Arcus 610 401 User manual

INSTRUCTION
FOR USE
HR-LR Adaptor
GA189GB-11.11
Phone
General
+49 (0) 89 / 436 04-0
Seat of the Company
Truderinger Str. 199
D-81673 Munich
Internet
www.ARCUS-Schiffmann.com
[e-mail]
Fax
Sales Department
+49 (0) 89 / 436 04 73
Fax
General
+49 (0) 89 / 431 68 88
Technical data
rotpadARL-RH
:egatlovdlohserhT V08
:ycneuqerF zH05
:snoitcennoC )gulp(RH
)tekcos(RL
:dradnatS 5-34216CEI
:erutarepmetlatnemnorivnE C°06+otpuC°03-
:thgieW g05
Construction
Type no. 610 401

Periodic interface testing and voltage test:
Connect the HR-LR Adaptor to the red
measurement line L1 of ARCUSPHASE.
For further professional periodic interface
testing and voltage test, please consult
the instruction for use of ARCUSPHASE
(GA179GB, GA202GB).
Cleaning
For cleaning use a watered cloth. Mind
that the HR-LR Adaptor is totally dry !
Latest after 6 years
(periodic testing)
Periodic testing to IEC 61243-5, is to be
carried out latest after 6 years. Last
periodic testing is shown on the label of
the HR-LR Adaptor.
Waste disposal
Observe local regulations for disposal of
HR-LR Adaptor and packing.
ARCUS Schiffmann will not be reliable for
unsuitable disposal.
For queries concerning used materials
please contact ARCUS Schiffmann.
Product liability and guarantee
This instruction for use was written with
greatest care and examined before
publishing.
Basis for guarantee is the proven
observation of this instruction for use
for storage, assembly, operation,
maintenance and care.
Valid are the GENERAL CONDITIONS
FOR THE SUPPLYOF PRODUCTS AND
SERVICES OF THE ELCTRICAL AND
ELECTRONICS INDUSTRY.
Copyright © 2011 ARCUS Schiffmann
Application
This HR-LR Adaptor was developed
specially as accessory for ARCUSPHASE.
It is an electric and mechanic adaption
from HR- to LR-voltage detection
systems. Before usage of this HR-LR
Adaptor, please read the instruction for
use of ARCUSPHASE (GA179GB,
GA202GB). In case parts are damaged
and operational reliability is limited, or
labels are illegible, withdraw the HR-LR
Adaptor from further use !
Measurement of phase angle:
Plug the HR-LR Adaptor to measurement
lines L1 and Lx of ARCUSPHASE.
Please find instruction for professional
phase angle measurement in the
instruction for use of ARCUSPHASE
(GA179GB, GA202GB).
Storage
Store HR-LR Adaptor in a dry place.
Application (Continued)
