Aras INTELLIGENT NETWORK KEYBOARD User manual

Network Keyboard
i
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated "dangerous voltage" within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
COMPLIANCE NOTICE OF FCC:
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL
DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE
REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN
A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO
FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION
MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS
EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE, IN WHICH CASE
USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE
FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-
CAUSING EQUIPMENT REGULATIONS.
The information in this manual is believed to be accurate as of the date of publication. IDIS Co., Ltd. is not responsible
for any problems resulting from the use thereof. The information contained herein is subject to change without notice.
Revisions or new editions to this publication may be issued to incorporate such changes.

User’s Manual
ii
Important Safeguards
1. Read Instructions
All the safety and operating instructions should be read before the appliance
is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future reference.
3. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do not use
liquid aerosol cleaners. Use a damp soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the approval of the
manufacturer as such additions may result in the risk of fire, electric shock
or other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with water.
6. Accessories
Do not place this equipment on an unstable cart, stand or table. The
equipment may fall, causing serious injury to a child or adult, and serious
damage to the equipment. Wall or shelf mounting should follow the
manufacturer's instructions, and should use a mounting kit approved by
the manufacturer.
This equipment and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the equipment and
cart combination to overturn.
7. Power Sources
This equipment should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power,
please consult your equipment dealer or local power company.
8. Power Cords
Operator or installer must remove power and TNT connections before
handling the equipment.
9. Lightning
For added protection for this equipment during a lightning storm, or when
it is left unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This will
prevent damage to the equipment due to lightning and power-line surges.
10. Overloading
Do not overload wall outlets and extension cords as this can result in the
risk of fire or electric shock.
11. Objects and Liquids
Never push objects of any kind through openings of this equipment as
they may touch dangerous voltage points or short out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the
equipment.
12. Servicing
Do not attempt to service this equipment yourself. Refer all servicing to
qualified service personnel.
13. Damage requiring Service
Unplug this equipment from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid is spilled, or objects have fallen into the equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by following the operating
instructions, adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician
to restore the equipment to its normal operation.
E. If the equipment has been dropped, or the cabinet damaged.
F. When the equipment exhibits a distinct change in performance ─this
indicates a need for service.
14. Replacement Parts
When replacement parts are required, be sure the service technician has
used replacement parts specified by the manufacturer or that have the same
characteristics as the original part. Unauthorized substitutions may result
in fire, electric shock or other hazards.
15. Safety Check
Upon completion of any service or repairs to this equipment, ask the service
technician to perform safety checks to determine that the equipment is
in proper operating condition.
16. Field Installation
This installation should be made by a qualified service person and should
conform to all local codes.
17. Correct Batteries
Warning: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
18. Tmra
A manufacturer’s maximum recommended ambient temperature (Tmra)
for the equipment must be specified so that the customer and installer may
determine a suitable maximum operating environment for the equipment.
19. Elevated Operating Ambient Temperature
If installed in a closed or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater than room ambient.
Therefore, consideration should be given to installing the equipment in
an environment compatible with the manufacturer’s maximum rated
ambient temperature (Tmra).
20. Reduced Air Flow
Installation of the equipment in the rack should be such that the amount
of airflow required for safe operation of the equipment is not
compromised.
21. Mechanical Loading
Mounting of the equipment in the rack should be such that a hazardous
condition is not caused by uneven mechanical loading.
22. Circuit Overloading
Consideration should be given to connection of the equipment to supply
circuit and the effect that overloading of circuits might have on over current
protection and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
23. Reliable Earthing (Grounding)
Reliable grounding of rack mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct
connections to the branch circuit (e.g., use of power strips).
WEEE (Waste Electrical & Electronic Equipment)
Correct Disposal of This Product
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the
end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for
details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should
not be mixed with other commercial wastes for disposal.

Network Keyboard
iii
Table of Contents
Chapter 1 — Introduction ............................................................................................ 1
1.1 In This Manual.................................................................................................. 1
1.2 Features ........................................................................................................... 1
1.3 Package Contents............................................................................................ 1
1.4 Rear Panel ....................................................................................................... 2
1.5 Bottom Panel.................................................................................................... 3
Factory Reset ................................................................................................... 3
1.6 Front Panel....................................................................................................... 4
1.7 Typical Applications ......................................................................................... 5
Chapter 2 — Installation .............................................................................................. 9
2.1 PTZ Camera..................................................................................................... 9
Basic Setup ...................................................................................................... 9
Advanced Setup............................................................................................. 10
2.2 DVR System...................................................................................................10
Basic Setup .................................................................................................... 10
Advanced Setup............................................................................................. 11
2.3 Network Matrix System (Transmitter, Receiver and Camera) ....................... 12
2.4 MMX System .................................................................................................. 14
Chapter 3 — Operation .............................................................................................17
3.1 Overview ........................................................................................................ 17
3.2 Operation Commands .................................................................................... 17
3.3 PTZ Camera...................................................................................................18
PTZ Camera Control ...................................................................................... 18
3.4 DVR System...................................................................................................18
PTZ Camera Control ...................................................................................... 19
DVR Control on Main Monitor ........................................................................ 19
DVR Control on Monitor (Advanced Setup Installation Only) ........................ 19
3.5 Network Matrix System (Transmitter, Receiver and Camera) ....................... 19
PTZ Camera Control ...................................................................................... 20
Camera Control on Main Monitor................................................................... 20
Camera Control on Pane ............................................................................... 20
3.6 MMX System .................................................................................................. 21
PTZ Camera Control ...................................................................................... 21
DVR Control on Main Monitor ........................................................................ 21
Camera Control on Main or Spot Monitor ...................................................... 21
DVR Control on Pane..................................................................................... 22
Camera Control on Pane ............................................................................... 23
Chapter 4 — LCD Menu Configuration .....................................................................25
4.1 Buttons for LCD Menu Configuration .............................................................25
4.2 Entering or Exiting LCD Setup Menu ............................................................. 25
4.3 Setup Menu .................................................................................................... 26
System ........................................................................................................... 26
Device ............................................................................................................ 26

User’s Manual
iv
Chapter 5 — Remote Configuration ..........................................................................27
5.1 System ........................................................................................................... 27
General........................................................................................................... 27
Button ............................................................................................................. 28
LCD ................................................................................................................ 28
Audio .............................................................................................................. 29
5.2 Network .......................................................................................................... 29
IP Address...................................................................................................... 29
DVRNS........................................................................................................... 29
5.3 Device ............................................................................................................ 30
General........................................................................................................... 30
Setup .............................................................................................................. 31
5.4 Function.......................................................................................................... 32
Macro ............................................................................................................. 32
Button ............................................................................................................. 33
Appendix.................................................................................................................... 35
Troubleshooting..................................................................................................... 35
Connector Pin Outs...............................................................................................35
Front Panel Buttons .............................................................................................. 35
PTZ Camera Model Number ................................................................................. 38
Specifications ........................................................................................................ 39

Network Keyboard
1
Chapter 1 — Introduction
1.1 In This Manual
This manual is intended for users of the network keyboard and includes instructions for using and managing
the network keyboard on the network.
1.2 Features
This network keyboard controls DVRs, MMXs, network transmitters, network receivers, network cameras
and PTZ cameras remotely via RS485 or Ethernet connections. The network keyboard can be accessed,
configured and managed by using the INIT (Integrated Network Installation Tool) program. This network
keyboard offers the following features:
yRemote control of DVRs, MMXs, network transmitters, network receivers and network cameras via RS485
or Ethernet connections
yRemote control of various models of PTZ cameras via network connections
yTwo-way audio communication
yConvenient firmware upgrades via either the USB port or Ethernet
yFirmware duplication and autorecovery functions to enhance system stability
yManagement of multiple network keyboards via Ethernet connections
yRecalls of maximum 100 macros and function mapping of maximum 8
yProgrammable through LCD screen (Basic Setup only)
Compatible Devices
yDVRs (Digital Video Recorder)
yMMX (Multi-Matrix Extension)
yNetwork Transmitters
yNetwork Receivers
yNetwork Cameras
yPTZ Cameras
1.3 Package Contents
yNetwork Keyboard
yJoystick (Removable)
yDC Adapter (5V)
yPower Cord
yInstallation CD (INIT)
yUser’s Manual (This Document)
yINIT User’s Manual
yRack-mount Kits

User’s Manual
2
1.4 Rear Panel
No. Designation Details
1Speaker
Connect to an amplifier. (Line-out)
2MIC
Connect to an audio source. (Line-in or Microphone)
3USB Ports
Connect a USB flash drive to upgrade the software. Refer to INIT User’s Manual
– Management, Upgrade for details on software upgrades.
4Network Port
Connect a UTP Cat5 cable with an RJ-45 jack. Refer to INIT User’s Manual
– Setup, IP Address Setup for details on network connection setup.
5RS485 PTZ
Port
Connect to PTZ cameras. Connect TX+/RX+ and TX-/RX- of the PTZ camera
to the + and – (respectively) of the network keyboard. Refer to the PTZ camera
manufacturer’s manual for configuring the RS485 connection.
6RS485 DVR
Port
Connect to DVRs. Connect TX+/RX+ and TX-/RX- of the DVR to the + and –
(respectively) of the network keyboard. Refer to the DVR manufacturer’s
manual for configuring the RS485 connection.
7Power In
Connect the power adaptor to the network keyboard. The network keyboard
starts booting as soon as power is applied.
8Joystick
Connect a joystick cable to the network keyboard.
NOTES:
yThe network keyboard does not have amplified audio output, so you will need a speaker with
an amplifier.
yAudio surveillance may be prohibited by laws that vary by region. Check the laws in your area
before using this product for surveillance purposes.
CAUTION: The network connector is not designed to be connected directly with cable or
wire intended for outdoor use.
WARNING: ROUTE POWER CORDS SO THAT THEY ARE NOT A TRIPPING HAZARD. MAKE
CERTAIN THE POWER CORD WILL NOT BE PINCHED OR ABRADED BY FURNITURE.
DO NOT INSTALL POWER CORDS UNDER RUGS OR CARPET. THE POWER CORD HAS
A GROUNDING PIN. IF YOUR POWER OUTLET DOES NOT HAVE A GROUNDING PIN
RECEPTACLE, DO NOT MODIFY THE PLUG. DO NOT OVERLOAD THE CIRCUIT BY
PLUGGING TOO MANY DEVICES INTO ONE CIRCUIT.

Network Keyboard
3
1.5 Bottom Panel
No. Designation Details
1Factory Reset
Switch
Use to return all settings to the original factory settings. See below
for details.
2Joystick Bracket
Attach the joystick by using the bracket provided with the product to control
a PTZ camera.
3RS485 DVR
Termination
Set the switch to On if RS485 communication environment is not good
when controlling a DVR via RS485 connection.
4RS485 PTZ
Termination
Set the switch to On if RS485 communication environment is not good
when controlling a PTZ camera via RS485 connection.
5Joystick Input Port Connect the joystick cable.
Factory Reset
This switch will only be used on the rare occasions that you want to return all the settings to the original
factory settings.
CAUTION: When performing a Factory Reset, you will lose any settings you have saved.
You can perform a factory reset while the network keyboard is turned on. Poke a straightened paperclip
into the factory reset switch hole and hold the switch for about three seconds. Releasing the reset switch
performs factory reset and restarts after completing the factory reset. A factory reset also can be performed
remotely by running the INIT program and selecting the Reset – Factory Reset menu. The network keyboard
restarts after completing the factory reset. Refer to INIT User’s Manual for details on remote factory resetting.

User’s Manual
4
1.6 Front Panel
No. Designation Details
1Joystick Controls Pan, tilt and zoom of a PTZ camera.
2PTZ Camera
Control Buttons
Controls the PTZ camera by setting up presets or expanded PTZ features. See
Appendix: Front Panel Buttons, PTZ Camera Control for details.
3LCD Screen
Displays command for operations or menu for configuration. See Chapter 3
— Operation, Chapter 4 — LCD Menu Configuration for details.
4Device Control
Buttons
Controls remote devices. See Appendix: Front Panel Buttons, Device
Control for details.
5Arrow Buttons
Arrow buttons allows you to navigate through setup menus or adjust number’s
value during the LCD setup. They also are used to control Pan and Tilt when
in the PTZ mode. In the playback mode, pressing the and , plays video
backward and forward. When in the pause mode, pressing the button moves
to the next image and pressing the button moves to the previous image.
6Enter Button
Pressing the (Enter) button selects an item or completes an entry that you
have made during the LCD setup. In the live monitoring mode, pressing the
button freezes the current screen. When in the playback mode, pressing
the button pauses playing video.
7Command
Control Buttons
Commands the preset action. See Chapter 3 — Operation, 3.2 Operation
Commands (p. 17) for details.
8
Jog Dial
The Jog Dial only functions when playback video has been paused. By turning
the jog dial clockwise, you can play video forward image-by-image. By turning
the jog dial counterclockwise, you play video backward image-by-image.
Shuttle Ring
Functions only in the Playback mode. The shuttle ring is spring loaded and
returns to the center position when released. Turning the ring clockwise plays
video forward. Turning the ring counterclockwise plays video backward.
Playback varies with the amount the ring is turned. The playback speeds are
fast forward, rewind, step forward and step backward.

Network Keyboard
5
1.7 Typical Applications
PTZ Camera
9You can control PTZ cameras directly connected to a network keyboard via RS485 connections. The
PTZ control buttons and joystick are provided for the PTZ control. See Chapter 2 — PTZ Camera (p. 9)
section for details of the connections.
DVR System
RS485 Connection
9You can control DVRs directly connected to a network keyboard via RS485 connections. The live or
playback video is displayed on the main monitor connected to each DVR. See Chapter 2 — DVR System
(p. 10) section for details of the connections.

User’s Manual
6
Ethernet Connection
9You can control DVRs remotely by a network keyboard via Ethernet connections. The live or playback
video is displayed on the main or spot monitor connected to each DVR, and you can change camera
channels on the monitor remotely. See Chapter 2 — , DVR System (p. 10) section for details of the
connections.
Network Matrix System (Network Transmitter, Receiver and Camera)
9You can build a virtual matrix system with network transmitters, network receivers and network cameras
via Ethernet connections. See Chapter 2 — Network Matrix System (Transmitter, Receiver and
Camera) (p. 12) section for details of the connections.

Network Keyboard
7
MMX Connections
9You can build a matrix system with MMXs and DVRs and control live monitoring and playback on the
main and spot monitors by a network keyboard via Ethernet connections. You also can control PTZ cameras
connected to DVRs. See Chapter 2 — MMX System (p. 14) section for details of the connections.

User’s Manual
8

Network Keyboard
9
Chapter 2 — Installation
The network keyboard provides two kinds of setup type for registration of devices: Basic setup and Advanced
setup. The Basic setup supports RS485 connections only, and the Advanced setup supports both RS485
and Ethernet connections. The LCD setup menus are provided for the Basic setup, and the INIT program
is provided for both the Advanced setup and Basic setup.
2.1 PTZ Camera
You can register PTZ cameras directly connected to a network keyboard via RS485 connections in both
the Basic setup and the Advanced setup. The Basic setup does not support network connections of any
devices while the Advanced setup support both RS485 connections and Ethernet connections.
Basic Setup
PTZ cameras can be registered on the network keyboard in the Basic setup locally through the LCD setup
menus or remotely through the INIT program. See Chapter 5 — Remote Configuration, 5.3 Device
for details on the remote registration through the INIT program.
1. Connect PTZ cameras to RS485 PTZ port of the network keyboard referring to the PTZ camera’s User’s
Manual.
2. Enter the LCD setup menu. See Chapter 4 — LCD Menu Configuration for details on entering and
configuring the LCD setup menu.
3. Go to the Device →General menu.
3.1. Set up Setup Type to Basic.
3.2. Set up Port to PTZ and set up port for RS485 communications referring to the settings on the PTZ
camera.
→→
→
→→ →
4. Go to the Setup menu.
4.1. Enter the number of cameras connected to the network keyboard in the Number of CAMs field.
4.2. Enter the ID to distinguish the camera from others when controlling it by a network keyboard and
then the 485 ID and model number for the RS485 communication. See Appendix: PTZ Camera
Model Number for details on the model number of each PTZ camera.
→→ →

User’s Manual
10
→
Advanced Setup
PTZ cameras can be registered on the network keyboard in the Advanced setup remotely through the INIT
program. You can set up Baud Rate, Data bit, Stop bit and Parity differently for each PTZ camera when
PTZ cameras have different settings in the Advanced setup while the settings are applied to all PTZ cameras
in the Basic setup. See Chapter 5 — Remote Configuration, 5.3 Device for details on the remote
registration through the INIT program.
2.2 DVR System
You can register DVRs connected to a network keyboard via RS485 connections or Ethernet connections.
The Basic setup does not support network connections of any devices while the Advanced setup support
both RS485 connections and Ethernet connections.
Basic Setup
DVRs can be registered on the network keyboard in the Basic setup locally through the LCD setup menus
or remotely through the INIT program. See Chapter 5 — Remote Configuration, 5.3 Device for details
on the remote registration through the INIT program.
1. Connect DVRs to RS485 DVR port of the network keyboard referring to the DVR’s User’s Manual.
2. Enter the LCD setup menu. See Chapter 4 — LCD Menu Configuration for details on entering and
configuring the LCD setup menu.
3. Go to the Device →General menu.
3.1. Set up Setup Type to Basic.
3.2. Set up Port to DVR and set up port for RS485 communications referring to the settings on the DVR.
→→
→
→→ →
4. Check the DVR’s system ID in the DVR settings for remote control by a network keyboard.

Network Keyboard
11
Advanced Setup
DVRs can be registered on the network keyboard in the Advanced setup remotely through the INIT program.
You can control DVRs with the user-defined ID registered on the network keyboard in the Advanced setup
while you control DVRs with the DVR’s system ID preset in each DVR in the Basic setup. You can also set up
monitor ID for controlling the main monitor or spot monitors. See Chapter 5 — Remote Configuration,
5.3 Device for details on the remote registration through the INIT program.
1. Connect DVRs to the RS485 DVR port of the network keyboard via RS485 connections, or to the network
via Ethernet connections referring to the DVR’s User’s Manual
2. Connect the network keyboard to network via Ethernet connections See Chapter 1 — Rear Panel.
3. Run the INIT program and connect to the network keyboard to register the DVRs.
4. Go to the following menus: Setup →Remote Setup →Network
→IP Address
Set up the network keyboard’s network connection information.
5. Go to the following menus: Setup →Remote Setup →Device
→General
Select Advanced from the Setup Type drop-down list.
6. Go to the following menus: Setup →Remote Setup →Device
→Setup
6.1. Click DVR in the device list and the Add button to register
the DVR on the network keyboard.

User’s Manual
12
6.2. Set up the registration information.
yID: The network keyboard assigns the ID automatically in registration
order and you can change it. The ID will be used when controlling the
device by a network keyboard.
yConnection: Select RS485 or Ethernet depending on the connections
to the network keyboard.
−RS485: Enter the DVR’s system ID preset in the DVR settings when
the DVR is connected via RS485 connections.
−Ethernet: Enter the IP address, port number, user ID and password
for the connection to the DVR when the DVR is connected via RS485
connections.
6.3. Click the OK button.
6.4. Click the DVR pull-down menu in the device list, then the
registered DVR’s pull-down menu. A list of monitors and
cameras connected to the DVR is displayed.
6.5. Click a monitor or a camera in the list and click the Edit
button.
6.6. Set up the monitor or camera information.
yID: The network keyboard assigns the ID automatically in registration
order when the DVR is registered and you can change it. The ID
will be used when controlling the monitor or camera by a network
keyboard.
yType: Set up the camera type.
−Fixed: Select if the camera is not a PTZ camera.
−PTZ Camera: Select if the camera is a PTZ camera and set up
the device that the PTZ camera is connected.
2.3 Network Matrix System (Transmitter, Receiver and Camera)
You can register network devices including network transmitters, receivers and cameras connected to a
network keyboard via Ethernet connections. Only Advanced setup is supported remotely through the INIT
program.
1. Connect the network devices to network via Ethernet connections referring to each device’s User’s Manual.
2. Run the INIT program and connect to the network keyboard to register the devices.

Network Keyboard
13
3. Go to the following menus: Setup →Remote Setup →Network
→IP Address
Set up the network keyboard’s network connection information.
4. Go to the following menus: Setup →Remote Setup →Device
→General
Select Advanced from the Setup Type drop-down list.
5. Go to the following menus: Setup →Remote Setup →Device
→Setup
5.1. Click Network Camera, Network Transmitter or Network
Receiver in the device list and the Scan or Add button
to register the device on the network keyboard.
Clicking Scan button lists up all of network transmitters,
receivers and cameras in a LAN environment. Checking the
boxes of devices to register and clicking the Add button
allows you to register more than one device at a time on
the network keyboard. You can find a specific device by
entering the network information and by clicking the Manual
Scan button when the device is not listed up. Click the Add
button to register the device on the network keyboard.
5.2. Set up the registration information.
yID: The network keyboard assigns the ID automatically in registration
order and you can change it. The ID will be used when controlling the
device by a network keyboard.
yConnection: Select Ethernet and enter the IP address, port number,
user ID and password for the connection to the network device.
5.3. Click the OK button.

User’s Manual
14
5.4. Click the device’s pull-down menu in the device list, then
the registered device’s pull-down menu. A list of monitors
or cameras connected to the device is displayed.
5.5. Click a monitor or a camera in the list and click the Edit
button.
5.6. Set up the monitor or camera information.
yID: The network keyboard assigns the ID automatically in registration
order when the device is registered and you can change it. The ID
will be used when controlling the monitor or camera by a network
keyboard.
yPane ID: You can set up a pane ID to each pane of the monitor. The
pane ID provides a shortcut for selecting a pane during operation.
Pressing a pane ID and the PANE button is the same as pressing a
monitor ID and the MON, and then a pane number and PANE button.
yType: Set up the camera type.
−Fixed: Select if the camera is not a PTZ camera.
−PTZ Camera: Select if the camera is a PTZ camera and set up the
device that the PTZ camera is connected.
2.4 MMX System
You can register MMXs connected to a network keyboard via Ethernet connections. Only Advanced setup
is supported remotely through the INIT program.
1. Connect the MMXs to network via Ethernet connections referring to MMX’s User’s Manual.
2. Run the INIT program and connect to the network keyboard to register the devices.
3. Go to the following menus: Setup →Remote Setup →Network
→IP Address
Set up the network keyboard’s network connection information.
