Aratek Marshall Quick start guide

Mobile ID Terminal- Marshall
Operational Manual

V 1.0
Table OF CONTENTS:
1. Introduction………………………………………………………………………….….3
2. Important Safety Information…………………………………………….…….3
3. Product Interface………………………………………………………………….….4
4. Operations……………………………………………………………………………….7
5. Troubleshooting ………………………………………………………………………10
6. Technical Specifications……………………………………………………………11

Introduction
Portable. Powerful. Versatile. The ARATEK MARSHALL is an all-in-one device for easy identification and
Portable. Powerful. Versatile. The ARATEK MARSHALL is an all-in-one device for easy
identification and authentication anywhere. It is designed for demanding conditions
that require portability and accuracy.
Using advanced fingerprint capture technology and the patented BIONE biometric
engine, the ARATEK MARSHALL is the intelligent choice for identification and
authentication applications for voter registration and authentication, census, border
control, financial inclusion, welfare distribution, SIM card activation, and mobile
Time and Attendance management.
The ARATEK MARSHALL Fingerprint Scanner carries the FBI PIV Mobile ID FAP 20
(option for FAP30, FAP45) Certification, a guarantee of high quality captures, fast
and reliable matches, usability, and interoperability every time you need it.
Important Safety Information
Please follow the following safety instructions:
※Do not use liquid or aerosol cleaners for cleaning.
※Do not disassemble or modify the device.
※Do not try to charge the battery with other chargers.
※Do not yank the power cord or place anything on the power cord.
※Do not expose the device into fire or heat it, or it may cause crack and injury.
※Do not use or store the device under too hot, too cold or dusty environment.
※Do not drop, knock or shake the device violently, or it may damage internal circuit
board.
※Do not forget to turn off the device before SIM card insert and remove.

Product Interface
Model Name: Marshall
Specs: FAP20 FPR, NFC, Printer, MRZ, 10000mAh Battery, 3G/4G,2D
barcode, SCR

Operations
Before switching ON Marshall for the first time or after a long time period,
put it on charging until full power.
1.Charge
Even if the device is not switched ON, the battery will be charged
whenever the DC Adaptor power is available.
Red/green indicator light: red light when power charging is less
than 90%; green light when power charging is greater than or equal
to 90%.

2.On/Off operation
3.Install/Remove battery

4.Insert/Remove SIM card

Troubleshooting
Problem 1: charge failure
Solution: (1) Check if the plug is inserted correctly.
(2) Ensure that micro USB charging port has good contact.
Problem 2: heating
Solution: Avoid using the device under too hot environment. Stop device operation
for a while.
Problem 3: crash
Solution: a. Long press power button to turn off, then turn on.
b. Press reset button to restart device.
c. Contact SMARTMATIC support team.
Problem 4: Other problems
Solution: Contact Aratek for support, website: www.aratek.co
Technical Specifications

Basic
Operating System Android 8.1
Processor MT8735 Quad-core 1.3GHz
Memory 2G RAM + 16G ROM
Display 5 Inches 720*1280 Pixels IPS LCD
Resolution 720*1280 IPS
Camera 13 MP Auto Focus (Rear)
Expansion Card TF Card, Up to 64G
Printer (option) 2 Inches Thermal Printer
Battery 10000 mAh/3.7V Hi-Performance Li-ion
Charging DC 5V/2A
Weight 585g
Dimension 210*85*90 mm (L*W*H)
Accessories Power adapter, USB cable
Temperature and Humidity
Operation: 0℃~45℃, 10%~75%
Storage: -20℃~50℃, 5%~85
Biometrics
Type FAP20/FAP30/FAP45
Platen Area 21.0*16.0 mm
Sensing Area 20.3mm*15.2mm
Image Size Image Size: 300*400
Image Resolution 500 dpi
Grayscale 256 level
Communications
SIM Card Micro Sim Card *2
SAM Card PSAM Card *2
Wi-Fi 802.11 b/g/n
3G WCDMA B1 (EU) or WCDMA B2/ B5 (US)
4G LTE-FDD:B3 / B5 LTE-TDD: B40 (EU
) or
LTE-
FDD:B4 / B7 / B28 (US)
GPS PS/Glonass/A-GPS
Bluetooth Bluetooth 4.0
USB USB 2.0 *1, Micro USB (OTG) *1
Credential
Reading
NFC ISO/IEC 14443 A/B
2D Barcode 1D, 2D, PDF417, QR code, Code 39, Code 128,
DataMatrix, UPC-A, etc.
Smart Card Reader ISO 7816
MRZ Reader
ICAO 9303 e-passport ,
EN 60950-1: 2009,
FCC 47CFR Part 15 Class A,
EN 55024: 1998 + Amd1:2001 + Amd2: 2003

FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
SAR Information Statement
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radiofrequency (RF)
energy set by the Federal Communications Commission of the U.S. Government.
These limits are part of comprehensive guidelines and establish permitted levels of
RF energy for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health. The
exposure standard for wireless mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6
W/kg. * Tests for SAR are conducted with the phone transmitting at its highest
certified power level in all tested frequency bands. Although the SAR is determined
at the highest certified power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless base station antenna,
the lower the power output. Before a phone model is available for sale to the public,

it must be tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the ear and worn on the body) as
required by the FCC for each model. The maximum scaled SAR in front of face is
0.225W/Kg and extremity is 1.158W/Kg. While there may be differences between
the SAR levels of various phones and at various positions, they all meet the
government requirement for safe exposure. The FCC has granted an Equipment
Authorization for this model phone with all reported SAR levels evaluated as in
compliance with the FCC RFexposure guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/ oet/fccid after searching on
FCC ID: 2AGUJMARSHALL Additional information on Specific Absorption Rates (SAR)
can be found on the Cellular Telecommunications Industry Asso-ciation (CTIA)
web-site at http://www.wow-com.com. * In the United States and Canada, the SAR
limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one
gram of tissue. The standard incorporates a sub-stantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure
requirements, a minimum separation distance
of 10mm must be maintained between the user’s body and the handset, including
the antenna. Third-party belt-clips, holsters,
and similar accessories used by this device should not contain any metallic
components. Body-worn accessories that do not meet these requirements may not
comply with RF exposure requirements and should be avoided. Use only the
supplied or an approved antenna.
