arcelik 5064 F User manual

Washing Machine
User's Manual
5064 F

2EN
Please read this user manual first!
Dear Customer,
We hope that you get the best results from the product which has been manufactured in
state-of-the-art plants and passed through a strict quality control procedure.
Therefore, please read the entire user manual carefully before using the product and keep
it as a reference for future use. In case of transferring the product to someone else, give
the manual as well.
The user manual will help you use your machine in a fast
and safe way.
• Read the user manual before installing and starting your product.
• Always follow the safety instructions.
• Keep this user manual within easy reach for future reference.
• Read also the other documents supplied with the product.
Remember that this user manual is also applicable for several other models. Differences
between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning for electric shock.
2820521813_EN/120112.1630

3EN
TABLE OF CONTENTS
1 Your washing machine 4
Overview . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical specifications . . . . . . . . . . . . . 5
2 Important safety
instructions 6
General safety . . . . . . . . . . . . . . . . . . . . 6
Intended use . . . . . . . . . . . . . . . . . . . . . 6
Children's safety . . . . . . . . . . . . . . . . . . 7
3 Installation 8
Appropriate installation location . . . . . . . 8
Removing packaging reinforcement. . . . 8
Removing the transportation locks. . . . . 8
Connecting water supply. . . . . . . . . . . . 9
Connecting to the drain . . . . . . . . . . . . . 9
Adjusting the feet. . . . . . . . . . . . . . . . . 10
Electrical connection . . . . . . . . . . . . . . 10
First use . . . . . . . . . . . . . . . . . . . . . . . 11
Disposing of packaging material . . . . . 11
Transportation of the product. . . . . . . . 11
Disposing of the old product . . . . . . . . 11
4 Preparation 12
Things to be done for energy saving . . 12
Sorting the laundry . . . . . . . . . . . . . . . 12
Preparing laundry for washing . . . . . . . 12
Correct load capacity . . . . . . . . . . . . . 13
Loading the laundry. . . . . . . . . . . . . . . 13
Using detergent and softener . . . . . . . 14
Tips for efficient washing . . . . . . . . . . . 16
5 Operating the product 17
Control panel. . . . . . . . . . . . . . . . . . . . 17
Preparing the machine. . . . . . . . . . . . . 18
Programme selection. . . . . . . . . . . . . . 18
Main programmes . . . . . . . . . . . . . . . 18
Temperature selection . . . . . . . . . . . . . 19
Spin speed selection . . . . . . . . . . . . . . 19
Programme selection and consumption
table . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Auxiliary function selection . . . . . . . . . . 21
Starting the programme. . . . . . . . . . . . 21
Child Lock . . . . . . . . . . . . . . . . . . . . . . 21
Progress of programme. . . . . . . . . . . . 22
Loading door lock . . . . . . . . . . . . . . . . 22
Changing the selections after programme
has started . . . . . . . . . . . . . . . . . . . . . 22
Canceling the programme . . . . . . . . . . 22
End of programme . . . . . . . . . . . . . . . 23
6 Maintenance and cleaning24
Cleaning the detergent drawer. . . . . . . 24
Cleaning the loading door and the
drum . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Cleaning the body and control panel . . 24
Cleaning the water intake filters . . . . . . 24
Draining remaining water and cleaning the
pump filter . . . . . . . . . . . . . . . . . . . . . . 25
7 Troubleshooting 27

4EN
1 Your washing machine
Overview
7
3
4
6
5
2
1
8
1- Power cable
2- Top panel
3- Control panel
4- Filter cap
5- Adjustable feet
6- Loading door
7- Detergent drawer
8- Drain hose

5EN
Models (EN)
Maximum dry laundry capacity (kg)
Height (cm)
Width (cm)
Depth (cm)
Net weight (±4 kg.)
Electrical input (V/Hz)
Total current (A)
Total power (W)
Spin speed (rpm max.)
Stand-by mode power (W)
Off-mode power (W)
Technical specifications
CTechnical specifications may be changed without prior notice to improve the quality of
the product.
C Figures in this manual are schematic and may not match the product exactly.
CValues stated on the product labels or in the documentation accompanying it
are obtained in laboratory conditions in accordance with the relevant standards.
Depending on operational and environmental conditions of the product, these values
may vary.
5064 F
5
84
60
45
60
220-240 V / 50Hz
10
2000-2350
600
1.00
0.25

6EN
2 Important safety instructions
This section contains safety instructions
that will help protect from risk of personal
injury or property damage. Failure to follow
these instructions shall void any warranty.
General safety
• This product should not be used
by persons with physical, sensory
or mental disorders or unlearned
or inexperienced people (including
children) unless they are attended by
a person who will be responsible for
their safety or who will instruct them
accordingly for use of the product.
• 8 years and older children and people
with reduced physical, sensory, and
mental abilities as well as unskilled
or inexperienced persons can use
this appliance provided that they are
supervised and instructed on safe
use of the appliance as well as to the
related dangers. Children should not
play or tamper with the appliance.
Cleaning and user maintenance should
never be performed by children unless
supervised by a responsible adult.
• Never place the product on a carpet-
covered floor; otherwise, lack of
airflow beneath the machine will cause
electrical parts to overheat. This will
cause problems with your product.
• Do not operate the product if the
power cable / plug is damaged. Call
the Authorized Service Agent.
• Have a qualified electrician connect
a 16-Ampere fuse to the installation
location of the product.
• If the product has a failure, it should not
be operated unless it is repaired by the
Authorized Service Agent. There is the
risk of electric shock!
• This product is designed to resume
operating in the event of powering on
after a power interruption. If you wish to
cancel the programme, see "Cancelling
the programme" section.
• Connect the product to a grounded
outlet protected by a fuse complying
with the values in the "Technical
specifications" table. Do not neglect to
have the grounding installation made
by a qualified electrician. Our company
shall not be liable for any damages
that will arise when the product is used
without grounding in accordance with
the local regulations.
• The water supply and draining hoses
must be securely fastened and remain
undamaged. Otherwise, there is the
risk of water leakage.
• Never open the loading door or remove
the filter while there is still water in the
drum. Otherwise, risk of flooding and
injury from hot water will occur.
• Do not force open the locked loading
door. The loading door will be ready
to open just a few minutes after the
washing cycle comes to an end.
In case of forcing the loading door
to open, the door and the lock
mechanism may get damaged.
• Unplug the product when not in use.
• Never wash the product by spreading
or pouring water onto it! There is the
risk of electric shock!
• Never touch the plug with wet hands!
Never unplug by pulling on the cable,
always pull out by grabbing the plug.
• Use detergents, softeners and
supplements suitable for automatic
washing machines only.
• Follow the instructions on the textile
tags and on the detergent package.
• The product must be unplugged during
installation, maintenance, cleaning and
repairing procedures.
• Always have the installation and
repairing procedures carried out
by the Authorized Service Agent.
Manufacturer shall not be held liable
for damages that may arise from
procedures carried out by unauthorized
persons.
Intended use
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must only be used for
washing and rinsing of laundry that are
marked accordingly.

7EN
• The manufacturer waives any
responsibility arisen from incorrect
usage or transportation.
Children's safety
• Electrical products are dangerous for
the children. Keep children away from
the product when it is in use. Do not
let them to tamper with the product.
Use child lock to prevent children from
intervening with the product.
• Do not forget to close the loading
door when leaving the room where the
product is located.
• Store all detergents and additives in a
safe place away from the reach of the
children.

8EN
3 Installation
Refer to the nearest Authorised Service
Agent for installation of the product. To
make the product ready for use, review
the information in the user manual and
make sure that the electricity, tap water
supply and water drainage systems are
appropriate before calling the Authorized
Service Agent. If they are not, call a
qualified technician and plumber to have
any necessary arrangements carried out.
CPreparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer's responsibility.
BInstallation and electrical connections
of the product must be carried out
by the Authorized Service Agent.
Manufacturer shall not be held liable
for damages that may arise from
procedures carried out by unauthorized
persons.
APrior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
CMake sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or
crushed while pushing the product into
its place after installation or cleaning
procedures.
Appropriate installation location
• Place the machine on a rigid floor. Do
not place it on a long pile rug or similar
surfaces.
• Total weight of the washing machine
and the dryer -with full load- when
they are placed on top of each other
reaches to approx. 180 kilograms.
Place the product on a solid and flat
floor that has sufficient load carrying
capacity!
• Do not place the product on the power
cable.
• Do not install the product at places
where temperature may fall below 0ºC.
• Place the product at least 1 cm away
from the edges of other furniture.
Removing packaging
reinforcement
Tilt the machine backwards to remove
the packaging reinforcement. Remove the
packaging reinforcement by pulling the
ribbon.
Removing the
transportation locks
ADo not remove the transportation
locks before taking out the packaging
reinforcement.
A Remove the transportation safety
bolts before operating the washing
machine, otherwise, the product will be
damaged.
1. Loosen all the bolts with a spanner until
they rotate freely (C).
2. Remove transportation safety bolts by
turning them gently.

9EN
3. Attach the plastic covers supplied in
the User Manual bag into the holes on
the rear panel. (P)
C Keep the transportation safety bolts in
a safe place to reuse when the washing
machine needs to be moved again in
the future.
CNever move the product without the
transportation safety bolts properly
fixed in place!
Connecting water supply
CThe water supply pressure required
to run the product is between 1 to 10
bars (0.1 – 10 MPa). It is necessary
to have 10 – 80 liters of water flowing
from the fully open tap in one minute
to have your machine run smoothly.
Attach a pressure reducing valve if
water pressure is higher.
CIf you are going to use the double
water-inlet product as a single (cold)
water-inlet unit, you must install the
supplied stopper to the hot water valve
before operating the product. (Applies
for the products supplied with a blind
stopper group.)
CIf you want to use both water inlets
of the product, connect the hot water
hose after removing the stopper and
gasket group from the hot water valve.
(Applies for the products supplied with
a blind stopper group.)
AModels with a single water inlet should
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
ADo not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
1. Connect the special hoses supplied
with the product to the water inlets
on the product. Red hose (left) (max.
90 ºC) is for hot water inlet, blue hose
(right) (max. 25 ºC) is for cold water
inlet.
AEnsure that the cold and hot water
connections are made correctly when
installing the product. Otherwise, your
laundry will come out hot at the end of
the washing process and wear out.
2. Tighten all hose nuts by hand. Never
use a wrench when tightening the nuts.
3. Open the taps completely after making
the hose connection to check for
water leaks at the connection points.
If any leaks occur, turn off the tap and
remove the nut. Retighten the nut
carefully after checking the seal. To
prevent water leakages and damages
caused by them, keep the taps closed
when the machine is not in use.
Connecting to the drain
• The end of the drain hose must be
directly connected to the wastewater
drain or to the washbasin.
AYour house will be flooded if the
hose comes out of its housing during
water discharge. Moreover, there is
risk of scalding due to high washing
temperatures! To prevent such
situations and to ensure smooth water
intake and discharge of the machine,
fix the end of the discharge hose tightly
so that it cannot come out.
• The hose should be attached to a
height of at least 40 cm, and 100 cm at
most.

10 EN
• In case the hose is elevated after
laying it on the floor level or close to
the ground (less than 40 cm above the
ground), water discharge becomes
more difficult and the laundry may
come out excessively wet. Therefore,
follow the heights described in the
figure.
• To prevent flowing of dirty water back
into the machine and to allow for easy
discharge, do not immerse the hose
end into the dirty water or drive it in the
drain more than 15 cm. If it is too long,
cut it short.
• The end of the hose should not be
bent, it should not be stepped on and
the hose must not be pinched between
the drain and the machine.
• If the length of the hose is too short,
use it by adding an original extension
hose. Length of the hose may not be
longer than 3.2 m. To avoid water leak
failures, the connection between the
extension hose and the drain hose of
the product must be fitted well with an
appropriate clamp as not to come off
and leak.
Adjusting the feet
AIn order to ensure that the product
operates more silent and vibration-free,
it must stand level and balanced on its
feet. Balance the machine by adjusting
the feet. Otherwise, the product
may move from its place and cause
crushing and vibration problems.
1. Loosen the lock nuts on the feet by
hand.
2. Adjust the feet until the product stands
level and balanced.
3. Tighten all lock nuts again by hand.
ADo not use any tools to loosen the lock
nuts. Otherwise, they will get damaged.
Electrical connection
Connect the product to a grounded outlet
protected by a fuse complying with the
values in the "Technical specifications"
table. Our company shall not be liable
for any damages that will arise when the
product is used without grounding in
accordance with the local regulations.
• Connection must comply with national
regulations.
• Power cable plug must be within easy
reach after installation.
• The voltage and allowed fuse or
breaker protection are specified in the
“Technical specifications” section. If the
current value of the fuse or breaker in
the house is less than 16 Amps, have
a qualified electrician install a 16 Amp

11 EN
fuse.
• The specified voltage must be equal to
your mains voltage.
• Do not make connections via extension
cables or multi-plugs.
BDamaged power cables must be
replaced by the Authorized Service
Agents.
First use
Before starting to use the product, make
sure that all preparations are made in
accordance with the instructions in
sections "Important safety instructions" and
"Installation".
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If your machine is not
featured with Drum Cleaning programme,
use Cottons-90 programme and select
Additional Water or Extra Rinse auxiliary
functions as well. Before starting the
programme, put max. 100 g of powder
anti-limescale into the main wash detergent
compartment (compartment nr. II). If the
anti-limescale is in tablet form, put only
one tablet into compartment nr. II. Dry the
inside of the bellow with a clean piece of
cloth after the programme has come to an
end.
CUse an anti-limescale suitable for the
washing machines.
CSome water might have remained in
the product due to the quality control
processes in the production. It is not
harmful for the product.
Disposing of packaging material
Packaging materials are dangerous to
children. Keep packaging materials in a
safe place away from reach of the children.
Packaging materials of the product are
manufactured from recyclable materials.
Dispose of them properly and sort
in accordance with recycled waste
instructions. Do not dispose of them with
normal domestic waste.
Transportation of the product
1. Unplug the product before transporting
it.
2. Remove water drain and water supply
connections.
3. Drain the remaining water in the
product completely; see, "Draining
remaining water and cleaning the pump
filter".
4. Install transportation safety bolts in the
reverse order of removal procedure;
see, "Removing the transportation
locks".
CNever move the product without the
transportation safety bolts properly
fixed in place!
Disposing of the old product
Dispose of the old product in an
environmentally friendly manner.
Refer to your local dealer or solid waste
collection centre in your area to learn how
to dispose of your product.
For children's safety, cut the power cable
and break the locking mechanism of the
loading door so that it will be nonfunctional
before disposing of the product.

12 EN
4 Preparation
Things to be done for
energy saving
Following information will help you use
the product in an ecological and energy-
efficient manner.
• Operate the product in the highest
capacity allowed by the programme
you have selected, but do not overload;
see, “Programme and consumption
table”.
• Always follow the instructions on the
detergent packaging.
• Wash slightly soiled laundry at low
temperatures.
• Use faster programmes for small
quantities of lightly soiled laundry.
• Do not use prewash and high
temperatures for laundry that is not
heavily soiled or stained.
• If you plan to dry your laundry in a
dryer, select the highest spin speed
recommended during washing
process.
• Do not use detergent in excess of
the amount recommended on the
detergent package.
Sorting the laundry
• Sort laundry according to type of
fabric, colour, and degree of soiling and
allowable water temperature.
• Always obey the instructions given on
the garment tags.
Washing water
temperature
Bleach can be
used
Suitable for drier
Wash with sensitive,
.short programmes
Do not use bleach
Do not dry with drier
Hang without
spinning
Can be ironed with
hot iron
Non machine-washable Do not wash
Dry-cleanable Do not dry-clean
Dry horizontally Dry on a hanger
Can be ironed
with warm iron
Do not iron
Preparing laundry for washing
• Laundry items with metal attachments
such as, underwired bras, belt buckles
or metal buttons will damage the
machine. Remove the metal pieces or
wash the clothes by putting them in a
laundry bag or pillow case.

13 EN
• Take out all substances in the pockets
such as coins, pens and paper clips,
and turn pockets inside out and brush.
Such objects may damage the product
or cause noise problem.
• Put small size clothes such as infant’s
socks and nylon stockings in a laundry
bag or pillow case.
• Place curtains in without compressing
them. Remove curtain attachment
items.
• Fasten zippers, sew loose buttons and
mend rips and tears.
• Wash “machine washable” or “hand
washable” labeled products only with
an appropriate programme.
• Do not wash colours and whites
together. New, dark coloured cottons
release a lot of dye. Wash them
separately.
• Tough stains must be treated properly
before washing. If unsure, check with a
dry cleaner.
• Use only dyes/colour changers
and limescale removers suitable for
machine wash. Always follow the
instructions on the package.
• Wash trousers and delicate laundry
turned inside out.
• Keep laundry items made of Angora
wool in the freezer for a few hours
before washing. This will reduce pilling.
• Laundry that are subjected to materials
such as flour, lime dust, milk powder,
etc. intensely must be shaken off
before placing into the machine. Such
dusts and powders on the laundry
may build up on the inner parts of
the machine in time and can cause
damage.
Correct load capacity
The maximum load capacity depends on
the type of laundry, the degree of soiling
and the washing programme desired.
The machine automatically adjusts the
amount of water according to the weight of
the loaded laundry.
AFollow the information in the
“Programme and consumption table”.
When overloaded, machine’s washing
performance will drop. Moreover, noise
and vibration problems may occur.
Laundry types and their average weights in
the following table are given as examples.
Laundry type Weight (g)
Bathrobe 1200
Napkin 100
Duvet cover 700
Bed Sheet 500
Pillowcase 200
Tablecloth 250
Towel 200
Hand towel 100
Evening gown 200
Underclothing 100
Men’s overalls 600
Men’s shirt 200
Men’s pajamas 500
Blouses 100
Loading the laundry
• Open the loading door.
• Place laundry items loosely into the
machine.
• Push the loading door to close until you
hear a locking sound. Ensure that no
items are caught in the door.
CThe loading door is locked while a
programme is running. The door
can only be opened a while after the
programme comes to an end.
AIn case of misplacing the laundry, noise
and vibration problems may occur in
the machine.

14 EN
Using detergent and softener
Detergent Drawer
The detergent drawer is composed of three
compartments:
- (1) for prewash
- (2) for main wash
– (3) for softener
– (*) in addition, there is siphon piece in the
softener compartment.
1
231
23
C
The detergent dispenser may be in two
different types according to the model
of your machine as seen above.
Detergent, softener and other cleaning
agents
• Add detergent and softener before
starting the washing programme.
• Never open the detergent drawer while
the washing programme is running!
• When using a programme without
prewash, do not put any detergent
into the prewash compartment
(compartment nr. I).
• In a programme with prewash, do not
put liquid detergent into the prewash
compartment (compartment nr. I).
• Do not select a programme with
prewash if you are using a detergent
bag or dispensing ball. Place the
detergent bag or the dispensing ball
directly among the laundry in the
machine.
• If you are using liquid detergent, do
not forget to place the liquid detergent
cup into the main wash compartment
(compartment nr. II).
Choosing the detergent type
The type of detergent to be used depends
on the type and colour of the fabric.
• Use different detergents for coloured
and white laundry.
• Wash your delicate clothes only with
special detergents (liquid detergent,
wool shampoo, etc.) used solely for
delicate clothes.
• When washing dark coloured clothes
and quilts, it is recommended to use
liquid detergent.
• Wash woolens with special detergent
made specifically for woolens.
AUse only detergents manufactured
specifically for washing machines.
ADo not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be
used depends on the amount of laundry,
the degree of soiling and water hardness.
Read the manufacturer’s instructions on
the detergent package carefully and follow
the dosage values.
• Do not use amounts exceeding the
dosage quantities recommended
on the detergent package to avoid
problems of excessive foam, poor
rinsing, financial savings and finally,
environmental protection.
• Use lesser detergent for small amounts
or lightly soiled clothes.
• Use concentrated detergents in the
recommended dosage.
Using softeners
Pour the softener into the softener
compartment of the detergent drawer.
• Use the dosages recommended on the
package.
• Do not exceed the (>max<) level
marking in the softener compartment.
• If the softener has lost its fluidity, dilute
it with water before putting it in the
detergent drawer.
Using liquid detergents
If the product contains a liquid
detergent cup:
• Make sure that you have placed the
liquid detergent cup in compartment nr.
“II”.
• Use the detergent manufacturer’s
measuring cup and follow the
instructions on the package.
• Use the dosages recommended on the
package.
• If the liquid detergent has lost its fluidity,
dilute it with water before putting in the
detergent cup.

15 EN
If the product does not contain a liquid
detergent cup:
• Do not use liquid detergent for the
prewash in a programme with prewash.
• Use the detergent manufacturer’s
measuring cup and follow the
instructions on the package.
• Liquid detergent stains your clothes
when used with Delayed Start function.
If you are going to use the Delayed
Start function, do not use liquid
detergent.
Using gel and tablet detergent
When using tablet, gel, etc. detergents,
read the manufacturer’s instructions on
the detergent package carefully and
follow the dosage values. If there is not
any instruction on the package, apply the
following.
• If the gel detergent thickness is fluidal
and your machine does not contain
a special liquid detergent cup, put
the gel detergent into the main wash
detergent compartment during first
water intake. If your machine contains
a liquid detergent cup, fill the detergent
into this cup before starting the
programme.
• If the gel detergent thickness is not
fluidal or in the shape of capsule liquid
tablet, put it directly into the drum
before washing.
• Put tablet detergents into the main
wash compartment (compartment
nr. II) or directly into the drum before
washing.
CTablet detergents may leave residues
in the detergent compartment. If you
encounter such a case, place the tablet
detergent between the laundry, close
to the lower part of the drum in future
washings.
CUse the tablet or gel detergent without
selecting the prewash function.
Using starch
• Add liquid starch, powder starch or the
dyestuff into the softener compartment
as instructed on the package.
• Do not use softener and starch
together in a washing cycle.
• Wipe the inside of the machine with
a damp and clean cloth after using
starch.
Using bleaches
• Select a programme with prewash
and add the bleaching agent at the
beginning of the prewash. Do not put
detergent in the prewash compartment.
As an alternative application, select a
programme with extra rinse and add
the bleaching agent while the machine
is taking water from the detergent
compartment during first rinsing step.
• Do not use bleaching agent and
detergent by mixing them.
• Use just a little amount (approx. 50
ml) of bleaching agent and rinse the
clothes very well as it causes skin
irritation. Do not pour the bleaching
agent onto the clothes and do not use
it for coloured clothes.
• When using oxygen based bleaches,
follow the instructions on the package
and select a programme that washes
at a lower temperature.
• Oxygen based bleaches can be used
together with detergents; however,
if its thickness is not the same with
the detergent, put the detergent first
into the compartment nr. “II” in the
detergent drawer and wait until the
detergent flows while the machine
is taking in water. Add the bleaching
agent from the same compartment
while the machine is still taking in water.
Using limescale remover
• When required, use limescale removers
manufactured specifically for washing
machines only.
• Always follow instructions on the
package.

16 EN
Tips for efficient washing
Clothes
Light colours and
whites Colors Dark colors Delicates/ Woolens/Silks
(Recommended
temperature range
based on soiling
level: 40-90C)
(Recommended
temperature range
based on soiling level:
cold-40C)
(Recommended
temperature
range based
on soiling level:
cold-40C)
(Recommended
temperature
range based
on soiling level:
cold-30C)
Soiling Level
Heavily Soiled
(difficult stains
such as grass,
coffee, fruits
and blood.)
It may be
necessary to pre-
treat the stains of
perform prewash.
Powder and
liquid detergents
recommended
for whites can be
used at dosages
recommended
for heavily soiled
clothes. It is
recommended
to use powder
detergents to clean
clay and soil stains
and the stains that
are sensitive to
bleaches.
Powder and
liquid detergents
recommended for
colours can be
used at dosages
recommended for
heavily soiled clothes.
It is recommended
to use powder
detergents to clean
clay and soil stains
and the stains that are
sensitive to bleaches.
Use detergents
without bleach.
Liquid
detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for heavily soiled
clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woollen and silk
clothes must
be washed with
special woollen
detergents.
Normally Soiled
(For example,
stains caused
by body on
collars and
cuffs)
Powder and
liquid detergents
recommended
for whites can be
used at dosages
recommended for
normally soiled
clothes.
Powder and
liquid detergents
recommended for
colours can be
used at dosages
recommended for
normally soiled
clothes. Use
detergents without
bleach.
Liquid
detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for normally
soiled clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woollen and silk
clothes must
be washed with
special woollen
detergents.
Lightly Soiled
(No visible
stains exist.)
Powder and
liquid detergents
recommended
for whites can be
used at dosages
recommended for
lightly soiled clothes.
Powder and
liquid detergents
recommended for
colours can be
used at dosages
recommended for
lightly soiled clothes.
Use detergents
without bleach.
Liquid
detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for lightly soiled
clothes.
Prefer liquid
detergents
produced for
delicate clothes.
Woollen and silk
clothes must
be washed with
special woollen
detergents.

17 EN
5 Operating the product
Control panel
1 - Programme Selection knob
2 - Spin Speed Adjustment button*
3 - Temperature Adjustment button*
4 - Start / Pause / Cancel button
5 - Auxiliary Function buttons
6 - On / Off button
7 - Programme Follow-up indicator
8 - Loading Door light*
* Varies depending on the model of your machine.
14
5
6
7
8

18 EN
Preparing the machine
1. Make sure that the hoses are
connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4. Place the laundry in the machine.
5. Add detergent and fabric softener.
Programme selection
1. Select the programme suitable for
the type, quantity and soiling degree
of the laundry in accordance with the
“Programme and consumption table”
and the temperature table below.
90˚C Heavily soiled white cottons
and linens. (coffee table covers,
tableclothes, towels, bed
sheets, etc.)
60˚C
Normally soiled, coloured,
fade proof cottons or synthetic
clothes (shirt, nightgown,
pajamas, etc.) and lightly soiled
white linens (underwear, etc.)
40˚C-
30˚C-
Cold
Blended laundry including
delicate textile (veil curtains,
etc.), synthetics and woolens.
2. Select the desired programme with the
Programme Selection button.
CProgrammes are limited with the
highest spin speed appropriate for that
particular type of fabric.
CWhen selecting a programme, always
consider the type of fabric, colour,
degree of soiling and permissible water
temperature.
C Always select the lowest required
temperature. Higher temperature
means higher power consumption.
CFor further programme details, see
“Programme and consumption table”.
Main programmes
Depending on the type of fabric, use the
following main programmes.
• Pamuklu (Cottons)
You may wash your normally soiled
durable cotton and linen laundry in this
programme with the highest energy and
water saving compared to all other wash
programmes suitable for cottons. Actual
water temperature may differ from the
declared cycle temperature. Programme
duration may automatically be shortened
during later stages of the programme if you
wash less amount (e.g. ½ capacity or less)
of laundry. In this case energy and water
consumption will be further decreased
giving you the opportunity for a more
economical wash. This feature is available
for certain models having remaining time
display.
• Sentetik (Synthetics)
Use this programme to wash your synthetic
clothes (shirts, blouses, synthetic/cotton
blends, etc.). It washes with a gentle action
and has a shorter washing cycle compared
to the Cottons programme.
For curtains and tulle, use the Synthetic
40˚C programme with prewash function
selected. As their meshed texture causes
excessive foaming, wash the veils/tulle
by putting little amount of detergent into
the main wash compartment. Do not put
detergent in the prewash compartment.
• Yünlü (Woollens)
Use this programme to wash your woolen
clothes. Select the appropriate temperature
complying with the tags of your clothes.
Use appropriate detergents for woolens.
Additional programmes
For special cases, additional programmes
are available in the machine.
C Additional programmes may differ
according to the model of the machine.
• Pamuklu EKO (Cotton Eco)
You may wash your normally soiled
durable cotton and linen laundry in this
programme with the highest energy and
water saving compared to all other wash
programmes suitable for cottons. Actual
water temperature may differ from the
declared cycle temperature. Programme
duration may automatically be shortened
during later stages of the programme if you
wash less amount (e.g. ½ capacity or less)
of laundry. In this case energy and water
consumption will be further decreased
giving you the opportunity for a more
economical wash. This feature is available
for certain models having remaining time
display.
• Narin 30 (Delicate)
Use this programme to wash your delicate
clothes. It washes with a gentle action
without any interim spin compared to the
Synthetics programme.

19 EN
• Elde Yıkama 30 (Hand wash)
Use this programme to wash your woolen/
delicate clothes that bear “not machine-
washable” tags and for which hand wash
is recommended. It washes laundry with
a very gentle washing action to not to
damage clothes.
• Mini 30
Use this programme to wash your little
amount of lightly soiled cotton clothes in a
short time (30 minutes).
Special programmes
For specific applications, select any of the
following programmes.
• Durulama (Rinse)
Use this programme when you want to
rinse or starch separately.
• Sıkma+Pompa (Spin + Drain)
Use this programme to apply an additional
spin cycle for your laundry or to drain the
water in the machine.
Before selecting this programme, select the
desired spin speed and press Start / Pause
/ Cancel button. First, the machine will
drain the water inside of it. Then, it will spin
the laundry with the set spin speed and
drain the water coming out of them.
If you wish to drain water only without
spinning your laundry, select the
Pump+Spin programme and then select
the “No Spin” function with the help of Spin
Speed Adjustment button depending on
the model of your machine and press Start
/ Pause button.
CIf your machine is not equipped
with Spin Speed Adjustment button and
No Spin auxiliary function and if you wish to
drain the water only without spinning your
laundry, select the Pump+Spin programme
and press Start / Pause button. Machine
will switch to spin step once it completes
pump step. Press Start / Pause / Cancel
button to stop the machine as soon as you
see the drum rotating.
CUse a lower spin speed for delicate
laundries.
Temperature selection
In models equipped with Temperature
Adjustment button, you can wash your
clothes at the desired temperature by using
this button.
ATo prevent damage on your laundry, do
not select a temperature that exceeds
the one recommended for your laundry
in the “Programme and consumption
table”.
Spin speed selection
In models equipped with Spin Speed
Adjustment button, you can spin your
laundry at the desired speed by using this
button.
In models not equipped with Spin Speed
Adjustment button, spin will be performed
at the recommended speed for the
selected programme.
CIf you wish to take out your laundry
without spinning, switch the Spin
Speed Adjustment button to No Spin
position.

20 EN
Programme selection and consumption table
• : Selectable
* : Automatically selected, no canceling.
**: Energy Label programme (EN 60456 Ed.3)
- : See the programme description for maximum load.
C Water and power consumption may vary subject to the changes in water pressure,
water hardness and temperature, ambient temperature, type and amount of laundry,
selection of auxiliary functions and spin speed, and changes in electric voltage.
C The auxiliary functions in the table may vary according to the model of your machine.
EN 2Auxiliary functions
Programme
Max. Load (kg) Programme Duration (~min) Water Consumption (l) Energy Consumption (kWh) Ön Yıkama İlave Durulama Suda Bırakma Spin speed reduction No Spin No Heat
Pamuklu 90 5 125 49 1.65 ••••••
Pamuklu 60 5 105 49 1.25 ••••••
Pamuklu 40 5 105 49 0.75 ••••••
Pamuklu Cold 5 95 49 0.16 ••••••
Pamuklu EKO 60** 5 150 50 0.87 ••••
Pamuklu EKO 60** 2.5 150 45 0.72 ••••
Pamuklu EKO 40** 2.5 135 45 0.54 ••••
Pamuklu EKO 40 5 130 49 0.69 ••••
Sentetik 60 2.5 113 52 0.92 ••••••
Sentetik 40 2.5 125 52 0.56 ••••••
Sentetik Cold 2.5 90 52 0.15 ••••••
Narin 30 30 2 65 45 0.36 •••••
Yünlü 40 1.5 60 45 0.36 •••••
Yünlü Cold 1.5 50 45 0.02 ••••
Elde Yıkama 30 30 1 45 32 0.21 •••
Mini 30 30 2.5 30 43 0.17 •••
** “Cotton eco 40°C and Cotton eco 60°C are the standard programmes.” These
programmes are referred to as ‘standard 40°C cotton programme’ and ‘standard
60°C cotton programme’
