Operator's Manual

MODEL TX163

HC1750

TRAILER

Maximum Field Rating

1750 lb.

Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5

Operator's Manual

TX163 HC1750 TRAILER

INTRODUCTION

Yutrax™ oers a full line of engineered outdoor gear. We appreciate your purchase of our world class ATV trailer. Follow these few

simple instructions and your product will be sure to give you many years of trouble free pleasure. Instructions should be kept in a

safe place and reviewed at least annually. .

If for any reason you have a problem with your product or are missing any parts, DO NOT return to the retailer, contact the

Yutrax™ Customer Service Department at 800-345-6007 for assistance.

CONTENTS

Introduction/Warranty ..................................................................................................................................................................................................................2

Warnings.............................................................................................................................................................................................................................................3

Assembly Instructions ...............................................................................................................................................................................................................4-7

Parts List..............................................................................................................................................................................................................................................8

Illustrated Parts Breakdown.........................................................................................................................................................................................................9

WARRANTY

Yutrax, a division of Ardisam Incorporated, oers a one year limited warranty to be free from defects in materials and workmanship for the

service life of the product, not to exceed twelve consecutive months from the date of purchase. This warranty applies to the original owner

with a proof of purchase and is not transferable. This warranty applies only to products which have not been subjected to negligent use,

misuse, alteration, accident or if repairs have been made by anyone outside our factory. This warranty supersedes all other warranties either

expressed or implied and all other obligations or liabilities on our part. Ardisam, Inc., does not assume, and does not authorize any other person

to assume for us, any liability in connection with the sale of our products. Warranty work must be sent directly to Ardisam, Inc. or one of our

authorized service centers and performed by them.

To obtain warranty service and/or replacement instructions, you must have prior approval

from Ardisam, Inc. before shipping your package to us by calling our customer service department at 800-345-6007 or by writing to: Ardisam, Inc.,

P.O. Box 666, 1160 Eighth Avenue, Cumberland, WI 54829 for a return material authorization number (RMA#).

All items must be shipped prepaid.

Ardisam, Inc. will at no charge, repair or replace, at their discretion, any defective part which falls under the conditions stated above. Ardisam

retains the right to change models, specications and price without notice.

For replacement parts, phone 800-345-6007 or go online to www.yutrax.com.

Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5 3

Operator's Manual

TX163 HC1750 TRAILER

READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY

STOP

MODEL TX163

TOTAL WEIGHT LIMIT  1750 LB.

WARNING

This product carries strict weight restrictions. Do Not use

this product if you exceed the total weight limit.

Stopping distance increases with speed and weight

of towed load. Travel slowly and allow extra time and

distance to stop.

Total towed weight must not exceed limits specied in

towing vehicle operator’s manual.

WARNING

READ, UNDERSTAND AND FOLLOW ALL ASSEMBLY,

INSPECTION, MAINTENANCE & USE INSTRUCTIONS

PROVIDED BEFORE EACH USE. FAILURE TO FOLLOW

ALL WARNINGS AND INSTRUCTIONS COULD RESULT

IN SERIOUS INJURY OR DEATH.

BE SURE TO FOLLOW ALL INSTRUCTIONS PROVIDED.

IF ANY INSTRUCTIONS ARE NOT UNDERSTOOD OF IF

YOU HAVE PART ISSUES CALL 8003456007 BEFORE

USING.

DOUBLE CHECK ASSEMBLY STEPS TO BE CERTAIN

YOU HAVE CORRECTLY ASSEMBLED THIS PRODUCT.

WARNING

Always use as an ATV trailer only.

Never tow behind vehicle on a highway. For o-road use

only!

Always follow the manufacturer’s recommendations for

weight limits for towed equipment and towing on slopes.

Excessive towed load can cause loss of traction and loss

control on slopes. Reduce towed weight when operating

on slopes.

Never shift to neutral and coast downhill.

Never drive in excess of 10 MPH while using this product.

Always use only approved hitches. Tow only with a

machine that has a hitch designed for towing. Do not

attach towed equipment except at the approved hitch

point.

Never turn sharply. Use additional caution when turning

or operating under adverse surface conditions. Use care

when reversing.

Always inspect before each & every use to be sure there

is no product damage or loose/missing bolts or hardware.

Over time, nuts and bolts may become loose from

vibration.

Be sure to always have the correct amount of air pressure

in tires. This will help deter from unnecessary wear and/

or damage. Air pressure can be found on side wall of tire.

Always be sure lock pins are latched to prevent accidental

removal.

Never use a damaged ATV trailer.

Always keep bystanders away when you operate a towed

attachment.

Always before you back machine and attachment, look

carefully behind attachment for bystanders.

Never allow people or animals to ride in the ATV trailer! It

is not designed for that matter.

Never use when intoxicated or using over-the-counter

medication or prescription drugs.

Never use carelessly – Think Safety!

Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5

Operator's Manual

TX163 HC1750 TRAILER

Item Part No. Description Image Qty

16 # 36535 WASHER 25 X

45 X 2.40 MM 2

17 # 25033 HITCH PIN 1

18 # 12118 HAIRPIN 1/8 IN 1

19 # 37772 LOCK PIN

6 X 40 MM 2

20 # 36790 SNAP PIN

1/4 x 3 IN 2

21 # 36789 SPACER 8.1 X

19 X 3.5 MM 2

22 # 8655B BOLT 5/16 X

13/4 IN 2

23 # 53730B BOLT 5/16 X

21/2 IN 4

24 # 17949 BOLT 5/16 X 18

X 2-3/4 IN 1

HARDWARE LIST

Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5 5

Operator's Manual

TX163 HC1750 TRAILER

- - 1/2 IN

WRENCH 2

HARDWARE LIST CONT.

TOOLS FOR ASSEMBLY

IMPORTANT ASSEMBLY TIP:

Do not tighten any nut and bolt combinations completely until all parts are assembled together! Finger tighten plus one turn of a

wrench only! This will temporarily hold the lock- nut on the bolt while helping alignment of all parts! After all parts are assem-

bled together, all nut and bolt combinations must be completely tightened.

STEP 1

1. Fold side rail left and right (7 & 8) up and attach front rail (9) to both side rails

using four 5/16-18 x 2-1/2 IN bolts and nuts (23 & 26).

ASSEMBLY INSTRUCTIONS

1/2

25 # 27966 BOLT 5/16 X 18

X 3-1/4 IN 3

26 # 60G5NYB NUT 5/16 IN 10

Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5

Operator's Manual

TX163 HC1750 TRAILER

STEP 3

3. Attach axle (5) to trailer bed (6) using two 5/16-18 x 3-1/4 and 5/16-18 x 1-3/4

IN bolts (22 &25) and four nuts (26).

Note: For easier assembly place unit upside down

STEP 2

2. Slide removable tailgate (10) into the brackets of the trailer bed (6) and secure

to left and right side rails (7 & 8) using two ¼ x 3 IN snap pins (20).

mesh hidden for clarity

Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5 7

Operator's Manual

TX163 HC1750 TRAILER

STEP 4

4. Attach trailer tongue to axle using one 5/16 x 18 x 2-3/4 IN bolt, two 8.1 x 19

x 3.5 MM plastic spacers, and one nut (24, 21, & 26). Attach trailer tongue to

trailer bed using one 5/16-18 x 3-1/4 IN bolt and nut (25 & 26).

Note: For easier assembly place unit upside down

STEP 5-7

5. Tighten all nut and bolt assemblies. Be sure not to over tighten or crush tubing when tightening.

6. Slide assembly wheel/tire (3) onto spindle between two 45MM washers (16) and secure by inserting lock pin 6 x 40MM (19) through the end

of the hex spindle (2).

7. Repeat Step 6 for the other side.

216

421

mesh hidden for clarity

Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5

Operator's Manual

TX163 HC1750 TRAILER

PARTS LIST

OPTIONAL ACCESSORIES

ITEM # PART # DESCRIPTION QT Y.

1 32783 SQ PLUG 25 MM 8

2 36338 HEX SPINDLE 2

3 36529 ASSEMBLY WHEEL/TIRE 18 X 9.5-8 IN 2

4 36721 TRAILER TONGUE 1

5 36725 AXLE 1

6 36731 TRAILER BED 1

7 36735 SIDE RAIL LEFT 1

8 36736 SIDE RAIL RIGHT 1

9 36737 FRONT RAIL 1

10 36740 TAILGATE 1

11 38758 PIN 8.45 X 65 MM 4

12 38759 WASHER 9.35 X 12.5 X 0.80 MM 4

13 38764 COTTER PIN 2 X 5 MM 4

14 48152 BOLT 5/16 X 18 X 1-1/2 IN 2

15 WF516B WASHER 5/16 X 7/8 X 5/64 IN 2

16 36535 WASHER 25 X 45 X 2.40 MM 2

17 25033 HITCH PIN 1

18 12118 HAIRPIN 1/8 IN 1

19 37772 LOCK PIN 6 X 40 MM 2

20 36790 SNAP PIN 1/4 X 3 IN 2

21 36789 SPACER 8.1 X19 X 3.5 MM 2

22 8655B BOLT 5/16 X18 X 1-3/4 IN 2

23 53730B BOLT 5/16 X 18 X 2-1/2 IN 4

24 17949 BOLT 5/16 X 18 X 2-3/4 IN 1

25 27966 BOLT 5/16 X 18 X 3-1/4 IN 3

26 60G5NYB NUT 5/16-18 10

PART # DESCRIPTION

TX113 2”Ball Hitch Kit

Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5 9

Operator's Manual

TX163 HC1750 TRAILER

ILLUSTRATED PARTS BREAKDOWN

17 4

26 24

*All weights, specications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product
