Arbor Technology Gladius G1050 Series User manual

Gladius G1050 Series
10.4"Intel®Atom™ Z530P
Rugged Tablet PC
User's Manual
Version 1.2
P/N: 4012105000120P 2013.06

- II -
This page is intentionally left blank.

- i -
Revision History
Version Date Description
1.0 2011/07/29 initial release
1.0 2011/11/18
revise spec, ordering info, packing list according to datasheet
add RS-232, 3G installation steps
update function key installation steps, Section 2.6.13
delete WiFi, Smart Card installation steps
1.0 2011/11/22
update spec, main menu in Ch2.6, RS-232 installation steps
in Section 2.6.7
add WiFi installation steps in Section 2.6.8, option name in
Section 1.2
1.1 2012/02/17
insert “G1050S” after “G1050”
expand Ordering Info
add G1050S spec in LCD Display, Power Supply, Mechanical
& Environmental
1.1 2012/03/09 add note on p.32
change pic on p.16
1.1 2012/03/15
change Section 1.7 title
expand description on p.3
1.2 2013/06/28
The updates include:
G1050C is included: The manual title changes to
“Gladius G1050 Series User’s Manual“
New manual structure: Changes are applied throughout
the manual.
Section 3.1. Use Touch Screen is newly added.
Section 3.7. Use GPS (Configure-to-Order) is newly
added.

- ii -
This page is intentionally left blank.

- iii -
Contents
Revision History ............................................................................................i
Contents.......................................................................................................iii
Preface..........................................................................................................vi
Copyright Notice..................................................................................................vi
Declaration of Conformity....................................................................................vi
CE ...............................................................................................................vi
FCC Class B ...............................................................................................vi
RoHS.......................................................................................................... vii
SVHC / REACH.......................................................................................... vii
Important Safety Instructions ............................................................................. vii
Warning............................................................................................................. viii
General Cleaning Tips....................................................................................... viii
We recommend you to follow the cleaning steps................................................ix
Introducing the Rechargeable Battery Pack........................................................ix
Disposing of Your Old Computer..........................................................................x
Symbols Description ...........................................................................................xi
Technical Support................................................................................................xi
Warranty..............................................................................................................xi
Chapter 1 - Introduction...............................................................................1
1.1. The Computer ...............................................................................................2
1.2. About This Manual ........................................................................................2
1.3. Specications................................................................................................3
1.4. Inside the Package........................................................................................6
1.5. Ordering Information .....................................................................................7
1.5.1. Optional Accessories..........................................................................7
1.5.2. Congure-to-Order Service................................................................8
Chapter 2 - Getting Started........................................................................ 11
2.1. System Overview ........................................................................................12
2.1.1. Dimensions ......................................................................................12
2.1.2. Tour the Computer ...........................................................................13
2.1.2.1. Front Side............................................................................13
2.1.2.2. Top & Bottom Sides.............................................................16
2.1.2.3. Left & Right Sides ...............................................................16
2.1.2.4. Rear View............................................................................17
2.2. Batteries......................................................................................................18
2.2.1. Install/Replace External Battery.......................................................18
2.2.2. Install/Replace Internal Battery ........................................................20
2.2.3. Instructions for Rechargeable Battery Pack.....................................22
2.3. Install SIM Card...........................................................................................24
2.4. Install Hand Strap........................................................................................26
2.5. Install Shoulder Strap (Optional).................................................................27
2.6. Install Neck Strap (Optional) .......................................................................28
2.7. Desktop Cradle (Optional)...........................................................................29
2.7.2. Specications...................................................................................29
2.7.4. Seat the Computer...........................................................................31
Contents

- iv -
Contents
2.7.5. Network with Other Devices.............................................................33
2.8. Dual-Bay External Battery Charger (Optional)............................................34
2.8.1. Overview ..........................................................................................34
2.8.2. Dimensions ......................................................................................35
2.8.3. Specications...................................................................................36
2.8.4. Charge Batteries ..............................................................................37
2.8.5. Status LED.......................................................................................38
2.9. VESA-Mount Bracket (Optional) .................................................................39
2.8.1. Overview ..........................................................................................39
2.8.2. Install................................................................................................39
2.10. VESA-75 to VESA-100 Adapter (Optional) ...............................................41
2.11. Driver Installation.......................................................................................42
2.11.1. Installation Sequence .....................................................................42
2.11.2. Start to Install .................................................................................43
2.11.3. Install Chipset Driver ......................................................................45
2.11.4. Install Graphics Driver ....................................................................46
2.11.5. Install Audio Driver .........................................................................46
2.11.6. Install Touch Screen Driver ............................................................47
2.11.7. Install Function-Keys Driver ...........................................................48
2.11.8. Install WiFi Driver ...........................................................................49
2.11.9. Install Bluetooth Driver ...................................................................50
2.11.10. Install 3G Driver & Utility (Congure-to-Order).............................51
2.11.11. Install Cradle LAN Driver (Optional) .............................................52
2.11.12. Install RFID Reader Driver (Congure-to-Order)..........................54
2.11.12.1. Program Your Own RFID Application .............................55
2.11.13. Install Smart Card Reader Driver (Congure-to-Order)................56
2.11.14. Install RS232 Driver (Congure-to-Order)....................................57
2.11.15. Install GPS Driver & Utility (Congure-to-Order) ..........................58
Chapter 3 - Use the Computer...................................................................59
3.1. Use Touch Screen.......................................................................................60
3.1.1. Resistive Touch ................................................................................60
3.1.2. Projected Capacitive Touch..............................................................60
3.1.3. Text Input..........................................................................................61
3.1.3.1 Onscreen Keyboard .............................................................61
3.1.3.2. Handwriting Recognition .....................................................62
3.2. Use (Physical) Function Keys .....................................................................63
3.3. Use Wi-Fi ....................................................................................................64
3.4. Use Bluetooth..............................................................................................66
3.4.1. Launch Bluetooth .............................................................................66
3.4.2. Bluetooth Device Name ...................................................................67
3.4.3. Hide/Expose Computer....................................................................67
3.4.4. Pair/Connect with Other Bluetooth Devices.....................................69
3.5. Use Camera (Congure-to-Order) ..............................................................71
3.5.1. Launch Camera................................................................................71

- v -
Contents
3.5.2. Take A Picture ..................................................................................72
3.5.3. Shoot A Video...................................................................................72
3.5.4. Congure Video Shooting ................................................................73
3.6. Use 3.75G (HSUPA) (Congure-to-Order)..................................................74
3.7. Use GPS (Congure-to-Order)....................................................................76
3.8. Use RFID Reader (Congure-to-Order)......................................................81
3.9. Use Barcode Scanner (Congure-to-Order) ...............................................85
3.9.1. Data Capture....................................................................................85
3.9.2. Supported Symbologies...................................................................87
Chapter 4 - Utilities.....................................................................................89
4.1. ARBOR System Suite .................................................................................90
4.1.1. Launch ARBOR System Suite..........................................................90
4.1.2. Use ARBOR System Suite...............................................................91
4.1.3. Customize Function Keys ................................................................94
4.2. PenMount Utilities (Resistive Touch Only) ..................................................95
4.2.1. PenMount Control Panel..................................................................95
4.2.1.1. Launch PenMount Control Panel ........................................95
4.2.1.2. Device tabbed page ............................................................97
4.2.1.3. Tools tabbed page.............................................................103
4.2.1.4. About tabbed page............................................................105
4.2.2. PenMount Gesture.........................................................................106
4.2.2.1. Launch PenMount Gesture ...............................................106
Chapter 5 - BIOS....................................................................................... 111
5.1. BIOS Main Setup ......................................................................................112
5.2. Advanced Settings ....................................................................................114
5.2.1. IDE Conguration...........................................................................115
5.3. Boot Settings.............................................................................................116
5.3.1. Boot Settings Conguration ...........................................................117
5.3.2. Boot Device Priority........................................................................118
5.3.3. Hard Disk Drives ............................................................................119
5.4. Security .....................................................................................................120
5.5. Exit Options...............................................................................................122

- vi -
Preface
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in order to
improve the reliability, design and function. It does not represent a commitment on the
part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect, special,
incidental, or consequential damages arising from the use or inability to use the product
or documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the directives of the
Union European (EU). A Certicate of Compliance is available by contacting Technical
Support.
This product has passed the CE test for environmental specications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from ARBOR. Please contact your local supplier for ordering
information.
FCC Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
Preface

- vii -
Preface
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
RoHS
ARBOR Technology Corp. certies that all components in its products are in compliance
and conform to the European Union’s Restriction of Use of Hazardous Substances in
Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose of
the directive is to prohibit the use of lead, mercury, cadmium, hexavalent chromium,
polybrominated biphenyls (PBB), and polybrominated diphenyl ethers (PBDE) in electrical
and electronic products. Member states of the EU are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a
maximum concentration value of 0.1% by weight or for cadmium exceed 0.01% by
weight, per homogenous material. Homogenous material is dened as a substance or
mixture of substances with uniform composition (such as solders, resins, plating, etc.).
Lead-free solder is used for all terminations (Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the earth we live,
Arbor hereby conrms all products comply with the restriction of SVHC (Substances of
Very High Concern) in (EC) 1907/2006 (REACH --Registration, Evaluation, Authorization,
and Restriction of Chemicals) regulated by the European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)
Important Safety Instructions
Read these safety instructions carefully:
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall
may cause damage.
3. Make sure the correct voltage is connected to the equipment.
4. For pluggable equipment, the socket outlet should be near the equipment and should
be easily accessible.
5. Keep this equipment away from humidity.
6. Disconnect this equipment from the A/C outlet before cleaning it. Use a moist cloth.
Do not use liquid or sprayed detergent for cleaning.
7. To fully disengage the power to the unit, please disconnect the power from the AC
outlet.
8. Do not scratch or rub the screen with a hard object.
9. Never use any of the solvents, such as Thinner Spray-type cleaner, Wax, Benzene,
Abrasive cleaner, Acid or Alkaline solvent, on the display. Harsh chemicals may
cause damage to the cabinet and the touch sensor.

- viii -
Preface
10. Remove dirt with a lightly moistened cloth and a mild solvent detergent. Then wipe
the cabinet with a soft dry cloth.
11. The openings on the enclosure are for air convection and protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
12. Position the power cord so that people cannot step on it. Do not place anything over
the power cord.
13. If the equipment will not be used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
14. Never pour any liquid into openings. This may cause re or electrical shock.
15. Never open the equipment. For safety reasons, the equipment should be opened
only by qualied service personnel.
16. If one of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to the
user’s manual.
e. The equipment has been dropped or damaged.
f. The equipment has obvious signs of breakage.
17. The sound pressure level at the operator’s position, according to IEC 704-1:1982, is
no more than 70dB(A).
18. Keep this User’s Manual for later reference.
19. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED ENVIRONMENT
WHERE THE STORAGE TEMPERATURE IS BELOW -20° C (-4° F) OR ABOVE
60° C (140° F). THIS MAY DAMAGE THE EQUIPMENT.
Warning
Any changes or modications not expressly approved by the guarantee of this device
could void the user’s authority to operate the equipment.
General Cleaning Tips
You may need the following precautions before you begin to clean the device. When you
clean any single part or component for the device, please thoroughly read and understand
the details below.
1. We strongly recommended that you should shut down the system before you start to
clean any single components.
2. When you need to clean the device, please rub it with a piece of dry cloth.
3. Be cautious of the tiny removable components when you use a vacuum cleaner to
absorb the dirt on the oor.
4. Never drop the components inside the device or get circuit board damp or wet.
5. Be cautious of all kinds of cleaning solvents or chemicals when you use it for the sake
of cleaning. Some individuals may be allergic to the ingredients.
