RB23
STDOPT
FITTING NOTICE
AUTOMATIC RECLOSERwith Mains Fault alarm
Option Battery State and Counter
A.R.C. 15 rue Buisson aux Fraises –ZI la Bonde - F-91741 Massy CEDEX
Tel : [phone] - Fax : [phone] - E-mail : [e-mail]
CIRCUIT DIAGRAM
MAINS
Surge
Protection
Device
Circuit Breaker
With Differential Protection
LOAD
PROTEC
RB23
2
Lead and Neutral (220 VAC)
Assembly
1. Fixthe reinforcement system on the initial support (e.g. Merlin-
Gérin orLegrand)
2. Fixthe circuit breakeron it
3. FixtheAutomatic Recloser (caution : take care to the small blade,
placeit correctlyon the blackpush button of the CB)
4. Adjust the screw
5. The system must beon vertical standing to correctly work
Alarm Output
1 2 3 5 6 7 84
Alarms
Output
Remote
Controls
The alarm output are set on "positive security" by opening of the contact.
The alarmsare activatedin these cases :
4-5 : Système = Numberofattempts reached, System Out of Service,
Locking Remote control activated when the Recloser tries to close the CB
4-6 : Amont = CB closed, No voltage Downstream (mainsabsence)
4-7 : Aval = CB opened, No Voltage Downstream (CB tripping)
4-8 : Def Bat = BatteryVoltage Low
Remote Control
1-2 : Enclenchement = An impulse causesan attempt to close the CBaftera delayof 2 seconds
(Like the ResetPushbutton)
1-3 : Déclenchement = An impulse causes an opening of the CBif the optional module ispresent
Verrouillage = Amaintained closed state locksthe Recloserand preventsany reset
Indicators / Pushbuttons
CHARGE : Lit if thedownstream mains ispresent (batterycharge is effective)
ON : Lit except in "OUT OF SERVICE"mode orin waking state
DEFAUT(1) : Lit = blocked bya permanent fault orbatterylow detection
: flickering =the 5 attemptson transient faultsare reached
BATTERIE : Lit with progressive extinction according to the battery load
TEST RAZ : Reset the system; if necessary, the Reclosermakesan attempt aftera 2 seconds delay
RAZ COMPT : Reset the attempts counter if this optional module is present
Security
Interrupter
IN/OUT SERVICE
Attempts
Counter
(Option)
BatteryTest Points
Protect
ion
Module
"PROTEC"
CHARGEindicator(GREEN)
ON Indicator (GREEN)
FAULT Indicator(RED)
ScrewAdjust
General Reset
R
e
set
Counter
Delays
:
8s
,
2, 10, 20, 30 and 45mn,
1h45, 2h30, 3hand 10h
Small Blade
CB opening detection
BatteryCharge
Indicator (Blue)

[phone]
RB23
STDOPT
FITTING NOTICE
AUTOMATIC RECLOSERwith Mains Fault alarm
Option Battery State and Counter
A.R.C. 15 rue Buisson aux Fraises –ZI la Bonde - F-91741 Massy CEDEX
Tel : [phone] - Fax : [phone] - E-mail : [e-mail]
Installation
Proceed to themechanical assembly and connect the wires
Set the Interrupteron "ENSERVICE" position
Mains Present : indicators"CHARGE" and "ENSERVICE" lit.The Recloseris readyto work
Mains Absent : indicator"CHARGE " off, "ENSERVICE"lit and "DEFAUT" Flickering;
Proceed on the pushbutton"TEST RAZ" toreset the Recloser
Tests
In all that follows, the Recloseris"ENSERVICE" and in Vertical standing
Manual Test:
Open the CB
Press the pushbutton "TEST RAZ",The Reclosermakesan attempt after a2 secondsdelay
Test onTransient Fault :
Open the CB
Aftera delay (e.g. 8 seconds), the CB isclosed
Wait about approximately 5 seconds and tryagain the2 pointsabove several times
At the 6th opening, the Reclosermust be blocked and the indicator "DEFAUT" flicks
Press the pushbutton "TEST RAZ", the CB is reclosed aftera 2 secondsdelay
Test onPermanent Fault:
Open the CB
When the Reclosermakesitsattempt,open again the CB, the Recloserblocksand the indicator"DEFAUT" lit
Press the pushbutton "TEST RAZ", the CB is reclosed aftera 2 secondsdelay
Battery : Charge,Test, Access and Maintenance
Charge : the battery ischargedif the DownstreamMains ispresent (indicator"CHARGE" lit). In the event of
completedischarge, let the Recloser charge it at least 30 hours.
Test : The best test isto open the CB; we advise with each visit of the site to open the CB. However an alarm will
appear when the voltage fallsinlowerpart ofa predetermined threshold.The usercan check the batteryvoltage
without disassembling by connecting a multimeterto the2 test pointson the front face
Access : To change the Battery, set the Recloser on "HORS SERVICE", withdrawthe PROTECmodule (no more
mainson the system)and open the trap doorunderthe PROTEC;disconnect the Batteryand changeit
Maintenance : The Average lifespan of the battery is 8years; a label on it specifies its date of manufacture (ARC Battery
guarantee is 4 years)
Faults
Upstream Fault: (no UpstreamMains) the Recloserdoesnot react and awaits possible tripping
TransientFault: The Reclosermakes5 attemptsand blocksat the 6th fault
Automatic Reset: Mainspresence on downstream CB during more than 3minutesmakes an automatic reset of the
attemptsnumber. The 5 attemptsare again authorized.
Permanent Fault : only one attempt is authorized before declaring afault
CAUTION : WAKING STATE
After an inactivity of 15mn, the Recloser passes in "waking state". The indicators "EN SERVICE" and "DEFAUT" are off. The
consumption is now lower than 100µA –Press one time on "TEST RAZ" pushbutton to light the indicator. A second press on the
pushbutton causes a general reset of the Recloser
Maintenance Advises
PROTEC2000 : Thismodule isa over voltage protection up to 20kV. In the event of amalfunction, the green
indicator"CHARGE" isunlighted.
BATTERY : Checkthe battery voltage (13 to 14VDC)on the test points
Do not hesitate to call ourtechnical departmentat the phone numberbelow
FeaturesAlarmsoutputs: Dry Contact 60V-50mA Supply: 220 VAC–50/60Hz
Remote Control : Auto-supplied 12VDC Consumption : 8mA /100µA
H / W/ D: 214 / 80 / 91mm H / W/ Dwith opening
module : 214 / 95 / 97mm
