ArduCAM 8MP IMX179 User manual

QUICK START GUIDE
Auto Focus USB
Camera Module
(SKU: UB0240)
8MP IMX179
INTRODUCTION
• About Arducam
Arducam has been a professional designer and
manufacturer of SPI, MIPI, DVP and USB cameras
since 2012. We also oer customized turnkey
design and manufacturing soluon services for
customers who want their products to be unique.
• About this USB Camera
The UB0240 is a new member of the Arducam’s
USB camera family. It’s a 8MP, UVC compliant, USB
2.0 camera. This USB camera is based on the
1/3.2” Sony IMX179 image sensor, and you can
read more about its specs in the next chapter.
Arducam also provides the sample applicaon that
demonstrates some of the features of this camera.
• About UVC
The UB0240 is a UVC-compliant camera. The nave
UVC drivers of Windows, Linux and Mac shall be
compable with this camera so that it does not
require extra drivers to be installed.
• About Customer Service
If you need our help or want to customize other
models of USB cameras, feel free to contact us at
[e-mail]
SPECS
Camera
Sensor 1/3.2” IMX179
Resoluon 8MP 3264H x 2448V
Pixel Size 1.4 µm x 1.4 µm
Data Format MJPG/YUY2
Frame Rate
MJPG: 30fps@640 x 480/600 x 800/1024x
768/1280 x 720 /1280 x 960/1600 x
1200/1920 x 1080/2048 x 1536/2592 x
1944/3264 x 2448
YUY2: 1fps@3264 x 2448; 2fps@2592 x
1944/2048 x 1536; 5fps@1920 x 1080/1600
x 1200; 7.5fps@1280 x 960; 10fps@1280 x
720; 15fps@1024 x768; 25fps@800 x 600;
30fps@640 x 480.
Lens
Field of View 62°(H)
Lens Mount M6.5*P0.25 mm
IR Sensivity Integral IR lter, visible light only
Funconality and Compability
Auto Controlled
Features Contrast/ Saturaon/ Exposure / White balance /Sharpness
Audio Single Microphone
Compability Win7/8/10, Android, Linux, and Mac OS
Power
Power Supply DC 5V
Working Current MAX 300mA
Physical
Operang Temp. -4°F~158°F (-20°C~+70°C)
Dimension 62x9x6mm
Connector No. SM05B-SRSS-TB
Cable Length 3.3 (1M)
QUICK START
• How to download the program
Download the APP AMCap from the following link
hps://www.arducam.com/downloads/app/
AMCap.exe
NOTE:
1. If used with the Andriod device, USB Camera
APP and connect adapter are needed.
2. For Mac OS, please open the nave soware
faceme and select the video camera “USB
Camera” .
• How to connect the camera
Connect the one end of the USB 2.0 cable to the
USB 2.0 connector provided on the back of
UB0240, and connect the other end to the USB 2.0
host controller on the computer.
LENS DIAGRAM

How to use the program
(Windows demo only)
The Menu bar at the top of the shown image con-
tains few menu items and the current preview
resoluon and the frame rate are displayed on the
boom bar when the applicaon is running. The
following secons describe each of the menu items
• Menu>Devices
This menu will show the available video devices to
host PC. The UB0240 named PC Camera. This cam-
era supports capturing audio, so you also need to
choose Microphone (PC Camera).
• Menu>Options
The opons menu can be used to select the pre-
view and audio and image parameters supported
by this camera.
How to use the program
(Windows demo only)
-Video Capture Filter -> Video Proc Amp/Camera
Control
How to use the program
(Windows demo only)
-Video Capture Pin
How to use the program
(Windows demo only)
• Menu> Capture
The capture menu is used to capture the sll image
and video by using this applicaon. You can also
select the related parameters.
Note: If you want to get the voice from the micro-
phone, you need to select the opon “Capture
Audio” before capturing video.
