Arbor Technology Nova-AGS1 User manual

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Nova 3 Door MDF Cupboard 400mm Wide (Nova-AGS1)
Before you commence the assembly process, we recommend that you read these instructions
thoroughly beforehand to familiarise yourself with the assembly process and to also check that
you have the correct components. If for any reason you need assistance, you can find our
contact details on the top of page of these instructions.
We highly recommend that any assembly is carried out on a flat, level surface if possible
and that you use another person to assist you if necessary. Also, all parts have stickers
with part numbers attached and for your convenience all guide holes are pre-drilled.
Package contents
2x Side panels (Part nr: AGS1_1)
3x Partitions (Part nr: AGS1_2)
1x Base (Part nr: AGS1_3)
1x Back panel (Part nr: AGS1_4)
1x Top door (Part nr: AGS1_5a)
1x Middle door (Part nr: AGS1_5b)
1x Bottom door (Part nr: AGS1_5c)
3x Leg panel (Part nr: AGS_2)
Bundle with fixings
Tools required
Electric screwdriver
No.2 and No.3 Pozi bits
Phillips Screwdriver
Hammer

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 1
Step 2
Lay the side panel (Part nr: AGS1_1) on a flat even
surface.
Take 6 hinge plates and prepare 4x16mm wood screws. Make
sure you are using pre-drilled guide holes.
Step 2.1
Step 3
Make sure that a small arrow on hinge plate facing
outwards.
Repeat steps 2 to 2.1 for the rest of hinge plates.

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 4
Step 5
Take base panel (AGS1_3) and align with side panel
(AGS1_1) pre-drilled guide holes as shown in step 5.
Flip your side panel of the side together with your base
panel and secure with confirmat screws as shown in step
5.1
Step 5.1
Step 6
In this step you might require an assistant, to hold you a
side panel.
Now, take 3x partition panels (AGS1_2) and proceed to step
7.

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 7
Step 8
Align partition panels as shown in the picture and secure
via pre-drilled guide holes using confirmat screws.
Flip your side panel back to starting position and your
cabinet at this stage should look like this.
Step 9
Step 10
Take you second side panel (AGS1_1) and secure it via pre-
drilled guide holes with confirmat screws. Don’t forget to
secure base as well.
**IMPORTANT**
Now, flip your cabinet as shown in the picture. Make sure
that hinge plates are facing down.
**IMPORTANT**

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 11
Step 12
Now take your back panel (AGS1_4) and place on top of
your cabinet back.
Secure back panel with provided nails using hammer. Make sure
that nails are spaced out approximately 30mm from each
corner.
Step 13
Step 14
At this stage, take 4 cabinet legs and secure them into
place as shown in the picture. These legs are adjustable
heigh 100mm to 130mm. You can adjust them at this stage
or later when you will position your cabinet into upright
position.
Position your cabinet into upright position (make sure you
have assistance) and at this stage your item should look like
this.

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 15
Step 16
Now take your doors (AGS1_5a/AGS1_5b/AGS1_5c).
Place hinges into pre-drilled holes and secure with wood screws
4x16mm. Repeat this step for all three doors.
Step 17
Step 18
At this stage, take first door (AGS1_5a) and secure it into
position as shown in the picture. Than take second door
(AGS1_5b) and secure into position and lastly take
(AGS1_5c) door and secure it into position. **Important**
insert the front of the plate in to front arm of the hinge.
Now press back arm of the hinge until you hear the click.
Now, using pre-drilled guide holes secure cabinet handles.

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 19
Step 20
At this stage your cabinet should look like this. However,
when you install the doors, they may be out of
alignment.
Start first by adjusting machine screw market as number one on
the arm of the hinge, this will adjust your door left-to-right or
horizontal position. If you need to adjust in and out position
simple adjust cam-screw marked as number two. To adjust up
and down or vertical position, simple release hinge plate.
Step 21
Step 22
Last step is to cover legs with a panel. Take leg panels
(AGS_2) and secure leg supports using pre-drilled guiles
and wood screws.
Take shorter and longer braces and align predrilled guide holes.

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
Step 23
Step 24
Secure both panels using confirmat screws. Repeat steps
for the other side.
Take your finished leg panel and clip it to the legs.

Phone number: 01945 410950
[e-mail]
http://www.arborgardensolutions.co.uk
Trading address: Unit 11, Cattle Dyke, Wisbech, England, PE1 34NR
**IMPORTANT**
If you have more than one Nova product, we strongly advise to connect them together via
guide holes, which you can find in each side panel corner. Also, please note that cabinets
and wall cupboards need fixing to walls conventionally using wall plugs and screws
suitable for your wall material. Please employ a tradesman if in doubt.
Step 1
Step 1.1
To connect cabinet to other cabinet, use pre-drilled
guide holes as shown in the picture. This should be your
last step, when you decided about the layout of your
Nova Garage Cabinet Systems.
Your 3 door cabinet is now completed!
We hope that you found your product quick and easy to assemble but if you require further
assistance or have any questions you can contact us via details above.
