Arctic F8 PWM PST Operating and safety instructions

www.arctic.acDear Customer,Thank you for choosing a fan of the ARCTIC F-series.YOU are the centre of ARCTIC. We work hard to approach all angles from a user's perspective and are fully dedicated to create innovative, user-friendly and affordable devices. YOUR satisfaction is our ultimate goal. In order to assist you even better, we launched a support platform for Smartphones (support.arctic.ac).I hope you enjoy the fan and we at ARCTIC look forward to further enriching your life with our products. If you would like to share how you use ARCTIC's products please do so at https://www.facebook.com/ARCTIC.enARCTIC is a fully carbon neutral company and your support helps us to compensate every kilogram of CO we produce. 2Thank You.Sincerely, Magnus HuberARCTIC CEOWelcome Guidesupport.arctic.ac/fpwmpstENDEFRES...F PWM PSTF PWM PST CO

Plugs / Sockets
4-pin PWM plug4-pin PWM socket 4-pin PWM socket 12D4-pin PWM plugF8 / F9 / F12 / F14 PWM PSTF8 / F9 / F12 / PWM PST COCPU Cooler / Fan(PWM Controlled)ABC
How to Plug Your Fan
D4-pin PWM plugCPU Cooler / Fan(PWM Controlled)CPU Cooler / Fan(PWM Controlled)C4-pin PWM socket MainboardC4-pin PWM socket MainboardA4-pin PWM plug4-pin PWM plugCase Fan3BCase Fan4-pin PWM socket D4-pin PWM plugCPU Cooler / Fan(PWM Controlled)CPU Cooler / Fan(PWM Controlled)C4-pin PWM socketMainboardCase FanA4-pin PWM plug4-pin PWM plugMainboard

Case Fan 1Case Fan 2CPU Cooler*We recommend not to chain more than 5 fans as some motherboards may only deliver 1.0A per fan header. Please consult your motherboard specification.C4-pin PWM socket 4-pin PWM socket MainboardD4-pin PWM plugCPU Cooler / Fan(PWM Controlled)CPU Cooler / Fan(PWM Controlled)
If Connecting with Multiple Fans
Fan speed reading

Activate PWM Control
ASRockFM2A85X-ITX (UEFI Setup Utility)In the mainboard BIOS, you can activate and configure the PWM fan speed. Please note the examples below are for reference only. Refer to your mainboard manual regarding the settings in your BIOS.H/W Monitor > CPU_FAN1 Setting > Silent ModeSilent ModeCPU_FAN1 Setting

Gigabyte MA78GM-S2H (CMOS Setup Utility)PC Health Status > CPU Smart FAN Control [Enable]CPU Smart FAN Mode [Auto]H/W Monitor > CPU Fan Setting > CPU Fan Setting [Automatic mode]Notes:- Target Fan Speed [Level 1 - 9]- At Level 1, the case fan may NOT spin at start up, it will spin at a higher CPU temperature.ASRock H55M/USB 3 P1.40 (BIOS Setup Utility)Power > PC Health Status >CPU Fan Mode [Manual] Target Fan Speed [0 - 255]JW Technology JW-H55M-PRO V 1.01(BIOS Setup Utility)Notes:- Fan will spin at minimum speed at 40-60.- Approximate PWM Value would be Target Fan Speed /2.5 e.g. Target Fan Speed 40 ~ PWM Value 16%Power > CPU Q-Fan Control [Enable]CPU Fan Profile [Silent / Optimal /Performance mode]Notes:- The case fan spins slowly at idle for all three mode.ASUS P5G41T-M LX (BIOS Setup Utility)It is also possible to adjust the fan speed inmanual mode to customize according to yourown preference. With PWM values set below 15%, the fan(s) may not start right away and thus only get active at higher temperature.

WarrantyThis ARCTIC product includes a six-year limited warranty. For further information, please visit warranty.arctic.ac© 2015 ARCTIC (HK) Ltd. All rights reserved.No part of this manual including the products described in it, may be reproduced, transmitted, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purpose, without the express written permission of ARCTIC (HK) Ltd. In no event shall ARCTIC, its directors or employees be liable for any indirect damages, incidental or consequential damages arising from any defect or error in this manual or product.Like us on facebookwww.facebook.com/ARCTIC.enPKMNL00011BEC Declaration of ConformityThis product is compliant with all applicable CE Directives for this type of product. A detailed Declaration of Conformity is available on ARCTIC website : http://www.arctic.acDirective 2002/96/EC about Waste of Electrical and Electronic Equipment (WEEE)Waste of Electrical and Electronic Equipment must not be disposed of with domestic waste.If the device cannot be used anymore, the user is legally obliged to separate it from domestic waste and hand it over to a designated collection point of his community/district.Thereby it is guaranteed that the Waste of Electrical and Electronic Equipment is recycled properly and negative impacts for the environment are avoided. Therefore, electronic devices are marked by this sign.ARCTIC and the ARCTIC logo are registered trademarks of Boost Up International Limited.
