ARC Technology ALMST-1405 User manual

Version 1.
Overview :
Installation :
Magnetic Switch Transmitter
1. Use a flat head screwdriver to inert Cover locker then remove front covers of magnetic
and transmitter ( Fig 1 ), ( Fig 2 )
2. Secure “Back plates” of magnetic and transmitter to desired locations, like window or door either by
using screws ( Fig 3 ) or double glue sticker ( Fig 4 ) to fix back plates to frame of window or door.
illustration with ( Fig 5 ) and ( Fig 6 ).
Fig1 Fig2 Fig3 Fig4
Window / Door Detector
ALMST-1405
LED

Version 1.
Fig5 Fig6
Pairing :
Pair Magnetic Switch Transmitter (ALMST ) with Siren.
1. Place battery into compartment of MST. Pay attention on direction of battery polarity.
2. Press and hold Siren Learn button about 3 seconds till LED will is slowly blinking to confirm in Learn
mode. Learn mode will be lasting 12 seconds then exit automatically.
3. Using small tool to press and hold ALMST “ SET “ button about 3 seconds while Siren in Lean mode
to pair ALMST with Siren.ALMST and Siren’s LED will be quickly blinking 5 times to confirm paired
successfully.
Enter Learn Mode Press and hold Set for 3 seonds
Test function of ALMST with Siren,
Enter test mode
1 : Short press “ Set “ button one time. ALMST LED will be slowly blinkingg.
2 : Place Magnetic together with Switch Transmitter then apart magnetic from Switch
transmitter more than 1cm, Siren LED will be alarm flashing two times accompany two alert
sounds.
3 : Place magnetic together with Switch Transmitter again, Siren will be alarm flashing one time
accompany an alert sound.
4 : Repeat procedure 1 and 2 for more than two times to confirm it is working with Siren.
Short press “ Set “ again will stop alarm flashing and exit test mode immediately. Test mode will
expire automatically after 20 seconds .

Version 1.
Short Press Set Place together Apart Flash &
Alert
>1cm
Un-Pairing :
Un-pairing Magnetic Switch Transmitter (ALMST) from Siren.
Press and hold Siren “Learn” button 3 seconds to enter Learn mode, press and hold ALMST “ DEL”
button about 3 seconds to un-pair ALMST from Siren. Both Siren and MST LED will be quickly
blinking 5 times to confirm successfully un-pairing.
Enter Learn Mode Press and hold DELfor 3 seconds
Delete ALMST all Pairs.
Pressandhold“DEL”buttonabout3secondstillLEDisblinkingtoconfirminDeletemode.
Releasethepressing,thenpress“DEL”buttonagainformorethan6secondstillLEDquickblinking,
Releasethepressing,thenshortpress“DEL”buttonagaintodeleteallpairs.ALMSTLEDwillbequickly
blinking5timestoconfirmsuccessfullydeleteallpairs.
Enter Delete Mode Release Press and hold Del Release Short Press
for 6 seconds
Important Notice:
Siren’s all parings must be deleted at the same time once ALMST all pairings be deleted. Please refer
to delete Siren all pairings procedure to delete Siren all pairings after ALMST all pairings be deleted.

Version 1.
Operation :
Arm :
Press and hold ALKCT “Arm” button more than 1 second to enable siren enter Arm mode. ALCKT red LED
will Lights ON for 1.5 second to confirm in Arm mode.ALCKT LED will be quick blinking for three times
if fail to
enter Arm mode. Repeat pressing ALKCT Arm button to ensure Siren to enter Arm mode. Siren will be ready
for operation 75 seconds later after Siren entering into Arm mode.
Disarm:
Press and hold ALKCT Disarm button more than 1 second to disable siren arm mode, ALCKT red will lights
ON for 1.5 second to confirm exist arm mode. ALCKT LED will be quick blinking for three times if fail to
exit Arm mode. Repeat pressing ALKCT “Disarm” button to ensure Siren exist Arm mode.
Arm Disarm
Active and Inactive Siren:
1. Set Siren entering “Arm” mode and wait for 75 seconds.
2. Open door or window, MST will trigger Siren start alarming alert sound accompany flashing light, the
alert alarm sound will be last for 4 minutes. To stop alert alarm sound press Disarm button again.

Version 1.
Low Battery.
LED will be blinking 3 times every 6 seconds to indicator battery is low battery. LED will be blinking
for about 7 days. However, it is recommended to replace with new battery immediately.
Technical Specification
Magnetic Switch Transmitter ( MST ) item number : ALMST-1405
Radio frequency : 868.3 Mhz FSK two ways communication
Operation voltage : 3V DC
Communication distance : min.120M (Straight line open area)
Battery : AAA 1.5 V x 2 pcs
Battery Life : 18 months
Battery low indicator : LED indicator
Dimension : 103.5 x 20.5 x 25.5 mm ( L x W x H)
