version 4 (TCP/IPv4), then click Properties
13

7. In the General tab, click Use the following IP address: and enter the IP address
and subnet mask, then click OK.
IPAddress 192.168.20.2
Subnet Mask 255.255.255.0
14

8. Open a browser and navigate to https://192.168.20.254/. Log in using the default
credentials:
Username araknis
Password araknis
9. After configuring the switch, set your computer’s IPv4 Properties back to Obtain an
IP address automatically, then click OK.
15

16

Specifications
AN-620-SW-R-8-
POE
AN-620-SW-R-24-
POE
Ethernet ports
2.5G RJ-45 PoE ports 8 24
10G SFP+ ports 2 2
Hardware performance
Flash memory NAND: 128MB
NOR:32MB
NAND: 128MB
NOR:32MB
SDRAM 512MB 512MB
Packet buffer 12MB 16MB
MACaddress table size 16K 32K
Switching capacity 80Gbps 160Gbps
Forwarding rate 59.52Mpps 119.04Mpps
PoE features (802.3bt Type 3 PoE++)
Max power output per port 60W 60W
Total PoE power budget 240W 720W
Enable/Disable per port Yes Yes
Priority setting per port Yes Yes
Overload protection per port Yes Yes
Power level Setting per port Yes Yes
Environmental
Dimensions (W x H x D)
443 mm (17.44")x 300
mm (11.81")x 44 mm
(1.73")
443 mm (17.44")x 300
mm (11.81")x 44 mm
(1.73")
Power supply 110-240V AC,50/60HZ 110-240V AC,50/60HZ
17

AN-620-SW-R-8-
POE
AN-620-SW-R-24-
POE
Device power consumption 33.68W 70.77W
Max power consumption 42.1W 88.47W
Operating temperature 0-50°C 0-50°C
18

Technical Support
For chat and telephone, visit snp1.co/techsupport • Email:
[e-mail]. Visit snp1.co/tc for discussions, instructional videos,
news, and more.

19

Warranty and Legal Notices
Find details of the product’s Limited Warranty and other resources such as regulatory
notices and patent and safety information, at snapone.com/legal or request a paper
copy from Customer Service at 866.424.4489.

