arcelik Selamlique MVK1960 User manual

/ 26 EN
Selamlique Coffee Machine With Capsules
User Manual
Selamlique Capsule Turkish Coffee
Machine
Kapsüllü Türk Kahvesi Makinesi
Kullanma Kılavuzu
MVK1960

Dear Customer,
Thank you for choosing this Arçelik product.We hope that you get the best
results from your product which has been manufactured with high qual-
ity and state-of-the-art technology. For this reason please read this user
manual and all other accompanying documents carefully before using the
product and keep it as a reference for future use. If you give the product
to someone else, give the user manual as well. Follow the instructions by
paying attention to all the information and warnings in the user manual.
Meanings of the symbols
Following symbols are used in the various sections of this manual:
CImportant information and useful ad-
vices regarding to usage.
AWarnings for dangerous situations
concerning the safety of life and
property.
Materials are intended to be in
contact with food.
It does not contain PCB.Complies with the WEEE Directive.
This product has been produced in environmentally-friendly facilities without harming the nature.
Please read this user manual first!

3 / 56 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
CONTENTS
1. Important safety
and environmental
instructions 4
1.1 General safety .................. 4
1.2 Compliance with the WEEE
Directive and disposal of the waste
product ................................. 9
1.3 Compliance with RoHS
Directive................................. 9
1.4 Package information ........ 9
2. Your turkish coffee
machine 10
2.1 Overview .......................... 10
2.2 Technical data................... 11
3. Use 12
3.1 Initial use.......................... 12
3.2 Brewing............................ 13
3.3 Sleep mode ...................... 16
3.4 Notifications ..................... 17
4. Cleaning and
maintenance 19
4.1 Cleaning........................... 19
4.2 Cleaning mode ................. 24
4.2.1 Quick cleaning............... 24
4.2.2 Intense cleaning............. 25
4.2.3 Lime removal................. 26
4.3 Storage ............................ 26
4.4 Handling and
transportation ......................... 26
5. Technological superiorities
of the appliance 27
6. Actions to be taken before
calling the service 27
01M-7489670200-4416-07

4 / 54 EN Selamlique Capsule Turkish Coffee Machine / User Manual
This section contains safety instructions that will
help protect from risk of personal injury or property
damage.
Failure to follow these instructions will void all types
of warranty.
1.1 General safety
•This appliance complies with the international
safety standards.
•Do not use this appliance outdoors and or the
bathroom.
•Never attempt to dismantle or separate the mounted
parts of the appliance.
•Only use the original parts or parts recommended
by the manufacturer.
•Always use the appliance on a stable, flat, clean,
dry and non-slip surface.
•Do not put any other substances (milk etc.) into the
water tank other than water.
•Never put hot water into the water tank.
•If you keep the package material, keep it away from
children.
1. Important safety and environmental
instructions

5 / 54 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
•When the water tank is not in its place, do not pour
water into the slot where the water tank is mounted.
•The appliance is designed to operate at 4-37°C
80% relative humidity.
•Due to the manufacturing technology, steam and
odour may arise in the heating element of the
appliance during the initial use. This is normal for
your appliance. It will return to normal after being
used for a few times.
•Avoid contacting the hot surfaces. The base
(heating surface) where brewing reservoir gets hot
and thus, the brewing reservoir also gets hot during
operation. Therefore, do not touch this area during
usage process and until the appliance gets cold,
hold the brewing reservoir by its handle. Otherwise,
there is a risk of burning.
•Do not move the appliance when there is liquid in
the brewing reservoir, when there is water in the
water tank or when the appliance is still hot.
•Make sure that the appliance is unplugged before
moving the appliance.
1. Important safety and environmental
instructions

6 / 54 EN Selamlique Capsule Turkish Coffee Machine / User Manual
•For additional protection, this appliance should be
connected to a household residual current circuit
breaker of maximum 30 mA.
•Connect the appliance to a grounded outlet
protected by a 16 ampere fuse.
•Do not use the appliance if the power cable or the
appliance itself is damaged.
•Do not use the appliance with an extension cable.
•Do not expose or immerse the appliance in water
or other liquids.
•Never touch the appliance or its plug with damp or
wet hands.
•Prevent damage to the power cable by not
squeezing, bending, or rubbing it on sharp edges.
Keep the power cable away from hot surfaces and
naked flame.
•Make sure that there is no danger that the power
cord could be accidentally pulled or that someone
could trip over it when the appliance is in use.
•Unplug the appliance if any failure occurs.
1. Important safety and environmental
instructions

7 / 54 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
•Unplug the appliance before cleaning it and never
clean it when it is in use. (Out of quick and deep
cleaning).
•Do not pull the power cable of the appliance to
unplug the appliance from the outlet.
•Your mains power supply should comply with
the information given on the rating plate of the
appliance.
•Do not use the appliance in or near places where
combustible or inflammable places or materials are
present.
•Do not use the appliance next or close to heat
resources (hob, grill, heater core, stove etc.).
•Keep the appliance away from steam resources and
avoid using it in environments containing excessive
steam.
•Do not use the brewing reservoir with any other
heater (hob etc.) apart from the appliance.
•Make sure the appliance is kept in a place out of
the reach of children.
1. Important safety and environmental
instructions

8 / 54 EN Selamlique Capsule Turkish Coffee Machine / User Manual
•The appliance is designed to be used in houses,
kitchens of the employees at offices, stores and
other working environments, and in the guest rooms
at the hotels, motels and other accommodation
places.The appliance is not intended for commercial
use.
•Do not use the appliance for anything other than
preparing coffee.
•Extreme caution is advised when using the appliance
near children and persons who are restricted in
terms of their physical, sensory or mental abilities.
•This appliance may be used by children who are at
the age of 8 or over and the people whose physical,
perceptive or mental skills are impaired or who
are inexperienced or not knowledgeable about
the appliance as long as they are supervised or
informed and made understood the safe use of the
appliance and the encountered dangers.
•Children should not play with the appliance.
Cleaning and user maintenance procedures should
not be performed by children over 8 unless they are
supervised by an older person.
1. Important safety and environmental
instructions

9 / 54 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
1.2 Compliance with WEEE directive and disposing of
the waste product
This product complies with EU WEEE Directive (2012/19/EU).
This product bears a classification symbol for waste electrical
and electronic equipment (WEEE).This product has been manu-
factured with high quality parts and materials which can be re-
used and are suitable for recycling. Do not dispose of the waste
product with normal domestic and other wastes at the end of its service
life. Take it to the collection center for the recycling of electrical and elec-
tronic equipment. Please consult your local authorities to learn about
these collection centers.
1.3 Compliance with RoHS Directive
The product you have purchased complies with EU RoHS Directive
(2011/65/EU). It does not contain harmful and prohibited materials speci-
fied in the Directive.
1.4 Package information
Package of the product is made of recyclable materials in ac-
cordance with our National Legislation. Do not dispose of the
packaging materials together with domestic or other wastes.
Take them to the packaging material collection points desig-
nated by the local authorities.
1. Important safety and environmental
instructions

10 / 56 EN Selamlique Capsule Turkish Coffee Machine / User Manual
2.1 Overview
The values which are declared on the markings affixed to your product or in other printed documents supplied with it
represent the values which have been obtained in the laboratories pursuant to the pertinent standards. These values may
vary according to the usage of the appliance and ambient conditions.
1. Water adjustment pot
2. Handle of the brewing reservoir
3. Brewing reservoir
4. Capsule popping blade
(detachable)
5. Water tank lid
6. Upper lid handle
7. Coffee brewing start key
8. Mode light
9. Cleaning start key
10. Front lid release key
11. Cup fitting slot
12. Loophole
13. Waste water reservoir
14. Mains cable
15. Waste coffee reservoir
16. Cleaning brush
2. Your turkish coffee machine
4
3
2
1
7
11
6
5
9
10
13
14
15
12
8
16

11 / 56 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
2.2 Technical data
Current: Max 3A
Power: 670 W
Voltage: 220-240 V AC ~, 50 Hz
Cable length: 100 cm
Technical and design modification
rights are reserved.
2. Your turkish coffee machine

12 / 56 EN Selamlique Capsule Turkish Coffee Machine / User Manual
3.1 Initial use
Please read the "cleaning and main-
tenance" chapter in your user manu-
al before using the appliance.
1. Plug in the appliance.
– The appliance will switch on
automatically.
2. Remove the water tank lid (5).
3. Fill the water reservoir with water
up to the max. level. Depending
on how you like it, you can also
fill the water by displacing the
water tank completely as well.
Repeat the same process after the
appliance gives out water depleted
alarm.
4. Activate the auto-cleaning fea-
ture by touching the cleaning
start (9) key during 1 sec.
CIn this way, proper op-
eration of the pump in
the appliance is ena-
bled.
3. Use

13 / 56 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
A
WARNING: Repeat
this process also after
you remove/place the
water tank from/into
its place and before
brewing coffee.
5. Set the suitable position depend-
ing on your cup size by using the
water adjustment pot (1).
C
So as change the po-
sition of the water ad-
justment pot, remove
the waste water res-
ervoir (13) complete-
ly. You can change the
water adjustment pot
by hand.
3. Use
C
There are two posi-
tions of water adjust-
ment pot. Water ad-
justment pot match-
es up to " I " while
in the lowest position
and to " II " while in
the upper position.
The recommended
cup sizes are 67 ml
while in " I " position
and 77 ml while in "
II " position.
C
Repeat the water
amount adjusting
process when you
prefer to change the
cup size.
3.2 Brewing
1. Plug in the appliance.
– The appliance will switch on au-
tomatically.
AWARNING: Make
sure that there is
enough water in the
water tank.
2. Open the upper lid with the help
of the handle (6).

14 / 56 EN Selamlique Capsule Turkish Coffee Machine / User Manual
3. Place the coffee capsule in the
capsule slot (4) in such a way
that the wide surface of the cap-
sule is below.
C
Your appliance is
designed to make
a single coffee with
one capsule. The
capsules to be used
in the appliance are
prepared according
to the different fla-
vour and sugar level
options. That is why
you do not need to
add extra sugar.
A
WARNING: Your ap-
pliance is designed
to comply with the
Selamlique-branded
coffee capsules.
4. Close the upper lid with the help
of the handle (6).
A
WARNING: Before
starting the brewing
process, make sure
that waste water
reservoir (13) is in its
place/empty and the
brewing reservoir (3)
is in its housing.
3. Use

15 / 56 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
3. Use
C
When your appliance
is ready for brewing
coffee, the status
light will flash in sta-
ble white.
5. Place your cup into the cup fit-
ting slot (11).
6. Proceed to the brewing process
by touching the coffee brewing
start key (7).
– The appliance will give an au-
dio warning (beep) and status
light (8) will turn into red.
CBrewing time is 1.5 -
2 minutes.
C
Cooking time will
decrease in succes-
sive brewing as the
heating surface will
already be hot.
C
Touch and hold the
coffee brewing start
key (7) for 3 seconds
to cancel the coffee
making process for
any reason. When the
brewing is cancelled,
the appliance will give
an audio warning and
status light (8) will
start to blink in red
and the blend inside
the brewing reservoir
is poured into the
cup/waste water
reservoir.
7. When the coffee is ready, the
status light (8) will start to blink
in red while the coffee is poured
into the cup.

16 / 56 EN Selamlique Capsule Turkish Coffee Machine / User Manual
3. Use
8. After the coffee pouring process
is completed, the appliance will
give an audio warning and the
status light (8) will turn into white.
Take your cup from the cup fitting
slot.
3.3 Sleep mode
If no operation is performed on
the device for 3 minutes, it will
give a long audio warning (beep)
and switch to stand-by mode and
the status light (8) will light in
dim white. When an operation is
performed (when the touch keys
are touched, brewing reservoir is
placed/removed into/from its slot, if
the upper lid is opened/closed, the
water tank and waste water reser-
voir is placed/removed into/from its
slot) 2 audio warnings (beeps) are
given. Status light turns into white
and the appliance becomes ready
to operate.

17 / 56 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
3.4 Notifications
Product is ready to be
brewed
(Steady white light)
Cooking
Steady red light)
Cooked and coffee is
being poured into the
cup
(Blinking red light)
Cleaning is being per-
formed
(Steady blue light)
Water tank is not in its
place / No adequate
water in the water tank
/ Brewing reservior is
not in its housing.
(Blinking blue light)
Please check if the wa-
ter tank and brewing
reservoir is in its place
If both of them are in
their place, fill the water
tank to max. level.
3. Use

18 / 56 EN Selamlique Capsule Turkish Coffee Machine / User Manual
3. Use
Time-out error
(Steady pink light)
Please wait until the
status led become
White.
The machine is ready
to brew coffee if the
status led is wihte.
Try to brew coffee
again, please be sure
that you pop capsule
for this brewing cycle.
Contact service if the
failure occurs again.

19 / 56 EN
Selamlique Capsule Turkish Coffee Machine / User Manual
4.1 Cleaning
After you take the product out of its
package, remove the tape adhered
on the product prior to use. Wash
and clean all the removable parts
(loophole, waste water reservoir,
brewing reservoir, water tank, wa-
ter tank lid) under the running wa-
ter by using a mild cleaning agent
slightly before using the product.
Place the parts you have washed
when they are completely dry.
A
WARNING: Never
use gasoline, solvent,
abrasive cleaning
agents, metal objects
or hard brushes to
clean the appliance.
AWARNING: Do not
wash any part of the
product in the dish-
washer.
A
WARNING: Since
the appliance will be
hot during brewing,
please wait until is
cooled if you would
like to clean it after-
wards.
1. Unplug the appliance before
starting any cleaning procedure.
2. Open the front lid by pressing the
front lid release key (10).
3. Remove the brewing reservoir (3)
out of its slot.
4. Clean the brewing reservoir (3) un-
der running water.
4. Cleaning and maintenance

20 / 56 EN Selamlique Capsule Turkish Coffee Machine / User Manual
C
After cleaning, make
sure that there are
no water drops un-
derneath the base of
the brewing reser-
voir (3). Otherwise,
an annoying noise
will arise when the
water drops get into
contact with the hot
base during brewing.
A
Make sure that the
heating surface is
dry and clean. Do
not clean the heating
surface with abrasive
sponge or steel wool.
Wipe the heating
surface with a damp
cloth and clean the
brewing reservoir
with a soft sponge.
Pay particular atten-
tion not to scratch
these surfaces.
C
Do not neglect to
wipe the brewing de-
tection sensor with
a damp cloth after
every 15-20 brewing
operations.
5. Place the brewing reservoir (3)
into its housing.
4. Cleaning and maintenance
