Please read this manual first!
Dear Valued Customer,
Thank you for preferring this Arçelik appliance. We hope that you get the
best results from your appliance which has been manufactured with high
qual-ity and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully
before using the appliance and keep it as a reference for future use. If you
handover the appli-ance to someone else, give the user manual as well.
Follow the instructions by paying attention to all the information and
warnings in the user manual.
Meanings of the symbols
Following symbols are used in various sections of this user manual:
C
Important information and useful
hints about usage.
A
WARNING: Warnings against dan-
gerous situations concerning the
security of life and property.

Coffee Machine / User Manual 3 / EN
CONTENT
ENGLISH 4-22

Coffee Machine / User Manual
4 / EN
Ths secton contans safety nstructons that wll help
protect from rsk of personal njury or property damage.
Falure to follow these nstructons wll vod all types of
warranty.
1.1 General safety
• Ths applance comples wth the nternatonal safety
standards.
• Do not use the applance outdoors and n the
bathroom.
• No responsblty or warranty clam shall be assumed
for damages arsng from msuse or mproper handlng
of the applance.
• Never attempt to dsmantle or separate the mounted
parts of the applance.
• Only use the orgnal parts or parts recommended by
the manufacturer.
• Always use the applance on a stable, flat, clean, dry
and non-slp surface.
• Do not start to cook coffee wthout puttng water
nto the cookng pot.
1 Important safety and envronmental
nstructons

Coffee Machine / User Manual 5 / EN
1 Important safety and envronmental
nstructons
• Do not put any substances apart from coffee, sugar
and nto the cookng pot.
• Coffee Machne s desgned to operate at 4-37°C
80% relatve humdty.
• Do not drnk the Greek cooked coffee usng the
cookng pot.
• Due to the manufacturng technology, steam and
odour may arse n the heatng element of the
applance durng the ntal use. Ths s normal. They
wll dsappear after a few cycles.
• Do not move the applance when t s stll hot or when
there s lqud nsde the cookng pot.
• Avod contactng the hot surfaces. Hold the cookng
pot only by ts handle; otherwse there s the rsk of
burnng. Cookng pot gets hot durng cookng.
• The base (heatng surface) on whch the cookng pot
s placed gets hot durng operaton. Therefore, do not
touch ths area whle usng and untl the applance
gets cold.
• Ensure that the applance s swtched off before
movng t.

Coffee Machine / User Manual
6 / EN
• For addtonal protecton, ths applance should be
connected to a household resdual current crcut
breaker of maxmum 30 mA.
• Connect the applance to a grounded outlet protected
by a 16 ampere fuse.
• Do not use t f the power cable or the applance tself
s damaged.
• Do not use the applance wth an extenson cord.
• Dry the seat of cookng pot before pluggng n the
applance and seatng the parts.
• Do not mmerse the applance, power cord, or power
plug n water or any other lquds.
• Do not touch the applance or ts plug wth damp or
wet hands.
• Poston the applance n such a way that the plug s
always accessble.
• Prevent damage to the power cable by not squeezng,
bendng, or rubbng t on sharp edges. Keep the power
cable away from hot surfaces and naked flame.
1 Important safety and envronmental
nstructons

Coffee Machine / User Manual 7 / EN
• Make sure that there s no danger that the power
cord could be accdentally pulled or that someone
could trp over t when the applance s n use.
• Unplug the applance f any falure occurs.
• Unplug the applance before cleanng t and never
clean t when t s n use.
• Do not pull the power cable of the applance to unplug
the applance from the outlet and do not wrap ts
power cable around the applance.
• Your mans power supply should comply wth the
nformaton suppled on the ratng plate of the
applance.
• Do not use the applance n or near places where
combustble or nflammable places or materals are
present.
• Do not use the applance next or close to heat
resources (hob, grll, heater core, stove etc.).
• Keep the applance away from steam resources and
avod usng t n envronments contanng excessve
steam.
1 Important safety and envronmental
nstructons

Coffee Machine / User Manual
8 / EN
• Do not use the cookng pot wth any other heater
(hob and etc.) apart from the applance.
• The applance s desgned to be used n homes, the
ktchens of the employees at offces, stores and other
workng envronments, and n the guest rooms at the
hotels, motels and other accommodaton places. Ths
applance s not ft for professonal use.
• Do not use the applance for anythng other than ts
n tended use.
• Ths applance can only be used to cook coffee.
• Extreme cauton s advsed when beng used near
chldren and persons who are restrcted n ther
physcal, sensory or mental abltes.
• Ths applance may be used by chldren who are at
the age of 8 or over and the people whose physcal,
perceptve or mental sklls are mpared or who are
nexperenced or not knowledgeable about the
applance as long as they are supervsed or nformed
and made understood the safe use of the applance
and the encountered dangers. Chldren should not
play wth the applance.
1 Important safety and envronmental
nstructons

Coffee Machine / User Manual 9 / EN
• Cleanng and user mantenance procedures should
not be performed by chldren unless they are
controlled by ther elders.
• If you keep the package materal keep t away from
chldren.
• Make sure the applance s kept n a place out of the
reach of chldren.
1.2 Complance wth the WEEE drectve and
dsposal of the waste product
Ths product does not nclude harmful or prohbted materals spe-
cfed n the "Regulaton for Supervson of the Waste Electrc and
Electronc Applances" ssued by the Mnstry of Envronment and
Urbansaton. Ths product conforms to the WEEE regulaton. Ths
product has been manufactured from hgh qualty parts and mate-
rals whch are recyclable and re-usable. For ths reason, do not dspose of
ths product wth the domestc or other types of wastes at the end of ts ser-
vce lfe. Take t to a collecton pont whch s dedcated to recyclng of electrc
and electronc applances. Ask the local authorty n your area for these col-
lecton ponts. Help protect the envronment and natural resources by recy-
clng used products.
1 Important safety and envronmental
nstructons

Coffee Machine / User Manual
10 / EN
1.3 Package nformaton
Package of the product s made of recyclable materals n accor-
dance wth our natonal legslaton. Do not dspose the package
waste wth the domestc wastes or other types of wastes, take
them to the collecton ponts whch are recommended by the local
authortes.
1.4 Plug Wrng
The moulded plug on ths applance ncorporates a 13 A fuse. Should the
fuse need to be replaced an ASTA approved BS1362 fuse of the same ra-
tng must be used. Do not forget to reft the fuse cover. In the event of
losng the fuse cover, the plug must not to be used untl a replacement
fuse cover has been ftted. Colour of the replacement fuse cover must be
the same colour as that vsble on the pn face of the plug Fuse covers are
avalabe from any good electrcal store.
• Fiting a different plug
•As the colours of the wres n the mans lead of ths applance may not
correspond wth the coloured markngs dentfyng the termnals on
your plug, proceed as follows:
•Brown cable = L (Lve)
•Blue cable = N (Neutral)
1 Important safety and envronmental
nstructons

Coffee Machine / User Manual 11 / EN
1 Important safety and envronmental
nstructons
•Green/yellow cable must be connected to ground (E) lne
•Wth the alternatve plugs a 13 A fuse must be ftted ether n the plug
or adaptore or n the man fuse box. If n doubt contact a qualfed elect-
rcan.

Coffee Machine / User Manual
12 / EN
2.1 Overvew
The values which are declared in the markings affixed on your appliance or the other printed documents sup-
plied with it represent the values which were obtained in the laboratories pursuant to the pertinent standards.
These values may vary according to the usage of the appliance and ambient conditions.
2 Your coffee machne
1
2
3
4
5
6
7
8
9
10
11
1. Water tank upper cover
2. Water tank
3. Start button for
1 servng and the status lght
4. Start button for
2 servngs and the status lght
5. Start button for
3 servngs and the status lght
6. Cookng detecton sensor
7. Coffee-makng (cookng) pot
seat
8. Mans cable
9. Heatng surface
10. Coffee measure
11. Coffee-makng pot
2.2 Techncal data
Current: Max 3A
Power: 670 W
Voltage: 220-240 V AC ~, 50 Hz
Cable length: 90 cm
Techncal and desgn modfcaton
rghts are reserved.

13 / EN
Coffee Machine / User Manual
3 Use
3.1 Intal use
C
Read the whole user
manual before usng
the product.
1. Make sure that the applance
stands uprght on a balanced, flat,
clean, dry and non-skd surface.
2. Plug n the applance.
- The applance wll swtch on
automatcally.
3. Remove the water tank ld (1).
4. Fll the water pot wth water up
to the max. level. Dependng on
how you lke t, you can also fll
the water by dsplacng the wa-
ter tank completely as well.
– Repeat the same process after
the applance gves out a water
depleted alarm.
5. Ft the cookng pot n ts place
so that the pump and the wa-
ter system are flled wth water.
Press the coffee-makng button
for 1 servng. Once the water
pumpng process s complete,
press and hold the same button
for 3 seconds to end the process,
and dran the water n the coo-
kng pot.
C
Ths way, proper
operaton of the
pump n the applan-
ce s enabled.
A
WARNING: Repeat
ths process also
after you remove/
place the water tank
from/nto ts place
and before brewng
coffee.
Adjustng the water
amount accordng to
the sze cup
1. Place the cookng pot (11) onto
ts seat (7).
2. Press the coffee-makng button
for 1 servng (3).
3. Once the water pumpng process
s complete, press and hold the
same button for 3 seconds to

14 / EN Coffee Machine / User Manual
end the process and pour the
water n the cookng pot nto
your cup.
4. If the water you have poured
nto your cup s too lttle or too
much, adjust the water amount
as follows.
5. To change the water amount,
take out the cookng pot from ts
seat. Press and hold the coffee-
makng button for two servngs
(4) for 3 seconds to enter the
water adjustment mode.
C
The status lght,
whch comes on
when you enter the
water adjustment
mode, wll show the
water level to whch
the product s set.
6. Once you have entered the
water adjustment mode, press
the button that s approprate
for your cup wthn 3 seconds.
3 Use
The status lght of the button
pressed wll lght n blue for 1
second and the water level wll
change.
-Button for 1 servng: Small cup.
55 ml on average.
-Button for 2 servngs: Medum
szed cup. 65 ml on average.
-Button for 3 servngs: Large
cup. 75 ml on average.
A
WARNING: When
you are n the water
adjustment mode, f
you do not press the
button that s app-
roprate for your cup
wthn 3 seconds, the
product wll ext the
water adjustment
mode and reman n
the old settng.

15 / EN
Coffee Machine / User Manual
3 Use
C
Repeat the water
amount adjustng
process when you
prefer to change the
cup sze.
3.2 Coffee makng
A
WARNING: To ob-
tan a tasty coffee,
make sure that the
nsde of the cookng
pot (11) s dry and
clean.
A
WARNING: Make
sure that there s
enough water n the
water tank (2) .
1. Put coffee and sugar for one,
two or three person(s) nto the
cookng pot (11).
A
WARNING: Make
sure that there are
no water drops un-
derneath the cook-
ing pot (11) when
preparing the cof-
fee. Otherwise, an
annoying noise will
arise when the water
drops get into contact
with the hot base.
2. Place the cookng pot (11) nto ts
seat.
A
WARNING: Fully
nsert the pot back
nto ts seat (7) and
n uprght poston.
Otherwse your pro-
duct wll not operate.
3. Press the start button for 1, 2 or
3 servng(s) accordng to the cof-
fee amount to start the coffee-
makng process.
– You wll hear a beep, ndcatng
that the process has started,
and the status lght (3, 4, 5) wll
lght n red.

Coffee Machine / User Manual
16 / EN
3 Use
C
Cookng tme s 1-1.5
mn. for 1 person. , 1.5-
2.5 mn. for 2 persons
and 2-3.5 mn. for 3
persons.
C
Cookng tme wll
decrease n repettve
cookng as the hea-
tng surface (9) wll
already be hot.
C
For a tasty coffee,
take the cookng pot
(11) from the cookng
pot seat (7) wthout
watng! Watng for
long tme may cause
the foam to collapse
and the grout to sett-
le down.
C
Pour coffee swftly
n order to prevent
foam and grounds
from remanng n the
cookng pot (11).
C
Keep the start coo-
kng button (3, 4, 5)
pressed for 3 sec. to
cancel cookng coffee
for any reason.
4. When the coffee s ready, the
applance wll gve an audo war-
nng and status lght (3, 4, 5) wll
start to flash n red. Once the
status lght has turned whte,
pour your coffee nto the cup and
serve t.
Recommended quantities of ingredients to prepare coffee
Plain With little sugar Medium Sweet
Coffee 1 mea-
sure
1 measure 1 measure 1 measure
Sugar -1/2 cube sugar /
1/2 tea spoon of
granulated sugar
1 cube of sugar
/ 1 tea spoon of
granulated sugar
2 cubes of sugar
/ 2 tea spoons of
granulated sugar
Following quantities are for single serving. You can prepare coffee for max 3
persons.

17 / EN
Coffee Machine / User Manual
A
WARNING: Pay at-
tenton not to stan
the heatng surface
(9). If you drp coffee
onto the heatng
surface, wpe t wth
a lghtly dampened
cloth before t gets
dry.
A
WARNING: Do not
use the cookng
pot on any cookng
applance other than
the Coffee Machne!
(Cooker etc.)
3.3 Amounts
1. Ths s an easy-to-use applance
desgned to make coffee. You
can prepare foamy coffee that
suts to your tastes by usng the
amounts n the table. Followng
quanttes are provded only for
nformaton purposes. You can
adjust them as per your personal
tastes.
2. Use the coffee measure (10)
suppled wth the Coffee Machne
to put coffee. Use fresh coffee
for a tasty and foamy coffee.
3 Use
3.4 Sleep mode
2. If no operaton s performed on
the devce for 3 mnutes, t wll
gve an audo warnng (beep) and
swtch to stand-by mode. When
an operaton s performed (coo-
kng pot s placed/removed onto/
from ts seat or the start button
s pressed) 2 audo warnngs (be-
eps) s gven. Status lght turns
nto whte and the applance
becomes ready to operate.

18 / EN Coffee Machine / User Manual
3 Use
3.5 Notfcatons
Cookng
(steady red lght)
Take out the pot from
ts seat.
Please wat
(Do not take the pot
from ts seat)
Take out the coffee makng
(cookng) pot from ts seat.
Use a damp cloth to clean the
base of the cookng (coffee-
makng) pot, heatng surface
(make sure that the hea-
tng surface s cold) and the
sensor glass.
When the lght turns steady
whte, you can start another
coffee-makng process.
Contact servce f the error
occurs agan.
Swtch off and on the
applance. Contact
servce f the error
occurs agan.
Fll the water pot
wth water up
to the max. level.
Cookng s complete
(blnkng red lght)
Cookng error
(flashng pnk lght)
Tme-out error
(steady pnk lght)
No water
(flashng blue lght)
Product s ready
to be made
(steady whte lght)

19 / EN
Coffee Machine / User Manual
4.1 Cleanng
A
WARNING: Do not
move the product
whle the cookng
(coffee-makng) pot
(11) s wthn the
product. The coffee-
makng pot mght
get damaged.
A
WARNING: Never
use gasolne, sol-
vent, abrasve clea-
nng agents, metal
objects or hard
brushes to clean the
applance.
A
WARNING: Never
mmerse the app-
lance or ts power
cable (8) n water or
n any other lqud.
1. Unplug the applance before
startng any cleanng procedure.
2. Wat for the applance to cool
down.
3. Remove the cookng pot (11)
from ts seat (7).
4. Clean the cookng pot (11) under
runnng water.
5. Completely remove the water
pot out of ts seat and clean t
under runnng water.
C
Take out and hand-
wash the water tank
(2) at least every
three months.
C
Do not clean the he-
atng surface (9) and
cookng pot wth ab-
rasve sponge or steel
wool. Wash t wth a
soft sponge. Pat par-
tcularattentonnotto
scratchthesesurfaces.
A
WARNING: Never
use the cookng
(coffee makng) pot
(11) or the water
tank (2) n dshwas-
her.
A
WARNING: Do not
wash any part of the
product n the dsh-
washer.
4 Cleanng and care

20 / EN Coffee Machine / User Manual
4 Cleanng and care
A
WARNING: Snce
the applance wll be
hot durng brewng,
please wat untl s
cooled f you would
lke to clean t after-
wards.
C
In order to preserve
the taste of the
coffee you would
prepare, clean the
cookng pot (11)
after every cookng
operaton wthout
watng.
6. Use a damp and soft cloth and a
lttle amount of soft cleanser n
order to clean the exteror of the
applance.
C
Do not neglect to
wpe the cookng
level detecton sen-
sor (6) wth a damp
cloth at every 15-20
cookng operatons.
7. Place the cookng pot (11) onto
ts seat.
4.1.1 Descalng
To clean the stans (deposts) that
mght be observed n the coffee-
makng (cookng) pot n tme wt-
hout harmng the nner base surfa-
ce, pour one dessert spoon of ctrc
acd crystals to the coffee-makng
pot and pour bolng water on t, so
that water flls 1/3 of the pot. Wat
for 10 mnutes. At the end of the
watng process, you can rnse the
cookng pot (11) and use t agan.
4.2 Storage
• If you do not ntend to use the
applance for a long tme, store
t carefully.
• Please make sure that the app-
lance s unplugged, cooled and
totally dry.
• Store the applance n a cool and
dry place.
• Keep the applance out of the re-
ach of chldren.
