Arcam DiVA CD62 User manual

CD62HANDBOOK
Arcam CD62 Compact Disc player

CD62
2
CD62
2
Safety guidelines
Safety instructions
This product is designed and manufactured to meet strict
quality and safety standards. However, you should be aware of
the following installation and operation precautions:
1. Take heed of warnings and instructions
You should read all the safety and operating instructions
before operating this appliance. Retain this handbook for future
reference and adhere to all warnings in the handbook or on
the appliance.
2. Water and moisture
The presence of electricity near water can be dangerous. Do
not use the appliance near water – for example next to a
bathtub, washbowl, kitchen sink, in a wet basement or near a
swimming pool, etc..
3. Object or liquid entry
Take care that objects do not fall and liquids are not spilled into
the enclosure through any openings. Liquid filled objects such
as vases should not be placed on the equipment.
4. Ventilation
Do not place the equipment on a bed, sofa, rug or similar
soft surface, or in an enclosed bookcase or cabinet, since
ventilation may be impeded. We recommend a minimum
distance of 50mm (2 inches) around the sides and top of the
appliance to provide adequate ventilation.
5. Heat
Locate the appliance away from naked flames or heat
producing equipment such as radiators, stoves or other
appliances (including other amplifiers) that produce heat.
6. Climate
The appliance has been designed for use in moderate climates.
7. Racks and stands
Only use a rack or stand that is recommended for use with
audio equipment. If the equipment is on a portable rack it
should be moved with great care, to avoid overturning the
combination.
8. Cleaning
Unplug the unit from the mains supply before cleaning.
The case should normally only require a wipe with a soft, damp,
lint-free cloth. Do not use paint thinners or other chemical
solvents for cleaning.
We do not advise the use of furniture cleaning sprays or
polishes as they can cause indelible white marks if the unit is
subsequently wiped with a damp cloth.
9. Power sources
Only connect the appliance to a power supply of the type
described in the operating instructions or as marked on the
appliance.
10. Power-cord protection
Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against
them, paying particular attention to cords and plugs, and the
point where they exit from the appliance.
11. Grounding
Ensure that the grounding means of the appliance is not
defeated.
12. Power lines
Locate any outdoor antenna/aerial away from power lines.
13. Non-use periods
If the unit has a standby function, a small amount of current will
continue to flow into the equipment in this mode. Unplug the
power cord of the appliance from the outlet if left unused for
a long period of time.
14. Abnormal smell
If an abnormal smell or smoke is detected from the appliance,
turn the power off immediately and unplug the unit from the wall
outlet. Contact your dealer immediately.
15. Servicing
You should not attempt to service the appliance beyond that
described in this handbook. All other servicing should be
referred to qualified service personnel.
16. Damage requiring service
The appliance should be serviced by qualified service personnel
when:
A. the power-supply cord or the plug has been damaged, or
B. objects have fallen, or liquid has spilled into the
appliance, or
C. the appliance has been exposed to rain, or
D. the appliance does not appear to operate normally or
exhibits a marked change in performance, or
E. the appliance has been dropped or the enclosure
damaged.
Safety compliance
This product has been designed to meet the EN60065
international electrical safety standard.

CD62
3
Using this handbook
Contents
Safety guidelines 2
Safety instructions 2
Safety compliance 2
Using this handbook 3
Safety 3
Models covered 3
Installation 4
Positioning the unit 4
Connecting to other equipment 4
Connecting to a power supply 4
CD62 rear panel 4
Using your CD player 5
CDs with text 5
Using the CR224 remote control 6
Technical specification 7
Guarantee 8
On-line registration 8
This handbook has been designed to give you all the
information you need to install, connect, set up and use the
Arcam CD62 compact disc player. The CR224 remote control
handset supplied with this equipment is also described, as it
applies to operating the CD62.
Note that this product is not upgradeable to a CD72, CD92, or
any other model in the Arcam range.
Safety
Safety guidelines are set out on the inside front cover of this
handbook.
Many of these items are common sense precautions, but for
your own safety, and to ensure that you do not damage the unit,
we strongly recommend that you read them.

CD62
4
Installation
Positioning the unit
Always place the CD player on a level, firm surface. Placing
your player on a set of dedicated sorbothane isolation feet
will isolate the unit from its surroundings as well as absorbing
the vibrations created within the player itself. You will generally
hear some sonic improvements, which makes this an extremely
cost-effective upgrade.
Connecting to other equipment
Interconnect cables
Interconnecting cables are not supplied with this CD player. We
recommend high quality cables as inferior quality cables will
degrade the sound quality of your system. Please contact your
Arcam dealer for details of suitable cables.
Audio outputs
Connect these to your amplifier’s CD or any other line-level
input using suitable high quality interconnect cables. Ensure
that the left and right audio outputs from the CD player are
connected to the same left and right inputs on your amplifier.
Coaxial digital output
Use this socket if you are using a separate digital to analogue
converter (DAC) or digital recorder. Connect to the DAC or
recorder’s digital input using a suitable 75Ωscreened cable.
CAUTION: Never connect the digital output socket to a
conventional audio input.
Optical digital output
Use this socket if you are using a separate DAC or digital
recorder with an optical connection. Connect using a suitable
optical cable.
Remote input
It is not necessary to make any connection to this socket in
normal use. The connection is for ease of installation to multi-
room remote control systems and is suitable for modulated
IR commands. Contact your multi-room installer for more
information.
Connecting to a power supply
Wrong plug?
Check that the plug supplied with the unit fits your supply and
that your mains supply voltage agrees with the voltage setting
(120V or 230V) indicated on the rear panel of the unit.
If your mains supply voltage or mains plug is different, consult
your Arcam dealer or Arcam Customer Support on +44
(0)1223 203203.
Mains lead
The appliance is normally supplied with a moulded mains plug
already fitted to the lead. If for any reason the plug needs to
be removed, it must be disposed of immediately and securely,
as it is a potential shock hazard when inserted into the mains
socket. Should you require a new mains lead, contact your
Arcam dealer.
Plugging in
Push the plug (IEC line socket) of the power cable supplied with
the unit into the socket (POWER INLET) in the back of the unit.
Make sure it is pushed in firmly.
Put the plug on the other end of the cable into your power
supply socket and switch the socket on.
POWER INLET
230V
2143
REMOTE
IN
AUDIO OUTPUT
R L
CO-AXIAL OPTICAL
DIGITAL OUTPUTS
5
CD62 rear panel (part)
1Power inlet, with voltage indicator
2Coaxial digital output
3Optical digital output
4Single audio output
5Remote input

CD62
5
Using your CD player
POWER 1
Press this button to switch the CD player on and off. When first
powered up with no CD installed the display shows:
--NO DISC--
LOAD 2
To install a CD, press LOAD (or OPEN on the remote control).
The CD tray opens –it accepts 12cm and 8cm discs. Place
the CD in the tray with the label facing uppermost. Press LOAD
again (or press PLAY, or gently push the tray in 5mm) to close
the tray. You will see the total number of tracks and total disc
time, for example…
8 52.19
TRACK INDEX MIN SEC
112345
678
The display returns to ‘0’after a few seconds. The disc is now
ready to play.
PLAY 3
Press to play the CD. To restart from track 1, press STOP and
then PLAY.
Make sure your amplifier’s input source selector is set to the
correct input.
STOP 4
Press to stop the CD playing. The display shows ‘0’and the
number of tracks.
PAUSE 5
Press to pause the disc (interrupt play).
Press PAUSE again, or PLAY to resume play from the same
point.
SEARCH 6
Press to search backwards, or to search forwards
for a particular passage within the currently playing track. If the
player is in ‘PAUSE’mode the search is made at high speed
with the sound muted.
SKIP TRACK 7
To start a CD with a track other than the first, press or
to locate the desired track.
To select another track during play, press or . The
track is played automatically after selection. Pressing once
returns to the start of the current track. To select the previous
track, press twice quickly. To go back two tracks, press
three times, and so on.
CDs with text
Load
You will see the total number of tracks and the total disc time
with ‘CD TEXT’illuminated in the display. The artist and album
title scrolls across the display before returning to show the
artist and total number of tracks.
ANASTACIA
TRACK INDEX MIN SEC
CD TEXT
12345
678910
11 12
Play
The track number is briefly displayed, followed by the track title
scrolling across the display. The display returns to showing the
track number and time.
Track selection
When a new track is selected, the track number is briefly
displayed, followed by the track title scrolling across the
display. The display returns to showing the track number and
time.
POWER
COMPACT DISC PLAYER
TRACK
PAUSESTOPPLAYLOAD
71 65324
CD62
24 BIT DAC
NOTE: The track title is always displayed when a track is
selected, either for playing or programming.
The artist is always displayed when the disc is stopped.
The TIME button turns the text display off.
The text display supports English only.

CD62
6
Using the CR224 remote control
DISP (Display)
Turns the display on or off. Turning the display off generally
produces a slight improvement in sound quality.
A–B
This button enables you to repeat any section of music
within a track. Whilst the disc is playing, press the A–B
button at the start of the section you wish to repeat.
‘REPEAT’is shown on the display and the letter ‘A–’ flashes.
Press the button a second time when you reach the end
of the section you wish to repeat. The ‘A–B’letters stop
flashing and remain lit. This section will repeat until you
press or or . The forward search button ( )
moves forward within the selected loop.
REPEAT
To repeat the entire CD or a pre-programmed selection of
tracks press REPEAT once: ‘REPEAT’lights on the display.
To repeat a particular track, select that track and then press
REPEAT twice so that ‘REPEAT 1’is shown on the display. If
you now select a different track, that track is repeated
instead.
To cancel the repeat function press REPEAT a third time.
TIME
Press TIME once to display the remaining time of
the currently playing track. Press again to display the
time remaining on the disc. Press a third time to
turn the text display on.
Press TIME again and the display reverts to its original
setting, showing the time elapsed for the current track.
For CDs with text, pressing TIME once while the disc
is loaded but not playing displays the artist’s name.
Pressing TIME a second time displays the total number of
tracks and the total playing time.
0–9 keypad
This allows direct access to individual tracks on the disc.
To select a track, press the corresponding keypad button.
For tracks greater than 9, enter the digits in sequence. For
example, to play track 15, press and hold 1until the number
on the display moves to the left, then press 5.
PROG (Program)
You can program a selection of up to 24 tracks from a disc
to play in any order. Select a track by using the and
buttons, then press PROG to program the track into memory
(‘PROGRAM’appears on the display to indicate that you have
started programming a sequence). Repeat these steps to
program the remaining tracks in your selection. Alternatively,
press PROG once and enter your track selection using the
0–9 keypad.
The display shows the track numbers programmed, the total
length of the programmed sequence and the number of tracks
programmed (shown by a number below the word ‘STEP’).
Each time you enter a track the number below ‘STEP’
increments by one and flashes until you press PROG to confirm.
If you fail to press PROG within about five seconds the display
stops flashing and you will have to reselect the track.
Press to play the program. Press again to replay the entire
sequence from the start. Press and hold CLEAR to erase the
programmed sequence. Press PROG again to exit the program
facility: the display flashes ‘CONTINUE’and shows ‘0’.
MUTE
Stops sound to the speaker outputs of certain Arcam
amplifiers.
VOL (Volume) +/–
Adjusts the volume on Arcam remote-controllable amplifiers.
Note that the volume (+/–) controls and MUTE button have
no effect on the audio output level of the CD players.
NOTE: Remember to install the two AAA batteries
supplied before trying to use your remote control.
Do not place anything in front of the display area on
the CD player (where the IR receiver is located), or the
remote control may not work.
OPEN
Opens and closes the CD tray.
Skip and Search Track
Skip track backwards and forwards;
Search backwards and forwards (see page 5)
Playback control
Play, Stop and Pause (see page 5).
SHUFFLE
Press once to shuffle play CD tracks (i.e. play them in
a random order). Press again to cancel shuffle play.
Source selection
These operate in the same way as the source selector
on the front panel of an Arcam integrated amplifier.

CD62
7
Digital to Analogue conversion
24-bit multilevel Delta-Sigma DAC
Laser pick-up 3 beam
Laser wavelength 780nm
Numerical aperture 0.45
Dynamic range 106dB
Signal to noise ratio (CCIR) >100dB
Harmonic distortion (0dB, 1kHz) <0.005%
Frequency response (±0.5dB) 5Hz–20kHz
Output level (0dB) 2.3Vrms
Output impedance 120Ω
Minimum recommended load 5kΩ
Technical specification
Physical
Dimensions W430 x D290 x H84mm
Weight 4.6kg nett/6.1kg packe
Power consumption 32VA maximum
Digital output connection 75Ωco-axial
optical TOSLINK
Supplied accessories
Mains lead
CR224 remote control
2 x AAA batteries
E&OE
Continual improvement policy
Arcam has a policy of continual improvement for its products.
This means that designs and specifications are subject to
change without notice.
Radio interference
The CD62 is a digital audio device which has been designed to
very high standards of electromagnetic compatibility.
The CD player and DAC generate, and can radiate RF (radio
frequency) energy. In some cases this can cause interference
with FM and AM radio reception. If this is the case, keep the CD
player and its connecting cables as far from the tuner and its
aerials as possible. Connecting the CD player and the tuner to
different mains sockets can also help to reduce interference.
EC COUNTRIES -–This product has been designed to comply
with directive 89/336/EEC.
USA –This product complies with FCC requirements.
Laser radiation
If an Arcam CD player is operated whilst the outer casing is
removed, invisible laser radiation could cause eye damage.
NOTE: All specification values are typical unless otherwise
stated.

Worldwide Guarantee
This entitles you to have the unit repaired free of charge, during
the first two years after purchase, at any authorised Arcam
distributor provided that it was originally purchased from
an authorised Arcam dealer or distributor. The manufacturer
can take no responsibility for defects arising from accident,
misuse, abuse, wear and tear, neglect or through unauthorised
adjustment and/or repair, neither can they accept responsibility
for damage or loss occurring during transit to or from the
person claiming under the guarantee.
The warranty covers:
Parts and labour costs for two years from the purchase date.
After two years you must pay for both parts and labour costs.
The warranty does not cover transportation costs at any time.
Claims under guarantee
This equipment should be packed in the original packing
and returned to the dealer from whom it was purchased, or
failing this, directly to the Arcam distributor in the country of
residence.
It should be sent carriage prepaid by a reputable carrier -–
NOT by post. No responsibility can be accepted for the unit
whilst in transit to the dealer or distributor and customers are
therefore advised to insure the unit against loss or damage
whilst in transit.
For further details contact Arcam at:
Arcam Customer Support Department,
Pembroke Avenue, Waterbeach, CAMBRIDGE
CB5 9PB, England.
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Problems?
Always contact your dealer in the first instance.
If your dealer is unable to answer any query regarding this
or any other Arcam product please contact Arcam Customer
Support on [phone] or write to us at the above
address and we will do our best to help you.
Guarantee
On-line registration
You can register your Arcam product on line at:
www.arcam.co.uk/reg
PEMBROKE AVENUE, WATERBEACH, CAMBRIDGE CB5 9PB, ENGLAND
telephone [phone] fax [phone] email [email protected] website www.arcam.co.uk
SH114Issue 1
